The REN is useful in determining the number of devices you may connect to your telephone line and still have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum of the RENs of all devices connected to one line should not exceed 5.
Page 3
NTERFERENCE NFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
You need an RJ11 type modular jack, which is the most common type of phone jack and might look like the one pictured here. If you don’t have a modular jack, call your local phone company to find out how to get one installed. AC power supply Telephone line cord...
Connect the telephone line cord from your telephone into the jack on the back of the answerer marked PHONE. (You don’t have to connect your telephone in order for the answerer to record incoming messages.)
ETUP ECORDING THE REETING The unit allows you to record 2 custom greetings or use the default greeting. To select which custom greeting the answerer will use, see “ Setting the Answer Status”. Before using your new answerer, you should record a greeting .
Page 8
Hold down the GREETING button. Record after the tone. Release GREETING when you finish. The unit plays back your greeting. To review the greeting, press and release GREETING. To return to the answerer's default greeting after you've recorded one, press GREETING and release it when you hear the tone, or press DELETE when the greeting is playing.
ETTINGS You can customize the following settings to suit your needs. Answer Status Selects greeting 1, greeting 2, or answer off. Day/Time Sets the day and time. Area Code Sets your local area code for Dial Back. LCD Contrast Selects the display contrast. Rings to Answer Selects the number of rings before the unit answers.
ETTING THE NSWER This setting allows you to turn the answerer on and select which greeting you want or to turn the answerer off. The choices available are: Answer On, Greeting One; Answer On, Greeting Two, and Answer Off. Press and release the MENU button. The unit announces and displays the current answer status.
This setting allows you to set the current day and time for the Time/Day stamp attached to each message. NOTE: The telephone company sends the time and date with the Caller ID information. The unit will reset the hour and minute each time a call is received.
Press and release NEXT or PREVIOUS until the unit announces and displays the desired setting. Press ENTER. The unit confirms the setting with a beep and enters the Hour menu. The unit announces and displays the current hour setting. Press and release NEXT or PREVIOUS until the unit announces and displays the desired setting.
INUTE The unit announces and displays the current minute setting. Press and release NEXT or PREVIOUS until the unit announces and displays the desired setting. Press ENTER. The unit confirms the setting with three beeps and enters the Area Code menu.
ETTING THE This setting allows you to set your local area code for the Dial Back feature. If you just adjusted the Day/Time menu, skip to step 3. If you haven’t adjusted any other setting, press and release the MENU button. Press and release ENTER until the unit announces and displays the current area code setting.
Page 15
Once the 1st digit is set, press ENTER. The unit confirms the setting with a beep and is ready to set the next digit. 5. Follow steps 3-4 until all the digits of the area code have been selected. Press ENTER. The unit confirms the setting with three beeps and enters the Display Contrast menu.
ETTING THE ISPLAY This setting allows you to select the display contrast for easier readability. If you just adjusted the Area Code menu, skip to step 3. If you haven’t adjusted any other setting, press and release the MENU button. Press and release ENTER until the unit announces and displays the current display contrast setting.
ETTING THE INGS TO This setting allows you to select the number of rings before the unit answers a call. If you just adjusted the LCD Contrast menu, skip to step 3. If you haven’t adjusted any other setting, press and release the MENU button.
• If you have no new messages, the unit answers after the 5th ring. You can hang up after the 4th ring and save the pay telephone or long distance charge. ETTING THE NCOMING ENGTH This setting allows you set the maximum length of time allowed for incoming messages.
Page 19
If you just adjusted the Rings to Answer menu, skip to step 3. If you haven’t adjusted any other setting, press and release the MENU button. Press and release ENTER until the unit announces and displays the current incoming message length. Press and release NEXT or PREVIOUS until the unit announces and displays the desired setting.
ETTING THE ECURITY This feature allows you to change the factory default security code used for remote access to you answerer. The default code is 123. If you just adjusted the Message Length menu, skip to step 3. If you haven’t adjusted any other setting, press and release the MENU button.
