YASKAWA AQ6370B User Manual

Optical spectrum analyzer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's
Manual
AQ6370B
Optical Spectrum Analyzer
IM 735302-01E
1st Edition

Advertisement

Table of Contents
loading

Related Manuals for YASKAWA AQ6370B

Summary of Contents for YASKAWA AQ6370B

  • Page 1 User’s Manual AQ6370B Optical Spectrum Analyzer IM 735302-01E 1st Edition...

  • Page 2: Product Registration

    Product Registration Thank you for purchasing YOKOGAWA products. YOKOGAWA provides registered users with a variety of information and services. Please allow us to serve you best by completing the product registration form accessible from our homepage. http://www.yokogawa.com/tm/ PIM 103-02E...
  • Page 3 For correct operation, please read this manual thoroughly before use. After reading this manual, keep it in a convenient location for quick reference in the event a question arises during operation. There are two manuals for the AQ6370B including this one. Read them along with this manual.

  • Page 4: Checking The Contents Of The Package

    MODEL Suffix Code Description 735302 Optical Spectrum Analyzer AQ6370B Power cord UL/CSA standard power cord (part no.: A1006WD), maximum rated voltage: 125 V VDE standard power cord (part no.: A1009WD), maximum rated voltage: 250 V AS standard power cord (part no.: A1024WD),...

  • Page 5: Safety Precautions

    Safety Precautions This instrument is an IEC safety class I(provided with terminal for protective earth grounding). The general safety precautions described herein must be observed during all phases of operation. If the instrument is used in a manner not specified in this manual, the protection provided by the instrument may be impaired.
  • Page 6 Safety Precautions Make sure to comply with precautions below. Not complying might result in injury or death. WARNING • Use the Correct Power Supply Before connecting the power cord, ensure that the source voltage matches the rated supply voltage of the instrument and that it is within the maximum rated voltage of the provided power cord.

  • Page 7: Operating Environment

    Safety Precautions Safety Precautions for Laser Products This instrument uses a laser light source. This instrument is a Class 1 laser product as defined by IEC 60825-1 Safety of Laser Products-Part 1: Equipment Classification, Requirements and User’s Guide. Laser Class 1 Label If the laser output is observed at a distance of CLASS 1 LASER PRODUCT 100mm or less from the laser beam emitting...

  • Page 8: Waste Electrical And Electronic Equipment

    Waste Electrical and Electronic Equipment Waste Electrical and Electronic Equipment (WEEE), Directive 2002/96/EC (This directive is only valid in the EU.) This product complies with the WEEE Directive (2002/96/EC) marking requirement. This marking indicates that you must not discard this electrical/ electronic product in domestic household waste.

  • Page 9: Conventions Used In This Manual

    Conventions Used in This Manual Safety Markings The following markings are used in this manual. Improper handling or use can lead to injury to the user or damage to the instrument. This symbol appears on the instrument to indicate that the user must refer to the user's manual for special instructions. The same symbol appears in the corresponding place in the user's manual to identify those instructions.

  • Page 10: Flow Of Operation

    Flow of Operation The figure below is provided to familarize the first-time user with the general flow of this instrument operation. For a description of each item, see the relevant section or chapter. Preparing for Measurement Installing the Instrument Section 3.1 Turning the Power ON/OFF Section 3.4 Wavelength Calibration...

  • Page 11: Table Of Contents

    Contents Checking the Contents of the Package..................... ii Safety Precautions ........................... iii Waste Electrical and Electronic Equipment ..................vi Conventions Used in This Manual ....................vii Flow of Operation........................... viii Chapter 1 Part Names and Functions Front Panel ........................1-1 Rear Panel ........................
  • Page 12 Contents 5.12 Measurement Start (Sweep) ..................5-34 5.13 Specifying a Sweep Range .................... 5-36 5.14 Pulse Light Measurement ....................5-37 5.15 External Trigger Measurement ..................5-39 5.16 Trigger Output ........................ 5-42 5.17 Synchronous Sweep Measurement with the Tunable Laser Source ......5-43 5.18 Analog Out ........................
  • Page 13 Contents Chapter 9 Other Operations Registering Soft keys ....................... 9-1 Data Initialization ......................9-2 Help ..........................9-15 Registering and Loading Character Strings ..............9-16 Other Settings ........................ 9-17 Chapter 10 Maintenance 10.1 Upgrading the Firmware ....................10-1 10.2 Mechanical Inspection ....................10-3 10.3 Operational Inspection ....................

  • Page 14: Chapter 1 Part Names And Functions

    Chapter 1 Part Names and Functions Front Panel Front Panel AQ6370B OPTICAL SPECTRUM ANALYZER FUNCTION DATA ENTRY CENTER SPAN LEVEL SWEEP ZOOM SETUP DISPLAY TRACE PEAK MARKER ANALYSIS COARSE SEARCH BACK USER MEMORY FILE SPASE PROGRAM ADVANCE SYSTEM ENTER OREMOTE...

  • Page 15: Rear Panel

    Rear Panel Rear Panel MAIN POWER TRIGGER TRIGGER ANALOG SERIAL ETHERNET VIDEO OUT (SVGA) (RS-232) 10/100BASE-TX 9 10 100-240V AC 150VA MAX 50/60Hz FUSE 250V T 5A GP-IB1 (IEEE488.1/488.2) GP-IB2 (IEEE488.1) (FOR TLS,ETC.) WARNING Do not operate without reading the safety precautions in the user’...

  • Page 16: Function Section

    Panel Keys and Knobs FUNCTION Section The FUNCTION section contains 17 function keys and 4 auxiliary keys. When you press a function key, information about the function is displayed on the soft key menu located FUNCTION on the right side of the LCD display. CENTER SPAN LEVEL...

  • Page 17: Data Entry Section

    1.3 Panel keys and Knobs MEMORY The MEMORY key contains functions for writing the contents of the active trace to the unit’s internal memory. When you press the MEMORY key, the traces and memory list screen (soft key menu) are displayed. A memory number may be entered in the DATA ENTRY section, or selected using the rotary knob or arrow keys.
  • Page 18 1.3 Panel keys and Knobs DATA ENTRY Section This unit allows you to enter measurement conditions and various other parameters through the DATA ENTRY section. Three different entry methods can be used in the DATA ENTRY DATA ENTRY section, the rotary knob, the arrow keys, and the numeric keypad. Rotary knob When you press a soft key which has a parameter, the current setting is displayed in the parameter entry window.

  • Page 19: Lcd Screen

    LCD Screen Function Data area Measurement conditions area (Displayed when any of the measurement conditions are changed.) Displays level axis scale per DIV (Displayed when measurement is not correctly carried out.) Displays reference level Label area (56 characters) Displays wavelength resolution Displays measurement sensitivity Displays averaging times Displays the number of measurement samples...
  • Page 20 1.4 LCD Screen Parameter display area Parameter input area OVERVIEW display screen (Only displayed when ZOOM function is used.) Displays sub-scale Index IM 735302-01E...

  • Page 21: Chapter 2 Functions

    Chapter 2 Functions System Structure System Structure Splitter cable PS/2 mouse PS/2 mouse Analog output PS/2 keyboard External trigger input Built-in printer (optional) GP-IB2 interface Video signal output AQ6370 OPTICAL SPECTRUM ANALYZER FUNCTION DATA ENTRY CENTER SPAN LEVEL trigger output SWEEP ZOOM SETUP...

