RCA RCRP05B Owner's Manual

Cable Replacement Remote
RCRP05B Universal Remote Control
Owner's Manual
Manual del Propietario (parte posterior)
Features and Functions
Introduction
Use the illustration below to locate features on the
The RCRP05B Cable Replacement Remote by RCA is our
RCRP05B Cable Replacement Remote and then study the
latest generation universal remote control. Its sophisticated
key descriptions below to learn how they function.
technology allows you to consolidate up to five of your
original home entertainment remote controls into one
To find out what type of devices can be controlled by each
easy-to-use product. Moreover, its packed with advanced
device key after programming, see the "Device Table"
features such as: section.
• Dedicated keys to control popular functions on your
DVR/PVR (Digital/Personal Video Recorder)
• Programmable MASTER POWER key for master on/off
control of your home entertainment equipment with a
single keypress
• Programmable Macro Keys to consolidate multi-step
actions into a single keypress
• Channel Lock to lock channel selection only to the cable
box or satellite receiver
• Volume Lock to lock volume controls to one mode or
individual modes
• Code Search to help program control of older or
discontinued components
• Color-coded keys to quickly locate popular functions for
cable and satellite
• Code library for popular video and audio devices
Before using the product, you will need to install batteries
and also perform some programming to operate the
specific home entertainment devices you wish to control.
Installing Batteries
1. On the back of the remote control, push the tab and lift
off the battery cover.
2. Insert two (2) AA batteries (not included). Match the +
and - marks with those in the battery case, then insert
them.
3. Align the covers keys with the cases holes and press the
cover back into place. The tab should click when the
cover is locked.
4. Test the remote control by pressing any mode key (e.g.,
TV). If the batteries are inserted correctly, the LED (red
light) will blink once.
NOTE: When batteries need replacement, the remote
control will cease to operate. Replace the batteries
and the unit will be restored to its full functionality,
complete with your favorite settings.
Battery Precautions:
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc) or
rechargeable (nickel-cadmium) batteries.
• Always remove old, weak or worn-out batteries promptly
and recycle or dispose of them in accordance with Local
and National Regulations.
Navigation keys move the cursor in the program guide and
menu screens and navigate within the interactive service.
OK chooses options, PPV events, and tunes to programs
from the program guide.
GUIDE displays the program guide.
EXIT leaves (or clears) your device's menu or guide.
DAY +/- moves a day forward (or back) on your device's
program guide.
PAGE +/- moves up or down one screen at a time through
menu screens and the program guide.
A,B,C,D (red, green, yellow, blue) access additional
features on your cable box, satellite receiver, or Blu-ray disc
player (see your device manual for details).
VOL +/- raises (or lowers) the audio volume.
ON DEMAND accesses your program provider's Video on
Demand services. The ON DEMAND key may not work with
your program provider. Test the key, and if it doesn't take
TV, DVR/AUX, CBL/SAT,
you to your program provider's On Demand service, you can
DVD/VCR, and AUD select
program the ON DEMAND key to access the service. See the
a home entertainment
"Programming Macro Keys" section later in this manual for
device to control. Also see
more information.
the "Device Table" section.
Each device key has an CH+/- selects the next higher (or lower) channel. For DVD
embedded LED (red light) players, use these keys to skip forward (or reverse) through
that blinks upon selection chapters. For amplifiers/receivers, use these keys to select
and indicates the remote the next higher (or lower) preset station.
control is working and (after
NOTE: By default, the CH+/- keys change channels on
programming) is sending
the CBL/SAT device regardless of what mode you're
signals.
in. To change the way the CH+/- keys work, see the
"Programming Channel Control Lock" section.
NOTE: If you have a digital
TV converter, you can
MUTE turns the sound off or on.
program it to the CBL/SAT or
FAV cycles through your favorite channels on your cable
DVR/AUX keys.
box or satellite receiver.
POWER/MASTER POWER
LAST recalls the last channel.
turns on or off a home
Number keys (1-9, and 0) tune directly to channels (e.g.,
entertainment device. For
09). For amplifiers/receivers, use the keypad numbers to
MASTER POWER control, see
select inputs 1 through 10.
the "Using the Master Power
Key" section. – accesses digital sub-channels (for example, 8.1 or 8.2).
ASPECT changes the aspect ratio of the show you are
SETUP is used in all
watching. (Not available on all devices).
programming sequences.
PIP turns the Picture-In-Picture feature on or off (if
LIVE commands your PVR/
available on your device).
DVR to return to watching
live TV.
SWAP switches PIP images and sound between the main
and window pictures.
LIST displays a list of
MOVE moves the PIP window to different positions on your
recorded shows on your PVR/
TV screen.
DVR.
PIP CH +/- are used to select the next higher or lower
(replay) commands your
channel and is displayed on your PIP window.
