Raypak
®
RHP Series
Swimming Pool and
Spa Heat Pump
OWNER and
INSTALLATION MANUAL
Models
RHP 100
RHP 115
RHP 160
(800) 260-2758
R
C
US
9900276
Part No. 00-02101D
Advertisement
Table of Contents
Related Manuals for Raypak RHP100
Summary of Contents for Raypak RHP100
- Page 1 P ers ons not qualified s hall not attempt to ins tall, s ervice, or maintain this equipment. Developed and printed in U.S.A. Raypak ® RHP Series Swimming Pool and...
- Page 2 This Warranty is VOID if the product is repaired or altered in any way by ANY persons or agencies other than those authorized by Raypak. CONTACT INFORMATION Raypak, Inc., 2151 Eastman Ave., Oxnard, CA 93030 Recognize this symbol in the manual as an indication of...
-
Page 3: Table Of Contents
RHP Series Swimming Pool and Spa Heat Pump OWNER and INSTALLATION MANUAL CONTENTS Introduction............. 1 I. -
Page 4: Introduction
Introduction This pool/spa heat pump is an electromechanical machine that incorporates a pressurized refrigerant gas in a sealed system. ONLY trained and qualified service personnel should attempt to install or service this equipment. Without proper training and knowledge of such equipment, any attempt to install or service the unit could result in serious injury or even death. -
Page 5: Electrical Connections
• Each side of the unit must be located at least 1 ft from walls, pipes, or other obstructions for unrestricted air intake and service access. Do not install the unit within 3 ft of fossil fuel burning heaters. Air intake along the sides of this heat pump could disturb the combustion process of the unit, and could cause damage or personal injury. -
Page 6: Water Connections
III. Water Connections The heat pump inlet and outlet connections are NOT interchangeable. They must be connected as instructed below. 1. Connect the heat pump in the return water line between the pool filter and the pool. See page 10, Plumbing Diagrams. 2. -
Page 7: Initial Start-Up And Check
Indicator Lamps: There are 6 indicator lamps located on the unit control panel: • (amber lamp): When lit, indicates power is applied to the unit. Power NOTE: The heat pump will not run when the Remote position is selected and there is no remote control system attached. •... -
Page 8: Seasonal Start-Up Or Annual Check
Spa thermostat Pool/Spa selector switch Pool thermostat VI. Seasonal Start-Up or Annual Check 1. Remove leaves, pine needles, etc. from the evaporator coil. Clean the coil by spraying it with a mild solution of household liquid soap and water. 2. Flush the coil with a garden hose; DO NOT use a high-pressure sprayer. 3. -
Page 9: Summer Shutdown
VIII. Summer Shutdown If you do not plan to use the pool heat pump during the summer months, secure and protect it as follows: 1. From the control panel, turn the control switch to 2. Turn the heat pump circuit breaker or disconnect switch to OFF. 3. -
Page 10: Troubleshooting
To clean the fins, spray with a garden hose. But avoid high water pressure, which will bend and damage the fins. B. Cabinet Care (optional) - The cabinet is designed for outdoor use and requires little care. However, you can clean it if you wish. Shut OFF electricity to the heat pump. - Page 11 operation. After the desired temperature is reached, return the system to normal operation of 8-10 hours per day. • Is airflow through the unit being obstructed? Restrictions such as shrubbery, tall grass, dirty coils, or any other obstruction to airflow will reduce performance. •...
- Page 12 POWER SUPPLY • Verify that all circuit breakers are reset and working properly. • If the lamp on the control panel still does not light, contact the installing dealer, Power since it may be a power problem requiring an electrician. WATER FLOW •...
-
Page 13: Plumbing Diagrams
Plumbing Diagrams Water In (from pool or Spa) For systems with pumps of less than 2 HP (under 80 gpm), no external bypass is required. Connections are 2-inch pipe slip. Plumb the heat pump after the filter and before any chlorinators. Water In (from pool or Spa) -
Page 14: Heat Pump Schematic
Heat Pump Schematic Pink Coil Coil... -
Page 15: Control Panel Assembly Replacement Parts List
Control Panel Assembly Replacement Parts List ITEM QTY DESCRIPTION Control Panel Contactor Compressor Fan Relay Control Board 24Volt Thermostat Transformer Timer IMC 203 Capacitor Pressure Switch Water Fuse Block Bushing Heyco 2184 Stand-off RLCBSR1 Terminal Strip Clamp Capacitor 04 Ground Lug Fuse 2A Type 3AG PART No. -
Page 16: Control Panel Cover Assembly Replacement Parts List
Control Panel Cover Assembly Replacement Parts List ITEM QTY DESCRIPTION Control Panel Cover Switch Type A403 Knob Label Control Panel Lamp Green Lamp Red Lamp Amber Front Back PART No. 81-30152 50-10004 50-10005 56-10001 84-10017 53-10001 53-10003 53-10002 RHP Control Panel Cover... -
