Linksys WUSB11 Quick Installation

This Quick Installation is meant to help you install the product quickly and easily. For detailed instructions on installation,
configuration, and further setup options, please consult the User Guide.
Instant Wireless ® Series
W W i i r r e e l l e e s s s s U U S S B B N N e e t t w w o o r r k k A A d d a a p p t t e e r r
System Requirements
One PC with the following:
• 200MHz or Faster Processor
• 64MB RAM Recommended
• Windows 98SE, Me, 2000, or XP
• Available USB Port
• CD-ROM Drive
Package Contents
• One Wireless USB Network Adapter (1)
• One USB Cable (2)
• One Wall Mount (3)
• One Setup CD-ROM with User Guide (4)
• One Quick Installation
WUSB11 ver. 2.6
• One Registration Card
Connecting the Wireless USB
Network Adapter to Your PC
Note to Windows XP users: You must install the Adapter's hardware before
installing the software. Do NOT run the Setup Wizard.
Note to Windows 98SE, Me, and 2000 users: You must run the Setup Wizard
to install the software before installing the hardware. Refer to the Quick
Installation for Windows 98SE, Me, and 2000.
A. The Adapter comes with the USB cable you will use to connect the Adapter
to your PC. (See Figure A. .)
1
A.
1
Connect one end of the USB cable to the USB port of the
Adapter (see Figure A. ).
2
Connect the other end of the USB cable to one of the USB
ports on your computer (see Figure A. ).
3
B. The Power LED should light up when the Adapter is plugged in. (Make sure
your PC is powered on.)
B
C. Raise the antenna. Make sure the antenna is positioned straight up into the
air, at a 90º angle from the Adapter. This ensures optimum wireless operat-
ing range and performance.
C
A.
2
Proceed to Step 2.
A.
3
Installing the Wireless USB Network
Adapter Driver
After connecting the Adapter to your computer, you will install the driver.
Important: Do NOT run the Setup Wizard. If the Setup Wizard runs auto-
matically after the Setup Wizard CD-ROM has been inserted, click Exit.
A. Windows XP will automat-
ically detect the Adapter.
Insert the Setup Wizard
CD-ROM into your CD-
ROM drive. Click the radio
button next to Install from
a list or specific location
(Advanced). Then click
Next.
A
B. Click the radio button next
to Search for the best
driver in these locations.
Select Include this loca-
tion in the search:, and
enter D:\Drivers in the
location field (if "D" is the
letter of your CD-ROM
drive). Click Next.
B
Continued on back
