USER'S MANUAL
SMOKE AND FIRE* ALARM
10 YEAR SEALED CONFORMS TO
BATTERY OPERATED
UL STD 217
PHOTOELECTRIC
SMOKE ALARM WITH Model P1210
SILENCE FEATURE
IMPORTANT! PLEASE READ CAREFULLY AND SAVE.
The warnings/limitations card and manual contains important information about your Smoke
Alarm's operation. If you are installing this Alarm for use by others, you must leave this
manual—or a copy of it—with the end user. Reference product card for additional information.
INTRODUCTION
Thank you for choosing First Alert® for your Smoke Alarm needs. You have purchased a state of the art Smoke Alarm designed to provide you with early warning of
a fire. Please take the time to read this manual and make the Smoke Alarm an integral part of your family's safety plan.
KEY FEATURES OF THE P1210 SMOKE ALARM:
Photoelectric Sensing Technology: Photoelectric Sensors are generally more sensitive than ionization sensors in detecting smoldering fires which commonly occur
in couches or bedding.
OptiPath 360 Technology™: Patented technology provides 360° of direct access to the smoke sensor.
Single Test/Silence Button: Allows you to test the Alarm or silence nuisance alarms. Testing the Alarm assures you that the unit is functioning correctly and ready
to protect you and your family. The Alarm can be silenced for up to 9 minutes in the event of a nuisance alarm.
10 Year End of Life Indicator: 3 horn pulses every 43 seconds alerts you that the unit must be replaced.
Local Alarm Memory: Green LED flashes 3 times every 43 seconds for 24 hours. After 24 hours the unit will chirp rapidly while the Test button is pressed. Memory is
cleared when the button is released.
Low battery warning: The Alarm will sound a "chirp" once per minute when the Smoke Alarm needs to be replaced.
Low battery silence: The Alarm can be silenced for 8 hours.
Red Blinking Power Indicator every 6 minutes: Confirms that the Smoke Alarm is receiving power
All First Alert® Smoke Alarms conform to regulatory requirements, including UL217 and are designed to detect particles of combustion. Smoke particles
of varying number and size are produced in all fires.
Ionization technology is generally more sensitive than photoelectric technology at detecting small particles, which tend to be produced in greater amounts by
flaming fires, which consume combustible materials rapidly and spread quickly. Sources of these fires may include paper burning in a wastebasket, or a
grease fire in the kitchen.
Photoelectric technology is generally more sensitive than ionization technology at detecting large particles, which tend to be produced in greater amounts by
smoldering fires, which may smolder for hours before bursting into flame. Sources of these fires may include cigarettes burning in couches or bedding.
For maximum protection, use both types of Smoke Alarms on each level and in every bedroom of your home.
___________________________________________________________________________________________________________________________
FIRE SAFETY TIPS
Follow safety rules and prevent hazardous situations: 1) Use smoking materials properly. Never smoke in bed. 2) Keep matches or lighters
away from children; 3) Store flammable materials in proper containers; 4) Keep electrical appliances in good condition and don't overload electrical circuits; 5) Keep
stoves, barbecue grills, fireplaces and chimneys grease- and debris-free; 6) Never leave anything cooking on the stove unattended; 7) Keep portable heaters and
open flames, like candles, away from flammable materials; 8) Don't let rubbish accumulate. Keep alarms clean, and test them weekly. Replace alarms immediately if
they are not working properly. Smoke Alarms that do not work cannot alert you to a fire. Keep at least one working fire extinguisher on every floor, and an additional
one in the kitchen. Have fire escape ladders or other reliable means of escape from an upper floor in case stairs are blocked.
___________________________________________________________________________________________________________________________
BEFORE YOU INSTALL THIS SMOKE ALARM
IMPORTANT! Read "Recommended Locations for Smoke Alarms" and "Locations to Avoid for Smoke Alarms" before beginning. This unit monitors the air, and when
smoke reaches its sensing chamber, it alarms. It can give you more time to escape before fire spreads. This unit can ONLY give an early warning of developing fires
if it is installed, maintained and located where smoke can reach it, and where all residents can hear it, as described in this manual. This unit will not sense gas,
heat, or flame. It cannot prevent or extinguish fires.
© 2015 BRK Brands, Inc. All rights reserved. Distributed by BRK Brands, Inc. First Alert® is registered trademark of The First Alert Trust Installed on Replace by
W
3901 Liberty Street Road, Aurora, IL 60504-8122 Consumer Affairs: (800) 323-9005 • www.firstalert.com www.brkelectronics.com • 10/15
Printed in Mexico • M08-0466-013
USER'S MANUAL
SMOKE AND FIRE* ALARM
10 YEAR SEALED CONFORMS TO
BATTERY OPERATED
UL STD 217
PHOTOELECTRIC
SMOKE ALARM WITH Model P1210
SILENCE FEATURE
IMPORTANT! PLEASE READ CAREFULLY AND SAVE.
The warnings/limitations card and manual contains important information about your Smoke
Alarm's operation. If you are installing this Alarm for use by others, you must leave this
manual—or a copy of it—with the end user. Reference product card for additional information.
INTRODUCTION
Thank you for choosing First Alert® for your Smoke Alarm needs. You have purchased a state of the art Smoke Alarm designed to provide you with early warning of
a fire. Please take the time to read this manual and make the Smoke Alarm an integral part of your family's safety plan.
KEY FEATURES OF THE P1210 SMOKE ALARM:
Photoelectric Sensing Technology: Photoelectric Sensors are generally more sensitive than ionization sensors in detecting smoldering fires which commonly occur
in couches or bedding.
OptiPath 360 Technology™: Patented technology provides 360° of direct access to the smoke sensor.
Single Test/Silence Button: Allows you to test the Alarm or silence nuisance alarms. Testing the Alarm assures you that the unit is functioning correctly and ready
to protect you and your family. The Alarm can be silenced for up to 9 minutes in the event of a nuisance alarm.
10 Year End of Life Indicator: 3 horn pulses every 43 seconds alerts you that the unit must be replaced.
Local Alarm Memory: Green LED flashes 3 times every 43 seconds for 24 hours. After 24 hours the unit will chirp rapidly while the Test button is pressed. Memory is
cleared when the button is released.
