- Page 1 PLASMA DISPLAY TV Chassis : D62B Model: PPM50H3QX/EDC SERVICE Manual PLASMA DISPLAY TV C O N T E N T S Specifications Alignment and Adjustments Exploded View and Parts List Service Item Schematic Diagrams...
-
Page 2: Specifications
External Speaker (10W+10W) AUDIO Output Audio Output (L/R RCA) VIDEO S-VIDEO COMPONENT 1 - 480i / 480p / 720p / 1080i VIDEO Input COMPONENT 2/RGB2(PC) IN (BNC, 5P, 480i~1080i, VGA~XGA) RGB1(PC1) - D-SUB 15P Monitor Output (RCA) VIDEO Output Samsung Electronics... - Page 3 MEMO Samsung Electronics...
-
Page 4: Service Mode
To increase and decrease the data of the selected items (ENTER) Confirm your choice(Store OR Enter) TV/VIDEO Button Change input source * While in Tuner mode, the direct access buttons can be used to select and change channels. Samsung Electronics... - Page 5 - Excute factory mode auto color to adjust gain and offset. - Load the Toshiba Pattern.(Pattern #16) and then adjust W/B. ♣ ♣ When factory mode auto color is executed, gain and offset value is adjusted automatically. Samsung Electronics...
- Page 6 - Component(DTV) - Auto Color Port (A-RGB) value(RGB) DTV Mode SIL169 (D-RGB) Different adjustment values will be applied to DVI, PC ,DTV(Component) and Video, mode. 2-2-2(A) White Balance Coordinates by Mode(Europe) VIDEO Component Y(fL) 38.5 38.5 38.5 38.5 Y(fL) Samsung Electronics...
-
Page 7: Factory Data
05. Y/C Delay Y/C Delay Setting according to the System and Input Modes √ 06. Motion Motion Enhancing Adjustment √ DNIe Registers 07. DNIe √ 08. Logic Logic Registers of the Panel √ Picture Size Registers 09. Picture Size Samsung Electronics... - Page 8 08.Sub Brightness 09.R Gain 10.G Gain 11.B Gain 12.R/Cr Offset AD9883 13.G/Y Offset 14.B/Cb Offset Ο Ο 15.Auto color on/off Input modes require respective storing the changes after adjustment. 01~06 : Logic 07~08 : DNIe 09~15 : AD9883 Samsung Electronics...
- Page 9 02.Tint VPC3230 03.RGB/YUV U-SAT 04.RGB/YUV V-SAT 05.RGB/YUV Tint FLI2310 06.FLI-saturation 07.R Gamma ASI510 08.G Gamma 09.B Gamma 10.Gain-Sel 11.Cr Gain CXA2151Q 12.Cb Gain 13.Y Gain 01 ~05 : VPC3230 07~09 : ASI510 06 : FLI2310 10~13 : CXA2151 Samsung Electronics...
- Page 10 03.Cont/Bri Enhancement Mode-1 Mode-2 Mode-3 Mode-4 01.Contrast 02.Brightness VPC3230 03.RGB/YUV Contrast 04.RGB/YUV Brightness 05.FLI-Contrast FLI2310 06.FLI-Brightness 07.R Contrast 08.G Contrast 09.B Contrast ASI510 10.R Brightness 11.G Brightness 12.B Brightness 01~04 : VPC3230 07~12 : ASI510 05~06 : FLI2310 Samsung Electronics...
- Page 11 Initial Values of Input Modes ITEM Relevant IC Video Component 04.Detail Enhancement Mode-1 Mode-2 Mode-3 Mode-4 01.VAPGAIN 02.VAPINV uPD64083 03.YPFT 04.YPFG 05.Peaking 06.Peaking Filter 07.Coring VPC3230 08.HPLL_ERR_MIN 09.HPLL_ERR_MAX 10.V_SLICER 11.HenhGain 12.HLEGain FLi2310 13.HChrEnGain 01~04 : uPD64083 05~10 : VPC3230 11~13 : FLI2310 Samsung Electronics...
- Page 12 12~13 : FLI2310 01.Picture Improve => 06.Motion Enhancing Adjustment Initial Values of Input Modes ITEM Relevant IC Video Component 06.Motion Mode-1 Mode-2 Mode-3 Mode-4 01.HPLL Speed-1 VPC3230 02.Auto Lock 03.V-motion Tresh FLi2310 01 ~ 02 : VPC3230 03 : FLI2310 Samsung Electronics...
- Page 13 13. CTI GAIN 14. DE NOISE GAIN 15. TH CORING 16. PATT SEL 17. NOISE TH2 18. H CONT 19. V CONT 20. BLACK GAIN 21. WHITE GAIN 22. WTE GAIN 23. CTE GAIN 01~23 : DNIe 2-10 Samsung Electronics...
- Page 14 03.B DRIVE 04.R CUTOFF 05.G CUTOFF 06.B CUTOFF 07.GAMMA 08.GTS SET Logic 09.ERD MODE 10.RANDOM NOISE 11.DIFF FILTER 12.APC 13.APC SET 14.APC VALUE 15.ACTIVE VPOS 16.ACTIVE HPOS 17.VSYNC POS 18.HSYNC POS 19.VSYNC WIDTH 20.HSYNC WIDTH 01~20 : Logic Samsung Electronics 2-11...