  • Page 22: Measurement

    Measurement Alignment Adjustment <<See section 3.6 for the operating procedure>> This function allows adjustment of the optical axis of the instrument’s built-in monochromator (spectroscope). The instrument’s optical performance is not guaranteed until the alignment adjustment function has been executed. Failure to perform this adjustment can result in distortion of measured waveforms.
  • Page 23 2.2 Measurement Higher resolution can be obtained since the wavelength resolution is being determined by the spectral line width of the tunable laser source. Also, since the tunable laser source scarcely outputs any other components than the measuring wavelength, and as the noise light which comes out faintly is being totally cut except for the section corresponding to the resolution range of this equipment, an extremely high optical dynamic range can be acquired.
  • Page 24 The power per 1 nm is called the power density. The level axis of the AQ6370B indicates the absolute power per wavelength resolution. For example, if the resolution is set to 0.1 nm, the power per 0.1 nm will be displayed.
  • Page 25 2.2 Measurement External Trigger Measurement <<See section 5.15 for the operating procedure>> This function performs measurement in synchronization with an external trigger signal. The SMPL TRG IN terminal is an input terminal on the TTL level and in positive/ negative logic (which can be set by the <EXT TRIGGER SETTING> key). The SMPL TRG IN terminal is an input terminal for TTL level, positive/negative logic signals.
  • Page 26 2.2 Measurement Analog Out <<See section 5.18 for the operating procedure>> An analog voltage is output from the ANALOG OUT terminal on the rear panel of the main unit according to the input light. The temporal changes in the input light can be measured by an oscilloscope. However, to enable this output, the sensitivity setting must be NORM/HOLD.
  • Page 27 Waveform Display Zoom <<See section 6.1 for the operating procedure>> This function allows you to zoom freely in and out on measured waveforms. You can easily zoom an area simply by selecting it with the mouse. Drag the mouse over an area of the displayed waveform to zoom in on the area.
  • Page 28 2.3 Waveform Display MAX/MIN HOLD Mode (Maximum/Minimum Value Detection Mode) Writes the maximum/minimum values of the waveform data for each sweep. When a trace is set to MAX/MIN HOLD mode, each time a sweep is performed, the data at the individual measurement points are compared with prior measurements, and the measurement with the higher level (MAX HOLD) or lower level (MIN HOLD) is written.
  • Page 29 2.3 Waveform Display Marker Functions <<See section 6.8 for the operating procedure>> Marker functions can be used to easily measure wavelength differences and level differences, and to search for peak wavelengths, peak levels, and spectrum widths. There are markers and line markers. Markers A total of 1025 markers (one moving marker and 1024 fixed markers) are provided.
  • Page 30 2.3 Waveform Display Noise Mask <<See section 6.10 for the operating procedure>> This key is used to display a waveform so that parts of the waveform at or below the set value are masked. In addition, when a noise mask value is set, the waveform is overwritten in real time.
  • Page 31 Analysis Spectrum Width Analysis <<See section 7.1 for the operating procedure>> You can display the spectrum width and center wavelength using the following four types of calculation. • THRESH method • ENVELOPE method • RMS method • PEAK RMS method <See appendix 2, “Spectrum Width Data Calculation Algorithms”...
  • Page 32 2.4 Analysis Optical Filter Characteristics Measurement <<See section 7.9 for the operating procedure>> Optical filter characteristics can be measured from the measured waveform of the light input to the optical filter from the light source, as well as from the measured waveform light output from the optical filter.

  • Page 33: Other

    Other Using the USB Mouse <<See section 4.2 for the operating procedure>> With a connected USB mouse you can perform the same operations as with the instrument’s panel keys. Also, if you move the mouse pointer over the item in the menu screen that you wish to select and click it, the instrument responds exactly as if you had pressed the corresponding soft key.

  • Page 34: Installing The Instrument

    Chapter 3 Preparing for Measurement Installing the Instrument WARNING The instrument has a built-in reference light source for wavelength calibration, and infrared light is always being output from the optical output connector. Never look into the optical output connector. Infrared light entering the eyes can cause severe injury and loss of vision.
  • Page 35 3.1 Installing the Instrument Also be sure to maintain sufficient clearance for connecting measurement cables, and opening and closing the cover of the built in printer. 20 cm or more AQ6370 OPTICAL SPECTRUM ANALYZER 20 cm or 20 cm or 20 cm or more more...

  • Page 36: Attaching The Connector Adapter

    Attaching the Connector Adapter Attach the optional connector adapter before using the instrument. WARNING Always turn the power OFF before replacing the connector adapter. The instrument has a built-in reference light source for wavelength calibration, and infrared light is always being output from the optical output connector. Never look into the optical output connector.
  • Page 37 3.2 Attaching the Connector Adapter CAUTION • As there may be dust adhering to calibration output, be sure to clean it before attaching the connector adapter. • Do not exhale or blow compressed air into the monochromator from the optical input.

  • Page 38: Connecting A Communication Interface

    Connecting a Communication Interface Connecting the Mouse You can use a USB or PS/2 mouse. Supported USB Mouse The instrument can support a USB HID Class Ver. 1.1 compliant mouse (with wheel). Connections The USB mouse is connected to the USB interface on the front panel of the instrument. Confirm that MAIN POWER switch on the rear panel is OFF.
  • Page 39 3.3 Connecting a Communication Interface Connecting a Keyboard You can connect a keyboard for entering file names, comments, and other items. Also, the functions and settings of the instrument are assigned to keyboard keys, allowing you to manipulate them with a keyboard just as you would by using the instrument’s panel keys.
  • Page 40 3.3 Connecting a Communication Interface Connecting a USB Storage Device Supported USB Storage Devices The instrument supports USB memory (USB card adapters). You cannot use a USB storage device not recognized by the instrument. If the USB storage device’s drive is partitioned, only the primary partition (F:) is recognized. If there are two or more USB storage devices, only the first connected device is recognized.

  • Page 41: Turning The Power On/Off

    Preparing to Turn ON the Power The AQ6370B has a MAIN POWER switch for turning the main power ON/OFF, and a POWER switch for starting and shutting down the instrument. The POWER switch is a push-button switch;...
  • Page 42 3.4 Turning the Power ON/OFF Power On and Screen Display Connect the power cord to the power cord connector on the back side of the instrument. Protective grounding 3-prong outlet terminal /6 0 Power cord 3-2 prong adapter (accessory) (Japan only) Turn ON the MAIN POWER switch on the rear panel of the instrument.
  • Page 43 3.4 Turning the Power ON/OFF If initialization finishes successfully, a message appears prompting you to execute wavelength calibration and alignment adjustment. The contents of the message are as follows. For this instrument to meet its specification, a Wavelength Calibration and an Optical Alignment Adjustment must be performed.
  • Page 44 YES and NO soft keys. Press the YES soft key. The message, “AQ6370B is shutting down. Please wait...” appears, and shut-down begins. If you do not wish to shut down, press the NO soft key.

  • Page 45: Connecting The Dut

    • Before connecting the input light, make sure that it does not exceed the AQ6370B’s maximum rated level. If input light exceeding the maximum rated level is introduced, the optical section may be damaged.

  • Page 46: Alignment Adjustment

    POWER switch. For instructions on turning the power ON and OFF, see section 3.4. Use a 9.5/125 µm SM optical fiber to connect the instrument’s optical input connector with the optical output connector. AQ6370B SM optical fiber (9.5/125 µm) Press SYSTEM. The soft key menu is displayed.
  • Page 47 3.6 Alignment Adjustment Note • Always use the reference light source built in to the instrument for alignment adjustments. Alignment adjustments will be incorrect if an external light source is used. • After alignment has been executed, wavelength calibration is also performed automatically inside the instrument.