Low battery warning: The Alarm will sound a "chirp" once per minute when the Smoke Alarm needs to be replaced.
Low battery silence: The Alarm can be silenced for 8 hours.
Red Blinking Power Indicator every 6 minutes: Confirms that the Smoke Alarm is receiving power
All First Alert® Smoke Alarms conform to regulatory requirements, including UL217 and are designed to detect particles of combustion. Smoke particles
of varying number and size are produced in all fires.
Ionization technology is generally more sensitive than photoelectric technology at detecting small particles, which tend to be produced in greater amounts by
flaming fires, which consume combustible materials rapidly and spread quickly. Sources of these fires may include paper burning in a wastebasket, or a
grease fire in the kitchen.
Photoelectric technology is generally more sensitive than ionization technology at detecting large particles, which tend to be produced in greater amounts by
smoldering fires, which may smolder for hours before bursting into flame. Sources of these fires may include cigarettes burning in couches or bedding.
For maximum protection, use both types of Smoke Alarms on each level and in every bedroom of your home.
___________________________________________________________________________________________________________________________
FIRE SAFETY TIPS
Follow safety rules and prevent hazardous situations: 1) Use smoking materials properly. Never smoke in bed. 2) Keep matches or lighters
away from children; 3) Store flammable materials in proper containers; 4) Keep electrical appliances in good condition and don't overload electrical circuits; 5) Keep
stoves, barbecue grills, fireplaces and chimneys grease- and debris-free; 6) Never leave anything cooking on the stove unattended; 7) Keep portable heaters and
open flames, like candles, away from flammable materials; 8) Don't let rubbish accumulate. Keep alarms clean, and test them weekly. Replace alarms immediately if
they are not working properly. Smoke Alarms that do not work cannot alert you to a fire. Keep at least one working fire extinguisher on every floor, and an additional
one in the kitchen. Have fire escape ladders or other reliable means of escape from an upper floor in case stairs are blocked.
___________________________________________________________________________________________________________________________
BEFORE YOU INSTALL THIS SMOKE ALARM
IMPORTANT! Read "Recommended Locations for Smoke Alarms" and "Locations to Avoid for Smoke Alarms" before beginning. This unit monitors the air, and when
smoke reaches its sensing chamber, it alarms. It can give you more time to escape before fire spreads. This unit can ONLY give an early warning of developing fires
if it is installed, maintained and located where smoke can reach it, and where all residents can hear it, as described in this manual. This unit will not sense gas,
heat, or flame. It cannot prevent or extinguish fires.
W
USER S MANUA
MOK ND M
R D M
B R O R D
U D
HO O C R C
MOK RM W H
NC UR
N RODUC ON
RE A E P
BE ORE OU N A H MOKE A ARM
W
Understand The Different Type of Smoke Alarms: Battery powered or electrical? Different Smoke Alarms provide different types of protection. See "About Smoke
Alarms" for details.
Know Where To Install Your Smoke Alarms: Fire Safety Professionals recommend at least one Smoke Alarm on every level of your home, in every bedroom, and in
every bedroom hallway or separate sleeping area. See "Recommended Locations For Smoke Alarms" and "Locations To Avoid For Smoke Alarms" for details.
Know What Smoke Alarms Can and Can't Do: A Smoke Alarm can help alert you to fire, giving you precious time to escape. It can only sound an alarm once
smoke reaches the sensor. See "Limitations of Smoke Alarms" for details.
Check Your Local Building Codes: This Smoke Alarm is designed to be used in a typical single-family home. It alone will not meet requirements for boarding
houses, apartment buildings, hotels or motels. See "Special Compliance Considerations" for details.
HOW TO INSTALL THIS SMOKE ALARM
TOOLS YOU WILL NEED: FOLLOW THESE SIMPLE STEPS
1. Hold the mounting bracket against the
THIS UNIT IS DESIGNED TO BE MOUNTED ON THE CEILING, OR ON THE
Mounting Hole Sets
ceiling (or wall) so the two clusters of
WALL IF NECESSARY.
• Pencil universal mounting holes are aligned
approximately at the 9:00 and 3:00
• Drill with 3/16" (5 mm) drill bit
o'clock positions. See image. Choose
• Standard flathead screwdriver B
• Hammer one of the three sets of holes shown, A,
C A
B or C (see image) and trace around one
C
A
of the sets. Be sure to choose a top and
B
bottom slot on opposite sides so you can
THE PARTS OF THIS SMOKE ALARM
rotate the universal mounting bracket into
position later. This will make it easier in
1. Test/Silence button
the future to remove the mounting bracket
2. Dual Power indicator
without completely removing the screws.
light and Alarm indicator:
WARNING! Do not install this Smoke Alarm over an existing electrical box.
Green LED provides visual
Only AC powered units are intended for installation over electrical boxes.
indication of an Alarm
2. Put the unit where it won't get covered with dust when you drill the mounting
Memory condition; Red LED
holes.
provides visual indication of
3. Using a 3/16" (5 mm) drill bit, drill a hole through the center of the oval outlines
an Alarm and Hush modes
you traced.
4. Insert the plastic screw anchors (in the plastic bag with screws) into the holes.
Tap the screw anchors gently with a hammer, if necessary, until they are flush
with the ceiling or wall.
1. Mounting bracket
5. Install the screws but do not tighten completely. Attach the mounting bracket
2. Mounting slots
by aligning the screws in the open portion of the universal mounting slots and
3. Turn this way to attach
rotating the bracket into place. Tighten the screws until they are snug to secure
4. Turn this way to remove
the bracket. Do not over tighten.
6. Activating the battery. Mount alarm to mounting bracket to activate. Once unit
is activated, it cannot be turned off.
NOTE: After you activate the battery, the power indicator light may flash.
2 1 (If the unit alarms, the light will blink rapidly, and the horn will repeatedly
sound 3 beeps, pause, 3 beeps.) Once the Smoke Alarm is on the bracket,
4
you can rotate the Alarm to adjust the alignment.
