In the event that service should be required, you may need both the model number and the serial number. In the space below, record the date and place of purchase, and the serial number: Model No. RV-9968/RV-9978 Remote Control No. CRK67G...
Table of Contents first things first ... unpack the receiver ... basic connections... connecting, placing & balancing the speakers ... connecting the antennas ... connecting for power ... using headphones ... receiver controls & operations ... general controls ... display messages ... tuning the receiver ...
• two packs - one pair each - of AAA batteries; • one audio cable (two wires) with red and white RCA connectors; • one video cable (single wire) with yellow RCA connectors; • one external, detachable FM T-type antenna;...
first things first Connecting, Placing & balancing The speakers Connecting the wires Each speaker - the two main, two surround and one central - has a designated set of terminals on the back panel of the central unit. Uncoil the speaker wires and locate the bare ends. Press and hold down on the tab to open the red terminal, then insert the red (+) wire.
Page 6
First Things First 2. Aim the speakers directly at the two main speakers, matching height to height. If the room is sparsely decorated, it may be necessary to slightly tilt the speakers down to increase sound quality. If the room is densely decorated, it may be necessary to face the speakers toward the rear wall or at the ceiling.
First Things First Each time you press the + or - button on your remote control to adjust a channel, the receiver provides you with two more seconds of pink noise to that channel before moving on to the next. 4.
receiver controls & operations POWER TUNING SPEAKERS PRESET SCAN AUTO PRO LOGIC VIDEO PHONES general controls POWER STAND BY/ON The POWER STANDBY/ON button activates or deactivates the system. When the system is activated, the unit will default to the last mode it was in before power was removed.
receiver controls & operations WIDE The WIDE mode can be activated in both the Pro Logic and the 3 Stereo modes. This mode utilizes just the three front speakers - left main, right main and center - with all audio delivered through the center speaker.
receiver controls & operations To Store a Station 1. Press the FM/AM button on the receiver (or the AM•FM button on the remote) to turn on the receiver. 2. Select the band—FM or AM. 3. Select the station you want to store in memory using the methods described above.
Speaker Terminals Red for positive (+) terminals. Black for negative (-) terminals. RCA Phono Type Terminals Red for the right (R) channel. White for the left (L) channel. Yellow for the video (V). Black for the subwoofer.
If your camcorder or video camera does not have an VOLUME RCA-type terminal for audio/video, you can purchase an adapter from an RCA dealer or electronic parts store. If the video connection is being used when you try to TAPE...
connecting auxiliary components connecting a compact disc player Using one paired (red/white) stereo cable, connect your new receiver to your compact disc player as shown to the right. To play a CD, press CD, put the receiver in CD mode and press PLAY.
connecting auxiliary components the ultimate connection Should you choose to utilize your new receiver to its fullest potential by running all your audio components through it, you will need purchase additional connectors. How many and what kind is purely situational. The following is a complete description of all the jacks on the back of the receiver and how they can be utilized to provide greater enjoyment.
Page 15
connecting auxiliary components Step 3: Connecting your receiver to your TV Using audio cables, connect the left and right “OUT” audio jacks on the back of your TV to the TV audio jacks on the back of your receiver. CABLE ANTENNA IN FROM ANT OUT TO TV...
3. Replace the cover. Basic Controls Your remote control is capable of operating most RCA audio and video equipment. To use the remote control effectively, always aim it directly at your receiver. POWER Turns the AM/FM receiver off with two presses.
Page 17
Number Buttons Let you enter numbers when needed. REV Lets you manually move down the AM/FM band. TV Controls + On some RCA TV models, used to adjust menu controls. – On some RCA TV models, used to adjust menu controls.
MOVE arrows Lets you point to different on-screen menu items. Number Buttons Let you enter numbers when needed. POWER Turns the RCA DSS ® receiver off. CD Player Controls CD Turns on the CD player and puts the remote in CD mode.