  • Page 48: Wavelength Calibration

    Wavelength Calibration WARNING The instrument has a built-in reference light source for wavelength calibration, and infrared light is always being output from the optical output connector. Never look into the optical output connector. Infrared light entering the eyes can cause severe injury and loss of vision.
  • Page 49 For instructions on turning the power ON and OFF, see section 3.4. Use a 9.5/125 µm SM optical fiber to connect the external light source’s optical output connector with the optical input connector. AQ6370B Light source Optical fiber Setting the Type of External Light Source and Calibration Wavelength Value Press SYSTEM.
  • Page 50 3.7 Wavelength Calibration For Laser Type Light Sources Press the EXECUTE LASER soft key. A screen for specifying the wavelength of the external light source is displayed. Select the laser wavelength value using the rotary knob or the arrow keys. The allowed wavelength range is 600–1700 nm.
  • Page 51 3.7 Wavelength Calibration Using the Instrument’s Internal Calibration Wavelength Value Press the CALIB WL SELECT soft key. The soft key menu changes to show wavelength values. Press the soft key corresponding to the appropriate wavelength value. Press the EXECUTE soft key. Wavelength calibration is executed. The previous screen is displayed again after the calibration process ends.
  • Page 52 3.7 Wavelength Calibration Calibration Table Editing the User Calibration table. (Wavelength) Press SYSTEM. Press the WL OFFSET TABLE soft key. The wavelength calibration table appears along with a soft key menu for editing calibration values. Press arrow soft keys to move the cursor to the wavelength to be edited, then press the WL EDIT soft key.

  • Page 53: Important Points During Measurement

    Important Points During Measurement Types of Optical Fibers The instrument can use single mode optical fibers with core diameters of 5 to 9.5 μm, and multimode (GI) optical fibers with core diameters of 50 and 62.5 μm. Functions may be limited or restricted depending on which type of optical fiber is used. The table below shows which of the typical types of fiber may be used and the limitations on their use. Limitations on Wavelength Resolution The maximum wavelength resolution for the instrument is 0.020 nm, which is only obtainable when using a single-mode optical fiber with a core diameter of 9.5 μm or less.
  • Page 54 3.8 Important Points During Measurement Input Optical Fiber Numerical Aperture (NA) and Level Measurement Values The level measurement error of the instrument changes as shown in the figure below, according to the numerical aperture (NA) of the optical fiber connected to the input connector. The instrument’s absolute level is calibrated using a 9.5/125 μm single-mode optical fiber (SSMA type in JIS C6835, with PC polishing, 9.5 μm mode field diameter, and 0.104 to 0.107 NA).
  • Page 55 3.8 Important Points During Measurement Measurement Sensitivity and Vertical Axis Effective Range When the measurement sensitivity is set to NORMAL HOLD, the internal amplifier has a fixed gain. Five different gains are set automatically according to the reference (REF) level setting. However, the effective range of measurement data is limited to the following range, using the reference (REF) level (dBm) as a reference.
  • Page 56 3.8 Important Points During Measurement Ripples in the 1350–1450 nm Area Water (OH-) ions present in the monochromator absorb light in the 1350–1450 nm area, resulting in ripples in the measurement waveform. Either set a coarser resolution or use the monochromator in a lower-humidity environment to reduce the amount of ripples. Waveforms with Resolutions of 0.020 nm When the resolution is set to 0.020 nm for measurements of a light source such as a DFB laser in which with the spectral width is narrower than the instrument’s resolution,...
  • Page 57 3.8 Important Points During Measurement Relationship between the Wavelength Displayed on Screen and the Actual Wavelength 1800 1700 1600 1500 1400 1300 1200 1100 1000 Second-order diffracted light 1266nm ex. 633nm 1000 1100 1200 1300 1400 1500 1600 1700 1800 Wavelength displayed on screen (nm) Example of measurement in which second-order diffracted light appears at 1266 nm The ghost spectrum of the second-order...

  • Page 58: Chapter 4 Common Operations

    Chapter 4 Common Operations Description of Soft Keys When you press a function key, the soft key menu (inside the screen) located on the right side of the screen changes. The soft key menus are designed to provide a certain level intuitiveness, with the individual soft keys having particular forms which make them easy to understand.
  • Page 59 4.1 Description of Soft Keys Display Examples LEVEL 1/2 LEVEL 2/2 REF LEVEL **.*dB/D ***.*dBm SUB LIN LOG SCALE *.***/D **.*dB/D SUB SCALE LIN SCALE **.*dB/km SUB SCA LE BASE LEVEL **.*%/D **.*mW SCALE MIN PEAK →REF LEVEL **.*% LENGTH AUTO REF LEVEL **.***km...

  • Page 60: Using The Mouse And External Keyboard

    Using the Mouse and External Keyboard Using the Mouse With a connected mouse you can perform the same operations as with the instrument's panel keys. Also, if you move the mouse pointer over the item in the menu screen that you wish to select and click it, the instrument responds exactly as if you had pressed the corresponding soft key.

  • Page 61: Help

    4.2 Using the Mouse and External Keyboard Using the External Keyboard The functions of each of the front panel keys of the instrument are assigned to keyboard keys, allowing you to manipulate them with a keyboard just as you would by using the instrument's panel keys.

  • Page 62: Entering Numerical Values And Strings

    Entering Numerical Values and Strings Entering Numerical Values You can use the numeric keypad, rotary knob, or arrow keys in the DATA ENTRY section. Press the soft key of a parameter. The currently set value is shown in the parameter input window. Direct Entry Using the Numeric Keypad Press a numeric keypad key.
  • Page 63 4.3 Entering Numerical Values and Strings Entering Strings Character strings can be entered from the character selection area displayed on screen using the rotary knob and soft keys. Entry Procedure The following is an example of entering a label. Press DISPLAY. The soft key menu for the screen display appears. Press the LABEL soft key.
  • Page 64 Screen Display Procedure Press SYSTEM. The soft key menu is displayed. Press the MORE 1/4 soft key two times. The soft key menu switches to the MORE 3/4 screen. Setting the Number of Displayed Digits for Level Data Press the LEVEL DISP DIGIT soft key. The digit setting menu is displayed. Press the soft key corresponding to the desired number of digits.

  • Page 65: Setting The Date And Time

    Setting the Date and Time The AQ6370B displays the date and time in the upper right corner of the screen. This information is used when outputting to a printer, or for a time stamp when recording data. Displaying the Date and Time Dialog Box Press SYSTEM.

  • Page 66: Printing Out Using The Internal Printer (Optional)

    Printing Out Using the Internal Printer (Optional) Printer Roll Paper The printer uses proprietary roll paper. Do not use any other kind of paper. When using the printer for the first time, use the paper included. When the roll paper runs out, order refills from you nearest Yokogawa branch, dealer, or sales office.
  • Page 67 4.6 Printing Out Using the Internal Printer (Optional) Installing Roll Paper Open the printer cover by lifting it up by the Lock release handle on the left side while pressing the lock lever release lever in the OPEN direction. Handle Printer cover Move the release arm in the right-front to the MAN FEED position.

  • Page 68: Copy

    4.6 Printing Out Using the Internal Printer (Optional) Printing You can output the measured waveforms displayed on screen to the internal printer. Executing Printing Press COPY. An image of the current screen is printed on the built-in printer. Cancelling Printing Press UNDO/LOCAL.

  • Page 69: Chapter 5 Mesurement

    Chapter 5 Mesurement Auto Measurement Procedure This key automatically sets the optimal measurement conditions for the light source being measured, and performs measurement. Press SWEEP. The soft key menu regarding sweeping appears. Press the AUTO soft key. The soft key display reverses, and auto measurement executes.

