Fluke 419D Quick Reference Manual

W
CAUTION
The Meter produces a visible laser beam
which emerges from the front of the
Meter.
It is a Class 2 laser product in
accordance with: IEC60825-1 : 2007
"Radiation safety of laser products"
Default
1x
2x
Auto-detect
1x = Recall
. . .
1 20
Use the value shown
=
2 sec.
in the Summary line
for further calcuations.
+
2 Sec. = Delete History
1
2
1x = Set back or clear value
2x = Clear all
+
2 Sec. = Delete History
2 Sec. = Off
0.000 m 0.00 ft
0.000 0 m 0'00" 1/32 *
2 Sec. =
0.00 m 0.000 in
0 in 1/32
* default
+ =
On/Off
+ =
On/Off
Quick
Reference
Guide
Laser Distance Meter
419D
1
2
9
8
7
Buttons
1. Measure/Min Max/Power On
2. Plus (+)/Scroll Up
3. Minus (-)/Scroll Down
4. Area/Volume
5. Memory
6. Clear/Off
7. Reference/Units
8. Timer
9. Indirect Measurement
(Pythagoras)/Stake Out
PN 4117715 June 2012
