HEZ2460S
HEZ3060S
HEZ2460S/HEZ3060S
115 35 77-10 (004)
OWNER'S/OPERATOR'S
MANUAL
STICK EDGERS
WARNING
The engine exhaust from this
product contains chemicals
known to the State of California to
cause cancer, birth defects or
other reproductive harm.
WARNING
Before using our products,
please read this manual carefully
to understand the proper use of
your unit.
This spark ignition system complies with
the Canadian standard ICES-002.
U
S
US-1
Advertisement
Table of Contents
Related Manuals for RedMax HEZ2460S
Summary of Contents for RedMax HEZ2460S
- Page 1 HEZ2460S HEZ3060S HEZ2460S/HEZ3060S 115 35 77-10 (004) OWNER'S/OPERATOR'S MANUAL STICK EDGERS WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. WARNING Before using our products,...
-
Page 2: Table Of Contents
HEZ2460S/HEZ3060S SAFETY FIRST Instructions contained in warnings within this manual marked with a concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail. -
Page 3: Parts Location
Displacement ·················································································································· 1.5cu-in (23.6 cm Max. output ························································································ 1.15Hp (0.858kW) at 8000 min Idle speed····················································································································· 3000±200 min Fuel ··················································································································· Mixture(Gasoline 50 : Oil 1) ·················································································································(when using RedMax genuine oil) Carburetor ··············································································································· Walbro Diaphragm type Spark plug ································································································································NGK CMR7H Fuel tank capacity····························································································································21.3 fl.oz (0.63 ) Transmission ·······················································... -
Page 4: Warning Labels On The Machine
( 4 ) ( 5 ) ■ EMISSION CONTROL An emission control label is located on the engine. [ HEZ2460S ] THIS ENGINE MEETS U.S. EPA AND CALI- FORNIA EXH / EVP REGS FOR 2010* ENGINE FAMILY : AHQZS.0244BV* EMISSION CONTROL SYSTEM : EXH;EM/EVP;SP*... -
Page 5: For Safe Operation
3. Wear the following protective equipments when operating the product. a: Approved helmet to reduce the risk of falling objects. HEZ2460S/HEZ3060S b: Approved ear protection to reduce the risk of hearing loss. c: Approved (ANSI Z87.1.) eye protection and foot protection to reduce the risk of injury associated with thrown objects. - Page 6 RedMax servicing dealer for repair. ■ Using the product IMPORTANT Cut only materials recommended by the manufacturer.
- Page 7 Comply with times listed in local ordinances. 2. To reduce sound levels, limit the number of pieces of equipment used at any one time. HEZ2460S/HEZ3060S 3. Operate the product at the lowest possible throttle speed to do the job. 4. Check your equipment before operation, especially the muffler, air intakes and air filters.
- Page 8 5. For safe operation lubricant, always be sure to use only RedMax products or products which have been certified by RedMax for use with the RedMax product. 5. In the event that any part must be replaced or any maintenance or repair work not...
-
Page 9: Set Up
(A). Fasten the clamp bolt (B) firmly. (SE1) (A) Screw (B) Clamp bolt (B) Tightning Torque: 70~130 in-lb (8~15 N.m) 2. Install the handle to the shaft tube and clamp at a position best for your job. (SE2) HEZ2460S/HEZ3060S US-9... -
Page 10: Fuel
• Poor quality gasolines or oils may damage sealing rings, fuel US-10 lines or fuel tank of the engine. • Failures caused by operating engines on gasoline with octane rating lower than 89 are not covered by the RedMax Two- Stroke engine warranty. WARNING • Alternative Fuels (Not Gasoline) - Page 11 Do not mix more gasoline/oil than you intend to use in 30 days, and 60 days when fuel stabilizer is added. RedMax Air-Cooled "Max Life" Synthetic blend Premium two-stroke engine oil "Contains fuel stabilizer" and will automatically extend your gasoline/oil mixture life up to 60 days.
-
Page 12: Operation
HEZ2460S/HEZ3060S 8. Operation The RedMax stick edgers are designed for edging lawn in gardens, parks, roadsides and so on. Before starting the engine, take the operating position and adjust the handle position and the wheel height as necessary. ■ ADJUSTING WHEEL HEIGHT 1. - Page 13 • Before edging, make sure the area is soft enough so the blade does not bog down. • Do not move the edger into the work so fast that the engine or blade bogs down. • Do not operate using starting throttle lock.
-
Page 14: Maintenance
• Never alter the stick edger or take the engine apart. • When replacing parts, always be sure to use only RedMax products or products which have been certified by RedMax for use with the RedMax stick edger. ■ BE SURE TO CHECK THE FOLLOWING BEFORE USING YOUR STICK EDGER... - Page 15 Clean the spark plug and check that the plug gap is in the correct range. For a replacement plug, use the correct type specified by RedMax. (MA3) .026 in 0.65 mm HEZ2460S: NGK CMR7H...
- Page 16 HEZ2460S/HEZ3060S 9. Maintenance ■ BLADE (MA6) • Place the blade between holders (A) and (B) while locking the gear shaft by putting the bar, through the key holes on the holder (A) and the gearcase. Use the socket to tighten the blade mounting bolt.
-
Page 17: Storage
HEZ2460S/HEZ3060S ACTION drain it and with correct fuel clean adjust to normal range clean/dry correct (GAP: 0.6 – 0.7 mm) (HEZ2460S) correct (GAP: 0.9 – 1.0 mm) (HEZ3060S) retighten ACTION drain it and with correct fuel adjust to normal range... - Page 18 As the small off-road engine owner, you should however be aware that the RedMax may deny you warranty coverage if your small off-road engine or a part has failed due to abuse, neglect, or improper maintenance or unapproved modifications.
- Page 19 Add-on or modified parts that are not exempted by CARB or EPA may not be used. The use of any non- exempted add-on or modified parts will be grounds for disallowing a warranty claim. RedMax will not be liable to warrant failures of warranted parts caused by the use of a non-exempted add-on or modified part.
- Page 20 WWW.redmax.com...