  • Page 70: Horizontal/Vertical Axis Settings

    Horizontal/Vertical Axis Settings Procedure Setting Up the Horizontal Axis The units of the horizontal axis can be set to wavelength or frequency. Press SETUP. The soft key menu for sweep condition settings appears. Press the HORIZON SCAL nm/THz soft key. The units for the horizontal axis switch from THz to nm, or viceversa.
  • Page 71 5.2 Horizontal/Vertical Axis Settings Setting Up the Vertical Axis Setting to Log Scale Display Press LEVEL. The soft key menu for vertical axis settings appears along with the reference level setting screen. Press the LOG SCALE soft key. The vertical axis is displayed with the currently specified log scale values.
  • Page 72 5.2 Horizontal/Vertical Axis Settings Setting Units for the Vertical Axis Press LEVEL. Press the LEVEL UNIT soft key. When the vertical axis is log scale, the instruments toggle between dBm and dBm/nm each time you press the key. With a linear scale, it scrolls through nW, μW, mW, or pW, and nW/nm, μW/nm, mW/nm or pW/nm.
  • Page 73 5.2 Horizontal/Vertical Axis Settings Explanation Wavelength Display Mode • Displays the measured waveform with the wavelength on the X axis. • The measurement scale and display scale are set based on the wavelength. • The X axis unit for marker values and analysis function results is wavelength. Frequency Display Mode •...
  • Page 74 5.2 Horizontal/Vertical Axis Settings LIN SCALE This key is used to set the main scale to linear scale. Settings per 1 DIV are set in the reference level. LIN BASE LEVEL **.*mW Value when the vertical axis is linear scale, you can set the level scale low-end. This is not available when using a log scale.

  • Page 75: Sub Scale

    Sub Scale Procedure The level scale is displayed based on relative values when a differential waveform (based on LOG values) or normalized waveform is displayed. A level scale based on relative values is called a sub scale. Displaying the Sub Scale Following section 6.5, “Displaying MATH Waveforms”...
  • Page 76 5.3 Sub Scale Log Display of the Sub Scale Press LEVEL. The soft key menu for vertical axis settings appears. Press the MORE 1/2 soft key. The soft key menu for the sub scale appears. Press the SUB LOG soft key. The sub scale is displayed with the currently specified log scale values.
  • Page 77 5.3 Sub Scale Setting the Sub Scale to Linear Display Press LEVEL. The soft key menu for vertical axis settings appears. Press the MORE 1/2 soft key. The soft key menu for the sub scale appears. Press the SUB LIN soft key. The sub scale is displayed with the currently specified linear scale values.
  • Page 78 5.3 Sub Scale Explanation SUB SCALE **.*dB/km (Setting the sub scale to dB/km) The setting range is 0.1 to 10.0 dB/km. Settings can be adjusted in steps of 0.1. If you press the COARSE key you can change the numerical value in 1-2-5 steps, for example: 1dB/DIV ->...

  • Page 79: Setting The Reference Level

    Setting the Reference Level Procedure There are two ways of setting the reference level. • Press the REF LEVEL soft key. • Use the one-action key. The following explains these procedures. Settings by Pressing the REF LEVEL Soft Key (Log Scale) Press LEVEL.
  • Page 80 5.4 Setting the Reference Level Setting by Pressing the REF LEVEL Soft Key (Linear Scale) Press LEVEL. The soft key menu for vertical axis settings appears along with the reference level setting screen. When the vertical axis is not using a linear scale, press the LIN SCALE soft key. If a linear scale is displayed, continue to step 4.
  • Page 81 5.4 Setting the Reference Level Setting by Using the One-Action Key Sets the peak level of the waveform as the reference level. Press LEVEL. Press the PEAK -> REF LEVEL soft key. The specified reference level is displayed, and the displayed waveform is redrawn according to the changed reference level.
  • Page 82 5.4 Setting the Reference Level Explanation Log Scale (REF LEVEL) The setting range for the log scale reference level is -90.0–30.0 dBm. Settings can be adjusted in steps of 0.1. The value changes in steps of 1 if you press the COARSE key. Linear Scale (REF LEVEL) The setting range for the linear scale reference level is 1.00 pW–1000 mW.

  • Page 83: Center Wavelength (Center Frequency) Setting

    Center Wavelength (Center Frequency) Setting Procedure The following are three ways of setting the center wavelength (center frequency). • Press the CENTER WL or CENTER FREQ soft key. • Press the START WL/STOP WL or START FREQ/STOP FREQ soft key. •...
  • Page 84 5.5 Center Wavelength (Center Frequency) Settings Setting with the START WL/STOP WL or START FREQ/STOP FREQ Soft Key Press CENTER. The soft key menu for center wavelength or center frequency settings appears. Setting the Start Wavelength or Start Frequency Press the START WL soft key for start wavelength or the START FREQ soft key for start frequency.
  • Page 85 5.5 Center Wavelength (Center Frequency) Settings Setting by Using the One-Action Key You can set the center wavelength or center frequency by pressing the one-action key one time in the soft key menu that appears when you press CENTER. Press CENTER. For the center wavelength setting, when using peak wavelength or peak frequency, press the PEAK->CENTER soft key.
  • Page 86 5.5 Center Wavelength (Center Frequency) Settings Explanation Center Wavelength The setting range is 600.000 to 1700.000 nm. If you press the COARSE key you can use the rotary knob or arrow keys to change the numerical value in 1 nm steps. The value changes in 0.1 nm steps if you do not press the COARSE key.
  • Page 87 5.5 Center Wavelength (Center Frequency) Settings Center Frequency The setting range is 176.5000 to 500.0000 THz. If you press the COARSE key you can use the rotary knob or arrow keys to change the numerical value in 0.1 THz steps. The value changes in 0.01 THz steps if you do not press the COARSE key.

  • Page 88: Sweep Width Settings

    Sweep Width Settings Procedure The following are three ways of setting the sweep width. • Press the SPAN WL or SPAN FREQ soft key. • Press the START WL/STOP WL or START FREQ/STOP FREQ soft key. • Use the one-action key (soft key). The following explains these procedures.
  • Page 89 5.6 Sweep Width Settings Setting with the START WL/STOP WL or START FREQ/STOP FREQ Soft Key Press SPAN. The soft key menu for sweep width settings appears. Setting the Start Wavelength or Start Frequency Press the START WL soft key for start wavelength or the START FREQ soft key for start frequency.
  • Page 90 5.6 Sweep Width Settings Setting by Using the One-Action Key Setting the Sweep Width from the Measured Waveform Press SPAN. Press the Δλ→ SPAN soft key. Sets the span as six times the RMS 20 dB width of the active trace measurement waveform. Sets spacing between line markers 1 and 2 for sweep width.
  • Page 91 5.6 Sweep Width Settings Explanation Wavelength Sweep Width The available setting range is 0, and 0.1 to 1100.0 nm. If you press the COARSE key you can use the rotary knob or arrow keys to change the numerical value in 1-2-5 steps. The value changes in 1 nm steps if you do not press the COARSE key.

  • Page 92: Wavelength (Frequency) Resolution Settings

    Wavelength (Frequency) Resolution Settings Procedure Press SETUP. The soft key menu for sweep condition settings appears. Press the RESOLUTION soft key. The resolutions that can be set appear in the soft key menu. Press the soft key corresponding to the desired resolution. The screen returns to the previous stage, and the value specified by the RESOLUTION soft key is displayed.
  • Page 93 5.7 Wavelength (Frequency) Resolution Settings Correcting the Resolution Press SETUP. The soft key menu for sweep condition settings appears. Press the MORE 1/2 soft key. Press the RESOLN CORRECT OFF ON soft key. Each time you press the soft key the setting toggles between ON and OFF. Note •...
  • Page 94 5.7 Wavelength (Frequency) Resolution Settings Explanation Conditions under Which “UNCAL” Is Displayed “UNCAL” is displayed when a single or repeat sweep is started based on the following relationship between span, setting resolution, and set number of samples: Span x 5 < Set number of samples - 1 Setting resolution Waveforms with Resolutions of 0.020 nm When the resolution is set to 0.020 nm for measurements of a light source such as a...

