NetSurge is a state-of-the-art modular surge protector, that protects your sensitive
equipment from the most severe electrical environment. NetSurge is available
with or without a telephone module for protecting modems, fax machines, and
other telecommunications equipment. The NetSurge protector can be upgraded at
any time with additional telephone, LAN, or CATV modules.
SAVE THESE INSTRUCTIONS
Important Safety, Grounding, and Installation Instructions
NetSurge is intended for INDOOR USE ONLY.
NetSurge must be connected to a grounded, three-wire, AC outlet.
Never install telephone or CATV wiring during a lightning storm.
NetSurge should be located away from heat sources, such as heat registers.
Avoid the use of extension cords and adapters.
Installation
1. Plug the equipment to be protected into the NetSurge protector receptacles.
Ensure that the total load does not exceed 15A.
2. Plug the NetSurge protector into a grounded, three-wire, AC outlet.
3. Turn on the unit by pressing the large round button once.
4. Verify that the two green indicators are illuminated. See the "Diagnostics"
section if the indicators are not illuminated.
Advertisement
Summary of Contents for Powerware NetSurge Plus
- Page 1 NetSurge is a state-of-the-art modular surge protector, that protects your sensitive equipment from the most severe electrical environment. NetSurge is available with or without a telephone module for protecting modems, fax machines, and other telecommunications equipment. The NetSurge protector can be upgraded at any time with additional telephone, LAN, or CATV modules.
- Page 2 Diagnostics The NetSurge protector has two indicators that provide diagnostic information: the Power Fault and Status indicator. Status Power Fault Condition Indicator Indicator Normal Operation The wall outlet may be incorrectly wired and/or have a poor ground connection. Have a qualified electrician check the outlet wiring.
-
Page 3: Wall Mounting Instructions
Powerware also provides hardware coverage limited to repair or replacement cost of properly connected protected equipment per occurrence up to a limit of $50,000 on the NetSurge Plus and $25,000 for the NetSurge... -
Page 4: Connected Equipment Warranty
$50,000 for the NetSurge Plus or $25,000 for the NetSurge. No employee of Powerware or any other party is autho- rized to make any representation beyond the right to audit damage, site and/or cost of repairs. - Page 5 CATV TEL 4 Wire CATV RS232 RS232 Mail the module to: FREE Upgrade Dept. 4300 Fortune Place, Suite A W. Melbourne, FL 32904 For questions,call the Powerware hotline at: 800-554-3448 (option 4) Please keep this card as proof of purchase!
