Neo Car Audio ProLink P2MZV1 Installation Manual & User Manual

Model Firmware / OS Version Model
1G nano 1.3.1 160 GB classic
iPod 5G 1.3 5G nano
2G nano 1.1.3 3G touch
iPod classic 1.1.2 iPhone 4
3G nano 1.1.3 4G touch
iPod touch iOS 3.1.3 6G nano
iPhone iOS 3.1.3
iPhone 3G iOS 4.2.1
4G nano 1.0.4
120 GB classic 2.0.1
2G touch iOS 4.2.1
iPhone 3GS iOS 4.3.5
6
Optional Remote Kit: Functions for iPod
iPod:
iPod: No feature assigned
iPod: Next Track
iPod: Previous Track
1
iPod: Skip to the next PLAYLIST
4
iPod: Skip to the previous PLAYLIST
Connection Diagram
SIRIUS SAT radio Auxiliary device
(not included) (not included)
ProLink module
Vehicle BUS
(front)
connector
SIRIUS connector*
AUX connector
IR receiver (optional)
(optional)
*Do not connect the iPod dock cable under any circumstance to the SIRIUS module connector!
Improper connection can cause permanent damage to iPod/SIRIUS module.
1
Firmware / OS Version
2.0.4
1.0.2
iOS 4.3.5
iOS 4.3.5
iOS 4.3.5
1.0
NEO logo is a trademark of NEO Car Audio, Inc. SiriusConnect, Sirius and XM logos are trademark of SiriusXM. The Made for iPod logo is a trademark of Apple Inc. Apple iPod is not included in the package. For our detailed
terms and conditions please visit our website at www.neocaraudio.com.
5
Installation
1. Verify compatibility
Toggle the auido sources between iPod
SOURCE
and SIRIUS/AUX
2. Disconnect battery
No feature assigned
3. Remove radio from car
3
iPod: Skip to the next ALBUM
6
iPod: Skip to the previous ALBUM
4. Install ProLink cable
Some radios will enter an anti-theft security mode and will lock requiring the radio's security code
* ARTIST is currently not supported to be entered to unlock it. This code can be requested from the vehicle's dealership.
7
Attention installer! Please read the following!
NEO Car Audio strongly recommends that the unit be installed in an easily accessible place!
DO NOT PLACE IT BEHIND THE RADIO!
iPod/iPhone
ProLink module
(not included)
(back)
Whether the unit is professionally or self installed, put the module where you, the end user can get to it easily
in the future. (Have the installer show you where the NEO interface module is installed.)
-Add possible future upgrades, changing software, adding new features, improving operation;
-Access the AUX input on the module to attach any audio device;
Update port -Access the DIP switches located on the module;
iPod dock cable*
(USB to PC)
-Remove the unit in case of failure.
MAKE SURE THAT THE MODULE IS IN AN ACCESSIBLE PLACE!
for selected Mazda vehicles for selected Mazda vehicles
Installation Guide/User manual
P2MZV1
5. Route kit to glove box or other accessible location
6. Connect battery & test
7. Complete install by re-installing radio
ProLink kit
Identifying your ProLink kit
contents
NEO interface for iPod
Installation Guide/User Manual
user manual
XX X- XXX-XXX
ProLink module
iPod docking
Vehicle bus
connector
cable
NEO-MAZ-091411
4
Dip switch setting
SAT Emulation
ON ON
Use this setting for best user experience. Only
available on SAT capable radios. To enable
usage of the SIRIUS Connect tuner, SAT
TM
emulation must be used.
8
SAT emulation: Basic operation
Accessing the ProLink as the audio source:
Much like the radio's AM/FM tuner, satellite radio or CD audio sources, the ProLink is integrated to be
part of the vehicle's audio system. To access the ProLink source, press the SAT button on the radio.
ProLink source selection:
The ProLink adds additional audio sources including iPod, SIRIUS Satellite Radio* and/or audio input*.
the ProLink as the audio source.
*These sources require additional parts/accessories/service from NEO and/or third parties.
Note: When changing source, radio may temporarily display "UPDATING" when switching between iPod and
SIRIUS Connect sources.
ProLink interface settings (within first 5 seconds of accessing ProLink as the audio source):
Press remote button 2 to set the time iPod will charge after vehicle ignition is turned OFF.
Press remote button 3 to change ProLink audio gain setting.
Press remote button 4 to enable/disable scrolling text.
Press remote button 5 to set radio line display type.
Press remote button 6 to view ProLink firmware version.
Press remote button 1 to apply settings and resume audio playback.
3
Module serial number
DBM12345678
Product part number
-
CDC Emulation
OFF OFF
Use this setting when the SAT emulation is not
available due to the limitation of the radio.
- Radio does not display text in CDC mode
- Connection of SIRIUS Connect tuner is not
available in this mode.
See back for more
