Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
11.Specification
Dimension ：
320mmx265mmx170mm
Gross weight:
7.0kgs
Net weight ：
5 .8kgs
Power supply：
AC230V±10%,50Hz±5%; AC120V±10%,60Hz±5%; DC85-250V,50-60Hz
Power consumption ：
≤70W
Banknote size：
Min 50mm x 110mm ; Max90mm x 190mm
Counting speed ：
≥1050pcs/min
Batch range ：
1-999
Counting display ：
Front color LCD+Side LCD display
11
Message
Error
E01
Problem with the left counting sensor
E02
Problem with the right counting sensor
E03
Problem with the speed sensor
E04
Problem with the auto start sensor
E05
Problem with the preset sensor
E10
Problem with the UV sensor
Generally speaking, most of the above-mentioned problems may be caused by dust or dirt inside of
the machine. So keeping the machine clean is highly recommended .
9.Hopper adjustment
---When improper feeding of bills occur, adjust the feeding thickness setting in the hopper by tuning the adjustor wheel located in the
back of the machine to ensure proper feeding.
---Rotate towards right to diminish the thickness <see figure 4>
9
Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
Double Detection function (UV and MG)
<available for the models with UV detection or the model with both UV and MG detection>
---Used to check double-note
---By default, serving as a supplementary function, the detection can be activated when the unit is powered up.
---If the machine detects a double-note when counting, it will stop and emit beeping sound, while the batch display
will show the message "d3" (alerting the user of the presence of a double-note). The double-note will always be the
last one on the stacker. Remove the dubious bill, press "RESET" button to continue.
Half-note Detection Function <available for the models with UV detection or the model with both UV and MG detection>
---Used to check half-note.
---By default, serving as a supplementary function, the half-note detection can be activated when the unit is powered up.
---If the machine detects a half-note when counting, it will stop and emit beeping sound, while the counting display will show the message
"d5"alerting the user the presence of a half-note bill). The dubious bill will always be the last one on the stacker. Remove the dubious
bill, press"RESET"button to continue <the counting display will clear>.
Note: User can resume the original set of sensitivity level by manufacturer. Press" ADD "button for 3 seconds, the display will show "---"
which means the sensitivity restores factory setting now.
7
Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
1. Illustration
Hopper Block
Handle
Control Panel
Impeller
Stacker
Frontal platform
Rubber tongue
Bill thickness
adjustment
wheel screw
External screen jack
Power switch
Power outlet
1
Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
3. General instruction
To be the latest generation of bill counter, the model is the vanguard of our evolution in bill counting technology. Its compact and
stylish design is as remarkable as its integrated electronics and multifunction capabilities. Different from other counters,
it employs many new detection methods which other counters don't have. Being improved in many aspects
of internal structure which make it quite different from other bill counters, this hi-tech compact counting machine is easy to
operate and repair. It is sturdy and utterly reliable and suitable for all kinds of banking industry and store department.
We recommend the user to verify that gift box contains all of the items listed here:
①.Machine body
②. Operation manual
③. Power wire
④. Brush
⑤. Fuse
⑥. External display(Optional part)
4. Safety instruction
---Read and understand all of the instructions and
warnings both on the machine and in the manual.
---Follow all warnings and instructions marked on the unit.
---This product should be operated only from the type of the power source indicated in the user's guide. If you are not sure of the type of
power supply in your location, consult your dealer or local power company.
---Only use the cable provided with the unit. The use of other cable may result in electric shock, fire or bring serious damage to the unit.
---Never push objects of any kind into the unit through case slots, since they may touch dangerous voltage points or shortcut parts, resulting
in a risk of fire or electric shock.
---Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power supply cord or plug is damaged or frayed.
b. If the liquid has been spilled into the unit.
c. If the unit has been exposed to rain or water.
d. If the machine has been dropped or the case has been damaged.
e. If the product shows a noticeable change in performance.
3
Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
Note: The counting mode can be changed between Automatic and Manual. When turn on the machine,"AUTO"indicator is on, the machine
is in automatic counting mode; press the" AUTO " button , the "AUTO" indicator will be off, the machine is in manual counting mode, under
this mode, only pressing the"RESET"button after placing the bills to start counting.