  • Page 95: Sampling Point/Interval Settings

    Sampling Point/Interval Settings Procedure The following are three ways in which the number of samples can be entered. • Setting the number of samples directly • Setting by the sampling interval • Automatically setting the optimum number of samples or the sampling interval according to the sweep width (span) and resolution setting Press SETUP.
  • Page 96 5.8 Sampling Point/Interval Settings Explanation Sampling points (the number of points measured in a single sweep) Sampling points are the number of points measured within the range of the specified span. The setting range is 101 to 50001. Relationship between Sampling Points, Interval, and Span The relationship between the number of samples, the interval, and the span is as follows.

  • Page 97: Sensitivity Settings

    Sensitivity Settings Procedure Press SETUP. The soft key menu for sweep condition settings appears. Press the SENS/MODE soft key. Seven sensitivity choices appear in the soft key menu. Press the soft key corresponding to the desired choice. The screen returns to the previous stage, and the value specified by the SENS/MODE soft key is displayed.
  • Page 98 5.9 Sensitivity Settings Explanation CHOP MODE This mode activates the internal chopper of the monochromator. Stray light specific to the monochromator is reduced by turning the chopper. When CHOP MODE is set to SWITCH, measurements of better S/N can be made. You can set the CHOP MODE to SWITCH if the sensitivity setting is HIGH1–HIGH3 or MID.

  • Page 99: Averaging Times Setting

    5.10 Averaging Times Setting Procedure Press SETUP. The soft key menu for sweep condition settings appears. Press the AVERAGE TIMES soft key. The averaging times setting screen is displayed. Enter a number of averaging times using the rotary knob, arrow keys, or numeric key pad.

  • Page 100: Trace Settings

    5.11 Trace Settings Procedure The following explains selecting a trace, writing waveform data, and displaying the data on screen. Press TRACE. The soft key menu for traces appears. Press the ACTIVE TRACE soft key. Traces A through G appear in soft keys. Press the soft key corresponding to the trace you wish to use.
  • Page 101 5.11 Trace Settings Explanation Active Trace Active trace refers to a target trace to which settings and changes can be applied. A trace shows a waveform and measurement conditions. The instrument has a total of seven independent traces (A through G). You can specify Show/Hide on each trace, and display multiple traces in the waveform screen.

  • Page 102: Measurement Start (Sweep)

    5.12 Measurement Start (Sweep) Procedure Press SWEEP. The soft key menu regarding sweep appears. Press the SINGLE or REPEAT soft key. Sweeping begins. To set the sweep interval, press the SWEEP INTERVAL soft key. The sweep interval setting screen is displayed. Enter a numerical value using the rotary knob, arrow keys, or numeric keypad, then press ENTER.
  • Page 103 5.12 Measurement Start (Sweep) Starting the Sweep Press the SEGMENT MEASURE soft key. Only the specified segment unit is measured, and sweeping stops. The first time (only), sweeping begins from the start wavelength. If you press the SEGMENT MEASURE soft key again, sweeping of a segment unit begins from the stopped position.

  • Page 104: Specifying A Sweep Range

    5.13 Specifying a Sweep Range Procedure Sweeping between Line Markers You can sweep between wavelength line marker 1 and wavelength line marker 2. Set wavelength line marker 1 and wavelength line marker 2 at either end of the range you want to sweep. (For the display procedure, see section 6.8, “Displaying Markers.”) Press SWEEP.

  • Page 105: Pulse Light Measurement

    5.14 Pulse Light Measurement Procedure Pulse Light Measurement Settings Press SETUP. The soft key menu for sweep condition settings appears. Press the MORE soft key. The MORE 2/2 soft key menu is displayed. Press the PLS LIGHT MEASURE soft key. Press the PEAK HOLD soft key.
  • Page 106 5.14 Pulse Light Measurement Explanation PLS LIGHT MEASURE You can enter pulse light measurement settings and external trigger mode settings. PEAK HOLD You can set the peak hold value for the pulse light. Pulse light measurement can be carried out based on this. The setting range is 1 to 9999 ms.

  • Page 107: External Trigger Measurement

    5.15 External Trigger Measurement Procedure Setting the Trigger Input Mode Press SYSTEM. The soft key menu regarding the system settings appears. Press the MORE soft key. The MORE 2/4 soft key menu is displayed. Press the TRIG INPUT MODE soft key. The trigger input mode's setting menu is displayed.
  • Page 108 5.15 External Trigger Measurement Setting External Trigger Mode (for SMPL TRIG) Press SETUP. The soft key menu for sweep condition settings appears. Press the MORE soft key. The MORE 2/2 soft key menu is displayed. Press the PLS LIGHT MEASURE soft key. Press the EXT TRIGGER MODE soft key.
  • Page 109 5.15 External Trigger Measurement Explanation Data measurement or signal sweeping starts when triggered by an external signal. An external trigger input terminal is located on the rear panel of the instrument. Input signals are of TTL levels. SMPL TRIG: Measurement starts per external trigger signals. You can set whether the trigger activates on a rising or falling edge of the signal.

  • Page 110: Trigger Output

    5.16 Trigger Output Procedure Setting the Trigger Output Mode Press SYSTEM. The soft key menu for the system settings appears. Press the MORE soft key. The MORE 2/4 soft key menu is displayed. Press the TRIG OUTPUT MODE soft key. The trigger output setting menu is displayed.

  • Page 111: Synchronous Sweep Measurement With The Tunable Laser Source

    Do not operate without reading the safety precautions in the user’ s manual. Tunable Laser Source AQ6370B Connecting the Turnable Laser Source When Using the AQ4321 Series Connect the GP-IB2 connector of the instrument and the GP-IB connector of the AQ4321A/D using the GP-IB cable.
  • Page 112 5.17 Synchronous Sweep Measurement with the Tunable Laser Source Setting the GP-IB Address of the Turnable Laser Source Press SYSTEM. Press the MORE soft key. The MORE 2/4 soft key menu is displayed. Press the GP-IB SETTING soft key. Press the TLS ADDRESS soft key. The address setting screen is displayed. Enter the GP-IB address of the turnable laser source connected to the instrument using the rotary knob, arrow keys, or numeric key pad.
  • Page 113 5.17 Synchronous Sweep Measurement with the Tunable Laser Source Setting the GP-IB2 Port Address Press the GP-IB2 PORT ADDRESS soft key. The address setting screen is displayed. Enter the instrument's GP-IB2 port address using the rotary knob, arrow keys, or numeric key pad.
  • Page 114 5.17 Synchronous Sweep Measurement with the Tunable Laser Source Executing Synchronous Sweep Confirm that the SYSTEM CONTROLLER soft key in the soft key menu in step 7 is turned ON. Press SETUP. Press the MORE1/2 soft key. Press the TLS SYNC SWEEP soft key. It turns ON. Press the SWEEP key.

  • Page 115: Analog Out

    5.18 Analog Out Procedure Connecting to the Oscilloscope AQ6370B Oscilloscope MAIN POWER TRIGGER TRIGGER ANALOG Coaxial cable SERIAL ETHERNET VIDEO OUT (RS-232) 10/100BASE-TX (SVGA) INPUT 100-240V AC 150VA MAX 50/60Hz FUSE 250V T 5A GP-IB1 (IEEE488.1/488.2) GP-IB2 (IEEE488.1) (FOR TLS,ETC.)
  • Page 116 5.18 Analog Output Explanation The saturation level and noise level varies depending on the REF level. The table below shows the relationship between the REF level and the saturation level. REF LEVEL(dBm or dBm/nm) Saturation Level * (dBm) REF > 0 23 dBm or more 0 <...