7. Test the Smoke Alarm. See "Weekly Testing."
8. After 10 years of operation or Low Battery
warning, deactivate the Smoke Alarm: Insert a tool
below edge where shown and break tab. Then ON - DEACTIVATE
3 slide activation switch to deactivate mode.
NOTE: At end of life or low battery indication (chirp): unit must be put into
deactivation mode to deactivate remaining stored energy in battery. Unit will
no longer function once put into this mode. Unit will resist re-mounting.
OPTIONAL LOCKING FEATURE
The optional locking feature is designed to prevent unauthorized removal of the alarm. It is not necessary to
activate the lock in single-family households where unauthorized alarm removal is not a concern.
Locking Pin
Tools you will need: Needle-nose pliers or utility knife • Standard flathead screwdriver
The feature uses a locking pin which is molded into the mounting bracket. Remove locking pin by using
needle-nose pliers or a utility knife.
To permanently remove the locking pin, insert a flathead screwdriver
between the locking pin and the lock and pry the pin out of the lock.
Understand The Different Type of Smoke Alarms: Battery powered or electrical? Different Smoke Alarms provide different types of protection. See "About Smoke
Alarms" for details.
Know Where To Install Your Smoke Alarms: Fire Safety Professionals recommend at least one Smoke Alarm on every level of your home, in every bedroom, and in
every bedroom hallway or separate sleeping area. See "Recommended Locations For Smoke Alarms" and "Locations To Avoid For Smoke Alarms" for details.
Know What Smoke Alarms Can and Can't Do: A Smoke Alarm can help alert you to fire, giving you precious time to escape. It can only sound an alarm once
smoke reaches the sensor. See "Limitations of Smoke Alarms" for details.
Check Your Local Building Codes: This Smoke Alarm is designed to be used in a typical single-family home. It alone will not meet requirements for boarding
houses, apartment buildings, hotels or motels. See "Special Compliance Considerations" for details.
HOW TO INSTALL THIS SMOKE ALARM
TOOLS YOU WILL NEED: FOLLOW THESE SIMPLE STEPS
1. Hold the mounting bracket against the
THIS UNIT IS DESIGNED TO BE MOUNTED ON THE CEILING, OR ON THE
Mounting Hole Sets
WALL IF NECESSARY. ceiling (or wall) so the two clusters of
universal mounting holes are aligned
• Pencil
approximately at the 9:00 and 3:00
• Drill with 3/16" (5 mm) drill bit
• Standard flathead screwdriver o'clock positions. See image. Choose B
one of the three sets of holes shown, A,
• Hammer A
C
B or C (see image) and trace around one
A C
of the sets. Be sure to choose a top and
B
bottom slot on opposite sides so you can
THE PARTS OF THIS SMOKE ALARM
rotate the universal mounting bracket into
position later. This will make it easier in
1. Test/Silence button
the future to remove the mounting bracket
2. Dual Power indica
without completely removing the screws.
WARNING! Do not install this Smoke Alarm over an existing electrical box.
Only AC powered units are intended for installation over electrical boxes.
2. Put the unit where it won't get covered with dust when you drill the mounting
holes.
3. Using a 3/16" (5 mm) drill bit, drill a hole through the center of the oval outlines
you traced.
4. Insert the plastic screw anchors (in the plastic bag with screws) into the holes.
Tap the screw anchors gently with a hammer, if necessary, until they are flush
with the ceiling or wall.
5. Install the screws but do not tighten completely. Attach the mounting bracket
by aligning the screws in the open portion of the universal mounting slots and
rotating the bracket into place. Tighten the screws until they are snug to secure
the bracket. Do not over tighten.
6. Activating the battery. Mount alarm to mounting bracket to activate. Once unit
is activated, it cannot be turned off.
NOTE: After you activate the battery, the power indicator light may flash.
(If the unit alarms, the light will blink rapidly, and the horn will repeatedly
sound 3 beeps, pause, 3 beeps.) Once the Smoke Alarm is on the bracket,
you can rotate the Alarm to adjust the alignment.
7. Test the Smoke Alarm. See "Weekly Testing."
8. After 10 years of operation or Low Battery
warning, deactivate the Smoke Alarm: Insert a tool
below edge where shown and break tab. Then ON - DEACTIVATE
slide activation switch to deactivate mode.
NOTE: At end of life or low battery indication (chirp): unit must be put into
deactivation mode to deactivate remaining stored energy in battery. Unit will
no longer function once put into this mode. Unit will resist re-mounting.
OPTIONAL LOCKING FEATURE
The optional locking feature is designed to prevent unauthorized removal of the alarm. It is not necessary to
activate the lock in single-family households where unauthorized alarm removal is not a concern.
Tools you will need: Needle-nose pliers or utility knife • Standard flathead screwdriver
The feature uses a locking pin which is molded into the mounting bracket. Remove locking pin by using
needle-nose pliers or a utility knife.
To permanently remove the locking pin, insert a flathead screwdriver
between the locking pin and the lock and pry the pin out of the lock.
HOW O N A H MOKE A ARM
OO O W O OW M
O MO M
OP ONA OCK NG EA URE
TO LOCK THE MOUNTING BRACKET TO UNLOCK THE MOUNTING BRACKET
1. Using needle-nose pliers, detach the pin 1. Insert a flathead screwdriver in
from the mounting bracket. between the mounting bracket and the
locking pin.
2. Insert the locking pin through the hole on
the back of the smoke alarm as shown 2. Pry the alarm away from the bracket
in the diagram. by pushing up the screwdriver and
turning the alarm counterclockwise
3. When you attach the (left) at the same time.
alarm to the mounting
bracket the locking
pin's head will fit
into a notch on the
bracket.
WEEKLY TESTING
• NEVER use an open flame of any kind to test this unit. You might accidentally damage or set fire to the unit or to your home.
• If the Alarm ever fails to test properly, replace it immediately. Products under warranty may be returned to the manufacturer for replacement. See
"Limited Warranty" for details.
• DO NOT stand close to the Alarm when the horn is sounding. Exposure at close range may be harmful to your hearing. When testing, step away when
horn starts sounding.