Page 21
Once the 1st digit is selected, press ENTER. The unit confirms the setting with a beep and is ready to set the next digit. Follow steps 3-4 until all the digits of the security code have been selected. The unit announces, “Press and hold GREETING key to record announcement.
Total number of calls New call Total number of messages NEW CALLS 10-12 GREETING 1 Answer status Ready - To - Answer Display DJUSTING THE OLUME Use the VOLUME control to adjust the speaker volume to a comfortable level. Current time VOLUME control...
NSWERER PERATION LAYING ESSAGES Use the PLAY/STOP button to play new and old messages as well as display call info received from callers who did not leave messages. The unit first plays new messages, in the order received, then the Caller ID information for calls received without messages is displayed for 2-3 seconds.
Page 24
• To restart the message that is playing, press and hold PREVIOUS until the message restarts. • To replay the previous message, press and release PREVIOUS. • To play the next message, press and release NEXT. Current call Time Date NEW CALLS 12 : 15 8/24...
ELETING ESSAGES INGLE ESSAGES You can delete a message itself, leaving the Caller ID information; or you can delete the message along with the call info. • While the message is playing, press and release DELETE. The unit erases the current message and announces, “Message erased.”...
ESSAGES You can also delete all the messages only, leaving the Caller ID information; or you can delete the messages along with the call info. While the unit is in ready-to-answer mode, press and release DELETE. The unit announces, “Press and release delete key to erase all messages.
EAVING A Use the MEMO button to record a specific message for others who have access to the unit. Press and hold the MEMO button. Record your message after the beep. Release MEMO when you’re finished talking. The unit treats the memo as a message, as the display shows.
EMORY When the unit's memory is full, it answers after 10 rings and announces, “Memory is full.” A 20- second waiting period follows, allowing you to enter your security code. EMOTE CCESS You can access your answerer from any touch- tone phone by entering your 3-digit security code (the default security code is 1 2 3, but you can change it.) Be aware that remote functions do not...
Page 29
To access your answerer: Call your telephone number. After you hear the beep that follows the greeting, enter your 3-digit security code. The unit confirms your code with a beep. To bypass the greeting, you can enter your 3-digit security code any time while the greeting is playing.
Page 30
The unit can store up to 99 calls for later review. VERY IMPORTANT: The Caller ID feature of this product requires a subscription to Caller ID service from your telephone company. NOTE: Check with your local phone company regarding name service availability. Total number of calls...
ALLER WITH Provided you subscribe to Caller ID with Call Waiting service from your phone company, you are able to see who is calling when you hear the call waiting beep. The caller identification information appears in the display after you hear the tone.
Page 32
EVIEWING ECORDS Use either the PREVIOUS or NEXT button to review your Caller ID records. • Press PREVIOUS to scroll through the call records from the most recent to the oldest. • Press NEXT to scroll through the call records from the oldest to the newest.
ID I ELETING ALLER You can delete a Caller ID record, leaving any associated message; or you can delete the Caller ID info along with the message. • While the call info is displayed, press and release DELETE. The unit erases the current Caller ID info and the next record is displayed.
Page 34
When reviewing Caller ID records, you can dial back the number shown on the display by pressing the DIAL button. Use PREVIOUS or NEXT to display the Caller ID number you want to dial. Press DIAL. The number to be dialed is shown.
HANGING THE It may be necessary to change the format of the number to be dialed before using Dial Back. Use PREVIOUS or NEXT to display the Caller ID number you want to dial. Press DIAL. The number to be dialed is shown.
Page 36
Press DIAL again. After a brief pause, the number dials automatically and PICK UP PHONE is displayed. Pick up the attached phone to connect the call. NOTE: To cancel Dial Back, press PLAY/STOP or wait for the unit to return to the ready-to-answer mode.
ROUBLESHOOTING Problem Doesn’t answer, or answers on 10th ring Incoming messages are incomplete Won’t respond to remote commands Explanation/Solution • Make sure answerer is turned on. • Memory is full, erase some messages. • Check AC power and phone line connections. •...
