Summary of Contents for Quicklook Zoom
- Page 1 Q U I C K L O O K User Manual Please read the “Important Instructions for Use” overleaf...
- Page 2 • Do not open Quicklook - there are no user serviceable parts inside and opening it will invalidate your warranty. • At the end of its life, Quicklook should be disposed of responsibly in accordance with local ordinances. Never dispose of the unit by fire.
-
Page 3: Contents Of The Package
Quicklook Zoom is supplied with the following items: o Main unit with integrated display, camera & battery o Protective pouch o Wrist strap o Charger with power lead Charging the battery Quicklook Zoom is supplied with the battery partially charged, we recommend that you... - Page 4 The light will go off when the battery is substantially charged. takes about three hours to charge the battery from a discharged state. Additional charging will not cause any damage to the unit. Quicklook Zoom can be used while the battery is being charged.
- Page 5 Wrist strap loop Charge input and indicator Freeze / Brightness button Mode button Zoom up button Zoom down button Camera Pic of the mouse on the handwriting stand. Pic of the mouse on the handwriting stand. Maybe show the mouse as it...
-
Page 6: Operation
In this respect Quicklook Zoom differs from a magnifying glass in that the image you see does not correspond to the area directly beneath. Quicklook Zoom can be viewed from any... - Page 7 Enhanced reading mode with false colours. colour Inverted Enhanced reading mode with false colours reversed When using Quicklook Zoom on different material, experiment with different modes to see which helps you to see best. Note that all original colour is removed from the image in the enhanced modes.
- Page 8 Zoom-down button. By default the upper magnification stops at 9X, but holding the Zoom-up button for 3 seconds will temporarily unlock the two upper magnification levels. These levels will remain available until the unit is powered off.
- Page 9 Writing When you wish to write with the Quicklook Zoom, rotate the camera out fully to its second click position. While looking at the display, find the place on the page where you wish to write and place your pen in the picture.
-
Page 10: Adjusting The Backlight
You can turn the camera lights off by powering on the Quicklook while holding in the Brightness button. To turn the lights back on, simply turn the Quicklook off and back on again. -
Page 11: Using The Menu
Using the Menu The Quicklook Zoom has a menu system to allow you to customize it to suit your requirements. To bring up the menu, press and hold the Mode button for three seconds until an icon appears on the screen. - Page 12 Use Zoom-up and Zoom-down to navigate through the menu choices and press Mode to accept the choice. Press Freeze to cancel a choice and exit the menu. The Advanced menu contains options that are used only occasionally. Hold the Mode...
- Page 13 The Colour Mode Menu: Brightness – Use the Zoom-up and Zoom-down buttons to adjust the image brightness. Press Mode to accept the new setting. Contrast – As with brightness above use the Zoom-up and Zoom-down buttons to adjust the contrast of the image.
- Page 14 Press Zoom-up button change the ink colour and the Zoom-down button to change the paper colour. Press Mode to accept your choice. Mode-button set-up: You can customise the Mode button so that only the reading modes you use are available. If...
- Page 15 The Advanced Settings Menu: Battery display – You can display the level of power remaining in the battery in the upper left of the screen. Sounds –Use this option to turn the sounds on or off. Auto-off –This option will turn the unit off automatically after 5 minutes if a button has not been pressed during that time.
- Page 16 Fitting the wrist strap Quicklook Zoom is supplied with an optional wrist strap. To fit this, pass the thin loop of the strap through the hoop on the top of the unit.
-
Page 17: Maintenance
Dirt and finger marks on the screen should be cleaned with the lens cleaning cloth provided. If Quicklook becomes dirty it can be cleaned with a damp cloth and mild detergent. Never use any type of solvent or abrasive cleaning agents. Do not immerse Quicklook... - Page 18 Warranty The Quicklook Zoom has been fully tested prior to shipping and should provide reliable service. Ash Technologies warrants the equipment, when purchased new, to be free from defects in material and workmanship and will repair or replace at Ash...
-
Page 19: Specifications
DECLARATION OF CONFORMITY We, Ash Technologies Ltd., declare under our sole responsibility that this product, Quicklook Zoom, of the brand Ash Technologies to which this declaration relates, is in conformity with the following standards or other normative documents:... - Page 20 © Ash Technologies Limited 2007 Ash Technologies Ltd. +353-45-88 22 12 B5, M7 Business Park, +353-45-88 22 14 Naas, Ireland. info@ashtech.ie Made in Ireland www.ashtech.ie Quicklook Zoom User Manual EN Rev D...