You can program the remote to control most brands of remote controllable TVs, VCRs and cable boxes. If you have an RCA, GE or ProScan VCR, you may not need to program the remote at all. Other manufacturer’s brands need to be programmed.
2. Look up the brand and its code number(s) in the code list. 3. Press and hold the LD•VCR2 button on the remote. 4. Enter the three-digit code from the code list. Laserdisc Player Codes Pioneer ... 033, 037 ProScan ... 033, 037 RCA ... 033, 037...
PROGRAMMING THE REMOTE TO CONTROL A DVD PLAYER The remote is preprogrammed to control a RCA DVD player. A few of the remote buttons used with a DVD player are shown below. You may want to experiment with other buttons on the remote to see if they work with your DVD player.
Disconnect the system from AC power before cleaning the exterior of the system with a soft dust cloth. Equipment Specifications AMPLIFIER SECTION Left/Center/Right (at 8 RV-9968 20 watts/20 watts/20 watts RV-9978 50 watts/50 watts/50 watts 0.9% THD @ 1 KHz Rear Surround (at 16...
limited warranty What your warranty covers: • Any defect in materials or workmanship. For how long after your purchase: • One year. (The warranty period for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first.) What we will do: •...
Page 30
En los siguientes espacios en blanco, anote la fecha y el lugar en que efectuó la compra y el número de serial de su unidad: Modelo No. RV-9968/RV-9978 Control Remoto No. CRK67G...
Page 31
INDICE Introducción ...4 Desembale del receptor ... 4 Conexiones básicas ... 4 Conexión, posición y ajuste de los altavoces ... 5 Conexión de las antenas ... 7 Conexión a la fuente de alimentación ... 7 Utilización de los audífonos ... 7 Controles y funcionamiento del receptor ...
Desembale el receptor e identifique todos los accesorios. Usted debería tener; • un aparato receptor: • un control remoto universal RCA (CRK67G) • dos paquetes - un par cada uno - de pilas AAA; • un cable para audio (dos alambres) con conectores rojos y blanco RCA;...
Introducción Conexión, posición y ajuste de los altavoces Conexión de los cables Cada altavoz - los dos principales, los de sonorización periférica y el central - tiene un juego definido de terminales en el panel trasero de la unidad central. Desenrolle los cables de los altavoces hasta encontrar los extremos desnudos.
Page 34
Introducción A continuación se dan algunas sugerencias para instalar el equipo: 1. Instale los altavoces en un muro lateral, uno frente al otro, aproximadamente a unos tres pies (90 cm) por encima de la cabeza del oyente. 2. Oriente los altavoces directamente hacia los dos altavoces principales, igualando alturas.
Introducción 2. A medida que se genera el ruido rosado, vaya al lugar de la sala donde probablemente se instale para escuchar su sistema. El altavoz de sonorización periférica posterior y el altavoz central deberían equilibrarse para igualar el nivel de potencia de salida de los altavoces principales izquierdo y derecho.
Controles y funcionamiento del receptor POWER TUNING REMOTE SENSOR SPEAKERS PRESET SCAN AUTO PRO LOGIC VIDEO PHONES Controles generales Encendido/disponible La tecla POWER STAND BY/ON (encendido/disponible) enciende y apaga el sistema. Cuando el sistema se prende, la sistema vuelve al último modo de funcionamiento utilizado antes de apagarse.
Controles y funcionamiento del receptor Wide (completo) Este modo puede activarse en Pro Logic y 3 Stereo. Este modo utiliza los tres altavoces centrales - principal izquierdo, principal derecho y central - y todo el sonido sale por el altavoz central. El altavoz central reproducirá...
Controles y funcionamiento del receptor Programación de emisoras en la memoria Usted puede programar hasta 30 emisoras de AM y FM, que pueden guardarse en forma aleatoria. Para programar una emisora 1. Oprima la tecla FM/AM del receptor (o la tecla AM*FM del control remoto) para encender el receptor.
