SERVICE
Samsung Color Laser Printer
CLP-610ND/XAZ
Basic Model : CLP-610ND, 660ND
Manual
The keynote of Product
High SMB/Easy of Use Tandem CLBP
- Emulation : CLP-610ND(SPL-C),
CLP-660, 660N(PostScript 3, PCL6)
- Speed : CLP-610ND(20/20 ppm),
CLP-660, 660N(24/24 ppm)
- Resolution : CLP-610ND(1,200 x 600 dpi),
CLP-660N, 660ND(1,200 x 600 dpi)
- CPU : CLP-610ND(300 MHz),
CLP-660N, 660ND(533 MHz)
- Interface : N/W
- Memory : CLP-610ND / 64 MB,
CLP-660N, 660ND/128 MB (Max. 640 MB)
- Duplex (Option)
- 250 CST, 1 Manual, 100 MP
- Toner Cartridge: 2.5K/2K (Std.), 5.5K/5K (High)
- Printer Life: Color 200K / Mono 200K pages

Advertisement

Table of Contents
loading

Related Manuals for Samsung CLP-610ND

Summary of Contents for Samsung CLP-610ND

  • Page 1: Service Manual

    - Emulation : CLP-610ND(SPL-C), CLP-660, 660N(PostScript 3, PCL6) - Speed : CLP-610ND(20/20 ppm), CLP-660, 660N(24/24 ppm) - Resolution : CLP-610ND(1,200 x 600 dpi), CLP-660N, 660ND(1,200 x 600 dpi) - CPU : CLP-610ND(300 MHz), CLP-660N, 660ND(533 MHz) - Interface : N/W - Memory : CLP-610ND / 64 MB, CLP-660N, 660ND/128 MB (Max.

  • Page 2: Table Of Contents

    Contents 1. Precautions 1.1 Safety Warning 1.2 Caution for safety 1.3 ESD Precautions 1.4 Super Capacitor or Lithium Battery Precautions 2. Product spec and feature 2.1 Product Specifications 2.1.1 Product Overview 2.1.2 Specifications 2.1.3 Maintenance List (CRU & FRU) 2.1.4 Periodic Replacing Parts 2.1.5 Competitor Model 2.2 System Overview 2-10...
  • Page 3 Continued 3.4.1 Cover Unit 3.4.2 HVPS Board 3-10 3.4.3 Main Board 3-11 3.4.4 SMPS Board 3-11 3.4.5 Fuser control Board 3-12 3.4.6 LSU Unit 3-12 3.4.7 CRUM 3-13 3.4.8 Fuser Drive Unit 3-13 3.4.9 Pick-up Roller 3-15 3.4.10 Feed Drive 3-15 4.
  • Page 4 Continued 5.4 OPE Unit 5.5 Front Cover 5-10 5.6 Exit Cover 5-12 5.7 MP Tray 5-14 5.8 Frame 5-16 5.9 Feed Drive 5-18 5.10 Fuser Drive 5-20 5.11 Fuser 5-22 5.12 PTB Unit 5-25 5.13 Cassette 5-28 5.14 SCF Unit 5-31 5.15 SCF Cassette 5-33...

  • Page 5: Safety Warning

    High voltages and lasers inside this product are dangerous. This printer should only be serviced by a suitably trained and qualified service engineer. (2) Use only Samsung replacement parts There are no user serviceable parts inside the printer. Do not make any unauthorized changes or additions to the printer, these could cause the printer to malfunction and create electric shock or fire hazards.

  • Page 6: Caution For Safety

    Take care not to cut or damage the power cable or plugs when moving the machine. (9) Use caution during thunder or lightening storms. Samsung recommend that this machine be disconnected from the power source when such weather conditions are expected. Do not touch the machine or the power cord if it is still connected to the wall socket in these weather conditions.

  • Page 7: Handling Precautions

    1.2.4 Assembly / Disassembly Precautions Replace parts carefully, always use Samsung parts. Take care to note the exact location of parts and also cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly.

  • Page 8: Disregarding This Warning May Cause Bodily Injury

    Failure to do so could cause the printer to tip or fall possibly causing personal injury or damaging the printer. (5) Do not install the printer on a sloping or unstable surface. After installation, double check that the printer is stable. Service Manual Samsung Electronics...

  • Page 9: Esd Precautions

    2. Be sure to replace the battery with the same or equivalent type recommended by the manufacturer. 3. Super capacitor or Lithium batteries contain toxic substances and should not be opened, crushed, or burned for disposal. 4. Dispose of used batteries according to the manufacture’s instructions. Service Manual Samsung Electronics...

  • Page 10: Product Specifications

    1,200 x 1,200 dpi 1,200 x 1,200 dpi effective output effective output CHORUS3(SOC) 533 MHz GDI, N/W PCL6/PS3, N/W 250 CST, 100 MP 250 CST, 100 MP Duplex Duplex 2.5K/2K (Std.) 2.5K/2K (Std.) 5.5K/5K (High) 5.5K/5K (High) Service Manual Samsung Electronics...

  • Page 11: Specifications

    Color : Up to 20 ppm in A4 (21 ppm in Letter) Color : Up to 20 ppm in A4 (25 ppm in Letter) Duplex CLP-610N : Manual CLP-660/660N : Manual CLP-610ND : Built-in CLP-660ND : Built-in Warmup time Less than 20 sec Less than 20 sec FPOT (B&W)
  • Page 12 USB / Network CLP-660 : USB CLP-660N/660ND : USB / Network Smart Panel Network Set IP, Samsung Web Admin Service 4.0 Set IP, Samsung Web Admin Service 4.0 Management (SWAS 4.0)(Linux, SWAS: Iexplorer 5.0 or (SWAS 4.0)(Linux, SWAS: Iexplorer 5.0 or...

  • Page 13: Paper Handling

    Product spec and feature 2.1.2.4 Paper Handling Item CLP-610ND CLP-660N/660ND Standard Capa. 250-sheet Cassette Tray, 1 Manual 250-sheet Cassette Tray, MP 100 Max. Capa. 850 sheets @ 75g/ 850 sheets @ 75g/ Printing Max. Size 216 x 356mm (8.5" x 14") 216 x 356mm (8.5"...
  • Page 14 Product spec and feature 2.1.2.6 FRU Item CLP-610ND CLP-660N/660ND Fuser 100,000 Pages 100,000 Pages 70,000 Pages 70,000 Pages Pick-up Roller 70,000 Pages 70,000 Pages Friction pad 2.1.2.7 Reliability & Service Item CLP-610ND CLP-660N/660ND Printing Volume(AMPV) 630 page ( B&W : 252 page, Color : 378 pages) 630 page ( B&W : 252 page, Color : 378 pages)
  • Page 15 Product spec and feature 2.1.2.8 Environment Item CLP-610ND CLP-660N/660ND Acoustic Noise Printing Less than 50 dBA Less than 50 dBA Level(Sound Standby Less than 35 dBA Less than 35 dBA Power/Pressure) Sleep Background noise level Background noise level Input Voltages...