- Page 15 03. Movie 04. Custom 02.Initial Setting => 02.P-Mode Value 02. P-Mode Value Current Input Mode √ Available options for the PC/DVI Mode are High,Middle, 01. Dynamic Low and Custom. √ 02. Standard √ 03. Movie √ 04. Custom 2-12 Samsung Electronics...
- Page 16 Available Settings for the PC Mode are 02.Initial Setting Current Input Mode Custom,Color Tone 1, Color Tone 2, Color Tone 3 01. Cool2 02. Cool1 Available options for the DVI Mode are 03. Normal ColorTone1, ColorTone2, ColorTone3 04. Warm1 05. Warm2 Samsung Electronics 2-13...
- Page 17 11. TTX CONT Center Center Center Center Center SDA6001 12. TTX BRIGHTNESS Center Center Center Center Center 13.LOG PATTERN Logic 14.LOG HIGH LEVEL ASI510 15.LOG LOW LEVEL 16.ASI COLORBAR 01~10 : ASI510 11~12 : SDA6001 13~16 : Logic, ASI510 2-14 Samsung Electronics...
- Page 18 -. ATM available region : On -. ATM non-available region : Off -. ATM at the time of OFF one from Funtion item the Country is changed with the Area and the ATM is changed with auto search. Samsung Electronics 2-15...
- Page 19 * In the initial stage of the Operational Inspection, DDC Write is enabled (DDC Write is ON). DDC Write is disabled (DDC Write is OFF) after the Factory Reset. * To enable DDC Write at a later time, enter Factory Mode and set this menu to ON. 18. Initial Write 2-16 Samsung Electronics...
- Page 20 05. Number Range œ 4 √ 06. Line Range œ On √ 07. Temp Protection œ On √ 08. DNIe DEMO œ 21 √ 09. PILOT HIGH œ 16 √ 10. PILOT LOW œ 0000 √ 11. CHECKSUM Samsung Electronics 2-17...
- Page 21 MEMO 2-18 Samsung Electronics...
- Page 22 Exploded View & Parts List 3. Exploded View & Parts List 3-1 PPM50H3QX/EDC You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr Code No Description;Specification Q’ty Remark BN96-00172Q ASSY COVER P-FRONT;50P3H(VMB),ASIA,HIPS M0003 BN64-00098N CABINET-FRONT;50P3 VMB,HIPS,HB,HF-1690H, T0003 S.N.A...
-
Page 23: Service Item
Electrical Parts List 4. SERVICE ITEM You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr Loc. Code No Description;Specification Q’ty S.N.A D0254 AA32-00013B MODULE REMOCON;346HF5,38KHz,940mm,MESH,H T0074 BN59-00366A REMOCON;TM76,D61A,42,G6148,PPM42S3,EX T0055 BN64-00125A SCREEN-EMI,FITER;FILTER,50P3,T47%,1155+6 T0098 BN94-00494C ASSY PCB MISC-CONTROL;SPD-50P3H,D56A/D59... - Page 24 Electrical Parts List MEMO Samsung Electronics...
-
Page 25: Schematic Diagrams
Schematic Diagrams 5. Schematic Diagrams 5-1 SCART This Document can not be used without Samsung’s authorization. R1540 NTSC : 2007-001010 (51K) PAL : 2007-000097 (47K) R110 NTSC/PAL ADD OPTION R1541 NTSC : 2007-000097 (47K) PAL : 2007-000130 (39K) BD1401,C1432 LNA OPTION... - Page 26 Schematic Diagrams 5-2 VIDEO SW This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 27 Schematic Diagrams 5-3 3D COMB This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 28 Schematic Diagrams 5-4 VPC3230 FLI2310_MAIN DEINTERLACE This Document can not be used without Samsung’s authorization. VOUT +5V_VPC HOUT +3.3V_R L402 3.3UH C401 C402 HC-49/SM5H(20.25MHz) 100uF 100nF C403 C404 10pF X401 C405 100nF 100uF R401 C408 R402 C409 R403 R404 10pF...
- Page 29 Schematic Diagrams 5-5 PCIN_9883_2151 This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 30 Schematic Diagrams 5-6 DVI_SIL169 This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 31 Schematic Diagrams 5-7 FLI2310 This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 32 Schematic Diagrams 5-8 ASI510 This Document can not be used without Samsung’s authorization. ASI510 Samsung Electronics...
- Page 33 Schematic Diagrams 5-9 SDA6001 This Document can not be used without Samsung’s authorization. Samsung Electronics...
- Page 34 Schematic Diagrams 5-10 DNIe2 This Document can not be used without Samsung’s authorization. 5-10 Samsung Electronics...
- Page 35 Schematic Diagrams 5-11 JACK INPUT This Document can not be used without Samsung’s authorization. Samsung Electronics 5-11...
- Page 36 Schematic Diagrams 5-12 POWER This Document can not be used without Samsung’s authorization. 5-12 Samsung Electronics...
- Page 37 Schematic Diagrams 5-13 AUDIO This Document can not be used without Samsung’s authorization. NSP6241 Samsung Electronics 5-13...
- Page 38 ELECTRONICS © Samsung Electronics Co., Ltd. May. 2004 This Service Manual is a property of Samsung Electronics Co.,Ltd. Printed in Korea Any unauthorized use of Manual can be punished under applicable AA82-01607A International and/or domestic law.
