NAD T517AHT Service Manual
  1. Manuals
  2. Brands
  3. NAD Manuals
  4. DVD Player
  5. T517AHT
  6. Service manual

NAD T517AHT Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
© NAD 2008
T517C/T517CT
NAD ELECTRONICS INTERNATIONAL
DVD VIDEO PLAYER
TORONTO

Advertisement

Table of Contents
loading

Related Manuals for NAD T517AHT

Summary of Contents for NAD T517AHT

  • Page 1 © NAD 2008 T517C/T517CT NAD ELECTRONICS INTERNATIONAL DVD VIDEO PLAYER TORONTO...
  • Page 2 CONTENTS SECTION 1..SUMMARY SECTION 2..CABINET & MAIN CHASSIS SECTION 3..ELECTRICAL SECTION 4..MECHANISM (DP-12V) SECTION 5..REPLACEMENT PARTS LIST...

  • Page 3: Table Of Contents

    SECTION 1 SUMMARY CONTENTS PRODUCT SAFETY SERVICING GUIDELINES FOR DVD PRODUCTS ........1-3 SERVICING PRECAUTIONS ........................1-4 • GENERAL SERVICING PRECAUTIONS • INSULATION CHECKING PRODEDURE • ELECTROSTATICALLY SENSITIVE (ES) DEVICES THE PROCESS OF DISC DOWNLOAD ....................1-5 SPECIFICATIONS ............................1-7...

  • Page 4: Product Safety Servicing Guidelines For Dvd Products

    When servicing this product, under no circumstances should the original design be modified or altered without permission from NAD. All components should be replaced only with types identical to those in the original circuit and their physical location, wiring and lead dress must conform to original layout upon completion of repairs.

  • Page 5: Servicing Precautions

    SERVICING PRECAUTIONS CAUTION: Before servicing the DVD covered by this service Electrostatically Sensitive (ES) Devices data and its supplements and addends, read and follow the Some semiconductor (solid state) devices can be damaged SAFETY PRECAUTIONS. NOTE: if unforeseen circumstances easily by static electricity. Such components commonly are create conflict between the following servicing precautions called Electrostatically Sensitive (ES) Devices.

  • Page 6: The Process Of Disc Download

    THE PROCESS OF DISC DOWNLOAD Please follow the below process to download a program with disc 1. Turn on the DVD-player. (Note. Be sure that there is no disc in DVD-player) 2. Press “SETUP” button on Remote control. 3. Choose a “display” menu by using the cursor button and then choose a “TV Aspect” menu. And choose “16:9” menu.
  • Page 7 7. Copy the changed file to a disc. 8. Insert the copied disc to DVD-player. 9. If the below picture appears on the screen, Press “ ” key. 10.After the below picture appears on the screen, Disc will emerge from DVD-player automatically. Take the disc out of the DVD-player.

  • Page 8: Specifications

    SPECIFICATIONS • GENERAL Power requirements: AC 100 V ~ 240 V, 50 Hz / 60 Hz Power consumption: Dimensions (Approx.): 430 x 39 x 192 mm (17 x 1.5 x 7.6 inches) (W x H x D) without foot Net weight (Approx.): 1.5 kg (3.3 lbs) Operating temperature: 5 °C to 35 °C (41 °F to 95 °F)
  • Page 9 MEMO...
  • Page 10 SECTION 2 CABINET & MAIN CHASSIS CONTENTS EXPLODED VIEWS .............................2-2 1. CABINET AND MAIN FRAME SECTION ....................2-2 2. DECK MECHANISM SECTION (DP-12V)....................2-3 3. PACKING ACCESSORY SECTION......................2-4...

  • Page 11: Exploded Views

    EXPLODED VIEWS 1. CABINET AND MAIN FRAME SECTION OPTIONAL PART...

  • Page 12: Deck Mechanism Section (Dp-12V)

    2. DECK MECHANISM SECTION (DP-12V) 015B 015A...

  • Page 13: Packing Accessory Section

    3. PACKING ACCESSORY SECTION OPTIONAL PARTS 811 Plug Ass'y 1way(Yellow) 810 Cable Set Ass'y 812 Plug Ass'y 2way 808 Battery 900 Remocon 801 Owner's Manual 804 Packing Sheet 803 Packing 803 Packing 802 Box Carton...
  • Page 14 SECTION 3 ELECTRICAL CONTENTS ELECTRICAL TROUBLESHOOTING GUIDE ..................3-2 1. SMPS TROUBLESHOOTING FLOW ......................3-2 2. POWER CHECK FLOW ..........................3-4 3. SYSTEM OPERATION FLOW.........................3-5 4. SYSTEM TEST FLOW ...........................3-6 DETAILS AND WAVEFORMS ON SYSTEM TEST AND DEBUGGIBG ........3-12 1. SYSTEM 27MHZ CLOCK, RESET, FLASH R/W SIGNAL ..............3-12 2.