  • Page 16: Maintenance List (Cru & Fru)

    70,000 Friction Pad Color / Mono 70,000 70,000 70,000 * Toner Cartridge yield : Average CMY Cartridge Yield 5000 standard pages Average K Cartridge Yield 5500 standard pages Declared yield value in accordance with ISO/IEC 19798 Service Manual Samsung Electronics...

  • Page 17: Periodic Replacing Parts

    Product spec and feature 2.1.4 Periodic Replacing Parts Samsung shall specify parts requiring replacement and the frequency of replacement. The parts identified may be deemed customer replaceable parts. Periodic replacement parts shall be recommended as follows Toner Cartridge 2K(Color), 2.5K(Mono) Page5K(Color), Initial Toner, User replaceableUser 5.5K (Mono) pages...
  • Page 18 Product spec and feature Competitor Model Model Name Samsung CLP- 610ND HP CLJ 2605n OKI 3400N Image Speed (ppm) 20/20 12/10 20/16 FPOT 9/13 Resolution 1,200 x 600 dpi 2,400 x 600 dpi 1,200 x 600 dpi Processor Ram(Max.) 64 (320)

  • Page 19: System Overview

    This chapter describes the functions and operating principles of the main components. 2.2.1 System Structure 2.2.1.1 Main Parts of System OPC (Organic Deve Roller Pick_up Roller Photo Conductor) Rigi Roller Transfer Roller Exit Roller Charge Roller Heat Roller Duplex Roller MP Roller Pressure Roller Service Manual 2-10 Samsung Electronics...
  • Page 20 3) Transfer Roller Once the complete, full colour, image, has been built up on the ITB the Transfer Roller is used to transfer the image onto paper. This is called the T2 Transfer (T2 Transfer is none) Service Manual 2-11 Samsung Electronics...
  • Page 21 * Capacity : 500 Sheets (Standard paper 75mg/m 20lb) * Paper Size : A4, Letter * Paper Weight (average) : 60~90g/m (16~24lbs) * Paper Type : General Printing Paper * Additional Function : Paper Empty Sensor Paper Registration Sensor Paper Exit Sensor Service Manual 2-12 Samsung Electronics...
  • Page 22 8) Duplex Unit The Duplex function is used Duplex Unit of the PTB_SET. CLP-660N : Manual CLP-610ND,CLP-660ND : Built-in 9) Exit Unit The Exit Unit guides paper that is just about to leave the print engine. Printed-paper is discharged by the Exit Roller and Kicker into the Output Tray.
  • Page 23 * Heat Lamp : New Part - Dual Lamp Type(610:Single lamp type) * Fusing system : Belt fusing type - Heat roller : Pipe type(Lamp inside) - Pressure roller - Fuser roller - Belt * Thermistor - Temperature-Measuring Device * Thermostat - Critical Temperature-Detecting Device Service Manual 2-14 Samsung Electronics...
  • Page 24 This power supply uses the AC supply voltage to generate the DC voltages used by the system. The SMPS has 5 output channels (+3.3V, +5V, +24V, +24VF1, +24VF2). The AC Heater Control Unit that supplies power to the fuser is also located on the SMPS. Service Manual 2-15 Samsung Electronics...

  • Page 25: H/W Configuration (Engine & Controller)

    Product spec and feature 2.2.2 H/W Configuration (Engine & Controller) Service Manual 2-16 Samsung Electronics...

  • Page 26: Main Board

    PHY CHIP PHY CHIP CLP- 610 STEP MOTOR STEP MOTOR CHORUS 3 CHORUS 3 DDR 2 DDR 2 LPEC 3 LPEC 3 EEPROM USB CHIP USB CHIP 64KBIT NOR FLASH PHY CHIP PHY CHIP 16MBYTE Service Manual 2-17 Samsung Electronics...
  • Page 27 • CPU : CLP-610ND : Chorus3 (SoC) CLP-660N/660ND : Mips 7065C 533MHz + SPGPXm • Memory : - RAM : CLP-610ND : DDR2 Default 128MB + Option 128MB/256MB CLP -660N/660ND : DDR1 Default 128MB + Option 256MB/512MB - ROM : 16MB - EEPROM : 64kb •...
  • Page 28 • ROM : - Nor Flash used (16MB) - Interface With Chorus 3/SPGPXm ROM Controller • SDRAM : - Size : CLP-610ND(DDR2) : Default 128MB (Option 128MB/256MB) CLP-660N/660ND(DDR1) : Default 128MB (Option 256MB/512MB) • EEPROM : - Size : 64kb - Interface With Chorus 3/SPGPXm I2C Controller •...
  • Page 29 - 3.3V : I/O Operating (Digital & Analog) - 1.0V : Chorus 3 Core Voltage - 1.2V : SPGPXm Core Voltage • HVPS - High Voltage Source for EP Condition - Supply From SMPS +24V - Controlled By PWM Pulse & I/O Service Manual 2-20 Samsung Electronics...
  • Page 30 Product spec and feature Power Flow CLP-660N/660ND/610ND Service Manual 2-21 Samsung Electronics...
  • Page 31 24V SWITCH Supply DC : 4channel HVPS1(form mainboard) ATTR+ : 1channel HVPS2(form mainboard) ATTR- : 1channel Feed, CST empty sensor Transfer : 4channel MP solenoid, MP empty, CST detect Fuser Bias : 1channel Fuser bias Service Manual 2-22 Samsung Electronics...
  • Page 32 AC PWM 92(36%) (about 1740V) AC Vpp PWM 65(25%) [ AC JIG ] Transfer_Y,M,C,K 97(38%) 14uA 1.7V (132) ATTR 108(42%) 950V 100M 0.6V (46) ATTR[-] 350V Fuser Bias 128(50%) 300V 100M Eraser 100(39%) on/off (18mA 3mA) Y,M,C,K Service Manual 2-23 Samsung Electronics...
  • Page 33 • Zero crossing signal detect FUSER CONTROL (from Main board) • 2 lamp (800W+500W) Phase FUSER AC (to Fuser lamp) control SMPS AC ( to SMPS) CLP-610 • Zero crossing photo triac • 1 lamp (800W) Pulse control Service Manual 2-24 Samsung Electronics...
  • Page 34 Product spec and feature 2.2.2.5 SMPS AC FUSE VARISTOR 24V FUSE 5V FUSE AC from FDB SMPS : TYPE4 NC (not used) INPUT : V1-AC 110V, V2-220V 24V,5V to main board OUTPUT : 24V, 5V Service Manual 2-25 Samsung Electronics...
  • Page 35 Product spec and feature 2.2.2.6 CRUM Interface Service Manual 2-26 Samsung Electronics...

  • Page 36: Precautions When Replacing Parts

    3.1.1 Precautions when assembling and disassembling * Use only approved Samsung spare parts. Ensure that part number, product name, any voltage, current or temperature rating are correct. Failure to do so could result in damage to the machine, circuit overload, fire or electric shock.

  • Page 37: Releasing Plastic Latches

    CLP-C660B(Cyan) Sales : 5000 Pages CLP-M660B(Magenta) CLP-Y660B(Yellow) Approx. 50,000 black pages CLP-T660A or 50,000 color pages CLP-T660B(with duplex unit) Pick-up roller Approx. 70,000 Pages Engineer Replacement Approx. 100,000 black pages Fuser Unit or 100,000 color pages Service Manual Samsung Electronics...