PVR/DVR set-top box to
instantly replay the last 7 INPUT in CBL/SAT mode is used to view other video sources
seconds of a program you (A or B). In other modes, use INPUT to switch between the
are watching. source inputs on the device you are controlling.
MACRO1 and MACRO2 are reserved for use as macro keys
(skip
(see the "Programming Macro Keys" section).
forward, reverse, play,
forward, stop, pause,
Device Table
record)
In all modes
except CBL/SAT, use these
NOTE: Please refer to the table below when performing
keys to control a VCR, DVD
the instructions in the "Programming Device Control" or
player, or a PVR (after
"Setting Up a Combo Unit" sections.
selecting a desired device).
After programming, the RCRP05B Cable Replacement Remote
To record in DVD/VCR
will be able to control the following types of devices:
mode, press twice. In CBL/
SAT mode, use these keys
Television
TV
to control the DVR/PVR
functions of the cable box or
DVR/AUX DVR, PVR, or auxiliary TV, DVD player, VCR,
satellite receiver.
or digital TV converter
MENU displays the active
CBL/SAT Cable box, satellite receiver, or digital TV
device's menu system.
converter
INFO displays the current
DVD/VCR DVD player, VCR, TV/VCR combo, or TV/DVD
channel and program
combo
information.
Audio amplifier, tuner, or receiver
AUD
3. Use the codes in the accompanying code list to locate the
Programming Device Control
brand name and enter the first four-digit code for your
combo device (for example, TV/VCR). If you perform this
Before you can start using this remote, you must program it
procedure correctly, the DVD/VCR key will blink twice.
to control your components.
NOTE: If the DVD/VCR key did not blink twice after
NOTES:
entering the codes last digit, repeat steps 2 and 3 and
The RCRP05B Cable Replacement Remote is preprogrammed try entering the same code again. If you've located
to operate an RCA TV, a Toshiba DVD player, an RCA VCR, a setup code that works for your combo device (for
a Pioneer audio receiver, and a Motorola cable box. If you example, a TV/VCR Combo) and a separate TV code
own these brands of these devices, test the remote with is also listed, you'll need to program this code into
them. If they work, you do not have to program the remote the remote control to access volume control (see the
to operate them.
"Programming Device Control" section).
For control of a Combo device (for example, a TV/VCR 4. Aim the remote control at your combo device (for
combo), skip this section and perform the instructions example, TV/VCR Combo) and press POWER once. The
in the "Setting Up a Combo Unit" section. Also refer device should turn off. If it does not respond, repeat
to the "Device Table" to find out which devices can be steps 2 and 3, trying each code listed for your brand until
you find one that works. If it still does not respond, try
programmed onto each device key.
searching for the code (see the "Searching for Your Code"
section).
1. Turn on a device and, if applicable, insert video media,
(e.g., cassette or disc). 5. For future reference, write down each working device
code in the boxes below:
NOTE: Please read steps 2 through 5 completely before
proceeding. Highlight or write down the codes and
TV/VCR or TV/DVD Code:
device you wish to program before moving on to step 2.
TV Code (if used):
2. On the remote control, press a device key once (i.e., DVD/
VCR, DVR/AUX, AUD, TV, or CBL/SAT); it will blink once.
Searching For Your Code
3. Press and hold SETUP until the selected mode key blinks
twice, then release SETUP.
If your home entertainment device does not respond to the
RCRP05B Cable Replacement Remote after trying all of the
4. Use the codes in the accompanying code list to locate
codes listed for your brand, or if your brand is not listed at
the type of device and brand name and then enter
the first four-digit code for your device. If performed all, try searching for your code.
correctly, the selected mode key will blink twice.
For example, to search for a code for your TV:
NOTE: If the selected mode key emits a long blink, 1. Turn on your TV.
the entry is invalid. Repeat steps 2 through 4 and try
2. On the remote control, press TV once; it will blink once.
entering the same code again. Then press and hold SETUP until the TV key blinks twice.
5. Aim the remote control at the device and press POWER 3. Enter 9 9 1. The TV key will blink twice.
once. The device should turn off. If it does not, repeat
4. Aim the remote control at the TV and press POWER once.
steps 2 through 4, trying each code for your brand until
5. Press and release the CH+ key continuously, then stop
you find one that works. If it still does not respond,
when the TV turns off.
try searching for the code (see the "Searching for Your
NOTE: In the search mode, the remote control will send
Code" section).
IR codes from its library to the selected device, starting
NOTE: If the device does not have a POWER key (e.g.,
with the most popular code first.