  • Page 117: Chapter 6 Waveform Display

    Chapter 6 Waveform Display Zooming In/Out on Waveforms Procedure The following are three ways of zooming in and out on waveforms. • By specifying a center wavelength and display sweep • By specifying a start and stop wavelength • By zooming in/out on a range specified with the mouse The following explains the procedure for each of these methods.
  • Page 118 6.1 Zooming In/Out on Waveforms Note • It is not necessary to press nm/ENTER when using the rotary knob or arrow keys. • If a value outside the setting range is entered, the nearest permitted value is set. Zooming In/Out by Specifying a Start and Stop Wavelength Press ZOOM.
  • Page 119 6.1 Zooming In/Out on Waveforms Zooming In/Out on a Range Specified with the Mouse In the waveform display area, drag the portion of the waveform to zoom in/out on. A dotted outline is displayed around the selected range. (The zoom area.) When you release the left mouse button, the display zooms in on the zoom area.
  • Page 120 6.1 Zooming In/Out on Waveforms Setting Up the Overview Window When the waveform display is enlarged or reduced using the zoom function, the overview window is displayed at the very bottom of the waveform display area. (Only displayed when a zoom is performed.) Showing/Hiding the Window and Setting the Display Position Press ZOOM.
  • Page 121 6.1 Zooming In/Out on Waveforms Changing Settings Using the Mouse The mouse can be used in the overview window to change the display scale settings. Changing the Center Wavelength (Center Frequency) Move the mouse pointer into the overview window. Drag in the zoom area surrounded by a dotted line. When doing so, the mouse pointer changes to a hand tool.
  • Page 122 6.1 Zooming In/Out on Waveforms Explanation Zoom Center Wavelength The setting range is 600.000 to 1700.000 nm. If you press the COARSE key you can use the rotary knob or arrow keys to change the numerical value in 1 nm steps. The value changes in 0.1 nm steps if you do not press the COARSE key.
  • Page 123 6.1 Zooming In/Out on Waveforms Zoom Center Frequency The setting range is 176.5000 to 500.0000 THz. If you press the COARSE key you can use the rotary knob or arrow keys to change the numerical value in 0.1 THz steps. The value changes in 0.01 THz steps if you do not press the COARSE key.

  • Page 124: Wavelength Updating/Fixing

    Wavelength Updating/Fixing Procedure Selecting a Trace to Update or Fix Press TRACE. The soft key menu for trace settings appears. Press the ACTIVE TRACE soft key. Traces A through G appear in soft keys. Press the soft key corresponding to the trace you wish to update or fix. The selected trace is set as the active trace, and becomes the target of the operation below.
  • Page 125 6.2 Wavelength Updating/Fixing Explanation Active Trace Active trace refers to a target trace to which settings and changes can be applied. A trace shows a waveform and measurement conditions. The instrument has a total of seven independent traces (A through G). You can specify Show/Hide on each trace, and display multiple traces in the waveform screen.

  • Page 126: Max/Min Hold Display

    MAX/MIN HOLD Display Procedure Selecting a Trace to Hold Press TRACE. The soft key menu for trace settings appears. Press the ACTIVE TRACE soft key. Traces A through G appear in soft keys. Press the soft key corresponding to the trace whose maximum or minimum value you wish to hold.

  • Page 127: Sweep Average

    Sweep Average Procedure Selecting a Trace to Average Press TRACE. The soft key menu for trace settings appears. Press the ACTIVE TRACE soft key. Traces A through G appear in soft keys. Press the soft key corresponding to the trace you wish to average. The selected trace is set as the active trace, and becomes the target of the operation below.
  • Page 128 6.4 Sweep Average Explanation When a trace is set to ROLL AVG mode, each time measurement is performed the sweep average is taken of the current and past measured data, and the measurement data are updated. The roll averaging is calculated according to the following equation. Wj (i) =Wj-1 (i)•...

  • Page 129: Displaying Calculated Waveforms

    Displaying Calculated Waveforms Procedure Selecting Traces for Calculation Press TRACE. The soft key menu for trace settings appears. Press the ACTIVE TRACE soft key. Traces A through G appear in soft keys. Press the soft key corresponding to a trace that is available for trace-to-trace calculation (C, F, or G).
  • Page 130 6.5 Displaying Calculated Waveforms Explanation Executable Trace-to-Trace Calculations Trace C LOG calculations: A-B, B-A, A+B Linear calculations: A+B, B-A, A-B, 1-k(A/B), 1-k(B/A) Trace F LOG calculations: C-D, D-C, C+D, D-E, E-D, D+E Linear calculations: C+D, C-D, D-C, D+E, D-E, E-D Trace G LOG calculations: C-F, F-C, C+F, E-F.
  • Page 131 6.5 Displaying Calculated Waveforms Example of Specific Usage As shown below, this <1-kA/B→C k=*****.*> key or <1-kB/A→C k=*****.*> key may be used to estimate the transmission efficiency from the reflection light spectrum, or estimate the reflectivity from the transmission light spectrum for DUT. (1) Estimating the transmission efficiency (trace C) from the reflection light spectrum (trace A) Transmitted light spectrum (TRACE C) = 1-k (TRACE A/TRACE B) Transmitted light...
  • Page 132 6.5 Displaying Calculated Waveforms Trace F: CALCULATE F LOG MATH This key is used to perform LOG calculations on trace-to-trace data and write the results to trace F. Calculations can be applied to trace C, trace D, and trace E. If both traces selected for calculation are set to “BLANK”, then the sub-scale is displayed on the left side of the screen.
  • Page 133 6.5 Displaying Calculated Waveforms Trace G: CALCULATE G LOG MATH This key is used to perform LOG calculations on trace-to-trace data and write the results to trace G. Calculations can be applied to trace C, trace E, and trace F. If both traces selected for calculation are set to “BLANK”, then the sub-scale is displayed on the left side of the screen.

  • Page 134: Normalized Display

    Normalized Display Procedure Press TRACE. The soft key menu for trace settings appears. Press the ACTIVE TRACE soft key. Traces A through G appear in soft keys. Press the Trace G soft key. The Trace G setting menu is displayed. Press the VIEW G DISP/BLANK soft key and select DISP.

  • Page 135: Curve Fitting

    Curve Fitting Procedure Setting the Target Trace Press TRACE. The soft key menu for trace settings appears. Press the ACTIVE TRACE soft key. Traces A through G appear in soft keys. Press the Trace G soft key. The Trace G setting menu is displayed. Press the VIEW G DISP/BLANK soft key and select DISP.
  • Page 136 6.7 Curve Fitting Setting the Calculation Target Range Press the THRESH soft key. The threshold setting screen is displayed. Enter a threshold using the rotary knob, arrow keys, or numeric key pad. Press ENTER. Press the OPERATION AREA soft key. The calculation target range setting menu is displayed.
  • Page 137 6.7 Curve Fitting Peak Curve Fit Continuing on from step 5, press the PEAK CURVE FIT soft key. To peak curve fit Trace A press the G=PKCVFIT A soft key, to peak curve fit Trace B press G=PKCVFIT B, and to peak curve fit Trace G, press G=PKCVFIT C. Step 8 and thereafter are the same as for curve fitting.
  • Page 138 6.7 Curve Fitting Explanation Curve Fit Target Range Curve-fits the specified trace waveform and writes the results to trace G. Calculations are applied to data from the threshold value to the peak. The threshold value is set in the range of 0 to 99 dB (steps of 1). The trace display at the side of the data area changes to“CRV FIT @”...
  • Page 139 6.7 Curve Fitting Peak Curve Fit Target Range Peak-curve-fits the specified trace waveform and writes the results to trace G. Calculations are applied to mode peaks at the threshold value or more. The threshold value is set in the range of 0 to 99 dB (steps of 1). The trace display at the side of the data area changes to “PKCVFIT @".
  • Page 140 6.7 Curve Fitting Range of Target Data for Calculation Vertical axis Data from threshold value to peak. The threshold value is set in the range of 0 to 99 dB (steps of 1). Horizontal axis Soft key display. Targets all trace data for calculation. INSIDE L1-L2 Targets the data of between line markers for calculation.

