JBL JBL3310 Technical Manual

Technical Manual
JBL3310

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance:
• Power Capacity:
• Frequency Range:
• Sensitivity:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Cabinet:
• Grille:
• Low Frequency
Transducer:
• DC Resistance:
• High Frequency
Transducer:
• DC Resistance:
PACKAGE
Warranty 59660
Literature 980-00020-00
Carton
990-00013-00
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
8 ohm
75W Continuous IEC Noise
40 Hz to 20 kHz (–10dB)
89 dB SPL*
2.2 kHz
C3310
G3310 (128-00020-00)
200mm (8 in.) Cone Transducer
(508G)
5.9 ohm ±5% Copper Wire
25mm (1 in.) Pure Titanium
Dome Transducer (027Ti)
4 ohm ±10% Copper Wire
Cardboard Tray
(Top and Bottom)
991-00039-00
Polybag
74357
Filler
991-00017-00
Corner
Protector
991-00016-00
SYSTEM COMPONENTS:
• Crossover Network:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
*1 Watt (2.83 V RMS) @ 1 Meter

WIRING DIAGRAM

Speaker,
High Freq
027Ti (ARC)
(74528X)
YEL/BLK
Speaker,
Low Freq
508G
(70103X)
GRN/BLK
SCHEMATIC N3310 (331153-001)
R1
2 0
C1
6.2µF
IN
B1 B2
SK3
IN
L2
1.50mH
CONE/DIAPHRAGM KIT NOT AVAILABLE. DEFECTIVE SPEAKER SHOULD
BE REPLACED.
NOTE: POSITIVE VOLTAGE TO RED TERMINAL PRODUCES FORWARD CONE MOVEMENT.
(cont'd)
(331153-001)
7.0V Input, 40 Hz to 20 kHz
4.0V Input, 20 Hz to 1.2 kHz
2.0V Input, 2.0 kHzTO 20 kHz
445mm x 483mm x 275mm D
(17.5 x 19.0 x 10.84 in. D)
66 lbs. (30 kg.) in Pairs
YEL
Network
(331153-001)
GRN
R2
1.0
YEL
C2
C3
30.0µF
3.5µF
L1
0.25mH
R3
4.0
YEL/BLK
GRN
L3
0.35mH
C5
6.0µF
C4
13.0µF
R4
2 0
GRN/BLK
H.F.
027Ti
(ARC)
L.F.
508G
09-08
