Light Duty Commercial Electric Water Heater
USE & CARE MANUAL
WITH INSTALLATION INSTRUCTIONS FOR THE INSTALLER
!
Do Not Destroy this Manual. Please read carefully and
keep in a safe place for Future Reference.
!
NOTICE: This water heater is designed for use in a commercial application and the installation and maintenance of
it should be performed by qualified, licensed service personnel. If the foregoing assumption is not appropriate, then
we recommend that you obtain and retain our Residential Use & Care Manual.
!
CALIFORNIA PROPOSITION 65 WARNING: This product contains chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Printed in USA
The purpose of this manual is twofold: one, to provide the installer with the
basic directions and recommendations for the proper installation and
adjustment of the water heater; and two, for the owner–operator, to
explain the features, operation, safety precautions, maintenance and
troubleshooting of the water heater. This manual also includes a parts list.
It is imperative that all persons who are expected to install, operate or
adjust this water heater read the instructions carefully so they may
understand how to perform these operations. If you do not understand
these instructions or any terms within it, seek professional advice.
Any questions regarding the operation, maintenance, service or warranty
of this water heater should be directed to the seller from whom it was
purchased. If additional information is required, refer to the section on
"How to obtain service assistance."
!
Recognize this symbol as an Indication of Important
Safety Information!
®
LISTED
786H
AP11564-10 (01/05)
Advertisement
Table of Contents
Related Manuals for Rheem Light Duty Commercial Electric Water Heater
Summary of Contents for Rheem Light Duty Commercial Electric Water Heater
- Page 1 Future Reference. NOTICE: This water heater is designed for use in a commercial application and the installation and maintenance of it should be performed by qualified, licensed service personnel. If the foregoing assumption is not appropriate, then we recommend that you obtain and retain our Residential Use &...
-
Page 2: Table Of Contents
READ THIS MANUAL Inside you will find many helpful hints on how to use and maintain your water heater properly. Just a little preventive care on your part can save you a great deal of time and money over the life of your water heater. -
Page 3: General Safety Precautions
Be sure to read and understand the entire Use & Care Manual before attempting to install or operate this water heater. Pay particular attention to the following General Safety Precautions. Failure to follow these warnings could result in serious bodily injury or death . Should you have any problems un- derstanding the instructions in this manual, STOP, and get help from a qualified installer or service technician or the local utility. -
Page 4: Location
70. In Canada, use the latest edition of the Canadian Electric Code. LOCATION Locate the water heater in a clean dry area as near as practical to the area of greatest heated water demand. Long uninsulated hot water lines can waste energy and water. - Page 5 (1,034 kPa), the maximum working pressure of the water heater as marked on the rating plate. The BTUH Rating of the relief valve must not be less than the input rating of the water heater as in- dicated on the rating label located on front of the heater (1 watt = 3.412 BTUH).
-
Page 6: Electrical Connections
CAUTION The presence of water in the piping and water heater does not provide sufficient conduction for a ground. Non-metallic piping, dielectric unions, flexible connectors etc. can cause the water heater to be electrically isolated. The branch circuit wiring should include either: A. -
Page 7: Safety Controls
A. Do turn off power to water heater if it has been subjected to over heating, fire, flood or physical damage. B. Do Not turn on water heater unless it is filled with water. C. Do Not turn on water heater if cold water supply shut-off valve is closed. -
Page 8: Long Time Shut-Down
Attach a garden hose to the drain valve on the water heater and direct the stream of water to a drain where it will do no damage. -
Page 9: Trouble Shooting Guide
When contacting the manufacturer, the following information should be made available: a. Model and serial numbers of the water heater as shown on the rating plate attached to the jacket of the heater. b. Address where water heater is located and can be seen. -
Page 10: Replacement Parts List
Replacement Parts List Light Duty Commercial Models Tall or Short Versions Temperature & Pressure relief valve Dip tube/internal heat trap Internal heat trap Internal heat trap gasket Heating element gasket (on double element models only) Heating element (on double element models only) Upper thermostat bracket (on double element... - Page 11 Replace the thermostat and/or element as necessary. Replace the insulation and jacket access panel(s) before turning on the power to the water heater. NOTICE: The cavity insert crossbar is necessary for the manufacturing process only. The removal of the crossbar will not interfere with the operation of...
-
Page 12: Wiring Diagram
ELEMENT FIG. E ‡ This water heater is factory equipped for two (2) wire connection to electrical power. For use with "off-peak" meter (timer) remove wire nut from red and black leads and connect to "off-peak" meter (timer). DOUBLE ELEMENT...