Terminales de los altavoces: rojo para los terminales positivos (+), negro para los negativos (-). Terminales de audio RCA: rojo para el canal derecho (R), blanco para el canal izquierdo (L), amarillo para el video (V), negro para subgraves (no incluido).
RCA para audio/video, compre un adaptador en un VOLUME distribuidor de RCA o en una tienda que venda piezas electrónicas. si la conexión del video se utiliza cuando está tratando TAPE...
Conexión de los componentes auxiliares Conexión de un lector de discos compactos Con un cable de estéreo de dos colores (rojo/blanco) conecte su nuevo receptor de audio al lector de discos láser, tal como se indica a la derecha. Para escuchar un DC, oprima CD, ponga el receptor en el modo CD y luego oprima la tecla PLAY (reproducción).
Conexión de los componentes auxiliares Ultima conexión Si decidiera utilizar su nuevo receptor al máximo haciendo funcionar todos los componentes de audio, necesitará comprar conectores adicionales. El número y la clase dependerá de las circunstancias personales. Consulte la hoja sobre accesorios que viene con este aparato. A continuación se da una descripción completa de todos los jacks que se encuentran en la parte posterior del receptor y la manera de utilizarlos para que brinden el máximo placer.
Page 43
Conexión de los componentes auxiliares Tercer paso: conexión del recep- tor al televisor Con los cables de audio, conecte los jacks de audio derecho e izquierdo OUT e IN de la parte posterior del TV a los jacks de audio TV de la parte posterior del receptor.
3. Vuelva a colocar la tapa. Controles básicos Con este control remoto puede hacer funcionar la mayoría de los aparatos de audio y video RCA. Para lograr que sea eficaz, siempre apunte con el control remoto directamente al receptor. POWER (encendido/apagado): apaga el receptor de AM/FM con sólo oprimir dos vez.
PIP (imagen dentro de la imagen): hace aparecer y desaparecer la imagen dentro de la imagen en la mayoría de los modelos de TV de RCA que tienen esta función. POWER (encendido/apagado): apaga/enciende el televisor.
Page 46
MOVE (flechas de movimiento): permite señalar diferentes elementos del menú. Teclas numéricas: permiten teclear los números de los canales, cuando es necesario. POWER: apaga/enciende el receptor DSSMR RCA. Controles del lector de discos compactos CD (DC): enciende el lector de discos compactos y pone el control remoto en este modo.
Es posible programar el control remoto para controlar la mayoría de las marcas de televisores, VCR y cajas de cables controlables a distancia. Si usted tiene un VCR RCA, GE o ProScan, es posible que no necesite programar el control remoto. Las otras marcas deben programarse.
Page 48
Control remoto universal 2. Busque la marca de su VCR y el código numérico en la lista de códigos en la siguiente página o en la hoja de códigos que viene con su control remoto. 3. Mantenga oprimida la tecla VCR del control remoto.
Page 49
El control remoto está programado para controlar un lector de discos digitales de video RCA. A continuación se muestran algunas teclas del control remoto que se utilizan con un lector de este tipo. Usted puede experimentar con otras teclas del control remoto, para ver si funcionan.
Indice temático Agudos 8 Altavoces 8 Altavoces centrales 5 Altavoces de sonorización periférica 5 Altavoces principales 5 Altavoz para sonidos subgraves Antes de hacer la conexión... 11 Audífonos 9 Barrido preseleccionado 8 Barrido programado 10 BYPASS 9 Cambio de audio 10 Codigos para el control remoto de tv 22 Codigos para el control remoto...
Garantía limitada Su garantía cubre: • Todo defecto de materiales o mano de obra Vigencia de la garantía: • Un año a partir de la fecha de compra (El período de la garantía para los aparatos de alquiler comienza el primer día de alquiler 0 45 días a partir de la fecha de envío a la empresa de alquiler, cualquiera sea la fecha que cae primero.) Responsabilidad de la compañía:...