  • Page 15: Electrical Troubleshooting Guide

    ELECTRICAL TROUBLESHOOTING GUIDE 1. SMPS TROUBLESHOOTING FLOW No 3.3VA Replace the FR101 Is the FR101 normal? (Use the same ICW) Replace the Is the D105/D106/D107/ D105/D106/D107/D108 D108 normal? Is the Vcc (about 17V) Check or Replace the IC101 supplied to IC101 Pin2? Replace the D121 Is the D121 normal? Is there about 2.5V at the...
  • Page 16 ELECTRICAL TROUBLESHOOTING GUIDE No REG 5.0V Is the Vcc(=5.6V) • • Check or Replace the D123 supplied to Q126 Collector? Is the Vcc(=12V) • Check the ‘PWR CTL “H”’ • supplied to Q126 signal from μ-com Base? Check or Replace the Q126 No 12V Is the Vcc(=14V) •...

  • Page 17: Power Check Flow

    ELECTRICAL TROUBLESHOOTING GUIDE 2. POWER CHECK FLOW No 5V No 3.3VA. Is 3.3VA Is 3.3VA section working? section working? Is 3.3V Is 5.6V present at present at emitter No 3.3VA collector of Q126? of Q121? Replace Q126. Check FR101 Replace Q121. Is there a DC voltage at Check D105/D106/D107/ cathode of D105 or D107?

  • Page 18: System Operation Flow

    ELECTRICAL TROUBLESHOOTING GUIDE 3. SYSTEM OPERATION FLOW Power on 1. 8032 initializes SERVO,DSP & RISC registers 2. Write RISC code to SDRAM 3. Reset RISC Show LOGO Tray closed? Tray close to closed position SLED at inner side? SLED moves to inner position 1.

  • Page 19: System Test Flow

    ELECTRICAL TROUBLESHOOTING GUIDE 4. SYSTEM TEST FLOW TEST Check the AC Replace power PCBA or AC transformer. Voltage Power PCBA (110V or 220V) Switch on the power PCBA Is the DC voltage outputs OK? Repair or Replace power PCBA (5V, 3.3V, 12V, 5.6V MOTOR) Make sure the main PCBA don't short on VCCs and switch it on.
  • Page 20 ELECTRICAL TROUBLESHOOTING GUIDE RESET or power on. Check connection lines Flash between FLASH & MT1389S memory operates Show LOGO? and the FLASH access time properly? whether is suitable or not. Check connection lines SDRAM between SDRAM & MT1389S works properly? and the SDRAM is damaged.
  • Page 21 ELECTRICAL TROUBLESHOOTING GUIDE Does Motor Check the connection the SLED move driver STBY pin to inner side when it is line of STBY signal. is high? at outter position? Is FMSO Check the related DC level higher circuit of FMSO. than 1.4V? Check the amp circuit and SL- output...
  • Page 22 ELECTRICAL TROUBLESHOOTING GUIDE Check the laser power circuit Laser turns LD01 or LD02 on MT1389S and connecting on when reading output properly? to power transistor. disc? Collector Check the related circuit on voltage of power transistor laser power transistor. is OK? Check cable connection between transistor ouput and pick-up head.
  • Page 23 ELECTRICAL TROUBLESHOOTING GUIDE Proper Check connections between Focus on OK? signals on A, B, C, D of MT1389S and pick-up head. MT1389S Check the FOSO connection Check FEO signal on MT1389S and motor driver. on MT1389S Check FOSO signal on MT1389S Normal Check the related Track on OK?
  • Page 24 ELECTRICAL TROUBLESHOOTING GUIDE Normal Check the related Normal Audio output when audio DAC circuit of audio DAC. disc playback? out? Check audio filter, amplify, mute circuit. Commu- Normal nications between Check communication IR.VFD & Front pannel IR.VFD Front pannel lines on MT1389S. key functions? key &...