  • Page 141: Marker Display

    Marker Display Procedure Displaying Moving Markers Press the MARKER. The soft key menu for marker settings appears. Press the MARKER ACTIVE OFF/ON soft key. Note • If the active trace is not set to DISP, the moving marker cannot be used. Set the trace VIEW @ DISP/BLANK soft key setting to DISP.
  • Page 142 6.8 Marker Display Clearing Fixed Markers Press the CLEAR MARKER soft key. The number of the fixed marker to be cleared is entered in the DATA ENTRY section. Press the CLEAR soft key. Clearing All Markers Press the ALL MARKER CLEAR soft key. All markers (moving markers and fixed markers) displayed on the screen are cleared.
  • Page 143 6.8 Marker Display Using Moving Markers to Set the Center Wavelength to Be Measured, the Zoom Center Wavelength, and the Reference Level Setting the Moving Marker Wavelength as the Measurement Center Wavelength With the moving marker displayed, press the MARKER-> CENTER soft key. The measured center wavelength setting screen and setting value are displayed.
  • Page 144 6.8 Marker Display Setting Marker Difference Value Display You can set the difference display for markers displayed in the data area to OFFSET or SPACING. Press MARKER. Press the MORE soft key twice. The MORE 3/3 key menu is displayed. Press the MARKER DISPLAY soft key.
  • Page 145 6.8 Marker Display Setting the unit for the Marker Value Press MARKER. Press the MORE soft key twice. The MORE 3/3 key menu is displayed. Press the MARKER UNIT nm THz soft key. Each time you press the soft key, the instruments toggle between nm and THz.
  • Page 146 6.8 Marker Display Displaying Wavelength Line Markers Press the MARKER. The soft key menu for marker settings appears. Press the MORE 1/3 soft key. Press the LINE MARKER 1 OFF/ON or LINE MARKER 2 OFF/ON soft key to turn the function ON. Line marker values are displayed in the upper left of the waveform area.
  • Page 147 6.8 Marker Display Setting Measurement Sweep Width & Display Sweep Width with Line Markers Setting the Measurement Sweep Width between Line Markers 1 and 2 <<See section 5.6 for details>> With line marker 1 and 2 displayed, press the MRK L1-L2 ->SPAN soft key. The sweep width setting screen and setting value are displayed.
  • Page 148 6.8 Marker Display Displaying Level Line Markers Press the MARKER switch. The soft key menu for marker settings appears. Press the MORE 1/3 soft key. Press the LINE MARKER 3 OFF/ON or LINE MARKER 4 OFF/ON soft key to turn the function ON. Line marker values are displayed in the upper left of the waveform area.
  • Page 149 6.8 Marker Display Explanation Markers Moving Markers Line markers can be moved to an arbitrary wavelength using the rotary knob, arrow keys, or numeric key pad. You can also drag the markers with the mouse. Moving markers can be moved over a waveform to display the marker value in the data area.
  • Page 150 6.8 Marker Display MARKER DISPLAY This key is used to set whether to display the difference relative to the moving marker (OFFSET) or the difference relative to the next marker (SPACING) in the marker display (Fig. 6-10 "Data area when MARKER DISPLAY is set to OFFSET" and Fig. 6-11 "Data area when MARKER DISPLAY is set to SPACING").
  • Page 151 6.8 Marker Display Line Markers Wavelength Line Markers When line markers are displayed, the marker values are shown in the upper left part of the waveform area. When both wavelength line markers 1 and 2 are displayed, the wavelength difference (L2 –L1) is shown below the marker values.

  • Page 152: Displaying A Split Screen

    Displaying a Split Screen Procedure Splitting the Screen Press DISPLAY. The soft key menu for setting the screen display appears. Press the SPLIT DISPLAY soft key. The screen splits into upper and lower splits. Displaying a Trace in Either the Upper or Lower Split Press the soft key corresponding to the desired trace.
  • Page 153 6.9 Displaying a Split Screen Explanation HOLD The Hold function is used when displaying measured waveforms with the upper and lower portions of the screen having different wavelength ranges. For example, after measuring trace A in the upper screen, you can hold the upper screen, change measurement conditions, then measure trace B in the lower screen.

  • Page 154: Noise Mask

    6.10 Noise Mask Procedure Press DISPLAY. The soft key menu for setting the screen display appears. Press the NOISE MASK soft key. The noise mask value setting screen is displayed. Enter a noise mask value using the rotary knob, arrow keys, or numeric key pad. Press ENTER.
  • Page 155 6.10 Noise Mask Explanation Noise Masking HRZN Displays the waveform with level values at or below the mask value as the mask value. Mask line VERT Displays the waveform with level values at or below the mask value as the display lower limit value (–210 dBm).

  • Page 156: Copying And Clearing Traces

    6.11 Copying and Clearing Traces Procedure Copying Traces Press TRACE. The soft key menu for trace settings appears. Press the MORE 1/2 soft key. Press the TRACE COPY soft key. Press the SOURCE TRACE soft key and select the copy source trace (A to G). The screen returns to the previous state after a selection is made.
  • Page 157 6.11 Copying and Clearing Traces Clearing Traces Press TRACE. The soft key menu for trace settings appears. Press the MORE 1/2 soft key. Press the TRACE CLEAR soft key. Press the soft key (A through G) corresponding to the trace of the data you wish to clear.

  • Page 158: Searching

    6.12 Searching Procedure Finding the Peak Wavelength/Level Press PEAK SEARCH. The menu for searching for the peak value is displayed. Press the PEAK SEARCH soft key. The moving marker is set on the waveform peak (the maximum level value) and the marker value is displayed in the data area.
  • Page 159 6.12 Searching Setting the Minimum Peak/Bottom Difference of the Mode Judgment Reference Press PEAK SEARCH. The menu for detecting the peak value is displayed. Press the MORE 1/2 soft key. The 2/2 soft key screen is displayed. Press the MODE DIFF soft key. The screen for setting the minimum peak/bottom difference of the mode judgment reference is displayed.
  • Page 160 6.12 Searching Explanation Peak Search You can detect the peak or bottom values of the measured waveform. The following explains the soft keys related to peak searches. PEAK SEARCH Executes a peak search (a search for a maximum level value) on the active trace waveform.
  • Page 161 6.12 Searching ALL MARKER CLEAR This key is used to clear all currently displayed moving markers and fixed markers. MODE DIFF *.**dB This key is used to set the minimum peak/bottom difference (dB) serving as a basis for mode determination during mode detection. When you press this key, the setting screen and current setting value are displayed.