2>Addition Function.
Addition can be performed by pressing the" ADD" button (when the ADD indicator is on). In this case, removing the counted bills from
the stack will not clear the quantity counted and shown on the counting display. The next bills placed in the hopper will be counted and
added to the preceding quantity. The total amount of added bills will be shown on the counting screen. Press the"ADD" button to close
the function and clear the counting display.
3>Batch Function.
---The preset batch function can be performed by pressing the"BATCH" button(the BATCH indicator will appear). By default,
when pressing the "BATCH",the batch function is turn on. The batch number can be set in amounts between 1 and 999 by pressing
NO."0"-"9" button. To clear this function, press the "BATCH"button until the indicator is off.
---Under the batch counting mode, once the hopper is loaded, the machine will start counting and stop when the counted quantity reaches
the preset batch one.
---To repeat the batch counting operation under the same preset batch quantity, just remove the counted bill from the stacker. The unit will
batch the next group of bills under the same settings.
---If you wish to keep batching without removing the preset number, press the"RESET"button.
---If the counted number does not tally with the preset batch number, the counter display will show the quantity with blinking number.
---When counting with MG and/or UV detection on, the machine will stop automatically when detecting counterfeit currency. This function
can be resumed by removing the dubious bill from the stacker and pressing"RESET"button.
5
Solution
Clean the sensor or replace it
Clean the sensor or replace it
Clean the sensor or replace it
Clean the sensor or replace it
Clean the sensor or replace it
Clean the sensor or replace it
Hopper
Auto start sensor
Feeding roller
Counting sensor
External screen
OPERATION MANUAL
m m m
oney
oney
oney ounter
Professional Manufacturer For Money Counter
And Counterfeit Detector
CONTENT
1.Illustration---------------------------------------------------------------------------------1
2.Function controls and display----------------------------------------------------------2
3.General instruction-----------------------------------------------------------------------3
4.Safety instruction ------------------------------------------------------------------------
5.Power up-----------------------------------------------------------------------------------4
6.Counting function-------------------------------------------------------------------------4-5
7.Counterfeit Detection--------------------------------------------------------------------6-7
8.Error code and solution -----------------------------------------------------------------8-9
9.Hopper adjustment-----------------------------------------------------------------------9-10
10.Maintenance-----------------------------------------------------------------------------10
11.Specification ----------------------------------------------------------------------------11
Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
2. Function controls and display
2. Function controls and display
Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
---To reduce the risk of electric shock, do not disassemble this product.Take it to qualified service personnel when service or repair work
is required. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric
shock when the appliance is subsequently used.
---Do not use the unit if the power cord is damaged or if the plug socket contact is loose. Not following those instructions may result in
electric shock , fire or other hazards.
---When unplugging the power plug, do not pull it by the cord but rather grip the plug and pull it out, not following those instruction may
result in electric shock, fire or damage to the unit.
5.Power up
---Connect the power cord to the machine (power outlet), then plug it to power source and switch the unit on; the unit will conduct a
self-check by spanning the feeding roller while the MG and/or UV functions will be automatically turned on by default. The counting
display will show" 0 "when the unit is ready<the machine is in its normal working condition>.
6.Counting function
1>Counting Function
Once the bills are correctly placed in the hopper, the machine will start counting automatically. The number of counted bills will be shown
on the counting display. Moreover, once the bills are removed
from the stacker, the counting display will be clear and the batch
display in turn will show the number of counted bills instead.
Bills should be correctly placed as indicated in the following steps:
Place the bills between the counting guides as shown in the figure1
and figure2. Swiftly, push the bills with a figure<see figure3>
to make them rest on the top of the hopper plate, in the correct
counting position.
---Rotate towards left to increase the thickness <see figure 5>
---When the problem is not solved with the adjustment of the wheel, the rubber should be replaced.
---Press the hopper plate to change a new rubber <see figure6> or you can send the machine to authorized service center.
UV sensor
Counting sensor
Preset sensor
Figure4
10.Maintenance
---Do not operate the unit in areas with high temperature or high humidity since it may damage the machine.