  • Page 25: Details And Waveforms On System Test And Debuggibg

    DETAILS AND WAVEFORMS ON SYSTEM TEST AND DEBUGGIBG 1. SYSTEM 27MHz CLOCK, RESET, FLASH R/W SIGNAL 1) MT1389S main clock is at 27MHz (X601) FIG 1-1 2) MT1389S reset is low active 3.3V IC601 PWR_CTL RESET TIME FIG 1-2 3-12...
  • Page 26 3) RS232 waveforn during procedure (Downloading) FIG 1-3 4) Flash R/W enable signal during download (Downloading) IC602 FIG 1-4 3-13...

  • Page 27: Sdram Clock

    2. SDRAM CLOCK DCLK = 128MHz, Vp-p=2.2 IC603 FIG 2-1 3. TRAY OPEN/CLOSE SIGNAL IC601 TRIN TROUT TRCLOSE TROPEN FIG 3-1 3-14...

  • Page 28: Sled Control Related Signal (No Disc Condition)

    4. SLED CONTROL RELATED SIGNAL (NO DISC CONDITION) FMSO(1.9V/1.4V/1.1V) STBY(3.3V) SL+(4.2V/2.8V/1.2V) SL-(4.2V/2.8V/1.5V) FIG 4-1 5. LENS CONTROL RELATED SIGNAL (NO DISC CONDITION) FOSO(1.5V/1.4V/1.3V) F+(3.2V/2.7V/2.2V) F-(3.2V/2.7V/2.2V) FIG 5-1 3-15...

  • Page 29: Laser Power Control Related Signal (No Disc Condition)

    6. LASER POWER CONTROL RELATED SIGNAL (NO DISC CONDITION) IC601 MDI1 (0V/180mV) LD02 (3.3V/2.3V) LD01 (3.3V/2.3V) FIG 6-1 7. DISC TYPE JUDGEMENT WAVEFORM CN201 IC601 FIG 7-1 (DVD) 3-16...
  • Page 30 FIG 7-2 (DVD) FIG 7-3 (CD) 3-17...

  • Page 31: Focus On Waveform

    FIG 7-4 (CD) 8. FOCUS ON WAVEFORM IC601 FOSO FIG 8-1 (DVD) 3-18...

  • Page 32: Spindle Control Waveform (No Disc Condition)

    FOSO FIG 8-2 (CD) 9. SPINDLE CONTROL WAVEFORM (NO DISC CONDITION) DMSO (1.4V/1.8V) (3.6V/2.4V) (3.6V/4.8V) FIG 9-1 3-19...

  • Page 33: Tracking Control Related Signal (System Checking)

    10. TRACKING CONTROL RELATED SIGNAL (SYSTEM CHECKING) IC601 TRSO FIG 10-1 (DVD) CN201 TRSO FIG 10-2 (CD) 3-20...

  • Page 34: Mt1389S Audio Optical And Coaxial Output (Spdif)

    11. MT1389S AUDIO OPTICAL AND COAXIAL OUTPUT (SPDIF) IC601 FIG 11-1 12. MT1389S VIDEO OUTPUT WAVEFORM 1) Full colorbar signal (CVBS) JK701 2PIN FIG 12-1 3-21...

  • Page 35: Audio Output From Mt1389S

    13. AUDIO OUTPUT FROM MT1389S FIG 13-1 3-22...

  • Page 36: Connector Picture

    CONNECTOR PICTURE 1. ALL CONNECTOR PICTURE 3-23...

  • Page 37: Main Board Connector Picture

    2. MAIN BOARD CONNECTOR PICTURE 3-24...

  • Page 38: Cn201 Connector Picture

    3. CN201 CONNECTOR PICTURE CN201 (MD 23PIN) 4. CN202 CONNECTOR PICTURE CN202 (MD 9PIN) 3-25...

  • Page 39: Cn601 Connector Picture

    5. CN601 CONNECTOR PICTURE CN601 (Front 12PIN) 6. CN602 CONNECTOR PICTURE CN602 (POWER 10PIN) 3-26...

  • Page 40: Cn604 Connector Picture

    7. CN604 CONNECTOR PICTURE CN604 (USB 4PIN) 8. CN605 CONNECTOR PICTURE CN605 (KARAOKE 4PIN) 3-27...

  • Page 41: Cn705 Connector Picture

    9. CN705 CONNECTOR PICTURE CN705 (5.1ch 12PIN) 3-28...

  • Page 42: Block Diagrams

    BLOCK DIAGRAMS 1. OVERALL BLOCK DIAGRAM S-Video YC B/Pb R/Pr CVBS IR RCV FP CLK FP STB FP DATA 3-29...