It is important to test this unit every week to make sure it is working properly. Using the Test/Silence button is the recommended way to test this Smoke
Alarm. Press and hold the Test/Silence button on the cover of the unit until the alarm sounds (the unit may continue to alarm for a few seconds after you release the
button). If it does not alarm, make sure the unit is receiving power and test it again. If it still does not alarm, replace it immediately. During testing you will hear a
loud, repeating horn pattern: 3 beeps, pause, 3 beeps, pause. Red LED flashes rapidly.
REGULAR MAINTENANCE
This unit has been designed to be as maintenance free as possible, but there are a few simple things you must do to keep it working properly.
• Test it at least once a week.
• Clean the Smoke Alarm at least once a month; gently vacuum off any dust using your household vacuum's soft brush attachment, and test the Smoke Alarm after
cleaning. Never use water, cleaners or solvents since they may damage the unit.
• If the Smoke Alarm becomes contaminated by excessive dirt, dust and/or grime, and cannot be cleaned to avoid unwanted alarms, replace the unit immediately.
• Relocate the unit if it sounds frequent unwanted alarms.
See "Locations to Avoid For Smoke Alarms" for details.
• When the battery becomes weak, the Smoke Alarm unit will "chirp" approximately once a minute (the Low Battery warning). This low
battery warning should last for up to 30 days, but you should replace the Smoke Alarm immediately to continue your protection.
Actual service life depends on the Smoke Alarm and the environment in which it is installed. You MUST replace the Smoke Alarm
immediately once the unit starts "chirping" (the "low battery warning").
___________________________________________________________________________________________________________________________
IF THIS SMOKE ALARM SOUNDS
RESPONDING TO AN ALARM
During an alarm, you will hear a loud, repeating horn pattern:
3 beeps, pause, 3 beeps, pause. The Red LED flashes rapidly.
• If the unit alarms get everyone out of the house immediately.
• If the unit alarms and you are not testing the unit, it is warning you of a potentially dangerous situation that requires your immediate attention. NEVER ignore any
alarm. Ignoring the alarm may result in injury or death.
• Never remove the batteries from a battery operated Smoke Alarm to stop an unwanted alarm (caused by cooking smoke, etc.). Removing batteries disables the
alarm so it cannot sense smoke, and removes your protection. Instead open a window or fan the smoke away from the unit. The alarm will reset automatically.
WHAT TO DO IN CASE OF FIRE
• Don't panic; stay calm. Follow your family escape plan.
• Get out of the house as quickly as possible. Don't stop to get dressed or collect anything.
• Feel doors with the back of your hand before opening them. If a door is cool, open it slowly. Don't open a hot door. Keep doors and windows closed, unless you
must escape through them.
• Cover your nose and mouth with a cloth (preferably damp). Take short, shallow breaths.
• Meet at your planned meeting place outside your home, and do a head count to make sure everybody got out safely.
O OCK HE MOUN NG BRACKE O UN OCK HE MOUN NG BRACKE
WEEKLY TESTING
• NEVER use an open flame of any kind to test this unit. You might accidentally damage or set fire to the unit or to your home.
• If the Alarm ever fails to test properly, replace it immediately. Products under warranty may be returned to the manufacturer for replacement. See
"Limited Warranty" for details.
• DO NOT stand close to the Alarm when the horn is sounding. Exposure at close range may be harmful to your hearing. When testing, step away when
horn starts sounding.
It is important to test this unit every week to make sure it is working properly. Using the Test/Silence button is the recommended way to test this Smoke
Alarm. Press and hold the Test/Silence button on the cover of the unit until the alarm sounds (the unit may continue to alarm for a few seconds after you release the
button). If it does not alarm, make sure the unit is receiving power and test it again. If it still does not alarm, replace it immediately. During testing you will hear a
loud, repeating horn pattern: 3 beeps, pause, 3 beeps, pause. Red LED flashes rapidly.
REGULAR MAINTENANCE
This unit has been designed to be as maintenance free as possible, but there are a few simple things you must do to keep it working properly.
• Test it at least once a week.
• Clean the Smoke Alarm at least once a month; gently vacuum off any dust using your household vacuum's soft brush attachment, and test the Smoke Alarm after
cleaning. Never use water, cleaners or solvents since they may damage the unit.
• If the Smoke Alarm becomes contaminated by excessive dirt, dust and/or grime, and cannot be cleaned to avoid unwanted alarms, replace the unit immediately.
• Relocate the unit if it sounds frequent unwanted alarms.
See "Locations to Avoid For Smoke Alarms" for details.
• When the battery becomes weak, the Smoke Alarm unit will "chirp" approximately once a minute (the Low Battery warning). This low
battery warning should last for up to 30 days, but you should replace the Smoke Alarm immediately to continue your protection.
Actual service life depends on the Smoke Alarm and the environment in which it is installed. You MUST replace the Smoke Alarm
immediately once the unit starts "chirping" (the "low battery warning").
___________________________________________________________________________________________________________________________
IF THIS SMOKE ALARM SOUNDS
RESPONDING TO AN ALARM
During an alarm, you will hear a loud, repeating horn pattern:
3 beeps, pause, 3 beeps, pause. The Red LED flashes rapidly.
• If the unit alarms get everyone out of the house immediately.
• If the unit alarms and you are not testing the unit, it is warning you of a potentially dangerous situation that requires your immediate attention. NEVER ignore any
alarm. Ignoring the alarm may result in injury or death.
• Never remove the batteries from a battery operated Smoke Alarm to stop an unwanted alarm (caused by cooking smoke, etc.). Removing batteries disables the
alarm so it cannot sense smoke, and removes your protection. Instead open a window or fan the smoke away from the unit. The alarm will reset automatically.
WHAT TO DO IN CASE OF FIRE
• Don't panic; stay calm. Follow your family escape plan.
• Get out of the house as quickly as possible. Don't stop to get dressed or collect anything.
• Feel doors with the back of your hand before opening them. If a door is cool, open it slowly. Don't open a hot door. Keep doors and windows closed, unless you
must escape through them.
• Cover your nose and mouth with a cloth (preferably damp). Take short, shallow breaths.