DVD and VCR), press the (Play) key. 6. Press POWER. The TV should turn on, then press SETUP
once to lock in the code. The LED will blink twice to
6. Once you've found a code that turns your device on and
indicate that the code is saved.
off, test other remote commands for that device (e.g.,
volume, channel, menu, etc.). NOTE: If the TV does not turn on during step 6, then
slowly press and release CH- to go back through the
NOTE: By default, the CH+/- keys change channels on
codes, then press SETUP when the TV turns on.
the CBL/SAT device regardless of what mode you're in.
7. Test other remote commands for the TV (e.g., volume,
So, you should only use these keys to test for CBL/SAT
menu, etc.). If the commands you want to use with your
device codes at this point.
TV work, you've finished programming for your TV. If
7. Repeat steps 1 through 6 for each device you want the
they don't, repeat steps 1-4 above. In step 5, don't stop
remote control to operate. For future reference, write
when your TV turns off the first time—keep pressing
down each working device code in the boxes below.
CH+ until it turns off again.
NOTE: By default, the CH+/- keys change channels on
DVD/VCR Code:
the CBL/SAT device regardless of what mode you're in.
So, you should only use these keys to test for CBL/SAT
DVR/AUX Code:
device codes at this point.
AUD Code:
8. To search for the codes of your other devices, repeat steps
1 through 7, but substitute the appropriate key (e.g.,
CBL/SAT Code:
DVD/VCR, DVR/AUX, AUD, or CBL/SAT) for the device
TV Code: you're searching for.
Checking the Codes
Setting Up a Combo Unit
If you have set up your remote control by searching for your
If you own a combo unit such as a TV/VCR Combo or a TV/
device code, you may need to find out which four-digit code
DVD Combo, you need to follow special steps to set it up.
Perform the following instructions to control combo device: is operating your equipment.
For example, to find out which code is operating your TV:
1. For a TV/VCR Combo, turn on your TV/VCR Combo and
1. On the remote control, press TV once; it will blink once.
insert a video cassette. (For a TV/ DVD Combo, insert a
Then press and hold SETUP until the TV key blinks twice.
DVD).
2. Enter 9 9 0. The TV key will blink twice.
2. On the remote control, press DVD/VCR once; it will blink
once. Then press and hold SETUP until the DVD/VCR key 3. To view the code for the first digit, press 1 once. Count
blinks twice. the number of times the TV key blinks (e.g., 3 blinks = 3)
and write down the number in the left-most TV Code box
in the "Programming Device Control" section.
NOTE: If a code digit is 0, the selected mode key will
not blink.
4. Repeat step 3 three more times for the remaining digits.
Use 2 for the second digit, 3 for the third digit, and 4 for
the fourth digit. Finish writing down the code in the TV
Code boxes.
5. To check for other device codes, repeat steps 1 through 4,
but substitute the appropriate key (e.g., DVD/VCR, DVR/
AUX, AUD, or CBL/SAT) for the device you are checking.
Write down the codes in the appropriate boxes in the
"Programming Device Control" section.
Using Learning
The RCRP05B Cable Replacement Remote includes a
Learning feature so you can add functions that are unique
to your home entertainment devices (e.g., VCR tracking up
or down).
Learning Precautions
• Your original remote controls must be in working order
for learning to work properly.
• Learned keys are mode-specific, so each one can store a
unique function for each mode.
• Do not use the following keys for learning: device keys,
SETUP, (Record), Macro keys.
• Learning capacity is up to a total of 50 keys, depending
on the code being learned.
• Certain device functions are not learnable including
multi-frequency types, some high frequency ones, and
other unusual formats.
• For optimum learning, avoid high levels of ambient light
such as natural sunlight or energy-efficient fluorescent
lights.
NOTE: Please have your original remote controls handy
before programming learning.
Programming a Learned Key
NOTE: If more than 15 seconds pass between key
presses, the remote exits programming.
1. Press and hold SETUP until the last-selected mode key
blinks twice, then press 9 7 5.
NOTE: If the LED displays one long flash instead,
either your batteries are low, or the RCRP05B Cable
Replacement Remote has a memory fault.
2. Press a mode key once (i.e., DVD/VCR, DVR/AUX, AUD,
TV, or CBL/SAT) to assign a mode for learning.
3. Press the desired key on the RCRP05B once to store the
feature to be learned.
4. Place the RCRP05B Remote Control head-to-head (about
2" apart) from your original remote control. Also locate
the key (on your original remote control) that you want
the RCRP05B Cable Replacement Remote to learn.
2"
5. On the original remote, press and hold the key to be
learned. The device key's LED will blink rapidly, then turn
off. Continue holding the key on the original remote
until the device key LED blinks twice.
NOTE: If the LED displays one long blink, a learning
error has occurred. Try repeating this step again until
a successful capture occurs. If the function is still not
captured, press and hold SETUP to exit programming and
review the "Learning Precautions" earlier in this section. If
needed, also see "Troubleshooting" later in this manual.
After review, start programming again at step 1.