Page 38
Problem Won't set up Answerer doesn't work Can't hear messages Can't restart message Greeting continues to play even after an extension phone is picked up Explanation/Solution • Make sure you are in setup mode by pressing and releasing MENU. Press and release ENTER until you reach the setting you want to change.
EMOTE CCESS Digital Messaging System Dial phone number of the answerer. Enter 3-digit security code. Enter touch-tone command. Hang up. Write 3-digit security code in boxes. 2-9993 Play messages Play menu Hang up Play previous message (during message playback) Repeat current message (during message playback) Skip to next message (during message playback)
ENERAL RODUCT To keep your answerer working and looking good, follow these guidelines: • Avoid putting it near heating appliances and devices that generate electrical noise (for example, motors or fluorescent lamps). • DO NOT expose to direct sunlight or moisture. •...
NDEX Adjusting the Volume 22 All Messages 26 Answerer Operation 23 Before You Begin 5 Caller ID Features 30 Caller ID with Call Waiting 31 Changing the Dial Back Format 35 Day 11 Deleting Caller ID Info 33 Deleting Messages 25 Dial Back 34 FCC Registration Information 2 General Product Care 41...
Page 43
Parts Checklist 5 Receiving and Storing Calls 31 Recording the Greeting 7 Remote Access 28 Remote Access Card 39 Reviewing Call Records 32 Service 41 Setting the Answer Status 10 Setting the Area Code 14 Setting the Day/Time 11 Setting the Display Contrast 16 Setting the Incoming Message Length 18 Setting the Rings to Answer 17 Setting the Security Code 20...
Pay any charges billed to you by the Exchange Center for service not covered by the warranty. • Insure your shipment for loss or damage. Thomson accepts no liability in case of damage or loss en route to Thomson. Model 29993 15481430 (Rev. 1, E/S) 99-38 Printed in China •...
Page 45
29993 Sistema Digital de Mensajes con Identificador de Llamadas (Caller ID) y Llamada en Espera (Call Waiting) Creamos cosas buenas para la vida.
Page 46
NFORMACIÓN EGISTRO A LA Su equipo telefónico de la GE ha sido registrado con la Comisión Federal de Comunicaciones (FCC) y está en acuerdo con las Partes 15 y 68 de las Regulaciones y Reglas de la FCC. Notificación a la Compañía Telefónica Local Al fondo de este equipo Ud.
Page 47
NFORMACIÓN DE NTERFERENCIAS Este artefacto cumple con la Parte 15 de las Reglas de la FCC. Su funcionamiento es sujeto a las dos condiciones siguientes: (l) Este artefacto no puede causar interferencia dañosa, y (2) Este artefacto debe aceptar cualquier interferencia recibida, incluyendo interferencia que puede causar un funcionamiento no deseado.
Page 48
ABLA DE ONTENIDO NFORMACIÓN EGISTRO A LA NFORMACIÓN DE NTERFERENCIAS EQUISITOS DE CONEXIÓN ... 5 NTES DE OMENZAR ... 5 ISTA DE ARTES ... 6 NSTALACIÓN ... 7 ROGRAMACIÓN ... 7 RABAR EL ALUDO ... 9 ROGRAMACIONES ROGRAMAR LAS ONDICIONES PARA ...
NTES DE OMENZAR ISTA DE ARTES Asegúrese de que su empaque contenga los siguientes artículos: (ENTER) 10 : 25 12/08 25 15 1 - 315 - 555 - 1234 HERB GREEN DIAL VOICE • TIME • DAY • STAMP GREETING DELETE MEMO PLAY/STOP...
NSTALACIÓN Conecte el cable de línea telefónica en el enchufe marcado “LINE” en la parte poste- rior del aparato y después a un enchufe modular de pared. Conecte el cable de línea telefónica de su teléfono en el enchufe en la parte posterior del contestador, marcado “PHONE”.
