- Page 1 LGEPR_MCV902_MCD502_ENG_MFL32702807 MINI Hi-Fi SYSTEM OWNER’S MANUAL MODEL: MCV902 MCV902-A0U/D0U/X0U, MCS902F, MCS902S, MCS902AW, MCS902W MCD502 MCD502-A0U/D0U/X0U, MCS502F Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.
-
Page 2: Safety Precaution
Safety Precaution CAUTION: The apparatus should not be exposed to water (drip- ping or splashing) and no objects filled with liquids, such as CAUTION vases, should be placed on the apparatus. RISK OF ELECTRIC SHOCK CAUTION concerning the Power Cord DO NOT OPEN Most appliances recommend they be placed upon a dedicat- ed circuit;... -
Page 3: Table Of Contents
Notes on Discs Before use Handling discs Contents Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not Before use get on the surface. Never stick paper or tape on About the Symbols for instruction / the disc. -
Page 4: Front / Back Panel
- OPTIONAL • VOLUME CONTROL KNOB 12. Z PUSH EJECT position - TAPE 2 • EQ button 13. SPEAKER TERMINAL (MCV902 model) • SURROUND button 14. POWER CORD • USER EQ button 15. SPEAKER TERMINAL (MCD502 model) • MP3 OPT (MP3 OPTIMIZER) button 16. -
Page 5: Remote Control
Remote Control LINK button (MCV902 model) WOOFER POWER button (MCV902 model) MUTE button POWER button • USB button • FUNCTION button PRESET/FOLDER( ) buttons VOLUME ( ) buttons SLEEP button DIMMER button CD FUNCTION buttons PLAY/PAUSE ( B B / [] ) button •... -
Page 6: Connections
Connections Speaker System Connections MCV902 Model subwoofer(A) subwoofer(B) Surround Surround speaker speaker (Left) (Right) Gray Orange Wire band color: Blue Front Front Notes: speaker speaker • Do not place the surround/ subwoofer (Left) (Right) speakers by TV. • If TV screen becomes discolored do not place front speakers within 30cm from TV. -
Page 7: Antenna (Aerial) Connections
Antenna (Aerial) Connections Optional Equipment Connections Connect the supplied FM/AM antennas for listen- Connection of the TV/Monitor, Video Game or ing to the radio. DVD, etc. 1. Connect the video/audio output connector of a auxiliary device to the GAME LINK (VIDEO IN, FM wire antenna (supplied) AUDIO L/R) connector. -
Page 8: Operation
Operation XDSS (Extreme Dynamic Sound System) Audio Adjustment Press XDSS to reinforce treble, bass and the Headphone jack surround effect. The “XDSS ON” or “NORMAL” Connect a stereo headphone plug ( 6.3mm) into indicator lights. To cancel, press XDSS again. the headphone jack to listen to the sound through headphones. -
Page 9: Sleep Timer Function / Setting The Clock
Selecting the sound system Sleep Timer Function (MCV902 model) When the sleep timer is used, the power is auto- You can enjoy different sounds by selecting the matically turned off after the specified time has sound mode you want. elapsed. -
Page 10: Timer Function
Timer Function Press SET to confirm the hour to switch off. With the TIMER function you can have the radio Set the minute to switch off by turning reception, CD play, TAPE play and USB play MULTI JOG on the front panel. turned on and off at the desired time. -
Page 11: Presetting The Radio Stations
Presetting the Radio Stations Listening to the Radio You can preset 50 stations for FM and AM. Before tuning, make sure that you have turned Press TUNER on the front panel or FUNC- down the volume to the minimum. TION on the remote control to select the fre- Press TUNER on the front panel or quency (AM or FM) you want. -
Page 12: Rds Function - Optional
RDS Function - OPTIONAL Programme Search (PTY) A major benefit of RDS is its ability to encode broadcasts with Programme Type (PTY) codes About RDS that indicate the type of material being broadcast. This unit is equipped with RDS (Radio Data The following list shows the abbreviations used to System), which brings a wide range of informa- indicate each PTY along with an explanation of... -
Page 13: Tape Playback / Tape Recording
Tape Playback Tape Recording Use only normal tapes. Wind the tape to the point recording starts. Use only normal tapes. Basic Playback 1. Press TAPE (or FUNCTION) to select TAPE Basic Setting function. 1. Select a function you want to record except (“NO TAPE”... -
Page 14: Cd Playback
CD Playback Searching a Track Press bb/BB on the front panel, and then press Basic Playback once more at the point you want. 1. Press CD (or FUNCTION) to select CD func- Or hold .bb/BB> on the remote control tion. If no disc is loaded then “NO DISC” is during playback, then release at the point you displayed. -
Page 15: To Program Play / Repeat
To Program Play To modify program contents 1. Press PROGRAM/ MEMO on the remote You can arrange the order of the tracks on the control (or PROG. MEMO. on the front discs and create your own program. The pro- panel) to display the program number you gram can contain up to 20 tracks. -
Page 16: About Mp3/Wma
About MP3/WMA MP3/WMA Disc compatibility with this unit is limited as follows: 1. Sampling Frequency 8 - 48kHz(MP3), 32 - 48kHz(WMA) 2. Bit rate 8 - 320kbps(MP3), 48 - 320kbps(WMA) 3. CD-R physical format should be “ISO 9660” 4. If you record MP3/WMA files using the soft- ware which cannot create a FILE SYSTEM, for example “Direct-CD”... -
Page 17: Usb Function
USB Function To Remove the USB from the unit 1. Choose the other functions except USB You can enjoy the media files such as tunes function in order to remove the USB. (MP3/WMA) saved in an MP3 player or USB 2. -
Page 18: Reference
Reference Troubleshooting Symptom Cause Correction • The power cord is disconnected. • Plug the power cord into the wall outlet No power securely. • The audio cables (or SYSTEM connector • Connect the audio cable (or SYSTEM jack) are not connected securely. connector jack) into the jacks securely. -
Page 19: Specifications
Frequency Response 140 - 1800 Hz Output Power Front : 270 W + 270 W (MCV902 Model) 250 W + 250 W (MCD502 Model) Surround : 110 W + 110 W (MCV902 Model) Subwoofer : 180 W + 180 W (MCV902 Model) T.H.D... - Page 20 P/NO : MFL32702807...