  • Page 43: Power (Smps) Block Diagram

    2. POWER (SMPS) BLOCK DIAGRAM TRANS SWITCHING IC AC100~240V RECTIFIER 3-30...

  • Page 44: Mpeg & Memory Block Diagram

    3. MPEG & MEMORY BLOCK DIAGRAM Y_G_OUT CVBS R_SY_OU T B_SC_ OUT D_MUTE Y_G_OUT CVBS R_SY_OU T B_SC_ OUT 3-31...

  • Page 45: Servo Block Diagram

    4. SERVO BLOCK DIAGRAM 3-32...

  • Page 46: Video & Hdmi Block Diagram

    5. VIDEO & HDMI BLOCK DIAGRAM 3-33...

  • Page 47: Audio Block Diagram

    6. AUDIO BLOCK DIAGRAM 3-34...

  • Page 48: Circuit Diagrams

    MODIFIED OR ALTERED WITHOUT PERMISSION CUIT USED. THIS WAY, IMPLEMENTATION OF THE 2. Voltages are DC-measured with a digital voltmeter dur- FROM THE NAD. ALL COMPONENTS SHOULD BE LATEST SAFETY AND PERFORMANCE IMPROVE- ing Play mode. 1. POWER (SMPS) CIRCUIT DIAGRAM...

  • Page 49: Mpeg Circuit Diagram

    2. MPEG CIRCUIT DIAGRAM 3-37 3-38...

  • Page 50: Servo Circuit Diagram

    3. SERVO CIRCUIT DIAGRAM 3-39 3-40...

  • Page 51: Jack Circuit Diagram

    4. JACK CIRCUIT DIAGRAM 3-41 3-42...

  • Page 52: Scart Circuit Diagram (Option)

    5. SCART CIRCUIT DIAGRAM (OPTION) 3-43 3-44...

  • Page 53: Usb Circuit Diagram

    6. USB CIRCUIT DIAGRAM 7. KEY CIRCUIT DIAGRAM 3-45 3-46...

  • Page 54: Timer Circuit Diagram

    8. TIMER CIRCUIT DIAGRAM 3-47 3-48...

  • Page 55: Circuit Voltage Chart

    • CIRCUIT VOLTAGE CHART MODE MODE MODE MODE MODE MODE MODE MODE STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY STOP PLAY PIN NO. PIN NO. PIN NO. PIN NO. PIN NO. PIN NO. PIN NO.
  • Page 56 PLAY LOCATION SPEC C642 33μ F/16V 1.858 0.002 C666 100μ F/6.3V 3.244 0.003 C6C1 10μ F/16V 12.251 C6C2 10μ F/16V 11.556 C6C6 10μ F/16V 3.257 0.001 C6C9 220μ F/16V 3.259 0.001 C6E0 47μ F/6.3V 2.758 0.001 C6E1 10μ F/16V 1.372 0.002 C6E2 47μ...

  • Page 57: Printed Circuit Board Diagrams

    PRINTED CIRCUIT BOARD DIAGRAMS 1. MAIN P.C.BOARD (TOP VIEW) (BOTTOM VIEW) 3-53 3-54...

  • Page 58: Power (Smps) P.c.board

    2. POWER (SMPS) P.C.BOARD (TOP VIEW) (BOTTOM VIEW) 3. KEY P.C.BOARD 4. TIMER P.C.BOARD (TOP VIEW) (TOP VIEW) (BOTTOM VIEW) (BOTTOM VIEW) 3-55 3-56...

  • Page 59: Scart P.c.board (Option)

    5. SCART P.C.BOARD (OPTION) (TOP VIEW) (BOTTOM VIEW) 6. USB P.C.BOARD (TOP VIEW) (BOTTOM VIEW) 3-57 3-58...
  • Page 60 SECTION 4 MECHANISM (DP-12V) CONTENTS DECK MECHANISM PARTS LOCATIONS • Top View............................4-2 • Top View(without Tray Disc) .....................4-2 • Bottom View ..........................4-2 DECK MECHANISM DISASSEMBLY 1. Main Base ........................4-3 1-1. Clamp Assembly Disc ......................4-3 1-1-1. Plate Clamp ......................4-3 1-1-2. Magnet Clamp ......................4-3 1-1-3.

