RCA VR609HF User Manual

Rca video cassette recorder user's guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VR609HF
USER'S
GUIDE
VIDEO CASSETTE
RECORDER

Advertisement

Table of Contents
loading

Related Manuals for RCA VR609HF

Summary of Contents for RCA VR609HF

  • Page 1 VR609HF USER’S GUIDE VIDEO CASSETTE RECORDER...

  • Page 2: Cautions

    Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. The numbers are located on the back of the VCR. Model No.__________________________________________________________________ Serial No.

  • Page 3: Table Of Contents

    Insert Batteries in Remote ___________ 7 Turn on the TV ____________________ 8 Turn on the VCR ___________________ 8 Place Channels in VCR's Memory ____ 8 Add or Remove Channels from Select a Language/Choisissez une Set the Time and Date ______________ 9 Use TV•VCR Button _______________ 10...

  • Page 4: Hooking Up The Vcr

    The advanced hookups show the VCR hooked up to a monitor/receiver (TV with audio and video jacks). This connection may improve the picture quality as well as convenience of operation.

  • Page 5: Antenna Or Cable System Without A Cable Box

    A. Basic hookup. Use this hookup for a simple connection which requires fewer accessories. 1. Set the CH3 CH4 switch on back of VCR to either channel 3 or 4. You will tune the TV to this channel and use the TV•VCR button to watch the VCR.

  • Page 6: Cable System With Cable Box To Unscramble All Channels

    A. Basic hookup. Use this hookup for a simple connection which requires fewer accessories. 1. Set the CH3 CH4 switch on back of VCR to either channel 3 or 4. You will tune the TV to this channel and use the TV•VCR button to watch the VCR.

  • Page 7: Cable System With Cable Box To Unscramble Pay Channels Only

    A. Basic hookup. Use this hookup for a simple connection which requires fewer accessories. 1. Set the CH3 CH4 switch on back of VCR to either channel 3 or 4. You will tune the TV to this channel and use the TV•VCR button to watch the VCR.

  • Page 8: Connecting Two Vcrs For Copying Tapes

    2. Connect as shown. This connection requires additional accessories not provided. If your other VCR is not stereo, you may need a Y-adapter to hear sound from both left and right channels. 3. Plug in power cords of VCRs and TV.

  • Page 9: Setting Up The Vcr

    Setting Up the VCR Startup 1. Check accessories with VCR. Contact your dealer if any items are missing. POWER TV•VCR CHAN INPUT PREV CH MENU CLEAR DISPLAY MUTE PROG SEARCH PLAY STOP RECORD SPEED F.ADV PAUSE SLOW TRACKING Remote (Stock No. 233455) 2.

  • Page 10: Turn On The Tv

    A. Press VCR on the remote. 5. Place channels in the VCR’s memory. The first time you turn on the VCR or after a power interruption, perform the AUTO CHANNEL SEARCH so that your VCR can locate the channels available through your signal typeÑcable or antenna.

  • Page 11: Add Or Remove Channels From Vcr's Memory

    Channels 1-125 and VID1 were placed in memory at the factory. A. Press VCR on the remote. B. Press MENU on the remote to see the VCR MAIN MENU on the TV screen. C. Press 3 to display the CHANNELS menu.

  • Page 12: Use Tv•Vcr Button

    C. Press 2 to select Auto TV/VCR: ON or OFF. ¥ Select ON if you used one of the basic hookups and watch the VCR on channel 3 or 4 of your TV. The VCR will automatically switch the TV¥VCR setting...

  • Page 13: Using The Remote Control

    Controlling a TV The VCRÔs remote is preprogrammed to control the basic functions of a compatible RCA, ProScan, or GE TV. The remote can also be set up to control other manufacturerÔs brands. To program the remote, use the remote buttons that correspond to your brand.

  • Page 14: Remote Control

    ProScan, or GE TV and sets the remote to control the TV. Used with POWER button to turn on another brand of TV, other than RCA, when the remote is programmed to control that TV. See page 11. VCR Function Buttons...
  • Page 15 Turns off a compatible TV when remote is set to control TV. Used with TV button to turn on a compatible TV, other than RCA, when the remote is programmed to control that TV. See page 11. TRACKING Up and Down...

  • Page 16: Playing A Tape

    The VCR will automatically rewind the tape if it reaches the end of the tape during playback. While rewinding, you can press POWER and the VCR will turn off after rewinding. 7. Press STOP•EJECT on the VCR to eject the tape once it is completely rewound. CHANNEL...

  • Page 17: Using The Playback Features

    Using the Playback Features Auto Play Feature This feature lets you tell the VCR whether you want it to automatically start playing a tape that is inserted with the safety tab removed. 1. Press MENU on the remote to see the VCR MAIN MENU on the TV screen.

  • Page 18: Frame Advance

    Automatic Tracking The VCR has automatic tracking which adjusts the picture when playing back a tape recorded on another VCR. Automatic tracking is turned on whenever a tape is inserted or the VCRÕs power is turned on. Manual Tracking Occasionally, you may need to manually adjust tracking on a tape recorded on a different VCR or camcorder.

  • Page 19: Display Button

    1. Press DISPLAY to display the status of the VCR, channel number, time counter, date, time, and tape speed on the TV screen. The VCR status will appear in the display panel. The time and date must be set before they are displayed.