---When not using the unit for a long time, remove the power plug from the wall outlet.
---Never operate the unit under strong light.
---Clean the machine frequently after switching off and unpluging of the machine.
---Do not use this product in areas where it may be exposed to water or other liquids.
---Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaner. Use a brush or a damp cloth for cleaning.
Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
8.Error message and solution
The batch display may shows some error message when counting, which means there are some problems with the machine.
Refer to the following diagram to find way to solve it.
Message
Suspicious bill detected by UV system
d1
Problem in the UV system
Suspicious bill detected by MG system;
d2
Problem in the MG system.
Double-note detected by IR system
d3
Problem in the IR system
Note of size problem detected by size
d4
detection system; Problem in the size
detection system
Half-note detected by half-note detection
d5
system; Problem in the half-note
detection system.
Slope-note detected by Slope-note detection
d6
system; Problem in the slope-note detection
system.
d7
Chain-note detected by the counting sensor
Suitableforbothnew,old,dirty,tatteredpolymerbillsandpaperbills
7. Counterfeit Detection
UV(Ultraviolet)detection function
------ check all kinds of banknotes which contains UV features
---The UV function is automatically turned on by default when the machine is powered up. It can also be selected or deselected by
pressing the CF button located in the function console.
---If the machine detects a counterfeit note when counting, it will stop and emit beeping sound, while the batch display will show the
message"d1"and the UV indicator will blink (alerting the user the presence of a dubious bill). The dubious bill will always be the
last one on the stacker. Remove the dubious bill, press"RESET"button to continue.
---The sensitivity of UV detection can be adjusted. Hold "SET"button for 3 seconds until the batch display shows the current sensitivity
level "SE4/120"then press" ↑ "or" ↓ "button to choose the desired sensitivity level (range from 0-200). After choosing of the level,
restart the machine to confirm.
MG (Magnetic) detection function
------ check all kinds of banknotes which contains MG features
---The MG function is automatically turned on by default when the machine is powered up. It can also be selected or deselected by
pressing the CF button located in the function console.
---If the machine detects a counterfeit note when counting, it will stop and emit beeping sound, while the batch display will show the
message" d2 "and the MG indicator will blink (alerting the user the presence of a dubious bill). The dubious bill will always be the
last one on the stacker. Remove the dubious bill, press"RESET"button to continue.
---The sensitivity of MG detection can be adjusted. Hold"SET"button for 3 seconds, the counting display will show the current sensitivity
level"SE5/5" then press" ↑ "or" ↓ "button to choose the desired sensitivity level (range from 0-50). After choosing of the level,
restart the machine to confirm.
Note:hold"SET"button for 3 seconds "SE5"is used to adjust"MG1"sensitivity level, "SE6"is used to adjust"MG2"
sensitivity level.
c c c
ounter
---before operation, please be clear which model you have bought
---before operation, please be clear which model you have bought
The model with UV/MG1/MG2/IR/DD counterfeit detection
A
H
C
E
I
B
J
A. "CF"button(Detection function)
B. "AUTO" button
C. " 0-9 " button(Batch function)
D. " DD "button
E. "BATCH" button
F. "RESET" button
G."SET"button(Set the parameter)
H. "ADD"button(Addition function)
I. "C"button(Cancel function)
J."IR"button
Figure 1
Figure5
Error
Remove the suspicious bill from the
stacker, press "RESET" to continue;
Lower the UV sensitivity.
Remove the suspicious bill from the
stacker, press "RESET" to continue;
Lower the MG sensitivity.
Remove the suspicious bill from the
stacker, press "RESET" to continue;
Lower the IR sensitivity.
Remove the suspicious bill from the
stacker, press "RESET" to continue;
Lower the size checking sensitivity.
Remove the suspicious bill from the
stacker, press "RESET" to continue;
Remove the suspicious bill from the
stacker,press "RESET" to continue.
Remove the suspicious bill from the
stacker, press "RESET" to continue;
<available for the model with UV detection or the model with both UV and MG detections>
<available for the the models with both UV and MG detections>
3-4
D
G
F
2
Figure 2
Figure 3
4
Figure6
10
Solution
8
6
Advertisement