  • Page 61: Deck Mechanism Parts Locations

    DECK MECHANISM PARTS LOCATION • TOP VIEW (WITHOUT TRAY) Procedure Disass Fig- Parts Fixing Type embly Starting No. Main Base Clamp Assembly Disc 1, 2 Plate Clamp 1, 2, 3 Magnet Clamp 1, 2, 3, 4 Clamp Upper Tray Disc 1, 6 Base Assembly Sled 4 Screws,...

  • Page 62: Deck Mechanism Disassembly

    DECK MECHANISM DISASSEMBLY MAIN BASE TRAY DISC DISC CLAMP ASSEMBLY PLATE CLAMP MAGNET CLAMP CLAMP UPPER (Fig. A) BASE MAIN HOLDER LEVER BASE MAIN BASE MAIN BOTTOM SIDE VIEW FIG. 4-1 FIG. 4-2 1. MAIN BASE (FIG. 4-1) 2. TRAY DISC (FIG. 4-2) 1-1.

  • Page 63: Base Assembly Sled

    RUBBER DAMPER Distinguish upper and lower sides (Assemble with care) (S2) RUBBER DAMPER (S2) RUBBER DAMPER (S2) Distinguish upper and lower sides (Assemble with care) BASE PU (S2) GENERAL PICK UP ASSEMBLY GEAR RACK SPINDLE MOTOR ASSEMBLY FIG. 4-3 3. BASE ASSEMBLY SLED (FIG. 4-3) 3-3.

  • Page 64: Frame Assembly Up/Down

    GUIDE UP/DOWN GEAR LOADING GEAR PULLEY SCREW INSERTION TORGUE CONTROL BASE MAIN (800gf DOWN) (L4) BELT LOADING (H1) PWB ASSEMBLY LOADING (C2) (S5) BASE MAIN UP/DOWN FRAME ASSEMBLY (L5) GUIDE UP/DOWN FIG. (A) FIG. (B) GUIDE UP/DOWN GUIDE UP/DOWN FIG. (C) FIG.
  • Page 65 MEMO...

  • Page 66: Exploded View

    EXPLODED VIEW 1. DECK MECHANISM EXPLODED VIEW DP-12V 015B 015A...
  • Page 67 MEMO MEMO 4-10...

