Universal Remote Control UR4U-MDVR2 Operating Instructions

1
Introduction
Operating Instructions
This remote control is designed to operate all
For 4-Function
Motorola and Scientific Atlanta digital set top
boxes (including HD and DVR), plus the
Cable Remote Control
majority of TVs, DVDs and AUDIO equipment
on the market as shown below.
CABLE : Cable Converters
DVD : DVDs, TV/DVDs
UR4U-MDVR2 AUX : Audio Receivers and DVRs, etc.
2
Replacing Batteries
Before you program or operate this remote
control, you must first install two new AA Alkaline
batteries.
STEP1 Remove the battery compartment cover
on the back of your remote control.
STEP2 Check battery polarity carefully, and
install the batteries as shown in the
illustration below.
STEP3 Replace the battery compartment cover.
3
Operations
DEFAULT STATUS:
Component Default: CABLE
Channel Default: CABLE channel +/- and
numbers operate through the CABLE box.
You have the option of controlling channel +/- and
numbers through the TV or DVD. Refer to
section H for programming steps.
Volume Default: CABLE volume +/- and mute
operate through the TV. You have the option
Universal Remote Control, Inc.
of controlling volume through the Cable box
or DVD. Refer to section I for programming
www.universalremote.com
OCE-0053B REV 32 (08/26/16) steps.
4
Button Functions
G
TV : Televisions
5
Programming the Remote Control
There are three ways you can program your remote control:
* Quick Set-Up Method
* The Pre-Programmed 3-Digit Code Method
* The Auto-Search Method
The Quick Set-Up Method is a unique new feature that enables the fastest and easiest set-up by using
one-digit codes for up to 10 major brands for each component.
The Pre-Programmed Code Method allows you to setup all the buttons at once by entering 3-digit code
numbers that correspond to a particular Component's manufacturer/brand, so it's the fastest and
easiest of the two methods. (Code Tables are on the backside of this Instruction Sheet.) The Auto-
Search Method scans through all the codes in the remote control, one at a time.
IMPORTANT SETUP NOTES:
This pertains to all programming steps. When you are in setup mode in each component, a component
LED will light up for 30 seconds. If you do not press a button within 30 seconds, the LED light will turn off
and exit setup mode and you will need to start over.
When programming a combo unit, program as a DVD first.
C. Pre-Programmed 3-Digit Code
A. Quick Set-Up Method
Method
STEP1 Turn on the component you want to program.
STEP1 Turn on the Component you want to
To program your TV, turn on the TV.
program (TV, DVD or AUX).
STEP2 Press and hold the [DEVICE] key for 5
STEP2 Press the [COMPONENT] button (TV, DVD
seconds until the Device LED will blink
or AUX) to be programmed and [OK/SEL]
once and stays on. Continue to hold the
button simultaneously for 3 seconds. The
[DEVICE] key and press the number key
Component LED will light for 30 seconds
assigned to your brand in the Quick Set-up
indicating the unit is ready to be
Code Table and release both [DEVICE] key
programmed.
and the number key to save the code. The
Device LED will blink twice to confirm that
STEP3 Point the remote control toward the
the code is stored.
Component and enter the 3-digit code
number assigned to your brand.
STEP3 Point the remote control at the
component.
*Note : If the 3-digit code number you just entered
is correct, the Component will turn Off. If
STEP4 Press the power button. If it turns off, it is
it did not turn Off, continue entering code
programmed for your component. If it does
numbers listed for that brand until the
not turn off, use the Pre-Programmed 3-
Component turns Off.
Digit code Method or Scanning Method.
STEP4 After you've entered the correct code
Repeat the steps above for all components
number and the Component has turned
(CBL,TV,DVD, AUX).
Off, press the [POWER] button to turn the
Component back On. Now it's time to test
B. Quick Set-up Code Tables
the VOLUME and MUTE buttons for the
TV (or PLAY and STOP buttons for DVD) to
make sure they all work. If any of the
CBL
functions do not work as they should,
Quick Number Manufacturer/Brand
repeat from STEP 3 using the next 3-digit
0 PACE DTA
code number listed for that brand.
1 SA/CISCO, SAMSUNG, PACE DIGITAL
2 MOTOROLA DIGITAL
3 MOTOROLA DTA STEP5 Once you have found the correct 3-digit
4 EVOLUTION DTA
code, save it by pressing the same
5 CISCO IPTV
6 ADB IPTV
[COMPONENT] button one more time.
7 TECHNICOLOR
The Component LED light will blink twice
8 AMINO 140/540 IPTV
9 MOTOROLA IPTV
to confirm that the code was successfully
stored.
TV
Quick Number Manufacturer/Brand Now, program the rest of your Components by
repeating STEPS 1-5.
0 SANYO
1 SONY
2 SAMSUNG *Note : If the Pre-Programmed Method did not
3 LG
work, or if the Code Tables do not list
4 TOSHIBA
5 PANASONIC
your Component brand, use the Auto-
6 PHILIPS
7 HITACHI Search Method as explained in Section D.
8 SHARP
9 VIZIO
D. Auto-Search Method
DVD
STEP1 Turn on the Component you want to
Quick Number Manufacturer/Brand
program (TV, DVD or AUX).
