TP-Link TL-WA830RE Quick Installation Manual

Quick

Installation Guide

Applicable Model:
TL-WA830RE
Option ONE: Your router supports Wi-Fi Protected Setup (WPS). The WPS button of a router might look like one of these:
WPS
Your router doesn't support WPS or you are not sure.
Option TWO:
Option ONE Quick Setup using the WPS (RE) Button
Power on
Plug the extender's adapter into an electrical outlet
near your router. Then turn on the extender and
wait about 30 seconds until the Power LED
and solid green.
ON/OFF POWER ETHERNET RANGE EXTENDER RESET
Relocate
1
Plug in the extender halfway between your router and the Wi-Fi dead zone.
Wait about 1 minute until the LED
2
relocate it closer to the router to achieve better signal quality.
Enjoy!
The extended network shares the
as those of your host network.
Entertainment Adapter
The extender can be used as a wireless adapter to connect any Ethernet-only device such
as a Blu-ray player, game console, DVR, or smart TV to your Wi-Fi network.
First, connect the extender to your router using Option ONE or Option TWO. Then connect
your Ethernet-only device to the extender via an Ethernet cable.
Smart TV Game Console Desktop
Connect
Press the WPS button on
1
your router.
is lit
is lit with a solid green. If not,
same network name and password
Router
Some ISP gateways disable the WPS function by default. If the WPS method fails, please use Option TWO.
Host Network
Router
SSID (Host Network Name)
Password (12345678)
TP-LINK Tether APP
Tether
How to begin?
1 Download the Tether app from the Apple App Store or Play Store.
2 Ensure your device is wirelessly connected to the extender or to the
host router.
3 Launch the app and start managing your extended network.
For more information, please visit our website:
.
Press the RANGE EXTENDER button within
2
2 minutes, and the LED starts blinking.
The LED
change from blinking to
solid state, indicating
that WPS connection is
successful.
If not, please refer to
Option TWO.
RANGE EXTENDER
ON/OFF POWER ETHERNET RANGE EXTENDER RESET
Extended Network
Green: Ideal location
Red: Too far away
SSID (Host Network Name)
Password (12345678)
Tether app provides a simple, intuitive way to access and
manage your extender with your iOS or Android devices.
NOTE: AP mode of the extender is not supported by the Tether.
Set up the extender
Turn on/off the LED
http://www.tp-link.com
should
Clients
Modify current settings
Block unwelcome devices
Scan to download
©2016 TP-LINK
