- Page 1 Product Manual—Wireless Video Bridge Gen2 DIRECTV WIRELESS ® VIDEO BRIDGE GEN2 Product Manual Version 1.0 10/2017...
- Page 2 Product Manual—Wireless Video Bridge Gen2 Introduction Product Manuals are intended to help customers understand the workings of the hardware devices. This Product Manual is posted online at att.com and at directv.com/manuals for customer access. The purpose of this document is to communicate information associated with the Wireless Video Bridge Gen2 and to provide an overview addressing specific functions of the device.
-
Page 3: Table Of Contents
V. Installation Options ..........................10 A. Tabletop Installation ............................................10 B. Wall Mount Installation ............................................10 VI. Troubleshooting ............................12 A. WVB2 LED Troubleshooting .......................................... 12 VII. Appendix ............................... 13 A. Federal Communications Commission Interference Statement ........................ 13 B. Safety & Care ................................................14 C. - Page 4 Product Manual—Wireless Video Bridge Gen2 Terminology Term Description Wireless Video Bridge Version 1.0 10/2017...
-
Page 5: Overview
WVB Gen1 and has enhanced networking features. The WVB2 provides the ability to stream DIRECTV programming from a Genie server to the Genie Mini (C41W or higher) client wirelessly, creating a private network only accessible to DIRECTV products. This allows for video distribution throughout the home without the use of coaxial or CAT5 cables at every TV. -
Page 6: Hardware Information
The front panel contains: • Multicolor status indicator LED The WVB2 is to be installed vertically (it is not to be placed in a horizontal position). The WVB2 can be wall-mounted using the mounting bracket provided. When using the mounting bracket, the WVB2 should remain positioned upright (not upside down). -
Page 7: Rear Panel
Product Manual—Wireless Video Bridge Gen2 2. Rear Panel FIGURE 2: WVB2—REAR PANEL The rear panel contains: • Red reset button • Add Client button • Ethernet port • Two satellite in F connectors • DC power inlet connector matching EPS10 external power supply •... -
Page 8: Figure 3: Wvb2-Side View
Product Manual—Wireless Video Bridge Gen2 FIGURE 3: WVB2—SIDE VIEW WVB2 Specifi cations Size and Weight • Height: 182mm • Width: 190mm • Depth: 182mm • Weight: 12.05 oz. FIGURE 4: EPS10 POWER SUPPLY Version 1.0 10/2017... -
Page 9: Minimum Requirements
Product Manual—Wireless Video Bridge Gen2 III. MINIMUM REQUIREMENTS The minimum requirements for a Wireless Video distribution are: • SWiM installation • Genie server (HR34/HR44/HR54/H44+HDD) • Wireless Video Bridge • At least one wireless Genie Mini Client • EPS10 (DC 25.2V) External Power Supply Version 1.0 10/2017... -
Page 10: Features
Product Manual—Wireless Video Bridge Gen2 IV. FEATURES Functionally, the WVB Gen2 is identical to the WVB Gen1 with the exception of the following features: A. 802.11AC SUPPORT 802.11ac is the latest IEEE Wi-Fi® standard, which provides increased bandwidth and additional throughput over increased range compared to 802.11n (on which WVB Gen1 is based). -
Page 11: Figure 7: Slots For Mounting
Product Manual—Wireless Video Bridge Gen2 V. INSTALLATION OPTIONS continued B. WALL MOUNT INSTALLATION continued 1. Determine location. a. Ensure that the mounting location is free from hazards such as electric cables, wires, pipes, ducts, etc. 2. Drill pilot holes. a. If mounting in a stud partition wall: Locate the studs in the wall. At least one of the mounting screws should be attached to a wooden stud. -
Page 12: Troubleshooting
No MoCA network established Blinking Green Wireless Client Add Mode and Blue Solid Red The WVB2 has a good connection to the Genie server; however, there is a poor wireless connection to one or more wireless clients (C61W) Blinking Red Device error detected Version 1.0 10/2017... -
Page 13: Appendix
Product Manual—Wireless Video Bridge Gen2 VII. APPENDIX A. FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 14: Safety & Care
Product Manual—Wireless Video Bridge Gen2 B. SAFETY & CARE As part of our ongoing commitment to help conserve energy and reduce waste, we have made user manuals available online where you can conveniently access them at any time. Please go to att.com or directv.com/manuals Your DIRECTV®... - Page 15 Product Manual—Wireless Video Bridge Gen2 • Ensure proper ventilation—the vent slots on the DIRECTV® Receiver must be left uncovered to allow proper airflow to the unit. Blocking the airflow WARNING: To reduce the risk of fire or electronic to the unit could impair performance or damage your receiver and other shock, do not expose this product to rain or moisture.
-
Page 16: Caution-Additional Safety Instructions
Product Manual—Wireless Video Bridge Gen2 C. CAUTION—ADDITIONAL SAFETY INSTRUCTIONS The WVB2 requires the UL Listed EPS10-15 or EPS10-36 External Power Supply having the following rating: Input rating 120Vac, 60Hz, 1.8A, output rating 25.2Vdc, 2.86A, 72W. D. LIMITED 90-DAY WARRANTY DIRECTV warrants your DIRECTV® Receiver and any included accessories against defects in material or workmanship for a period of ninety (90) days after the date of acquisition. - Page 17 Product Manual—Wireless Video Bridge Gen2 DIRECTV makes no warranty that the access connection will be a local (not long distance) phone call. The continued provisioning of any of the programming and other services delivered through the Receiver including but not limited to television programming, show information, program guide data, and scheduling information.
