Sangoma 3050G Installation Manual

4. FXO MODULE ACTIVATION
The following steps will guide you through the software process to activate the FXO
ports.
A) Log into your Vega 3050G webGUI by typing its IP address inside the URL of a
browser of your choice
B) A window will pop up indicating there is a hardware change within the Vega.
This message is normal as the FXO plug-in module was added.
C) A factory reset of the Vega 3050G is required at this point to allow the unit to
fully detect the new FXO ports. Click the 'factory reset' button visible near the
bottom of the window (See Diagram below).
5. RESTORE YOUR CONFIGURATION
A) A restore of your con guration is now required. Navigate to 'System >
Con guration and click Choose File where it says 'Send File to Gateway' . A
window will pop up allowing you to search for the backup you previously
created (if you did not alter the name of the backup it will be called 'con g.txt')
B) Once selected click the 'Upload' button which will restore the Vega to previous
con guration
C) You will be required to Apply and Save settings
With the Vega now ready, you may now con gure the new FXO ports on your Vega
3050G. Navigate to POTS and con gure the ports.
100 Renfrew Drive, Suite 100, Markham ON L3R 9R6 Canada
+1 905 474 1990 or 1 800 388 2475 (toll free in N. America)
Sangoma.com © 2016 Sangoma Technologies Proprietary
Note: Save your
existing con guration if
you have not done so,
as described in Step 2.
If you do not perform a
back up, your existing
con guration will be
lost.