  • Page 38: Printer Cleaning

    * Do not touch transfer roller when cleaning inside of machine. If transfer roller gets dirty, printing quality could be low. * Please refer to the User Manual for cleaning instructions. Service Manual Samsung Electronics...

  • Page 39: Special Service Parts

    (hot water sets the toner). Do not ing the fuser. touch the developer roller surface as cont- amination will reduce print quality. Take care not to damage the roller's surface when installing or removing a toner car- tridge. Service Manual Samsung Electronics...

  • Page 40: Cover Unit

    The description of disassembly and reassembly in this manual is listed according to the disassembly procedures. 3.4.1 Cover Unit 2. Open the front cover. 3. Remove the PTB Unit after pull the handle. 1. Remove the Cassette Unit. Service Manual Samsung Electronics...
  • Page 41 5. Open the top cover. 8. To remove the left cover, remove the one screw. 6. Remove the Fuser unit after push the lever. 9. Unlatch the 2 hooks from the bottom of SET with any tool. Service Manual Samsung Electronics...
  • Page 42 13. Remove the 4 screws, and remove the rear cover. 11. Unplug the fan harness. 14. Remove the dummy cover after release the lever 12. In the same way ( procedure 8~10), remove the right cover. Service Manual Samsung Electronics...
  • Page 43 16. Remove the top cover after remove the 2 screws and the one connector. 19. Remove the Bracket hinge with any tool after remove one screw. 17. Remove the left link. 20. Remove the right link. Service Manual Samsung Electronics...
  • Page 44 Disassembly and Reassembly 21. Remove the Damper hinge-R after remove the 2 23. Remove the Damper hinge ( 2 EA). screws. 24. Remove the front cover. 22. Remove the Bracket hinge with any tool after remove one screw. Service Manual Samsung Electronics...

  • Page 45: Hvps Board

    1. Unplug the harness from the top/bottom of the HVPS 3. Remove the 8 screws and unlatch 4 hook. Board. 4. Unplug the harness and release the HVPS board. 2. Unplug the flat cable (2 EA). Service Manual 3-10 Samsung Electronics...

  • Page 46: Main Board

    1. Unplug the connectors and all the harness. 2. Remove the 4 screws. 3.4.4 SMPS Board 1. Unplug the Harness, as shown below. 2. Remove the 4 screws, and release the SMPS Board from the SET. Service Manual 3-11 Samsung Electronics...

  • Page 47: Fuser Control Board

    2. Remove the 4 screws, and release the Fuser control board from the SET. 3.4.6 LSU Unit 1. To remove the Bracket main & Duct, remove the 2. Remove the 4 screws and remove the LSU Unit. 7 screws and release it. Service Manual 3-12 Samsung Electronics...

  • Page 48: Crum

    1. Remove the CRUM after unlatch the lever. 3.4.8 Fuser Drive Unit 1. Remove the 2 screws and release the MEA UNIT- 2. Remove the Fuser Duct after remove the 2 screws COVER_OPEN. and the harness. Service Manual 3-13 Samsung Electronics...
  • Page 49 Disassembly and Reassembly 3. Remove the one screw and release the BRACKET- 5. Remove the Fuser Drive Unit after remove the 4 LOCKER PTB R. screws and the harness. 4. Remove the LOCKER_PTB R. Service Manual 3-14 Samsung Electronics...

  • Page 50: Pick-Up Roller

    Disassembly and Reassembly 3.4.9 Pick-up Roller 1. Remove the Pick up roller. 3.4.10 Feed Drive 1. Remove the two screws and unplug the harness. Service Manual 3-15 Samsung Electronics...
  • Page 51 Disassembly and Reassembly 2. Remove the MEA-GEAR PICK UP. 4. Remove the 4 screws, and then release the MEA UNIT-FEED DRIVE. 3. Remove the one screw and release the SOLENOID PICK UP. Service Manual 3-16 Samsung Electronics...

  • Page 52: Alignment And Adjustments

    Left/right arrow: Navigates available values by moving to the next or previous options. OK: Confirms the selection on the display. Back: Sends you back to the upper menu level. Stop: Stops an operation at any time. Service Manual Samsung Electronics...

  • Page 53: Led Function

    Check the message on the display. The toner cartridge is low, empty, or needs to be installed a new one. See Understanding the toner cartridge messages on the display Service Manual Samsung Electronics...

  • Page 54: Jam Removal

    2. Carefully remove the paper by pulling in the cover. direction as shown below. If you cannot find the jammed paper, or if there is any resistance removing the paper, stop pulling, and go to step 3. Service Manual Samsung Electronics...
  • Page 55 5. Remove the jammed paper by gently pulling it straight out as shown below. 8. Close the front cover firmly. The machine will resume printing. Service Manual Samsung Electronics...
  • Page 56 If you cannot find the jammed paper, or if there 4. Close the front cover firmly. The machine will is any resistance removing the paper, stop resume printing. pulling and go to step 2. 2. Using the handle, completely open the front cover. Service Manual Samsung Electronics...

  • Page 57: In The Fuser Unit Area

    5. After removing the jammed paper, check for paper which may be jammed in other parts of the machine. 6. Close the top cover. Make sure that it is The fuser securely latched. is hot! Service Manual Samsung Electronics...

  • Page 58: In The Paper Exit Area

    2. 2. Open the top cover. 5. Close the inner cover and push the levers down. 6. After removing the jammed paper, check for paper which may be jammed in other parts of the machine. Service Manual Samsung Electronics...

  • Page 59: In The Optional Tray

    2. If you see the jammed paper, remove the paper the way out, lift up the front part of the tray from the machine by gently pulling it straight out slightly to release the tray from the machine. as shown below. Service Manual Samsung Electronics...
  • Page 60 5. Pull the jammed paper out in the direction the two jam covers. shown. To avoid tearing the paper, pull it out gently and slowly. 4. Open the front cover. 6. Close the front cover firmly. The machine will resume printing. Service Manual Samsung Electronics...

  • Page 61: System Setup

    7. Press the OK button to process your selection, save your input or selection. An asterisk (*) appears next to the selection on the display, indicating that it is now the default. 8. To exit the menu, press the Back button repeatedly, or the Stop button. Service Manual 4-10 Samsung Electronics...