• Meet at your planned meeting place outside your home, and do a head count to make sure everybody got out safely.
O OCK HE MOUN NG BRACKE O UN OCK HE MOUN NG BRACKE
WEEK E NG
REGU AR MA N ENANCE
H MOKE A ARM OUND
O O M
W O O O
• Call the Fire Department as soon as possible from outside. Give your address, then your name.
• Never go back inside a burning building for any reason.
• Contact your Fire Department for ideas on making your home safer.
Alarms have various limitations. See "Limitations of Smoke Alarms" for details.
USING THE SILENCE FEATURE
The Silence Feature can temporarily quiet an unwanted alarm for up to 9 minutes. To use this feature, press the Test/Silence button on the cover. If the unit will not
silence and no heavy smoke is present, or if it stays in silence mode continuously, it should be replaced immediately. The LED will flash every 10 seconds
while in silence.
The Silence Feature does not disable the unit—it makes it temporarily less sensitive to smoke. For your safety, if smoke around
the unit is dense enough to suggest a potentially dangerous situation, the unit will stay in alarm or may re-alarm quickly. If you do not know the source
of the smoke, do not assume it is an unwanted alarm. Not responding to an alarm can result in property loss, injury, or death.
SILENCING THE LOW BATTERY WARNING
This silence feature can temporarily quiet the Low Battery warning "chirp". Press the Test/Silence button on the Alarm. The Red light flashes normally, once every 6
minutes, during Low Battery Warning Silence. After time, the low battery "chirp" will resume. Deactivate the Smoke Alarm and replace it immediately.
IF YOU SUSPECT A PROBLEM
Smoke Alarms may not operate properly because of a dead or weak battery, a build-up of dirt, dust or grease on the Smoke Alarm cover, or installation in an
improper location. Clean the Smoke Alarm as described in "Regular Maintenance," and then test the Smoke Alarm again. If it fails to test properly when you use the
test button, or if the problem persists, replace the Smoke Alarm immediately.
• If you hear a "chirp" about once a minute, replace the Smoke Alarm.
• If you experience frequent non-emergency alarms (like those caused by cooking smoke), try relocating the Smoke Alarm.
• If the alarm sounds when no smoke is visible, try cleaning or relocating the Smoke Alarm. The cover may be dirty.
• If the alarm does not sound during testing, make sure the power pack activating lever is pushed all the way securely.
Do not try fixing the Alarm yourself – this will void your warranty!
If the Smoke Alarm is still not operating properly, and it is still under warranty, please see "How to Obtain Warranty Service" in the Limited Warranty.
___________________________________________________________________________________________________________________________
RECOMMENDED LOCATIONS FOR SMOKE ALARMS
INSTALLING SMOKE ALARMS IN SINGLE-FAMILY RESIDENCES The National Fire Protection Association (NFPA), recommends one Smoke Alarm on every
floor, in every sleeping area, and in every bedroom. In new construction, the Smoke Alarms must be AC powered and interconnected. See "Agency Placement
Recommendations" for details. For additional coverage, it is recommended that you install a Smoke Alarm in all rooms, halls, storage areas, finished attics, and
basements, where temperatures normally remain between 40˚ F (4.4˚ C) and 100˚ F (37.8˚ C). Make sure no door or other obstruction could keep smoke from
reaching the Smoke Alarms.
MORE SPECIFICALLY, INSTALL SMOKE ALARMS:
• On every level of your home, including finished attics and basements.
• Inside every bedroom, especially if people sleep with doors closed.
• In the hall near every sleeping area. If your home has multiple sleeping areas, install a unit in each. If a hall is over 40 feet (12 meters) long, install an Alarm at
each end.
• At the top of the first-to-second floor stairway, and at bottom of basement stairway.
Specific requirements for Smoke Alarm installation vary from state to state and from region to region. Check with your local Fire
Department for current requirements in your area. It is recommended AC or AC/DC units be interconnected for added protection.
DINING ROOM BEDROOM KITCHEN DINING ROOM
BEDROOM
BEDROOM BEDROOM BEDROOM HALL BEDROOM
HALL
LIVING ROOM KITCHEN
LIVING ROOM
BEDROOM LIVING ROOM
BEDROOM LIVING ROOM
FINISHED BASEMENT SINGLE-STORY RESIDENCE, APARTMENT,
FINISHED BASEMENT SINGLE-STORY RESIDENCE, APARTMENT, MOBILE HOME
MOBILE HOME MULTI-STORY RESIDENCE
MULTI-STORY RESIDENCE KEY:
KEY: RECOMMENDED SMOKE ALARMS INTERCONNECTED
REQUIRED TO
FOR ADDITIONAL WITH SILENCE AC OR AC/DC
REQUIRED TO RECOMMENDED MEET NFPA
PROTECTION FEATURES SMOKE ALARMS
MEET NFPA FOR ADDITIONAL RECOMMENDATIONS
RECOMMENDED
RECOMMENDATIONS PROTECTION
FOR ADDITIONAL
PROTECTION
• Call the Fire Department as soon as possible from outside. Give your address, then your name.
• Never go back inside a burning building for any reason.
• Contact your Fire Department for ideas on making your home safer.
Alarms have various limitations. See "Limitations of Smoke Alarms" for details.