  • Page 68: Replacement Parts List

    CUTTING HDPE 100 100 0.05 BAG 534-008C Dry Cell Battery AAA(R03) 1PAIR 1.5V 50MAH AAA 6711R2N124D Remote Controller Assembly NAD DV302H-NE 08 DVD-P NAD *** Accessory Assembly *** 6851R-0074B Accessory Assembly VCR LGEIN 1WAY YELLOW 1.2M + 2 6850R-PAA2F Cable,Assembly RCA PLUG RCA PLUG 1.2M 1P YELL...
  • Page 69 Clamp MOLD POM DECK/MECHA dp-13 MOLD MJS31956302 Tray MOLD ABS XR-401 DVD dp-12 MOLD *** PCB Assembly,Power(POWER) *** EBR42200724 PCB Assembly,Power DV300'S SMPS IN WIDE NAD Total BC101 636-004C Filter,Bead BFS3550R2FD8 70OHM 9X3.5X7.5MM C101 624-088F Capacitor,Film,DIP PCX2 335 M9663 100nF 10% 275V...
  • Page 70 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS IC101 EAN34789801 IC,PWM Controller STR-A6259H 12.9V TO 15.7V 10V IC102 6500RDB011B Sensor,Position K1010B 5V DIP BK 4P 4PIN PHOTO IC102 657-063A Sensor,Position LTV-817B 5V DIP BK 2P PHOTO CO ALTERNATE IC103 0IPMGUC004B IC,LDO Voltage Regulator TL431 MAX12V 3.3V 600MW TO92 T...
  • Page 71 DVD DV302H-NE BSWENNK NAD play T517C AGL37044006 Panel Assembly,Front DVD DV302H-NE BSWENNT NAD play T517CT EBR50464802 PCB Assembly 08 DVD-P NAD TIMER IN _ C901 0CN1040K948 Capacitor,Ceramic,Axial CH UP050 F104Z-A-B Z 100nF -20 C902 0CN1010K518 Capacitor,Ceramic,Axial CH UP025 B101K-A-B Z 100pF 10%...
  • Page 72 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C220 0CE2274F638 Capacitor,AL,Radial SRA5.0TP16VM220M 220uF 20% 16V C240 0CE1074C638 Capacitor,AL,Radial SRA5.0TP6.3VM100M 100uF 20% 6. C242 0CE1064F638 Capacitor,AL,Radial ESS106M016T1A5B07G 10uF 20% 16 C642 0CE3364F638 Capacitor,AL,Radial ESS336M016T1A5E07G 33uF 20% 16 C666 0CE1074C638 Capacitor,AL,Radial SRA5.0TP6.3VM100M 100uF 20% 6.
  • Page 73 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C622 0CH1104K942 Capacitor,Ceramic,Chip 0603F104Z500CT 100nF -20TO+80% C623 0CK105CD94A Capacitor,Ceramic,Chip 0603F105Z100CT 1uF -20TO+80% 1 C624 0CK105CD94A Capacitor,Ceramic,Chip 0603F105Z100CT 1uF -20TO+80% 1 C625 0CK105CD94A Capacitor,Ceramic,Chip 0603F105Z100CT 1uF -20TO+80% 1 C626 0CK105CD94A Capacitor,Ceramic,Chip 0603F105Z100CT 1uF -20TO+80% 1 C627 0CK105CD94A Capacitor,Ceramic,Chip...
  • Page 74 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS C690 0CH1104K942 Capacitor,Ceramic,Chip 0603F104Z500CT 100nF -20TO+80% C692 0CH1104K942 Capacitor,Ceramic,Chip 0603F104Z500CT 100nF -20TO+80% C694 0CH4221K412 Capacitor,Ceramic,Chip 0603N221J500LT 220pF 5% 50V C0 C695 0CH4560K412 Capacitor,Ceramic,Chip 0603N560J500LT 56pF 5% 50V C0G C696 0CH4221K412 Capacitor,Ceramic,Chip 0603N221J500LT 220pF 5% 50V C0 C6A5 0CH4100K412...
  • Page 75 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS L627 6200HJC102A Filter,Bead HB-1M2012-102JT 1000OHM 2X1.25 L701 6200HJC102A Filter,Bead HB-1M2012-102JT 1000OHM 2X1.25 L702 6200HJC102A Filter,Bead HB-1M2012-102JT 1000OHM 2X1.25 L703 0LCCE00004E Inductor,Multilayer,Chip FI-C2012-103KJT 10UH 10% - 25M L704 0LCCE00004E Inductor,Multilayer,Chip FI-C2012-103KJT 10UH 10% - 25M Q201 0TR103709BB TR,Bipolar...
  • Page 76 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R213 0RH3903C622 Resistor,Chip MCR03EZPJ394 390KOHM 5% 1/10W R214 0RJ7503C677 Resistor,Chip MCR03EZPJ754 750KOHM 5% 1/10W R220 EBC40167001 Wire Pad WIRE PAD WIRE PAD 1 ALMIT R221 0RH1002C622 Resistor,Chip MCR03EZPJ103 10KOHM 5% 1/10W 1 R222 0RH1002C622 Resistor,Chip...
  • Page 77 S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS R704 0RH0752C422 Resistor,Chip MCR03EZPF750 75OHM 1% 1/10W 16 R705 0RH0752C422 Resistor,Chip MCR03EZPF750 75OHM 1% 1/10W 16 R706 0RH0752C422 Resistor,Chip MCR03EZPF750 75OHM 1% 1/10W 16 R707 0RH0752C422 Resistor,Chip MCR03EZPF750 75OHM 1% 1/10W 16 R708 0RH0752C422 Resistor,Chip...
  • Page 78 1SZZ0098J BH + 3MM 6.5MM MSWR 1SZZR-0097N Screw,Customized - + 3MM 8MM MSWR FZB SIN JIN *** PCB Assembly(SCART & USB) *** EBR50660002 PCB Assembly 08 DVD-P NAD SCART&IR _ C305 0CE477CC618 Capacitor,AL,Radial SMS5.0TP6.3VB470M 470uF 20% 6. C306 0CE477CC618 Capacitor,AL,Radial SMS5.0TP6.3VB470M 470uF 20% 6.