  • Page 62: Menu Overview

    System Setup Emulation Language Emulation Type Power Save Setup Auto Continue Altitude Adj. Auto CR Job Timeout Maintenance Clear Setting Network Setup Color TCP/IP Calibration Ethernet Speed Custom Color Clear Setting Auto Color Reg. Network Info Service Manual 4-11 Samsung Electronics...
  • Page 63 To print on both sides of paper, choose the binding edge. ( Off, Long Edge, Short Edge ) • Duplex Margin This menu allows set the margins for double-sided printing. Layout Orientation Simplex Margin Duplex Duplex Margin Service Manual 4-12 Samsung Electronics...
  • Page 64 • Resolution This menu can select the default resolution. If the resolution is high, the clarity of the printouts is shaper, but the print time may take longer. ( Draft, Normal, Best ) Graphic Resolution Service Manual 4-13 Samsung Electronics...
  • Page 65 - Alarm Shortage : Determines how the printer behaves when consumable items run low • Clear Setting Allows you to restore the printer’s factory default settings Setup Language Power Save Auto Continue Altitude Adj. Auto CR Job Timeout Maintenance Clear Setting Service Manual 4-14 Samsung Electronics...
  • Page 66 Note : ACR can be automatically executed in the following situations : 1) Power On 2) Cover Open -> Close 3) Waking up from sleeping mode 4) After printing every 100 or 50 pages 5) ... Service Manual 4-15 Samsung Electronics...
  • Page 67 Set the communication speed for ethernet connection. • Clear Setting Clear the network setting. • Network Info. Prints Network Configuration Page. Network TCP/IP Ethernet Speed Clear Setting Network Info 9) Network Application - SWS SWS ( SynchThru Web Service ) Service Manual 4-16 Samsung Electronics...
  • Page 68 • The SWS is an upgraded version of EWS(Embedded Web Service). • By entering the IP address of your printer, you can use the SWS. • Printer/Network settings can be easily changed by using SWS. • Printer/Network status can be monitored by using SWS. Service Manual 4-17 Samsung Electronics...
  • Page 69 Adjustment and Troubleshooting 10) Network Application - SWAS SWAS ( SynchThru Web Admin Service) Service Manual 4-18 Samsung Electronics...
  • Page 70 • Network Printer Administration can be conveniently made by using SWAS. • Remote Diagnostics can be accomplished by using SWAS. • The status of Samsung Network Printers (including CLP-660, CLP-610, CLP-300N, ML-3561N, etc) can be monitored by using SWAS. Service Manual...
  • Page 71 Adjustment and Troubleshooting 11) Network Application - SWAS Features • The status of each printer can be monitored in detail by using SWAS. Service Manual 4-20 Samsung Electronics...
  • Page 72 ENS (Email Notification System)/ATOS (Automatic Toner Ordering System) • ENS sends the specified users the email reports on the printer status, alert, and history. • CLP-610ND/660N/660 supports ENS. • ENS can be configured by using SWS. • ATOS sends toner ordering emails automatically by using ENS.

  • Page 73: Printing A Machine Configuration Report

    2. Press the OK button. 3. Press the Left/right arrow button until Network Info. displays. 4. Press the OK button. 5. The display shows Print?, then press the OK button to print the configuration report. Service Manual 4-22 Samsung Electronics...

  • Page 74: Monitoring The Supplies Life

    Clean the machine cabinet with a soft lint-free cloth. You can dampen the cloth slightly with water, but be careful not to let any water drip onto or into the machine. Cleaning the inside Contact a service representative to clean the inside of the machine. Service Manual 4-23 Samsung Electronics...

  • Page 75: Maintaining The Cartridge

    If you print a lot of graphics, you may need to change the cartridge more often. Service Manual 4-24 Samsung Electronics...

  • Page 76: Redistributing Toner

    4. Slide the toner cartridge back into the machine. 2. Grasp the handles on the toner cartridge and pull to remove the cartridge from the machine. 5. Close the front cover. Make sure that the cover is securely latched. Service Manual 4-25 Samsung Electronics...

  • Page 77: Replacing The Toner Cartridge

    3. Grasp the handles on the toner cartridge and pull to remove the cartridge from the machine. 6. Place the toner cartridge on a flat surface, as shown, and remove the paper covering the toner cartridge by removing the tape. Service Manual 4-26 Samsung Electronics...
  • Page 78 8. Close the front cover. Make sure that the cover matches the color slot and then grasp the is securely latched, and then turn the machine handles on the toner cartridge. Insert the cartridge until it clicks into place. Service Manual 4-27 Samsung Electronics...

  • Page 79: Replacing The Paper Transfer Belt

    3. Press the green release handle to release the paper transfer belt. Holding the handle on the paper transfer belt, lift it out of the machine. Service Manual 4-28 Samsung Electronics...
  • Page 80 Adjustment and Troubleshooting 7. Lower the paper transfer belt until it is parallel 8. Close the front cover firmly. with the front cover and firmly seated. 9. Turn the machine on. Service Manual 4-29 Samsung Electronics...

  • Page 81: Managing Your Machine From The Website

    Managing your machine from the website If you have connected your machine to a network and set up TCP/IP network parameters correctly, you can manage the machine via Samsung's SyncThru Web Service, an embedded web server. Use SyncThru Web Service to: •...

  • Page 82: Sample Pattern

    Printing a Demo Page Press "OK(Okay)" button for 2 or 3 seconds when "Ready" message displays on LCD panel. Then demo page will be printed out. Service Manual 4-31 Samsung Electronics...

  • Page 83: Printing A Configuration Page

    You can print a configuration page from the printer’s control panel. Use the configuration page to view the current settings, to help troubleshoot problems. To print a configuration page: In ready mode, press and hold the Stop button on the control panel for 5 seconds. A configuration page prints out. Service Manual 4-32 Samsung Electronics...
  • Page 84 It describe the network line status by checking the physical line. O.K - Network connection has no problem and connected Disconnected - Network connection is not connected. Defective Network line is connected but line has some defect (Short or Open) Service Manual 4-33 Samsung Electronics...
  • Page 85 Mono - 15~24%(1/3), 25~34%(1/4), 35~44%(1/5), 45~54%(1/6), 65~74%(1/8), 75%~(1/9) Auto Continue If auto continue set to ON, Printer automatically paper out after 15 sec in paper mismatch state Altitude Altitude Adj : It can adjust voltage conditions Service Manual 4-34 Samsung Electronics...

  • Page 86: Periodic Defective Image

    Periodic Band (by little difference of density) Gap-ring 39.0mm Periodic Band Fusing Belt 125.6mm White/Black Spot OPC (Organic Deve Roller Pick_up Roller Photo Conductor) Transfer Roller Rigi Roller Exit Roller Charge Roller Heat Roller Pressure Roller Duplex Roller MP Roller Service Manual 4-35 Samsung Electronics...

  • Page 87: Paper Jam

    After Feed sensor out , in case that Exit sensor does not detect the paper in regular time. • Jam In Exit Area After Exit sensor detect , in case of not Out in regular time. Service Manual 4-36 Samsung Electronics...