  • Page 20: Commercial Scan

    SRCH+ appears in the VCRÕs display panel. Index Search The VCR has a ÒVHS Index Search SystemÓ that automatically records an index mark on the tape every time you begin recording a program. During playback you can locate the program you want to play by the number of index marks.

  • Page 21: Zero Search

    8. Press STOP to stop zero search. Tape Playback: HI-FI/LINEAR/MIX Feature The VCR records the same audio on both the hi-fi and linear tracks on the tape. The hi-fi stereo sound is recorded on separate left and right stereo channels. Monaural sound is recorded on the linear track.

  • Page 22: Recording A Program

    Recording a Program Types of Recordings Your VCR provides different types of recording. These types are explained in the following sections: Basic Recording Ð Operating Instructions Recording While You're Away Timer Recording Recording Broadcast Stereo TV or SAP (Second Audio Program)

  • Page 23: Basic Recording Ð Operating Instructions

    Basic Recording – Operating Instructions To Make a Recording Turn on the TV and tune it to the VCR viewing channel, either 3, 4, or TVÕs video input channel. 1. Insert a tape with safety tab in place. The cassette-in indicator 2.

  • Page 24: Recording While You're Away Timer Recording

    Recording a Program Recording While You’re Away (Timer Recording) The timer program feature lets you program the VCR to record up to eight different programs within a one year period. Before setting the timer, make sure that: ¥ The clock is set correctly.

  • Page 25: Checking Or Clearing Timer Recordings

    Timer Recording From the VCR’s Line Input The line input refers to the signal coming from the AUDIO and VIDEO IN jacks of the VCR. Recording from the line input is convenient if you have a satellite receiver or similar component attached to these jacks. To timer record from the component connected to the VCRÕs line input:...

  • Page 26: Recording Broadcast Stereo Tv Or Sap

    Reception: STEREO/MONO/SAP feature lets you select the type of audio you want to record. To Record Stereo Broadcast TV or SAP Turn on the TV and tune it to the VCR viewing channel, either 3, 4, or TVÕs video input. 1. Insert a tape with safety tab in place.

  • Page 27: Recording Audio Only

    Recording Audio Only You can record audio only from another audio source connected to the AUDIO IN (L and R) jacks on the back of the VCR. Any video on the tape will be erased when you record audio only.

  • Page 28: Express Recording (Xpr)

    Recording a Program Express Recording (XPR) Express recording lets you record up to four hours without using the timer program feature. The VCR will turn off automatically at the end of the recording. POWER STOP • EJECT Operating Instructions 1. Turn on the VCR.

  • Page 29: Using Two Vcrs For Copying And Editing Tapes

    Tune TV to the VCR viewing channel, either 3, 4, or TVÕs video input. If you have connected your VCR using Option A (page 6), tune recording VCR to channel 3 or 4 Ñ the one selected on the back of the playback VCR. Caution: The unauthorized...

  • Page 30: References

    Rewinds the tape when the VCR is stopped. Searches the picture in reverse during playback. STOP•EJECT Stops the normal functions such as record, playback, rewind, fast-forward, or pause. Press when the VCR is stopped to eject the cassette.

  • Page 31: Back Panel

    Back Panel CH3 CH4 Switch Selects the channel to which you will tune the TV to see the VCR picture if you connect the VCR using one of the basic hookups. ANT. (Antenna) IN Connector Receives the signal from an antenna or cable system that is attached to this connector.

  • Page 32: Display Panel

    TIMER SLP REC Tape Speed Indicator Cassette-in Indicator Lights when a tape is in the VCR. Flashes while tape is ejecting. Channel Number, Line Indicator (VID1), Time, Time Counter, or Status Indicator The current time, time counter, channel number, or line indicator (VID1) appears here.

  • Page 33: Specifications

    Cleaning the VCR Use a soft cloth or dusting attachment of your vacuum cleaner to dust your VCR. Remove dust from the ventilation holes on the top, back, sides, and bottom of the cabinet. Plastic surfaces are easily scratched and can be marred by alcohol and various solvents.

  • Page 34: Trouble Checks

    References Trouble Checks Sometimes problems can be easily solved by checking a few basic things. Check below before you call for help or take your VCR to an Authorized RCA VCR Servicenter. Trouble No power VCR does not respond to remote Remote no longer controls a compatible TV No picture when VCR turned on –...

  • Page 35: Trouble Checks

    • Time counter display appears in VCR’s display panel. Press DISPLAY on remote. • VCR is removing tape from heads. This is normal. The head cylinder inside the VCR will continue to rotate for a few minutes after you put the VCR in the stop mode. • Check antenna connections.

  • Page 36: Limited Warranty

    Pay any Authorized RCA VCR Servicenter the labor charges to repair your VCR. • Pay any Authorized RCA VCR Servicenter for the new or, at our option, refurbished replacement parts required to repair your VCR. How you get service: •...

  • Page 37: Index

    Choosing a Hookup ......2 Cleaning the VCR ......31 CLEAR Button .
  • Page 38 References Index LANGUAGE Menu ......9 Limited Warranty ......34 Line Input, Recording From .
  • Page 39 Turn On TV .......8 Turn on VCR ......8 TV Button .
  • Page 40 Your toll free numbers are: English: 1-800-522-0338 French: 1-800-522-0445 If your VCR needs service, please contact your dealer or the nearest Servicenter from the yellow pages. Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will only add delays in service for your product.