USING THE SILENCE FEATURE KEY:
REQUIRED TO MEET
The Silence Feature can temporarily quiet an unwanted alarm for up to 9 minutes. To use this feature, press the Test/Silence button on the cover. If the unit will not BEDROOM KITCHEN DINING ROOM
KEY: NFPA RECOMMENDATIONS
BEDROOM HALL BEDROOM
silence and no heavy smoke is present, or if it stays in silence mode continuously, it should be replaced immediately. The LED will flash every 10 seconds REQUIRED TO MEET RECOMMENDED FOR
BEDROOM
BEDROOM HALL NFPA RECOMMENDATIONS ADDITIONAL PROTECTION
while in silence. BEDROOM DINING ROOM
KITCHEN
RECOMMENDED FOR LIVING ROOM KITCHEN SMOKE ALARMS WITH SILENCE
The Silence Feature does not disable the unit—it makes it temporarily less sensitive to smoke. For your safety, if smoke around ADDITIONAL PROTECTION FEATURES RECOMMENDED FOR
BEDROOM LIVING ROOM
ADDITIONAL PROTECTION
the unit is dense enough to suggest a potentially dangerous situation, the unit will stay in alarm or may re-alarm quickly. If you do not know the source LIVING ROOM KITCHEN
SMOKE ALARMS WITH SILENCE INTERCONNECTED AC OR
FINISHED BASEMENT SINGLE-STORY RESIDENCE, APARTMENT,
LIVING ROOM FEATURES RECOMMENDED FOR AC/DC SMOKE ALARMS
of the smoke, do not assume it is an unwanted alarm. Not responding to an alarm can result in property loss, injury, or death. BEDROOM MOBILE HOME
ADDITIONAL PROTECTION
MULTI-STORY RESIDENCE
FINISHED BASEMENT
SINGLE-STORY RESIDENCE, APARTMENT,
SILENCING THE LOW BATTERY WARNING
MOBILE HOME
MULTI-STORY RESIDENCE
This silence feature can temporarily quiet the Low Battery warning "chirp". Press the Test/Silence button on the Alarm. The Red light flashes normally, once every 6
minutes, during Low Battery Warning Silence. After time, the low battery "chirp" will resume. Deactivate the Smoke Alarm and replace it immediately.
IF YOU SUSPECT A PROBLEM
Smoke Alarms may not operate properly because of a dead or weak battery, a build-up of dirt, dust or grease on the Smoke Alarm cover, or installation in an
improper location. Clean the Smoke Alarm as described in "Regular Maintenance," and then test the Smoke Alarm again. If it fails to test properly when you use the
test button, or if the problem persists, replace the Smoke Alarm immediately.
• If you hear a "chirp" about once a minute, replace the Smoke Alarm.
• If you experience frequent non-emergency alarms (like those caused by cooking smoke), try relocating the Smoke Alarm.
• If the alarm sounds when no smoke is visible, try cleaning or relocating the Smoke Alarm. The cover may be dirty.
• If the alarm does not sound during testing, make sure the power pack activating lever is pushed all the way securely.
Do not try fixing the Alarm yourself – this will void your warranty!
If the Smoke Alarm is still not operating properly, and it is still under warranty, please see "How to Obtain Warranty Service" in the Limited Warranty.
___________________________________________________________________________________________________________________________
RECOMMENDED LOCATIONS FOR SMOKE ALARMS
INSTALLING SMOKE ALARMS IN SINGLE-FAMILY RESIDENCES The National Fire Protection Association (NFPA), recommends one Smoke Alarm on every
floor, in every sleeping area, and in every bedroom. In new construction, the Smoke Alarms must be AC powered and interconnected. See "Agency Placement
Recommendations" for details. For additional coverage, it is recommended that you install a Smoke Alarm in all rooms, halls, storage areas, finished attics, and
basements, where temperatures normally remain between 40˚ F (4.4˚ C) and 100˚ F (37.8˚ C). Make sure no door or other obstruction could keep smoke from
reaching the Smoke Alarms.
MORE SPECIFICALLY, INSTALL SMOKE ALARMS:
• On every level of your home, including finished attics and basements.
• Inside every bedroom, especially if people sleep with doors closed.
• In the hall near every sleeping area. If your home has multiple sleeping areas, install a unit in each. If a hall is over 40 feet (12 meters) long, install an Alarm at
each end.
• At the top of the first-to-second floor stairway, and at bottom of basement stairway.
Specific requirements for Smoke Alarm installation vary from state to state and from region to region. Check with your local Fire
Department for current requirements in your area. It is recommended AC or AC/DC units be interconnected for added protection.
BEDROOM KITCHEN DINING ROOM
BEDROOM DINING ROOM
BEDROOM HALL BEDROOM
BEDROOM HALL BEDROOM
LIVING ROOM KITCHEN
LIVING ROOM
BEDROOM LIVING ROOM
BEDROOM LIVING ROOM
FINISHED BASEMENT SINGLE-STORY RESIDENCE, APARTMENT,
FINISHED BASEMENT SINGLE-STORY RESIDENCE, APARTMENT, MOBILE HOME
MOBILE HOME
MULTI-STORY RESIDENCE
MULTI-STORY RESIDENCE
KEY:
SMOKE ALARMS INTERCONNECTED
KEY: REQUIRED TO RECOMMENDED
WITH SILENCE AC OR AC/DC
REQUIRED TO RECOMMENDED MEET NFPA FOR ADDITIONAL
FEATURES SMOKE ALARMS
MEET NFPA FOR ADDITIONAL RECOMMENDATIONS PROTECTION
RECOMMENDED
RECOMMENDATIONS PROTECTION
FOR ADDITIONAL
PROTECTION
KEY:
REQUIRED TO MEET
BEDROOM KITCHEN DINING ROOM
KEY: NFPA RECOMMENDATIONS
BEDROOM HALL BEDROOM
REQUIRED TO MEET RECOMMENDED FOR
BEDROOM
NFPA RECOMMENDATIONS ADDITIONAL PROTECTION
BEDROOM HALL BEDROOM
KITCHEN DINING ROOM
RECOMMENDED FOR LIVING ROOM KITCHEN SMOKE ALARMS WITH SILENCE
ADDITIONAL PROTECTION FEATURES RECOMMENDED FOR
BEDROOM LIVING ROOM ADDITIONAL PROTECTION
LIVING ROOM KITCHEN
SMOKE ALARMS WITH SILENCE
FINISHED BASEMENT SINGLE-STORY RESIDENCE, APARTMENT, INTERCONNECTED AC OR
LIVING ROOM FEATURES RECOMMENDED FOR AC/DC SMOKE ALARMS
BEDROOM MOBILE HOME
ADDITIONAL PROTECTION
MULTI-STORY RESIDENCE
FINISHED BASEMENT SINGLE-STORY RESIDENCE, APARTMENT,
OW MOBILE HOME W
MULTI-STORY RESIDENCE
O O M
m
RECOMMENDED OCA ON OR MOKE A ARM
AGENCY PLACEMENT RECOMMENDATIONS
NFPA 72 CHAPTER 29 "For your information, the National Fire Alarm and Signaling Code, NFPA 72, reads as follows:"
29.5.1* REQUIRED DETECTION.