  • Page 88: Cover Error

    Over heat : In case that the temperuture of FUSER is more than special temperuture, In case that Thermistor becomes short In case that the fuser temperature is continuous more than 4sec and over 230 Service Manual 4-37 Samsung Electronics...
  • Page 89 Left arrow Right arrow Stop CLP-6XX Description Menu Move to the top menu Left Arrow Move test item Start testing or select Sub-item Right arrow Move test item Back Move upper menu Stop Stop testing Service Manual 4-38 Samsung Electronics...
  • Page 90 When a top cover opened, Open message display LCD. If the top cover closed, Closed message display LCD. Tray2 Door When a tray2 door opened, Open message display LCD. If the tray2 door closed, Closed message display LCD. Service Manual 4-39 Samsung Electronics...
  • Page 91 5 seconds and OFF message will be displayed. LSU Fan If OK key is pushed after ON displayed, fan will be run. LSU fan will auto - stop after 5 seconds and OFF message will be displayed. Service Manual 4-40 Samsung Electronics...
  • Page 92 When OK key is pushed after ON message displayed, OFF message will be displayed after 5 seconds LSU Motor If OK key is pushed after ON displayed, motor will be run. LSU motor will auto - stop after 5 seconds and OFF message will be displayed. Service Manual 4-41 Samsung Electronics...
  • Page 93 Description Reset ColorReg YES is Selected, reset color registration starts. (Take care of this menu because all color regi. data is initialized.) 9. Print Test Item Description Pattern Print YES is Selected, pattern printing starts. Service Manual 4-42 Samsung Electronics...

  • Page 94: Error Message

    Unplug the power cord and plug it back in. Cycle Power under the normal range. If the problem persists, contact the service representatives. Install The transfer belt is not installed. Install a Samsung-genuine transfer belt. Transfer Belt Service Manual 4-43 Samsung Electronics...
  • Page 95 Invalid Toner indecates is not suitable for your machine. Samsung-genuine cartridge. The transfer belt is not for your machine. Install the Samsung-Invalid genuine transfer Invalid Transfer belt for your machine. Belt The network IP address you have set is being Check the IP address and reset it if necessary.
  • Page 96 Replace Toner This message appears between Toner Low Replace the corresponding toner cartridge with and Toner Empty. a Samsung-genuine cartridge. The arrow indicates which color toner cartridge has to be replaced. The life of the transfer belt is expired. Replace the fuser unit with a new one.
  • Page 97 Toner Empty The color toner cartridge which the arrow Replace the corresponding toner cartridge with indicates has run out. a Samsung-genuine cartridge. The color toner cartridge which the arrow Take out the corresponding toner cartridge and Toner Low indicates is almost empty.

  • Page 98: Troubleshooting

    OP Panel - Main PBA error - LCD Panel error Refer to Indicate Ready or Error Massage Error Massage Power save <Chapter 4.1.5> Test Print printing Refer to "Solution Quality is of Image Problem" Nomal? Service Manual 4-47 Samsung Electronics...

  • Page 99: The Cause And Solution Of Image Quality

    3. Damaged paper transfer Belt(PTB) or Contaminated Replace the PTB unit and test again. on PTB. 4. Contaminated on Replace the PTB unit or Cleaning the paper charge roller. paper charge roller. Service Manual 4-48 Samsung Electronics...
  • Page 100 Adjustment and Troubleshooting 2) Vertical White Line Description: White vertical voids in the image. Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Replace the toner Cartridge. Replace the toner Cartridge. 3. Scratch of OPC Drum. Service Manual 4-49 Samsung Electronics...
  • Page 101 4) Transfer Roller: 45 mm 5) Paper Charge Roller : 26.7 mm 6) OPC Drum : 75.4 mm 7) Fusing Belt : 125.6 mm 3. Contamination of the Gap-Ring Replace the toner Cartridge. -regular intervals 39.0 mm Service Manual 4-50 Samsung Electronics...
  • Page 102 Adjustment and Troubleshooting 4) Black/White Spot Description: 1. Dark or blurry spots occur periodically in the printing 2. White spots occur periodically in the printing Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-51 Samsung Electronics...
  • Page 103 Adjustment and Troubleshooting 5) Light Image Description: The printed image is light, with no ghost. Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-52 Samsung Electronics...
  • Page 104 Adjustment and Troubleshooting 6) Dark image or Black Description: The printed image is dark. Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-53 Samsung Electronics...
  • Page 105 Adjustment and Troubleshooting 7) Uneven Density Description: Print Density is uneven between left and right. Service Manual 4-54 Samsung Electronics...
  • Page 106 Adjustment and Troubleshooting 8) Strain in the Face of the Page Description:The background on the face of the printed page strained Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-55 Samsung Electronics...
  • Page 107 Description: The back of the page is strained at 43.9 or 75.5 mm intervals. Digital Digital Pri Digital Printer Digital Printer Digital Printer 1. PTB Cleaning Defect. Replace PTB Unit. Replace PTB Unit. 2. PTB belt damage. Service Manual 4-56 Samsung Electronics...
  • Page 108 Adjustment and Troubleshooting 10) Uneven Density Description: Print Density is uneven between left and right. Service Manual 4-57 Samsung Electronics...
  • Page 109 Adjustment and Troubleshooting 11) Blank Page Print out(1) Description: Blank page is printed. Service Manual 4-58 Samsung Electronics...
  • Page 110 12) Ghost Description: Ghost occur at 75.4mm intervals of the OPC drum or 33mm intervals of the developing roller in the whole Printing Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-59 Samsung Electronics...

  • Page 111: The Cause And Solution Of The Paper Feeding

    Adjustment and Troubleshooting 4.2.3 The cause and solution of the paper feeding 1) Wrong Print Position Description: Printing begins at wrong position on the paper. Service Manual 4-60 Samsung Electronics...
  • Page 112 Adjustment and Troubleshooting 2) JAM 0 Description: 1. Paper does not exit from the cassette. 2. Jam-0 occurs when the paper feeds into the printer Service Manual 4-61 Samsung Electronics...
  • Page 113 Adjustment and Troubleshooting 3) JAM 1 Description: 1. Paper is jammed in front of or inside the fuser. 2. Paper is stuck in the exit roller and in the fuser just after passing through the Actuator-Feed Service Manual 4-62 Samsung Electronics...
  • Page 114 4) JAM 2 Description: 1. Recording paper is jammed in front of or inside the fuser. 2. Recording paper is stuck in the discharge roller and in the fuser just after passing through the Actuator-Feed. Service Manual 4-63 Samsung Electronics...
  • Page 115 Adjustment and Troubleshooting 5) Paper rolled in the fuser Description: Paper rolled around fuser rollers or ‘Concertina’ jam Service Manual 4-64 Samsung Electronics...

  • Page 116: Ope Problems

    Adjustment and Troubleshooting 4.2.4 OPE Problems 1) Nothing Displayed on LCD Description: LCD does not display anything Service Manual 4-65 Samsung Electronics...
  • Page 117 Adjustment and Troubleshooting Service Manual 4-66 Samsung Electronics...

  • Page 118: Other Problems

    10 seconds and more In Printing state - When the Fuser is under 40 of target temperature for 10 seconds and more Over Heat Error When the set is over 210 for 4 seconds and more Service Manual 4-67 Samsung Electronics...

  • Page 119: Fuser Error

    Adjustment and Troubleshooting Fuser error Description : A message below is displayed in a LCD panel. Service Manual 4-68 Samsung Electronics...
  • Page 120 Adjustment and Troubleshooting 2) No Power(1) Description : When system power is turned on, all LED on the operator panel do not come on. Service Manual 4-69 Samsung Electronics...
  • Page 121 Adjustment and Troubleshooting 2) No Power(2) Description : When system power is turned on, you can hear short beep sound continuously. Service Manual 4-70 Samsung Electronics...
  • Page 122 Adjustment and Troubleshooting 3) LSU Error Description : A message below is displayed in a LCD panel. Service Manual 4-71 Samsung Electronics...
  • Page 123 No sunlight & white light exposure No touch (no finger print) No OPC cleaning with Acetone or Ethanol PTB Unit No touch No finger print No sharp object No sunlight Use only IPA or Ethanol when cleaning Service Manual 4-72 Samsung Electronics...