0 HITACHI
STEP2 Press the [COMPONENT] button (TV, DVD
1 SONY
2 PHILIPS
or AUX) to be programmed and [OK/SEL]
3 SAMSUNG
4 PHILIPS MAGNAVOX button simultaneously for 3 seconds. The
5 PANASONIC
Component LED will light for 30 seconds
6 LG
7 JVC
indicating the unit is ready to be
8 DENON
9 PIONEER programmed.
STEP3 Point the remote toward the Component
AUX
and press the [CH5] or [CH6] button
Quick Number Manufacturer/Brand
one step at a time or keep it pressed. The
remote will emit a series of ON/OFF
0 BOSE
1 HP
commands. Release the [CH5] or [CH6]
2 ONKYO
3 APPLE/iPod
button as soon as the Component turns
4 MICROSOFT / XBOX
Off.
5 SONY / PS2
6 LUTRON
7 X-10
STEP4 Test functions. (Same as for 3-Digit Code
8 YAMAHA
9 ROKU Programming Method - Section C). If any of
the functions do not work as they should, you press the AUX button, all the buttons will
repeat from STEP 3 using [CH5] or [CH6] work with that 4 th Component.
buttons to find the correct code.
G. Programming the System On/Off Button
STEP5 Save the code. (Same as for 3-Digit Code
Programming Method - Section C).
This allows you to program the System On/Off button so
it can send up to four power On/Off commands with one
Now, repeat the Auto-Search Method for those
button press.
Components you could not program earlier with the
Pre-Programmed Method.
STEP1 Press the [CBL] button.
STEP2 Press the [SYSTEM ON/OFF] button and the
E. Finding a Component Button's
[OK/SEL] button simultaneously for 3 seconds.
Setup Code Number
The [CBL] Component LED will light for 30
seconds.
If you used the Auto-Search Method to program a
Component, you may not know what the correct code
STEP3 Press the first [COMPONENT] button you want
number is. Here is a way for you to identify the code
to store in the [SYSTEM ON/OFF] button and
number, so you can record it for future reference.
then the [POWER] button. Repeat this for
other Components until you have stored all the
STEP1 Press the [COMPONENT] button (TV, DVD or
desired power commands into the [SYSTEM
AUX) you want to verify and the [OK/SEL] button
ON/OFF] button.
simultaneously for 3 seconds. The Component
LED will light for 30 seconds.
STEP4 Press the [CH5] button to save the power
STEP2 Press the [INFO] button and count the number commands you stored. The [CBL] button will
blink twice to confirm the commands have
of times the Component LED light blinks. This
been saved.
number indicates the first digit of the code,
followed by the second and third, each
separated by a one second pause when the H. Programming Channel Control
LED will turn off.
You can program the channel controls (Channel Up,
*Note : 10 blinks represents the number zero.
Channel Down, Last and Numbers) from one Component
to operate in another Component mode. Default channel
Example : One blink, (pause), eight blinks, (pause) and
control settings on the remote control are as follows:
three blinks, indicates code number 183.
CBL : CBL
F. AUX Function: Programming a 4 th
DVD : DVD
Component
If you wish to operate the TV channel control in TV
You can take advantage of the AUX function to program
mode, use the following steps.
a 4 th Component such as a second TV, DVD or Audio
STEP1 Press the [TV] button and the [OK/SEL] button
Component.
simultaneously for 3 seconds. The [TV]
STEP1 Turn on the 4 th Component you want to
Component LED will light for 30 seconds.
program (TV, DVD or Audio).
STEP2 Press the [VOL 6] button.
STEP2 Press the [AUX] button and the [OK/SEL]
STEP3 Press the [TV] button again.
button simultaneously for 3 seconds.The
The Component LED will blink twice to confirm
[AUX] Component LED will light for 30
the programming.
seconds.
STEP3 Press the [COMPONENT] button you want to
To return to original state:
setup. Point the remote control toward the
If you wish to restore the CABLE channel control in
Component and enter the 3-digit code number
TV mode, repeat the above steps but press [CBL] in
assigned to your brand.
STEP3.
*Note : If the 3-digit code number you just entered is
I. Programming Volume Control
the correct number, the Component will turn
Off. If it did not turn Off, continue entering
You can program the volume controls (Volume Up,
code numbers listed for that brand until the
Volume Down and Mute) from one Component to
Component turns Off
operate in another Component mode. Default volume
control settings on the remote control are as follows:
STEP4 Test functions. (Same as for 3-Digit Code
Programming Method - Section C). If any of
CBL : TV
the functions do not work as they should, you
DVD : TV
need to find a new code.
If you wish to operate the CBL volume control in CBL
STEP5 Once you have found the correct 3-digit code,
mode, use the following steps.
save it by pressing the [AUX] button one more
time. The Component LED light will blink twice STEP1 Press the [CBL] button and the [OK/SEL]
to confirm the code was stored. Now when button simultaneously for 3 seconds. The
T V : CBL
AUX : AUX
T V : TV
AUX : AUX