29.5.1.1* Where required by other governing laws, codes, or standards for a specific type of occupancy, approved single and multiple-station smoke alarms shall be
installed as follows:
(1)*In all sleeping rooms and guest rooms
(2)* Outside of each separate dwelling unit sleeping area, within 21 ft (6.4 m) of any door to a sleeping room, with the distance measured along a path of travel
(3) On every level of a dwelling unit, including basements
(4) On every level of a residential board and care occupancy (small facility), including basements and excluding crawl spaces and unfinished attics
(5)*In the living area(s) of a guest suite
(6) In the living area(s) of a residential board and care occupancy (small facility)
(Reprinted with permission from NFPA 72®, National Fire Alarm and Signaling Code Copyright © 2010 National Fire Protection Association, Quincy, MA 02269. This
reprinted material is not the complete and official position of the National Fire Protection Association, on the referenced subject which is represented only by the
standard in its entirety), (National Fire Alarm and Signaling Code® and NFPA 72® are registered trademarks of the National Fire Protection Association, Inc., Quincy,
MA 02269).
CALIFORNIA STATE FIRE MARSHAL (CSFM) Early warning detection is best achieved by the installation of fire detection equipment in all rooms and areas of the
household as follows: A Smoke Alarm installed in each separate sleeping area (in the vicinity, but outside bedrooms), and Heat or Smoke Alarms in the living rooms,
dining rooms, bedrooms, kitchens, hallways, finished attics, furnace rooms, closets, utility and storage rooms, basements, and attached garages.
___________________________________________________________________________________________________________________________
LOCATIONS TO AVOID FOR SMOKE ALARMS
FOR BEST PERFORMANCE, IT IS RECOMMENDED YOU AVOID INSTALLING SMOKE ALARMS IN THESE AREAS:
• Where combustion particles are produced. Combustion particles form when something burns. Areas to avoid include poorly ventilated kitchens, garages, and furnace
rooms. Keep units at least 20 feet (6 meters) from the sources of combustion particles (stove, furnace, water heater, space heater) if possible. In areas where a
20-foot (6-meter) distance is not possible – in modular, mobile, or smaller homes, for example – it is recommended the Smoke Alarm be placed as far from these
fuel-burning sources as possible. The placement recommendations are intended to keep these Alarms at a reasonable distance from a fuel-burning source, and thus
reduce "unwanted" alarms. Unwanted alarms can occur if a Smoke Alarm is placed directly next to a fuel-burning source. Ventilate these areas as much as possible.
• In air streams near kitchens. Air currents can draw cooking smoke into the sensing chamber of a Smoke Alarm near the kitchen.
• In very damp, humid or steamy areas, or directly near bathrooms with showers. Keep units at least 10 feet (3 meters) away from showers, saunas, dishwashers, etc.
• Where the temperatures are regularly below 40˚ F (4.4˚ C) or above 100˚ F (37.8˚ C), including unheated buildings, outdoor rooms, porches, or unfinished attics or
basements.
• In very dusty, dirty, or greasy areas. Do not install a Smoke Alarm directly over the stove or range. Keep laundry room Smoke Alarms free of dust or lint.
• Near fresh air vents, ceiling fans, or in very drafty areas. Drafts can blow smoke away from the unit, preventing it from reaching the sensing chamber.
• In insect infested areas. Insects can clog openings to the sensing chamber and cause unwanted alarms.
• Less than 12 inches (305mm) away from fluorescent lights. Electrical "noise" can interfere with the sensor.
• In "dead air" spaces. "Dead air" spaces may prevent smoke from reaching the Smoke Alarm.
AVOIDING DEAD AIR SPACES
"Dead air" spaces may prevent smoke from reaching the Smoke Alarm. To avoid dead air spaces, follow the installation recommendations below.
ON CEILINGS, install Smoke Alarms as close to the center of the ceiling as possible. If this is not possible, install the Smoke Alarm at least 4 inches (102 mm) from
the wall or corner.
FOR WALL MOUNTING (if allowed by building codes), the top edge of Smoke Alarms should be placed between 4 and 12 inches (102 and 305 mm) from the wall/
ceiling line, below typical "dead air" spaces.
ON A PEAKED, GABLED, OR CATHEDRAL CEILING, install the first Smoke Alarm within 3 feet (0.9 meters) of the peak of the ceiling, measured horizontally.
Additional Smoke Alarms may be required depending on the length, angle, etc. of the ceiling's slope. Refer to NFPA 72 for details on requirements for sloped or
peaked ceilings.
___________________________________________________________________________________________________________________________
LIMITED WARRANTY
BRK Brands, Inc., ("BRK") the maker of First Alert® brand products warrants that for a period of ten years from the date of purchase, this product will be free
from defects in material and workmanship. BRK, at its option, will repair or replace this product or any component of the product found to be defective during the
warranty period. Replacement will be made with a new or remanufactured product or component. If the product is no longer available, replacement may be made
with a similar product of equal or greater value. This is your exclusive warranty. This warranty is valid for the original retail purchaser from the date of initial retail
purchase and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. BRK dealers, service centers, or
retail stores selling BRK products do not have the right to alter, modify or any way change the terms and conditions of this warranty. This warranty does not cover
normal wear of parts or damage resulting from any of the following: negligent use or misuse of the product, use on improper voltage or current, use contrary to the
operating instructions, disassembly, repair or alteration by anyone other than BRK or an authorized service center. Further, the warranty does not cover Acts of God,
such as fire, flood, hurricanes and tornadoes or any batteries that are included with this unit. BRK shall not be liable for any incidental or consequential damages
caused by the breach of any express or implied warranty. Except to the extent prohibited by applicable law, any implied warranty of merchantability or fitness for
a particular purpose is limited in duration to the duration of the above warranty. Some states, provinces or jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights that vary from state to state or province to province.