  • Page 124: Exploded Views And Parts List

    - Emulation : CLP-610ND(SPL-C), CLP-660, 660N(PostScript 3, PCL6) - Speed : CLP-610ND(20/20 ppm), CLP-660, 660N(24/24 ppm) - Resolution : CLP-610ND(1,200 x 600 dpi), CLP-660N, 660ND(1,200 x 600 dpi) - CPU : CLP-610ND(300 MHz), CLP-660N, 660ND(533 MHz) - Interface : N/W - Memory : CLP-610ND / 64 MB, CLP-660N, 660ND/128 MB (Max.

  • Page 125: Exploded Views & Parts List

    Exploded Views & Parts List 5.1 Main Service Manual Samsung Electronics...
  • Page 126 Exploded Views & Parts List Main Parts List SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT'y Service Remark 5.1-0 CLP-610ND A4 CLBP,GDI,N/W,DUPLEX 5.1-0 CLP-610N A4 CLBP,GDI,N/W 5.1-0 CLP-660ND A4 CLBP,PCL,N/W,DUPLEX 5.1-0 CLP-660N A4 CLBP,PCL,N/W 5.1-1...
  • Page 127 Exploded Views & Parts List Main Parts List SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT'y Service Remark 5.1-26 MEA UNIT-COVER CLP-610ND 5.1-27 JC96-04391A ELA UNIT-DEV BK_SET 5.1-28 JC96-04392A ELA UNIT-DEV C_SET 5.1-29 JC96-04393A ELA UNIT-DEV M_SET 5.1-30...

  • Page 128: Cover Unit

    Exploded Views & Parts List 5.2 Cover Unit Service Manual Samsung Electronics...
  • Page 129 JC97-02941B MEA UNIT-COVER CLP-660N 5.2-0 JC97-02941C MEA UNIT-COVER CLP-660ND 5.2-0 MEA UNIT-COVER CLP-610 5.2-0 MEA UNIT-COVER CLP-610N 5.2-0 MEA UNIT-COVER CLP-610ND 5.2-1 JC96-04415A ELA-COVER TOP CLP-660 5.2-1 JC96-04415B ELA-COVER TOP CLP-660N 5.2-1 JC96-04415C ELA-COVER TOP CLP-660ND 5.2-1 ELA-COVER TOP CLP-610 5.2-1...

  • Page 130: Top Cover

    Exploded Views & Parts List 5.3 Top Cover Service Manual Samsung Electronics...
  • Page 131 Description QT'y Service Remark 5.3-0 JC96-04415A ELA-COVER TOP CLP-660 5.3-0 JC96-04415B ELA-COVER TOP CLP-660N 5.3-0 JC96-04415C ELA-COVER TOP CLP-660ND 5.3-1 JC63-01278A COVER-TOP 5.3-2 JC72-01346D PMO-STACKER RX 5.3-3 JC97-02847A MEA COVER-EXIT 5.3-4 JC96-04416A ELA-OPE 5.3-5 6003-000196 SCREW-TAPTITE Service Manual Samsung Electronics...

  • Page 132: Ope Unit

    Exploded Views & Parts List 5.4 OPE Unit Service Manual Samsung Electronics...
  • Page 133 5.4-0 JC96-04416C ELA-OPE CLP-660ND 5.4-1 JC63-01300A COVER-OPE CLP-660 5.4-1 JC63-01300B COVER-OPE CLP-660N 5.4-1 JC63-01300C COVER-OPE CLP-660ND 5.4-2 JC64-00301A KEY-STOP 5.4-3 JC64-00300A KEY-MENU 5.4-4 JC67-00218A LENS-STATUS 5.4-5 JC61-01847A HOLDER-LCD 5.4-6 JC92-01872A PBA SUB-OPE 5.4-7 6003-000196 SCREW-TAPTITE Service Manual 5-10 Samsung Electronics...

  • Page 134: Front Cover

    Exploded Views & Parts List 5.5 Front Cover Service Manual 5-11 Samsung Electronics...
  • Page 135 5.5-12 JC61-01842A HOLDER-LOCKER FRONT L 5.5-13 6107-001138 SPRING-ES 5.5-14 JC61-01841A HOLDER-KNOB HANDLE 5.5-15 JC63-01290A COVER-FRONT PATH 5.5-16 JC66-01353A LEVER-COUPLING R 5.5-17 JC66-01352A LEVER-COUPLING L 5.5-18 JC66-01421A LEVER-PTB TOP 5.5-19 6107-001345 SPRING-CS 5.5-20 JC97-02894A MEA-TRAY MP Service Manual 5-12 Samsung Electronics...

  • Page 136: Exit Cover

    Exploded Views & Parts List 5.6 Exit Cover Service Manual 5-13 Samsung Electronics...
  • Page 137 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT'y Service Remark 5.6-0 JC97-02847A MEA-COVER EXIT 5.6-1 JC63-01289A COVER-EXIT 5.6-2 JC63-01299A COVER-FUSER EXIT 5.6-3 6003-000196 SCREW-TAPTITE 5.6-4 JC75-00095A MEC-BRUSH ANTISTATIC 5.6-5 JC63-01277A GROUND-EXIT 5.6-6 6003-000282 SCREW-TAPTITE Service Manual 5-14 Samsung Electronics...

  • Page 138: Mp Tray

    Exploded Views & Parts List 5.7 MP Tray Service Manual 5-15 Samsung Electronics...
  • Page 139 Drawer# SEC_Code Description QT'y Service Remark 5.7-0 JC97-02894A MEA-TRAY MP 5.7-1 JC63-01287A COVER-MP_TRAY 5.7-2 JC63-01293A TRAY-ASF_INPUT 5.7-3 JC66-01349A LINK-TRAY_MP_L 5.7-4 JC66-01350A LINK-TRAY_MP_R 5.7-5 JG66-40003A GEAR-PINION 5.7-6 JC61-01043A GUIDE-_M_SIDE MP L 5.7-7 JC61-01042A GUIDE-_M_SIDE MP R Service Manual 5-16 Samsung Electronics...

  • Page 140: Frame

    Exploded Views & Parts List 5.8 Frame Service Manual 5-17 Samsung Electronics...

  • Page 141: Frame Parts List

    5.8-21 JC96-04485A ELA UNIT-FRAME_RIGHT 5.8-22 JC97-02854A MEA UNIT-FEED DRIVE 5.8-23 JC97-02895A MEA-GEAR PICK UP 5.8-24 JC67-00215A CAP-MAIN PICK-UP GEAR 5.8-25 JC33-00022A SOLENOID-PICK_UP 5.8-26 JC61-01922A PLATE-GND-SOLENOID 5.8-27 6003-000196 SCREW-TAPTITE;PWH,+,B,M3,L10,NI PLT, 5.8-28 6003-000269 SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC(WHT), 5.8-29 JC72-01379A SPONGE-SEALING_LSU Service Manual 5-18 Samsung Electronics...

