Rotel RA-932 Technical Manual

Quality Uncompromised
T echnical
Manual
Table of Contents
Specification......................................1
Parts List ...........................................2,3,4
Adustment..........................................4
Case Outlines....................................4
PCB Assembly ..................................5,6
Schematic Diagram...........................7,8
Specification
Continuous Power Output
(20 - 20 kHz, <0.03 %, 8 ohms)
Total Harmonic Distortion (20 Hz - 20k Hz)
Intermodulation Distortion (60 Hz : 7 kHz, 4:1)
Frequency Response
Phono Input
Line Level Input
Dampning Factor (20 - 20,000 Hz, 8 ohms)
Input Sensitivity / Impedance
Phono Input
Line Level Input
Input Overload
Phono Input
Line Level Input
Tone Controls - Bass/Treble
Signal to Noise Ratio(IHF"A"weighted)
Phono Input
Line Level Input
Power Requirements
USA Version
European version
Power Consumption
Dimensions(W x H x D)
Weight
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN
®
STEREO INTEGRATED AMPLIFIER
RA-932
35 watts/ch
<0.03 % at rated power,
1/2 power or 1 watt
<0.03 % at rated power,
1/2 power or 1 watt
20 Hz - 15 kHz, ± 0.3 dB
10 Hz - 40 kHz, ± 1 dB
180
2.5 mV / 47 Ohms
150 mV / 20 kOhms
5 V
180 mV
5 V
± 6 dB at 100 Hz / 10 kHz
80 dB
100 dB
115 volts, 60 Hz
230 volts, 50 Hz
180 Watts
440 x 92 x 347 mm
17 x 5 x 13
3/8" 5/8" 11/16"
5.5 kg / 12.1 lbs.
Serial. NO.
Beginning
Y-323A-00015C/S-S
Parts List-1
SYMBOL PARTS NO. DESCRIPTION
X-1284-01 PCB ASSEMBLY
C401,402 044 FSC160V151H CAP,STYROL 160V150PF
C403,404 041 U25V10LN CAP,ELEC.25V10UF
C405,406 044 S50V1000PG CAP,STYROL 50V1000PF
C407,408 044 S50V200PG CAP,STYROL 50V200PF
C409,410 044 S50V4300PG CAP,STYROL 50V4300PF
C411,412 044 U50V10RC2 CAP,ELEC.50V10UF
C413,414 041 TVX1E101 CAP,ELEC.25V100UF
C415 043 TC50V473 CAP,CERA.50V0.047UF
C501,502 041 U50V10RC2 CAP,ELEC.50V10UF
C503,504 044 FSC160V221H CAP,STYROL 160V220PF
C505,506 041 TVX1E101 CAP,ELEC.25V100UF
C507,508 044 50MSAN104J CAP,FILM 50V0.1UF
C509,510 044 50MSAN124J CAP,FILM 50V0.12UF
C511,512 044 50MSAN104J CAP,FILM 50V0.1UF
C513,514 044 S50V1500PJ CAP,STYROL 50V1500PF
C515,516 041 U50V10RC2 CAP,ELEC.50V10UF
C601,602 041 U50V10RC2 CAP,ELEC.50V10UF
C603,604 044 FSC160V101H CAP,STYROL 160V100PF
C605,606 041 U6.3V100RC2 CAP,ELEC.6.3V100UF
C607,608 043 TC50V331 CAP,CERA.50V330PF
C609,610 043 TC50V151 CAP,CERA.50V150PF
C611,612 044 FSC160V221H CAP,STYROL 160V220PF
C613,614 044 MKT18-2A104K CAP,FILM 100V0.1UF
C701 041 UTSS1H010-FB CAP,ELEC.50V1UF
C702,703 043 TC50VCH330 CAP,CERA.50V33PF
C704 043 TC50V473 CAP,CERA.50V0.047UF