ROGRAMACIÓN RABAR EL ALUDO El aparato le permite grabar 2 saludos preparados por usted o usar el saludo pre- programado de fábrica. Para seleccionar cual saludo preparado utilizará el contestador, vea “Programación de las Condiciones para Contestar”. Antes de utilizar su nuevo contestador, usted debe grabar un saludo.
Page 52
Mantenga oprimido el botón de saludo (“GREETING”). Grabe después del tono. Suelte el botón de saludo (“GREETING”) cuando termine. El aparato reproduce su saludo. Para revisar el saludo, oprima y suelte el botón “GREETING”. Para volver al saludo pre-programado de fábrica después de que usted ha grabado un saludo, oprima el botón “GREETING”...
ROGRAMACIONES Usted puede cambiar a su gusto las siguientes programaciones según sus necesidades. Condiciones para Contestar Día/Hora Clave de área Contraste de la Pantalla Timbres para Contestar Tiempo para Mensajes Código de Seguridad Programaciones de Fábrica Condiciones para Contestar Hora Clave de área Contraste de la Pantalla Timbres para Contestar...
ROGRAMAR LAS PARA ONTESTAR Este programa le permite activar el contestador y seleccionar cuál saludo quiere usar, o para desactivar el contestador. Las condiciones a elegir son: Answer On, Greeting One; Answer On, Greeting Two, and Answer Off (Contestador Activado, Saludo Uno; Contestador Activado, Saludo Dos;...
ROGRAMAR EL Este programa le permite programar el día y la hora actual para marcar el día y la hora que acompaña a cada mensaje. NOTA: La compañía telefónica manda la hora y la fecha junto con la información del Identificador de Llamadas.
Page 56
Oprima y suelte los botones “NEXT” o “PREVIOUS” hasta que el aparato anuncie la programación deseada. Oprima el botón “ENTER”. El aparato confirma la programación emitiendo un tono y pasa al menú de la Hora. El aparato anuncia y muestra la programación actual de la hora.
INUTOS El aparato anuncia y muestra la programación actual de los minutos. Oprima y suelte los botones “NEXT” o “PREVIOUS” hasta que el aparato anuncie y muestre la programación deseada. Oprima el botón “ENTER”. El aparato confirma la programación emitiendo un tono y pasa al menú...
ROGRAMAR LA Este programa le permite programar su clave de área local para usar la función de regresar el llamado (“Dial Back”). Si usted ha acabado ahora de ajustar el menú de Día/ Hora, salte al paso 3. Si usted no ha ajustado ninguna otra programación, oprima y suelte el botón “MENU”.
Page 59
Una vez que el primer dígito está programado, oprima el botón “ENTER”. El aparato confirma la programación emitiendo un tono y está listo para programar el siguiente dígito. Siga los pasos 3-4 hasta que todos los dígitos de la clave de área han sido seleccionados.
ROGRAMAR EL ANTALLA Este programa le permite seleccionar el contraste de la pantalla para facilitar su lectura. Si usted ha acabado ahora de ajustar el menú de la Clave de Area local, salte al paso 3. Si usted no ha ajustado ninguna otra programación, oprima y suelte el botón “MENU”.
ROGRAMAR EL IMBRES PARA ONTESTAR Este programa le permite seleccionar el número de timbres antes de que el contestador conteste la llamada. Si usted ha acabado ahora de ajustar el menú de contraste de la pantalla, salte al paso 3. Si usted no ha ajustado ninguna otra programación, oprima y suelte el botón “MENU”.
HORRADOR DE ARGOS El ahorrador de cargos puede ahorrarle el costo de una llamada cuando usted tiene acceso a sus mensajes desde una localización remota: • Si usted tiene mensajes nuevos, el aparato contesta después del segundo timbre. • Si usted no tiene mensajes nuevos, el aparato contesta después del quinto timbre.
Page 63
Si usted ha acabado ahora de ajustar el menú de Número de Timbres para Contestar, salte al paso 3. Si usted no ha ajustado ninguna otra programación, oprima y suelte el botón “MENU”. Oprima y suelte el botón “ENTER” hasta que el aparato anuncie y muestre la programación actual de duración de mensajes.
