Aztech WIPC409HD-E Easy Start Manual

This Easy Start Guide will help you set up your Aztech WIPC409HD-E in connecting to your network for the first
time. Before you continue with the installation, ensure that your modem's Internet connection is UP. This Easy
Start Guide, along with the User Manual which provides a more advanced guide to this product, is included in the
Resource CD and is also downloadable from our Aztech Support Website (www.aztech.com/support).
A

PAckAge contents

The following items below are included in your WIPC409HD-E package.
WIPC409HD-E Ethernet
Cable
Mounting Resource
Bracket CD
B

DevIce overvIew

3A FOR ANDROID USERS
1
1
2
2
4
3
3
5
4
5
Power Wireless
Adapter Antenna
Easy Start Warranty
Guide Policy
Wireless Antenna
Photo Resistance
Infrared LEDs
Lens
Built-in Speaker
BACK PANEL
Micro SD Card Slot
External Mic
LAN Port
External Speaker
PAGE 1
Download and Install the Aztech IP Cam App 2 on
Google Play. You may also scan the QR Code found
in the packaging box to automatically search for the
application.
Launch the Aztech IP Cam App 2 then tap the
button to begin adding a camera.
On the next page, tap the
Add manually button at
the bottom of the screen.
You may use the Scan button to scan the UID found
on the bottom label of the camera, Search to scan
for connected camera(s), or manually enter the
information needed.
NOTE: This 20-digit information is found on the
bottom label of your Camera. The UID is unique for
every device.
*(Sample QR Code Only)
Enter your camera's Security Code (password).
NOTE: The default Security Code for all Cameras is
admin.
Enter the camera's Name. (E.g. Cherry's Camera)
then press OK to apply changes.
You may now start viewing your WIPC409HD-E's
monitored area.
PAGE 3
MODEL
WIPC409HD-E
c InstAllAtIon stePs
4
Tablets / Smartphones
STEP 1
Connect your Aztech WIPC409HD-E to your router's Ethernet LAN port using an
Ethernet cable.
NOTE: Ensure that your router's internet connection is UP, for you to access your
WIPC409HD-E via the Internet.
STEP 2
Connect the power adapter to your WIPC409HD-E camera and plug it into a power
outlet to switch it ON.
STEP 3
3. 1 Connect your router to your computer's Ethernet LAN port using an Ethernet
Built-in Mic
cable.
WPS Button
3. 2 Connect the power adapter to your router, plug it into a power outlet and turn it
ON.
DC Jack
STEP 4
You can either set it up using your mobile phone or your Computer / Laptop. If you are
using a mobile phone, it is recommended to connect over the same Local Area Network
where your WIPC409HD-E is connected.
• For Android Users, please go to 3A (see Page 3).
• For Apple Users, please go to 3B (see on Page 5).
• For Desktop / PC Users, please go to 3C (see Page 6).
connecting your camera to your wi-Fi
A. Using the Aztech IP Cam App 2
1 2
3 4
5
6
7
2
Power
Adapter
WIPC409HD-E
1
3.1
Computer / Desktop
To connect your camera via Wireless Settings, simply follow
the instructions below:
Select your WIPC409HD-E Camera by tapping
1
beside the camera that you wish to connect to your
wireless network.
2
Tap the Edit Camera icon
On the Edit Camera > Advanced Setting section, tap the
3
Advanced button. Wait for the app to finish retrieving
all wireless networks within range.
After retrieving the Wireless Networks, tap on the
4
Manage Wi-fi Networks button. A drop-down selection
list would appear.
On the drop-down selection list, tap on the drop-down
5
arrow and select an SSID (wireless network name).
NOTE: For a more detailed guide of the WIPC409HD-E
IP Camera, you may refer to the User Manual.
After selecting the correct SSID, enter the wireless
6
network's password then press OK. Wait for the
camera to successfully connect to your router.
After the Camera successfully connects with your
7
router, simply tap the OK button to finish the setup. The
Advanced Setting > SSID area would indicate the SSID
(in this case Aztech7008-8AFB) you are connected to
with a Connected status.
Power Outlets
Power
Adapter
3.2
Router
PAGE 2
... the
.
PAGE 4
