- Page 1 3G3070 3G (HSPA) WIRELESS ALARM COMMUNICATOR INSTALLATION MANUAL V3.6 WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manu- facturer. The entire manual should be carefully read.
-
Page 3: Table Of Contents
Installing the 3G3070 ........4... - Page 4 IMPORTANT The equipment is fixed, wall-mounted and shall be installed in the position specified in these instructions. The equipment enclosure must be fully assembled and closed, with all the necessary screws/tabs and secured to a wall before operation. Internal wiring must be routed in a manner that prevents: - Excessive strain on wire and on terminal connections - Loosening of terminal;...
-
Page 5: Introduction
• Panel transmission monitoring for up to four phone numbers Technical Specifications The input voltage to the 3G3070 can be drawn from the control panel or provided by an external power supply rated for the application (external power-limited power source). -
Page 6: Identification Of Parts
O2 O3 O4 +OC L1 L2 L3 L4 +12V - 3G3070 All circuits are classified as Power Limited/Class II Power Limited except for the battery leads which are not power limited. Do not route any wiring over circuit boards. Maintain at least 1” (25.4mm) separation. A mini- mum 1/4”... -
Page 7: Description
4 hours standby power capabilities. An example of a suitable listed compatible control unit is the DSC Model PC1864 with an AUX output rated 11.1 - 12.6VDC. An example of a suitable Listed power supply is DSC Model PC5204 with an AUX output rated 11.6 - 12.6VDC. -
Page 8: Installing The 3G3070
NOTE: Electrical current drawn from this terminal is drawn directly from the power supply. This must be added to the 3G3070 current when determining the total draw on the host panel or power supply. Jumper JP3 does not limit the electrical current available on this output. -
Page 9: Status Leds
Network is unavailable, ‘No Service’. If this LED flashes, the following list indicates the specific trouble based on the number of flashes, by priority. When turned on, the 3G3070 checks for the trouble conditions to be restored in the order listed below. The 3G3070 indicates the status of the highest priority, unrestored trouble condition with the corresponding number of flashes of the red LED. -
Page 10: Operating Principles
• The central station receiver acknowledges the alarm and sends a command to the 3G3070 to gen- erate the corresponding 1400Hz Kiss-off signal for a minimum of 800msec. After the 3G3070 generates a Kiss-off signal, it sends the next alarm or, if no further alarms need to be sent, the control panel goes on-hook. -
Page 11: Outputs
The 3G3070 has four open collector outputs capable of a maximum of 50mA. Internal events on the 3G3070 can trigger the outputs to turn on an LED or activate an input on the host panel. The default settings are as follows. -
Page 12: Low Power Radio Shutdown
Failure to do so could result in the unit transmitting with the previously programmed configuration. NOTE: A Hardware default must be performed when the SIM card is being swapped. NOTE: Uploading a defaulted communicator will generate an error in the 3G3070 software appli- cation. Low Power Radio Shutdown When the battery voltage reaches the low battery threshold of 10.5V, the unit turns off the radio to... - Page 13 Events description Customer Code - type in a 4 character code (accepted values: digits and the letters A, B, C, D, E and F). Event Code - type in the Contact ID to be transmitted when the respective event occurs. Send - select (tick) the events to be sent.
-
Page 14: Status Page
Enable the panel force dial feature if the control panel used with the 3G3070 does not force dial (goes off hook but will not dial if there is no dial tone) Status Page This page allows real-time monitoring of all device functions. -
Page 15: Troubleshooting Guide
Powering up the 3G3070 – when powering up the 3G3070, always connect the battery first before connecting primary DC power from the control panel or transformer. Wiring Primary – R-1/T-1 of 3G3070 to RING/TIP of control panel, DC power from control panel or DC transformer to DC input, backup battery if JP3 OFF. -
Page 16: Status Indicator
• When used as the primary communicator, the yellow light will always be ON • When used as a backup communicator, the yellow light will be ON when there is a no phone line connected to the 3G3070 TIP and RING, or the line voltage goes below 2.8VDC Yellow Light OFF •... - Page 17 Once the 3G3070 low battery trouble condition is corrected, the red light will then begin flashing four times. General Troubles with System The control panel is displaying a tele- • Ensure T1 and R1 of the 3G3070 are wired to the TIP...
-
Page 18: General Information
• The lights will continue to flash in this sequence until the battery is charged above 12.4VDC Swinger Shutdown for Telephone • If the 3G3070 is configured as a backup, it can send a maximum of 3 TLM troubles and restorals per day Line Monitor (TLM) transmissions for •... -
Page 19: 3G3070 Wiring Diagrams
CMC. 3. Output 4 on the 3G3070 must be set as “Active High” (default). 4. When powering the 3G3070 Radio by an... - Page 20 Figure 4 - Wiring Diagram...
- Page 21 IMPORTANT READ CAREFULLY: DSC Software purchased with or without Products and Components is copyrighted and is purchased under the following license terms: 3. COPYRIGHT • This End User License Agreement ("EULA") is a legal agreement between You (the company, individual or entity who acquired the Soft-...
- Page 22 This equipment generates and uses radio frequency energy the end user. and if not installed and used properly, in strict accordance with the DSC c/o APL Logistics, 757 Douglas Hill Rd., Lithia Springs, GA 30122 manufacturer's instructions, may cause interference to radio and Additional Information television reception.
-
Page 23: Limited Warranty