AGENCY PLACEMENT RECOMMENDATIONS
NFPA 72 CHAPTER 29 "For your information, the National Fire Alarm and Signaling Code, NFPA 72, reads as follows:"
29.5.1* REQUIRED DETECTION.
29.5.1.1* Where required by other governing laws, codes, or standards for a specific type of occupancy, approved single and multiple-station smoke alarms shall be
installed as follows:
(1)*In all sleeping rooms and guest rooms
(2)* Outside of each separate dwelling unit sleeping area, within 21 ft (6.4 m) of any door to a sleeping room, with the distance measured along a path of travel
(3) On every level of a dwelling unit, including basements
(4) On every level of a residential board and care occupancy (small facility), including basements and excluding crawl spaces and unfinished attics
(5)*In the living area(s) of a guest suite
(6) In the living area(s) of a residential board and care occupancy (small facility)
(Reprinted with permission from NFPA 72®, National Fire Alarm and Signaling Code Copyright © 2010 National Fire Protection Association, Quincy, MA 02269. This
reprinted material is not the complete and official position of the National Fire Protection Association, on the referenced subject which is represented only by the
standard in its entirety), (National Fire Alarm and Signaling Code® and NFPA 72® are registered trademarks of the National Fire Protection Association, Inc., Quincy,
MA 02269).
CALIFORNIA STATE FIRE MARSHAL (CSFM) Early warning detection is best achieved by the installation of fire detection equipment in all rooms and areas of the
household as follows: A Smoke Alarm installed in each separate sleeping area (in the vicinity, but outside bedrooms), and Heat or Smoke Alarms in the living rooms,
dining rooms, bedrooms, kitchens, hallways, finished attics, furnace rooms, closets, utility and storage rooms, basements, and attached garages.
___________________________________________________________________________________________________________________________
LOCATIONS TO AVOID FOR SMOKE ALARMS
FOR BEST PERFORMANCE, IT IS RECOMMENDED YOU AVOID INSTALLING SMOKE ALARMS IN THESE AREAS:
• Where combustion particles are produced. Combustion particles form when something burns. Areas to avoid include poorly ventilated kitchens, garages, and furnace
rooms. Keep units at least 20 feet (6 meters) from the sources of combustion particles (stove, furnace, water heater, space heater) if possible. In areas where a
20-foot (6-meter) distance is not possible – in modular, mobile, or smaller homes, for example – it is recommended the Smoke Alarm be placed as far from these
fuel-burning sources as possible. The placement recommendations are intended to keep these Alarms at a reasonable distance from a fuel-burning source, and thus
reduce "unwanted" alarms. Unwanted alarms can occur if a Smoke Alarm is placed directly next to a fuel-burning source. Ventilate these areas as much as possible.
• In air streams near kitchens. Air currents can draw cooking smoke into the sensing chamber of a Smoke Alarm near the kitchen.
• In very damp, humid or steamy areas, or directly near bathrooms with showers. Keep units at least 10 feet (3 meters) away from showers, saunas, dishwashers, etc.
• Where the temperatures are regularly below 40˚ F (4.4˚ C) or above 100˚ F (37.8˚ C), including unheated buildings, outdoor rooms, porches, or unfinished attics or
basements.
• In very dusty, dirty, or greasy areas. Do not install a Smoke Alarm directly over the stove or range. Keep laundry room Smoke Alarms free of dust or lint.
• Near fresh air vents, ceiling fans, or in very drafty areas. Drafts can blow smoke away from the unit, preventing it from reaching the sensing chamber.
• In insect infested areas. Insects can clog openings to the sensing chamber and cause unwanted alarms.
• Less than 12 inches (305mm) away from fluorescent lights. Electrical "noise" can interfere with the sensor.
• In "dead air" spaces. "Dead air" spaces may prevent smoke from reaching the Smoke Alarm.
AVOIDING DEAD AIR SPACES
"Dead air" spaces may prevent smoke from reaching the Smoke Alarm. To avoid dead air spaces, follow the installation recommendations below.
ON CEILINGS, install Smoke Alarms as close to the center of the ceiling as possible. If this is not possible, install the Smoke Alarm at least 4 inches (102 mm) from
the wall or corner.
FOR WALL MOUNTING (if allowed by building codes), the top edge of Smoke Alarms should be placed between 4 and 12 inches (102 and 305 mm) from the wall/
ceiling line, below typical "dead air" spaces.
ON A PEAKED, GABLED, OR CATHEDRAL CEILING, install the first Smoke Alarm within 3 feet (0.9 meters) of the peak of the ceiling, measured horizontally.
Additional Smoke Alarms may be required depending on the length, angle, etc. of the ceiling's slope. Refer to NFPA 72 for details on requirements for sloped or
peaked ceilings.
___________________________________________________________________________________________________________________________
LIMITED WARRANTY
BRK Brands, Inc., ("BRK") the maker of First Alert® brand products warrants that for a period of ten years from the date of purchase, this product will be free
from defects in material and workmanship. BRK, at its option, will repair or replace this product or any component of the product found to be defective during the
warranty period. Replacement will be made with a new or remanufactured product or component. If the product is no longer available, replacement may be made
with a similar product of equal or greater value. This is your exclusive warranty. This warranty is valid for the original retail purchaser from the date of initial retail
purchase and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. BRK dealers, service centers, or
retail stores selling BRK products do not have the right to alter, modify or any way change the terms and conditions of this warranty. This warranty does not cover
normal wear of parts or damage resulting from any of the following: negligent use or misuse of the product, use on improper voltage or current, use contrary to the
operating instructions, disassembly, repair or alteration by anyone other than BRK or an authorized service center. Further, the warranty does not cover Acts of God,
such as fire, flood, hurricanes and tornadoes or any batteries that are included with this unit. BRK shall not be liable for any incidental or consequential damages
caused by the breach of any express or implied warranty. Except to the extent prohibited by applicable law, any implied warranty of merchantability or fitness for
a particular purpose is limited in duration to the duration of the above warranty. Some states, provinces or jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages or limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights that vary from state to state or province to province.
AGENC P ACEMEN RECOMMENDA ON
OCA ON O A O D OR MOKE A ARM
M ED WARRAN
