Remote Controller
• Applicable Model
Main
Remote controller
* Up to three remote controllers can be connected. Additional remote controllers cannot be con-
nected by themselves.
The remote controller must be installed in accordance with the installation manual enclosed in the
•
package.
KM3211WHQ cannot be used without a remote controller (main appliance body only).
•
Changing the temperature for operation of the main body
Can be used without the remote controller (main appliance only). The hot water temperature on
the RCM3211 can be switched between four settings (75, 60, 50, & 40°C).
Refer to the following for the setup method. When 75 or 60°C is set, the water is very hot, so
make sure that a mixing valve is installed.
Press the [
] or [
] button on the remote controller prior to switching on the controller. Changes
•
must be made within 10 minutes of the power being supplied to the unit. If the display does not
switch to maintenance mode despite pressing the [
repeat the above procedure.
The item number and data are shown as well as "Maintenance". (Initial setting for the item number
•
is "99".)
When the [
] button is pressed, the "99" displayed will change to 10, 11, ....,1F, 20, 21, etc..., and
•
conversely when the [
27, etc...
• 14 and 15 are set as per procedure 3. When the setup switch is pressed, "ON" or "OFF" blink.
Item No.
Temp.
40°C
50°C
60°C
75°C
• Press [
] button to switch between ON and OFF.
Note: The setting changes can be cancelled by pressing the Power On/Off button before confirming
the settings, or if the unit is left alone for ten minutes without confirming the settings. If the
default setting needs to be changed again, disconnect the electrical power to the unit, recon-
nect it and follow this procedure again.
• Once setup is complete, press the [
while the item number is blinking. Once completed, a buzzer sounds. (The modified setup will not be
recorded unless this step is performed.)
KM3211WH
RCM3211
] button is pressed, the "99" displayed will change to 10, FF, FE, FD, FC,
14
15
ON
ON
OFF
ON
* Factory Default Setting
OFF
OFF
ON
OFF
] and [
] buttons simultaneously for at least five seconds
KM3211WHQ
RCM3211 (included)
] or [
] buttons, unplug the power and
67