C705 041 UTSS1H4R7-FB CAP,ELEC.50V4.7UF
C706 042 TP50V103J CAP,MYLAR 50V0.01UF
C707 043 TC50V103 CAP,CERA.50V0.01UF
C901 044 DE1307E472M SPARK KILLER
C902-905 043 TC500V103 CAP,CERA.500V0.01UF
C906,907 041 50USP682 CAP,ELEC.50V6800UF
C908,909 043 TC500V103 CAP,CERA.500V0.01UF
C910 041 UTSS1H102 CAP,ELEC.50V1000UF
C911 041 UTES1C471-FB CAP,ELEC.16V470UF
C912 041 UTSS1E100-FB CAP,ELEC.25V10UF
C913 041 UTSS1V471 CAP,ELEC.35V470UF
C914,915 041 UTSS1E101-FB CAP,ELEC.25V100UF
C916 041 UTSS1H010-FB CAP,ELEC.50V1UF
C917 041 UTSS1E101-FB CAP,ELEC.25V100UF
C918,919 041 VX1V102 CAP,ELEC.35V1000UF
C920,921 041TVX1E101 CAP,ELEC.25V100UF
D601-605 034 T1N4148-86 DIODE
D701-706 034 T1N4148-86 DIODE
D707 034 TRD5.6JST1 ZENER DIODE
D901 034 BR84 BRIDGED DIODE
D902 034 T1N4148-86 DIODE
D903,904 034 T1N4003-TB DIODE
D905,906 034 TRD18JST1 ZENER DIODE
D907,908 034 TRD12JST1 ZENER DIODE
SYMBOL PARTS NO. DESCRIPTION
D909,910 034 T1N4148-86 DIODE
F601,602 036 5ST4 MINI FUSE 250VT4A
F901,902 036 5ST5 MINI FUSE 250VT5A
HJ601 065 C-3399#3 PHONE JACK
IC401 031 NE5532AN IC
IC501 031 OPA2604AP IC
IC701 031 TMP47C400BN IC
IC702 031 LB1641 IC
IC703 031 TC74HCU04AP IC
IC901 031 NJM78L05 IC
LY601 063 DH2TU-24 RELAY
LY901 063 DH2U-24 RELAY
PJ1 066 4TR-2408#3 4P PINJACK
PJ2,3 066 4TR-2408#1 4P PINJACK
Q601-608 032 TA1016-FG TRANSISTOR
Q609,610 032 B631-EF TRANSISTOR
Q611,612 032 TC1941-KL TRANSISTOR
Q615,616 033 D600-EF TRANSISTOR
Q617,618 033 B631-EF TRANSISTOR
Q701 032 TC536-FG TRANSISTOR
Q702 032 TA608-FG TRANSISTOR
Q901 032 B631-EF TRANSISTOR
Q902 032 TC536-FG TRANSISTOR
Q903 032 TC3708-ST TRANSISTOR
Q904 032 TC2362-FG TRANSISTOR
Q905 032 TA1016-FG TRANSISTOR
Q906 032 D600-EF TRANSISTOR
Q907,908 032 TC536-FG TRANSISTOR
R401,402 054 TMK2001KFECZ R,METAL 1% 1K
R403,404 054 TMK2047KFECZ R,METAL 1% 47K
R405,406 054 TMK201K2FECZ R,METAL 1% 1.2K
R407,408 054 TMK204K7FECZ R,METAL 1% 4.7K
R409,410 054 TMK2056KFECZ R,METAL 1% 56K
R411,412 054 TMK2910KFECZ R,METAL 1% 910K
R413,414 054 TMK2680RFECZ R,METAL 1% 680R
R415,416 054 TMK2001KFECZ R,METAL 1% 1K
R417,418 054 TMK2100KFECZ R,METAL 1% 100K
R501,502 054 TMK2470RFECZ R,METAL 1% 470R
R503,504 054 TMK2100KFECZ R,METAL 1% 100K
R505,506 054 TMF1001 R,METAL 1K
R507,508 054 TMF1802 R,METAL 18K
R509,510 054 TMF2201 R,METAL 2.2K
R511,512 054 TMF1801 R,METAL 1.8K
R513,514 054 TMF2202 R,METAL 22K
R515,516 054 TMF1501 R,METAL 1.5K
R517,518 054 TMF8201 R,METAL 8.2K
R519,520 054 TMF1501 R,METAL 1.5K
R521,522 054 TMK2033KFECZ R,METAL 1% 33K
R523,524 054 TMK2022KFECZ R,METAL 1% 22K
R525,526 054 TMK2100KFECZ R,METAL 1% 100K
2
