This gas grill must be used only outdoors in a well-ventilated space and must not be used inside a
building, garage, screened-in porch, gazebo or any other enclosed area.
DANGER
IF YOU SMELL GAS:
• Shut off gas to the appliance.
• Extinguish any open flame.
• Open lid.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
Notice to Installer: Leave these instructions with the grill owner for future reference.
Conforms
to ANSI STD
Z21.58b-2012
Certified to CSA
STD 1.6b-2012
Customer Solutions: 1-866-820-8686 or
Do not try to light this appliance without
reading the "LIGHTING" instructions section of
this manual.
Do not store or use gasoline or other flam-
mable liquids or vapors in the vicinity of this
or any other appliance. An L.P. cylinder not
connected for use must not be stored in the
vicinity of this or any other appliance. If the
information in these instructions is not fol-
lowed exactly, a fire or explosion may result,
causing property damage, personal injury or
death.
Napoleon Group of Companies
214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8
Phone: 1-705-726-4278 Fax: (705)-725-2564
www.napoleongrills.com
APPLY SERIAL NUMBER LABEL FROM CARTON
Serial No.
XXXXXX000000
MODEL NO.
410, 410SB
WARNING
grills@napoleonproducts.com
EN
Z415-0016 DEC 02/16

Advertisement

loading

Related Manuals for Napoleon 410

Summary of Contents for Napoleon 410

  • Page 1 Notice to Installer: Leave these instructions with the grill owner for future reference. Napoleon Group of Companies Conforms to ANSI STD 214 Bayview Dr., Barrie, Ontario, Canada L4N 4Y8 Z21.58b-2012...
  • Page 2 Cylinder Specification/Gas Hook Up This gas barbecue is certified under Canadian and American National Standards, CSA 1.6b-2012 and ANSI Z21.58b -2012 respectively for outdoor gas grills and should be installed to conform with local codes. In absence of local codes, install to the current CAN/CSA-B149.1 Propane Installation Code in Canada or to the National Fuel Gas Code, ANSI Z223.1 in the United States.

  • Page 3: Natural Gas Hook-Up

    Bubbles will indicate a gas leak. Either tighten the loose joint or have the part replaced with one recommended by the Napoleon Customer Care department and have the grill inspected by a certified gas installer. If the leak cannot be stopped, immediately shut off the gas supply, disconnect it, and have the grill inspected by a certified gas installer or dealer.

  • Page 4: Getting Started

    CAUTION! During unpacking and assembly we recommended you wear work gloves and safety glasses for your protection. Although we make every effort to make the assembly process as problem free and safe as possible, it is characteristic of fabricated steel parts that the edges and corners might be sharp and could cause cuts if handled incorrectly.
  • Page 5 5/8”(16mm) 6 x Z570-0027(1/4-20 x 3/8”) 3/8”(10mm) www.napoleongrills.com...
  • Page 6 9 x N570-0042 (#10-24 x 3/8”) 4 x N570-0042 (#10-24 X3/ 8”) www.napoleongrills.com...
  • Page 7 4 x N570-0042 (10-24 x 3/8”) www.napoleongrills.com...
  • Page 8 4 X Z570-0027(1/4-20 X 3/8”) 3/8”(10mm) WARNING! Propane Only - To avoid assembly difficulties, prior to mounting the grill head, remove zip tie hold- ing regulator. This was installed at the factory to protect the regulator hose during shipping and is no longer required. (Take care when removing the tie not to damage the hose).
  • Page 9 2 x N105-0011 www.napoleongrills.com...
  • Page 10 Insert the shelf pin into the left shelf bracket. Insérer la goupille dans le support de plateau plateau de gauche. Bend shelf open slightly to insert second pin into bracket. Pliez plateau légèrement ouverte pour insérer second axe dans le support. WARNING! Do not over bend.
  • Page 11 Push down and engage top pins to lock shelf in place. Poussez vers le bas et d'engager broches supérieures à verrouiller l 'étagère en place. Lift Lever To disengage shelf, pull up. Pour désengager plateau, trer vers le haut. www.napoleongrills.com...
  • Page 12 1 x N160-0023 410SB MODEL Ensure bushing snaps into base as shown. Fit the orifice into the burner tube and secure with the hose retainer clip supplied. Attach the wire from the manifold to the side burner electrode. Shelf safety lock, push to lower shelf To disengage shelf, pull up.
  • Page 13 1 x N160-0023 410SB  MODÈLE  Assurez-vous que la bague soit insérée dans la base latéral tel qu’illustré. Placez l’orifice dans le brûleur et fixez à l’aide de l’attache de retenue fournie. Fixez le fil du collecteur à l’électrode du brûleur latéral. Verrouillage de sécurité, appuyer pour abaisser la...
  • Page 14 www.napoleongrills.com...
  • Page 15 www.napoleongrills.com...
  • Page 16 N570-0042 (#10-24 x 3/8”) 1 x N640-0001 Propane Only Propane Seulement Clip hose to side panel using hose retainer clip supplied. Fixez le boyau au panneau latéral à l’aide de la clip de retenue fournie. www.napoleongrills.com...
  • Page 17 www.napoleongrills.com...
  • Page 18 Propane Only – Proper Hose Connection Propane Seulement - Branchement Adéquat Du Boyau Ensure the regulator drops into the small opening, between the tank heat shield and the right side of the cabinet. Assurez-vous que le régulateur passe dans la petite ouverture, entre le protecteur de chaleur de la bonbonne et le côté...
  • Page 19 3/4”(19mm) 1 x N640-0001 Natural Gas Only – Proper Hose Connection Gaz Naturel Seulement - Branchement Adéquat Du Boyau WARNING! The installation must be performed by a licensed gas fitter, and all connections must be leak tested before operating the grill. Do not use pipe dope or teflon tape on this connection. Tighten the connection with two wrenches.