  • Page 142: Feed Drive

    Exploded Views & Parts List 5.9 Feed Drive Service Manual 5-19 Samsung Electronics...
  • Page 143 SEC_Code Description QT'y Service Remark 5.9-0 JC97-02854A MEA UNIT-FEED DRIVE 5.9-1 JC66-01385A GEAR-RDCN FEED(79/39) 5.9-2 JC66-01383A GEAR-RDCN FEED(43/23) 5.9-3 JC66-01382A GEAR-RDCN FEED(35/22) 5.9-4 JC66-01363A GEAR-DRV MAIN PICK-UP 5.9-5 JC66-01384A GEAR-RDCN FEED(55/54) 5.9-6 JC61-01835A BRACKET-FEED DRIVE Service Manual 5-20 Samsung Electronics...

  • Page 144: Fuser Drive

    Exploded Views & Parts List 5.10 Fuser Drive Service Manual 5-21 Samsung Electronics...
  • Page 145 JC66-01362A GEAR-DRV FU 5.10-15 JC66-01070A LATCH-M-HUB CLUTCH 5.10-16 JC66-01155A GEAR-FUSER RDCN OUT V 5.10-17 JC61-01860A BRACKET-FUSER DRIVE R 5.10-18 JC31-00076A MOTOR STEP 5.10-19 JC61-01851A GUIDE-FUSER R 5.10-20 6003-000301 SCREW-TAPTITE 5.10-21 6003-000269 SCREW-TAPTITE 5.10-22 JC72-00825A PMO-IMPELLER_DRV Service Manual 5-22 Samsung Electronics...

  • Page 146: Fuser

    Exploded Views & Parts List 5.11 Fuser Service Manual 5-23 Samsung Electronics...

  • Page 147: Fuser Parts List

    GEAR-FUSER 5.11-27 6601-001478 BEARING-BALL 5.11-28 JC66-01410A ROLLER-FUSER 5.11-29 6044-000231 RING-E 5.11-30 6044-000125 RING-E 5.11-31 JC61-01918A BRACKET-HR 5.11-32 6601-001479 BEARING-BALL 5.11-33 1404-001355 THERMISTOR-NTC ASSY 5.11-34 JC61-01920A HOLDER-LAMP 5.11-35 4712-001039 THERMOSTAT 5.11-36 JC63-01311A COVER-FUSER_UPPER 5.11-37 JC61-01919A BRACKET-FU_DRIVE Service Manual 5-24 Samsung Electronics...
  • Page 148 JC66-01415A ROLLER-EXIT 5.11-53 JC66-00782A GEAR-_M_EXIT 5.11-54 JC61-01935A GUIDE-DUPLEX 5.11-55 JC64-00311A HANDLE-FUSER_R 5.11-56 JC64-00309A LOCKER-FUSER_R 5.11-57 JC64-00312A HANDLE-FUSER_L 5.11-58 JC64-00310A LOCKER-FUSER_L 5.11-59 JC61-00550A SPRING ETC-DEVE REAR 5.11-60 JC61-01930A HOLDER-HARNESS 5.11-61 6003-000282 SCREW-TAPTITE 5.11-62 JC63-00903 FELT-CLEAN TONER Service Manual 5-25 Samsung Electronics...

  • Page 149: Ptb Unit

    Exploded Views & Parts List 5.12 PTB Unit Service Manual 5-26 Samsung Electronics...
  • Page 150 SEAL-BRKT PTB,R 5.12-35 JC63-01267A COVER-DUPLEX GEAR 5.12-36 JC63-01268A COVER-UPPER PTB 5.12-37 JC63-01269A COVER-HANDLE INNER 5.12-38 JC63-01270A COVER-WASTE TONER,L 5.12-39 JC63-01271A COVER-WASTE TONER,U 5.12-40 JC64-00296A HANDLE-LOCKER PTB 5.12-41 JC64-00297A LOCKER-PTB,L 5.12-42 JC64-00298A LOCKER-PTB,R 5.12-43 JC66-00918A ROLLER-PAPER CHARGE Service Manual 5-27 Samsung Electronics...
  • Page 151 GUIDE-ALIGN-DUP 5.12-68 JC63-01297A GROUND-ALIGN_DUP 5.12-69 JC66-00444A SHAFT-IDLE ROLL, DUP 5.12-70 JC66-00896A ROLLER-M-IDLE_ DUP 5.12-71 JC66-00900A PULLEY-M-18-DUMMY_DUP 5.12-72 JC66-00901A ROLLER-FEED_DUP 5.12-73 JC66-01400A GEAR 5.12-74 JC67-00205A BRUSH-DUPLEX 5.12-75 JC70-00457A ICT-STUD PAPER GUIDE, DP 5.12-76 JK72-00058A PCT-SILP WASHER Service Manual 5-28 Samsung Electronics...

  • Page 152: Cassette

    Exploded Views & Parts List 5.13 Cassette Service Manual 5-29 Samsung Electronics...
  • Page 153 5.13-26 JC61-01940A PLATE-GND_KNOCKUP 5.13-27 JC63-01291A SHEET-MPF 5.13-28 JC61-01923A PLATE-GND-BRKT-GEAR 5.13-29 JC61-01128A HOLDER-_M_GEAR REGI 5.13-30 6107-001249 SPRING-CS 5.13-31 JC66-00774A GEAR-M-REGI 5.13-32 JC61-01127A HOLDER-_M_CLUTCH GEAR 5.13-33 JC63-01285A COVER-GEAR_BOX 5.13-34 JC33-00022A SOLENOID-PICK_UP 5.13-35 JC66-01355A LEVER-LINK_INDICATOR 5.13-36 JG66-40003A GEAR-PINION Service Manual 5-30 Samsung Electronics...
  • Page 154 SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT'y Service Remark 5.13-37 JC66-00764A ROLLER-IDLE FEED 5.13-38 JC61-01274A SPRING ETC-ROLLER 5.13-39 JC72-41191B PMO-BEARING SHAFT 5.13-40 JC61-00699A BUSH-D6/L4 5.13-41 6003-000196 SCREW-TAPTITE 5.13-42 6044-000125 RING-E 5.13-43 JC61-01856A FRAME-CASSETTE Service Manual 5-31 Samsung Electronics...

  • Page 155: Scf Unit

    Exploded Views & Parts List 5.14 SCF Unit Service Manual 5-32 Samsung Electronics...
  • Page 156 JC71-00042A BAR-P_CROSS BOTTOM 5.14-30 JC63-00686A COVER-M-DUMMY_SCF 5.14-31 JC70-11028A IPR-GROUND TOP 5.14-32 JC72-00992A PMO-ACTUATOR EMPTY,SCF 5.14-33 0604-001095 PHOTO-INTERRUPTER 5.14-34 JC63-01305A COVER-FRONT_SCF 5.14-35 JC63-01303A COVER-LEFT_SCF 5.14-36 JC33-00012A SOLENOID-MAIN 5.14-37 JC63-01304A COVER-RIGHT_SCF 5.14-38 JC61-01902A FRAME-SCF 5.14-39 6003-000196 SCREW-TAPTITE Service Manual 5-33 Samsung Electronics...