ROGRAMAR EL EGURIDAD Este programa le permite cambiar el código de seguridad pre-programado de fábrica que se usa para tener acceso remoto a su contestador. El código de seguridad de fábrica es 123. Si usted ha acabado ahora de ajustar el menú...
Page 65
Una vez que el primer dígito está programado, oprima el botón “ENTER”. El aparato confirma la programación emitiendo un tono y está listo para programar el siguiente dígito. Siga los pasos 3-4 hasta que todos los dígitos del código de seguridad han sido seleccionados.
Page 66
Número total de llamadas Llamada Número total de mensajes nueva NEW CALLS 10-12 GREETING 1 Estado actual del contestador Pantalla de Listo-Para-Contestar JUSTAR EL OLUMEN Utilice el control de volumen (“VOLUME”) para ajustar el volumen de la bocina a un nivel cómodo.
PERACIÓN DEL EPRODUCIR Utilice el botón “PLAY/ STOP” tanto para reproducir mensajes nuevos y viejos, como para mostrar información de llamadas de personas que llamaron y no dejaron mensaje. El aparato reproduce primero los mensajes nuevos, en el orden recibidos, después muestra la información del Identificador de Llamadas para llamadas recibidas sin mensaje durante 2-3 segundos.
Page 68
• Para volver a comenzar el mensaje que se está reproduciendo, oprima y sostenga el botón “PREVIOUS” hasta que el mensaje vuelva a comenzar. • Para volver a reproducir el mensaje previo, oprima y suelte el botón “PREVIOUS”. • Para reproducir el siguiente mensaje, oprima y suelte el botón “NEXT”.
ORRAR ENSAJES ENSAJES NDIVIDUALES Usted puede borrar unicamente el mensaje, dejando la información del Identificador de Llamadas; o usted puede borrar el mensaje junto con la información de la llamada. • Mientras el mensaje se está reproduciendo, oprima y suelte el botón “DELETE”. El aparato borra el mensaje actual y anuncia “Message erased,”...
ODOS LOS ENSAJES Usted puede también borrar unicamente todos los mensajes, dejando la información del Identificador de Llamadas (Caller ID); o usted puede borrar los mensajes junto con la información del Caller ID. Mientras el contestador está en la función de listo-para-contestar, oprima y suelte el botón “DELETE”.
información de las llamadas y anuncia “All messages and Caller ID erased,” (Todos los mensajes y la información del Identificador de Llamadas borrados). EJAR UN ECADO Utilice el botón para recados (“MEMO”) para grabar un mensaje específico para otras personas que tengan acceso al contestador.
EMORIA LENA Cuando la memoria del aparato está llena, éste contesta después de 10 timbres y anuncia “Memory is full” (la memoria está llena). Le sigue un periodo de espera de 20 segundos, que le permite inscribir su código de seguridad. CCESO EMOTO Usted puede tener acceso a su contestador desde...
Page 73
Para tener acceso a su contestador: Llame a su número telefónico. Después de que usted escuche el tono que sucede al saludo, inscriba su código de seguridad de 3 dígitos. El aparato confirma su código con un tono. Para saltarse el saludo, usted puede inscribir su código de seguridad de 3 dígitos en cualquier momento mientras el saludo se está...
UNCIONES DEL DENTIFICADOR DE El aparato recibe y muestra la información transmitida por su compañía telefónica local. Esta información puede incluir el número telefónico, fecha y hora; o el nombre, número telefónico, fecha y hora. El aparato puede almacenar hasta 99 llamadas para revisar posteriormente.
DENTIFICADOR DE LAMADAS CON LAMADA EN SPERA AITING Suponiendo que usted se suscribe al servicio de Identificador de Llamadas con Llamada en Espera (Caller ID con Call Waiting) a través de su compañía telefónica usted podrá ver quién le llama cuando usted escuche el tono de Llamada en Espera.