  • Page 157: Scf Cassette

    Exploded Views & Parts List 5.15 SCF Cassette Service Manual 5-34 Samsung Electronics...
  • Page 158 5.15-19 JC66-40003A GEAR-PINION 5.15-20 JC67-01222A GUIDE-P-SIDE_L 5.15-21 JC67-00037A CAP-M-GUIDE SIDE_L 5.15-22 JC61-01244A GUIDE-P-SIDE_R 5.15-23 JC61-01225B GUIDE-M_SIDE LOCK 5.15-24 JC66-01409A LEVER-INDICATOR_SCF 5.15-25 JC68-01552A LABEL¢Á-CASSETTE 5.15-26 JC64-00268A SHUTTER-PATH 5.15-27 JC61-01724A GUIDE-PAPER 5.15-28 JC63-01306A COVER_HANDLE 5.15-29 6002-000440 SCREW-TAPPING Service Manual 5-35 Samsung Electronics...

  • Page 159: System Diagram

    System Diagram 6. System Diagram 6.1 Block Diagram 6.1.1 24ppm Main Controller Block Diagram(CLP-660) Service Manual Samsung Electronics...

  • Page 160: 20Ppm Main Controller Block Diagram(Clp-610)

    System Diagram 6.1.2 20ppm Main Controller Block Diagram(CLP-610) Service Manual Samsung Electronics...

  • Page 161: Clp-610N-610Nd Engine Controller Block Diagram

    System Diagram 6.1.3 CLP-610N-610ND Engine Controller Block Diagram Service Manual Samsung Electronics...

  • Page 162: Clp-660N-660Nd Engine Controller Block Diagram

    System Diagram 6.1.4 CLP-660N-660ND Engine Controller Block Diagram Service Manual Samsung Electronics...

  • Page 163: Connection Diagram

    System Diagram 6.2 Connection Diagram 6.2.1 Connection Diagram(1) 6pin 24pin 30pin Service Manual Samsung Electronics...

  • Page 164: Connection Diagram

    System Diagram Connection Diagram(2) Service Manual Samsung Electronics...
  • Page 165 ThermoStat FUSER Unit CRUM FUSER Driver AC_H Second Cassette Feeder AC_N (2 LAMP) Dali Hardware Team R&D Group 3 LSU BLDC motor Digital Printing Division Fuser Samsung Electronics Bias (from HVPS) 2006.DEC.14 AC IN sensor1 sensor2 Service Manual Samsung Electronics...

  • Page 166: Reference Information

    • Brush • Tweezers Standard : For general home use, small type. • Cotton Swab Standard : For general home use, for medical service. • Software (Driver) installation CD ROM Install Driver CD Network S/W CD Service Manual Samsung Electronics...

  • Page 167: Acronyms And Abbreviations

    Enhanced Capability Port Inter Process CommunicationEPP Enhanced parallel Port Engine Control Unit Images Per Minute EEPROM Electronically Erasable Programmable Read Only Memory Image Transfer Belt Electro Magnetic Interference local area network Electro photographic Laser Beam Printer Service Manual Samsung Electronics...
  • Page 168 Read Only Memory Laser Scanning Unit SCF/SCT Second Cassette Feeder/Second Cassette Tray Megabyte SMPS Switching Mode Power Supply Megahertz SPGP Samsung Printer Graphic MPBF Mean Prints Between Failure Processor MPF/MPT Multi Purpose Feeder/Multi Samsung Printer Language Purpose Tray SPL-C Samsung Printer Language-Color...

  • Page 169: Select A Location For The Printer

    • Provide the proper environment : - A firm, level surface - Away from the direct airflow of air conditioners, heaters, or ventilators - Free of extreme fluctuations of temperature, sunlight, or humidity - Clean, dry, and free of dust Service Manual Samsung Electronics...

  • Page 170: A4 Iso 19752 Standard Pattern

    Reference Information 7.4 A4 ISO 19752 Standard Pattern This test page is reproduced at 70% of the normal A4 size Service Manual Samsung Electronics...

  • Page 171: Model List

    Reference Information 7.5 Model List Model Top Code Description CLP-610N 20PPM ENGINE,Color Laser Printer,Networt CLP-610ND 20PPM ENGINE,Color Laser Printer,Networt,Duplex CLP-660N 24PPM ENGINE,Color Laser Printer,Networt CLP-660ND 24PPM ENGINE,Color Laser Printer,Networt,Duplex CLP-T660A,B PTB UNIT,50K CLP-S660A SCF,Second Cassette CLP-C660A,B UNIT DEVE-C, 4K(sales) CLP-M660A,B...
  • Page 172 Reference Information View a point PCB, PBA Code & Chip position MODEL CLP-660N,ND CODE JC92-01870A Main PBA View a point PCB, PBA Code & Chip position MODEL CLP-610N,ND CODE JC92-01949A Main PBA Service Manual Samsung Electronics...
  • Page 173 PCB,PBA Code & Chip position ,connector pin Qt'y FDB-MULTI_TRIAC JC44-00143A V2,CLP-660 MODEL CLP-660N,ND CODE JC44-00142A FDB-MULTI_TRIAC V1,CLP-660 View a point PCB,PBA Code & Chip position ,connector pin Qt'y FDB-MULTI_TRIAC JC44-00153A V2,CLP-610 MODEL CLP-610N,ND CODE JC44-00152A FDB-MULTI_TRIAC V1,CLP-610 Service Manual Samsung Electronics...
  • Page 174 Reference Information View a point housing pin (3pin) MODEL CLP-660N,ND CODE JC39-00667A Fuser_Drawer_frame_3p View a point housing pin (2pin) MODEL CLP-610N,ND CODE JC39-00668A Fuser_Drawer_frame_2p Service Manual Samsung Electronics...
  • Page 175 Reference Information View a point PCB,PBA Code & Chip position PBA SUB-RAM MODEL CLP-660N,ND CODE JC92-01889A DIMM,128MB View a point PCB,PBA Code & Chip position MODEL CLP-610N,ND CODE JC92-01923A PBA-RAM DIMM, DDR2 Service Manual 7-10 Samsung Electronics...
  • Page 176 Reference Information View a point LEVER-FUSER-FRAME MODEL CLP-660N,ND CODE JC66-01300A LEVER-FUSER-FRAME View a point LEVER-FUSER-FRAME (None) MODEL CLP-610N,ND CODE JC66-01300A LEVER-FUSER-FRAME Service Manual 7-11 Samsung Electronics...
  • Page 177 North America : service.samsungportal.com Latin America : latin.samsungportal.com CIS : cis.samsungportal.com Europe : europe.samsungportal.com China : china.samsungportal.com Samsung Electronics Co.,Ltd. August. 2007 Asia : asia.samsungportal.com Printed in Korea. Mideast & Africa : mea.samsungportal.com CODE : 0610-C00XAZ VERSION NO. : 1.00...

This manual is also suitable for:

Clp-660nClp-660nd

Table of Contents