EVISAR ATOS DE Use los botones “PREVIOUS” (previo) o “NEXT” (siguiente) para revisar los archivos del Identificador de Llamadas. • Oprima el botón “PREVIOUS” para recorrer los archivos de llamadas, desde la más reciente a la más antigua. • Oprima el botón “NEXT” para recorrer los archivos de llamadas, desde la más antigua a la más nueva.
ORRAR INFORMACIÓN DEL DENTIFICADOR DE LAMADAS Usted puede borrar un archivo del Identificador de Llamadas, dejando cualquier mensaje asociado; o puede borrar la información del Identificador de Llamadas junto con el mensaje. • Mientras se muestra la información de la llamada, oprima ysuelte el botón “DELETE.”...
ONTESTAR EL Mientras usted revisa sus archivos del Identificador de Llamadas, usted puede volver marcar los números mostrados en la pantalla, simplemente oprimiendo el botón “DIAL.” Utilice los botones “PREVIOUS” o “NEXT” para mostrar el número del Identificador de Llamadas que usted quiere marcar.
AMBIAR EL ORMATO PARA LAMADO Puede ser necesario cambiar el formato del número que va ser marcado, antes de utilizar la función para regresar el llamado (Dial Back). Utilice los botones “PREVIOUS” o “NEXT” para mostrar el número del Identificador de Llamadas que usted quiere marcar.
Page 80
Oprima nuevamente el botón “DIAL.” Después de una breve pausa, el número se marca automaticamente y la indicación “PICK UP PHONE” aparece en la pantalla. Levante una extensión del teléfono para conectar la llamada. NOTA: Para cancelar la función de regresar el llamado (“Dial Back”), oprima el botón “PLAY/ STOP”...
OLUCIÓN DE ROBLEMAS Problema No contesta, contesta al décimo timbre Los mensajes entrantes están incompletos No responde a los comandos de larga distancia • Debe usar un teléfono de teclado (touch-tone) . Explicación/ Solución • Asegúrese de que el contestador está activado. •...
Page 82
Problema No programa El contestador no funciona No puede escuchar los mensajes No puede volver a comenzar un mensaje El saludo continúa reproduciéndose incluso después de que se levanta Explicación/ Solución • Asegúrese de que está en la función de programación oprimiendo y soltando el botón “MENU”.
Page 83
EMOTE CCESS Sistema Digital de Mensajes Marque el número telefónico Inscriba el código de seguridad de 3 dígitos Inscriba el comando de teclado (touch-tone) Cuelgue Escriba su código de seguridad de 3 dígitos en las cajas. Para: 2-9993 Reproducir mensajes Reproducir menú...
Page 85
UIDADO GENERAL DEL PRODUCTO Para mantener su contestador funcionando bien y con buena apariencia, observe las siguientes pautas: • Evite poner el teléfono cerca de calentadores (calefactores) de ambiente y dispositivos que generen interferencia eléctrica ejemplo, motores o lámparas fluorescentes). •...
Page 86
NDICE Acceso Remoto 28 Ahorrador de Cargos 18 Antes de Comenzar 5 Cómo obtener servicios de mantenimiento 41 Cuidado general del producto 41 Funciones del Identificador de Llamadas (Caller ID 30 Garantía limitada 44 Hora 12 Identificador de Llamadas con Llamada en Espera 31 Información de Interferencias 3 Información Del Registro a la FCC 2...
Page 87
Para Borrar Mensajes 25 Para Cambiar el Formato para Regresar el Llamado 35 Para Contestar el Llamado (Dial Back) 34 Para Dejar un Recado 27 Para Grabar el Saludo 7 Para Programar el Código de Seguridad 20 Para Programar el Contraste de la Pantalla 16 Para Programar el Día/ Hora 11 Para Programar el Número de Timbres para Contestar 17...
Page 88
• Asegure su paquete contra pérdida o daños. Thomson no acepta responsabilidad en caso de daños o pérdida durante el trayecto a Thomson. Modelo 29993 15481430 (Rev. 1, E/S) 99-38 Impresso en China •...