  • Page 162: Chapter 7 Analysis

    Chapter 7 Analysis Spectrum Width Measurement Procedure Spectrum width can be measured from the measured waveform. Press ANALYSIS. The soft key menu for analyzing measured waveforms appears. Press the SPEC WIDTH soft key. The analysis algorithm selection menu is displayed. Press the THRESH, ENVELOPE, RMS, or PEAK RMS soft key.
  • Page 163 7.1 Spectrum Width Measurement If you only want to change the THRESH LEVEL, you can also do so with the SPEC WIDTH THRESH soft key. Changing the Threshold Value for Each Algorithm Continuing on from step 3, press the SPEC WIDTH THRESH soft key. The threshold setting screen is displayed.
  • Page 164 7.1 Spectrum Width Measurement Explanation Algorithms Algorithms for Spectrum Width Analysis Algorithm Description THRESH Determines spectrum width from the width between points where the waveform crosses the threshold value. ENVELOPE Determines spectrum width from waveform envelope. Determines spectrum width from waveform standard deviation. PEAK RMS Determines spectrum width from waveform mode peak standard deviation.

  • Page 165: Notch Width Measurement

    Notch Width Measurement Procedure With notch width measurement, it is possible to measure notch width (pass band width/ notch width) from the measured waveform of a filter with V-character type or U-character type wavelength characteristics. Press ANALYSIS. The soft key menu for analyzing measured waveforms appears.
  • Page 166 7.2 Notch Width Measurement When changing the analysis parameters Continuing on from step 3, press the PARAMETER SETTING soft key. The notch analysis parameter setting screen is displayed. Move the cursor with the arrow keys or soft keys, and enter a setting value with the numeric key pad.

  • Page 167: Smsr Measurement

    SMSR Measurement Procedure You can measure SMSR from the measured waveform of a DFB-LD. Press ANALYSIS. The soft key menu for analyzing measured waveforms appears. Press the ANALYSIS 1 soft key. The analysis function selection menu is displayed. Press the SMSR soft key. Analysis is performed, and the results are displayed in the data area.
  • Page 168 7.3 SMSR Measurement Explanation SMSR SMSR stands for side-mode suppression ratio. SMSR represents the difference between the mode peak and the side-mode level. It is one of the parameters used to evaluate the performance of DFB-LDs and the like. Mode peak Side mode SMSR MASK AREA...

  • Page 169: Power Measurement

    POWER Measurement Procedure Optical power can be measured by integrating the measured waveform level values. Press ANALYSIS. The soft key menu for analyzing measured waveforms appears. Press the ANALYSIS 1 soft key. The analysis function selection menu is displayed. Press the POWER soft key. Analysis is performed, and the results are displayed in the data area.

  • Page 170: Dfb-Ld, Fp-Ld, And Led Measurement

    DFB-LD, FP-LD, and LED Measurement Procedure Light source parameters can be analyzed from the measured waveform of each light source (DFB-LD, FP-LD, LED). Press ANALYSIS. The soft key menu for analyzing measured waveforms appears. Press the ANALYSIS 1 soft key. The analysis function selection menu is displayed.

  • Page 171: Pmd Measurement

    PMD Measurement Procedure It is possible to measure the polarization mode dispersion (PMD) from a measured waveform by using the instrument in combination with a wideband light source and a polarizer, polarization controller, and an analyzer. Press ANALYSIS. The soft key menu for analyzing measured waveforms appears.
  • Page 172 The following explains the structure of, and acquisition procedure for PMD measurement. Wideband light Polarizer Polarization Analyzer AQ6370B controller source Enter measurement conditions so that the entire wavelength range of the wideband light source is measured. Set the resolution to about 0.050 nm.

  • Page 173: Wdm Transmission Signal Analysis

    WDM Transmission Signal Analysis Procedure You can measure the center wavelength, level, and SNR of each channel from the measured waveform of a WDM transmission signal. Press ANALYSIS. The soft key menu for analyzing measured waveforms appears. Press the ANALYSIS 2 soft key. The analysis function selection menu is displayed.
  • Page 174 7.7 WDM Transmission Signal Analysis When changing the analysis parameters Continuing on from step 3, press the PARAMETER SETTING soft key. The WDM analysis parameter setting screen is displayed. If a setting screen has multiple pages, press the NEXT PAGE soft key to display the next screen. Move the cursor with the arrow keys or soft keys, and enter a setting value with the numeric key pad.
  • Page 175 7.7 WDM Transmission Signal Analysis Explanation The following configuration is used to measure WDM transmission signals. AQ6370B Multi-channel light source Optical amplifier Measure the WDM signal light and write the waveform to the active trace. Setting Analysis Parameters The WDM analysis function parameters may be broadly divided into the following three configurations.
  • Page 176 7.7 WDM Transmission Signal Analysis Parameter Settings Related to Channel Detection These parameters are used to set threshold level and the like for WDM channel detection. THRESH LEVEL This parameter is used to set the threshold level for channel detection. This setting determines how far down in decibels from the peak level to detect a mode peak as a channel.
  • Page 177 7.7 WDM Transmission Signal Analysis FITTING ALGO This parameter is used to select the interpolation algorithm for determining the noise level. This parameter is only set when NOISE ALGO is set to MANUAL-FIX or MANUAL-CTR. Interpolation algorithms Fitting Algorithm Description LINER Linear interpolation GAUSS...
  • Page 178 7.7 WDM Transmission Signal Analysis Parameter Settings for Analysis Results Display These parameters are set with respect to the display format for displaying analysis results on the screen. DISPLAY TYPE This parameter is used to select the analysis results display format. Display Type Settings DISPLAY TYPE Description and Procedure...
  • Page 179 7.7 WDM Transmission Signal Analysis OUTPUT SLOPE Displays the least square approximation line passing through the detected channel peak. The channel slope can be obtained as a numerical value. OUTPUT RESULTS of analysis results OUTPUT SLOPE POINT DISPLAY This parameter is used to display the range of data used in interpolation for determining the noise level.

  • Page 180: Optical Amp Gain And Nf Measurement

    Optical Amp Gain and NF Measurement Procedure Measurement can be performed of the optical amp gain and noise figure from the measured waveform of the signal light going into the optical amp, and the measured waveform of the output light leaving the optical amp. Press ANALYSIS.
  • Page 181 7.8 Optical Amp Gain and NF Measurement When changing the analysis parameters Continuing on from step 3, press the PARAMETER SETTING soft key. The EDFA-NF analysis parameter setting screen is displayed. Move the cursor with the arrow keys or soft keys, and enter a setting value with the numeric key pad.
  • Page 182 Acquiring Waveforms Required for Analysis The following configuration and general procedure is used to measure optical amp gain and NF. Signal light measurement configuration AQ6370B Multi-channel light source Output light measurement configuration AQ6370B Multi-channel light source...
  • Page 183 7.8 Optical Amp Gain and NF Measurement Writing the Waveform of the Output Light from the Optical Amp to Trace B Input the light output from the optical amp into the instrument. Press TRACE followed by the ACTIVE TRACE soft key, then select Press the VIEW B soft key and select DISP.
  • Page 184 7.8 Optical Amp Gain and NF Measurement Explanation Setting EDFA-NF Analysis Parameters The EDFA-NF analysis function parameters may be broadly divided into the following two configurations. Parameter settings may be changed as desired according to the details of the particular analysis.
  • Page 185 7.8 Optical Amp Gain and NF Measurement Parameters Related to ASE Level Measurement These parameters are used to set the waveform level, offset, and interpolation method for ASE level measurement. OFFSET(IN) A level offset can be set on a signal light waveform (trace A). Set “0.00”...
  • Page 186 7.8 Optical Amp Gain and NF Measurement MASK AREA This parameter is used to set the range of signal light to be masked when determining the ASE level through interpolation. This parameter is only set when “FITTING ALGO” is not set to LINEAR. POINT DISPLAY This parameter is used to display the range of data used in interpolation for determining the noise level.

  • Page 187: Optical Filter Characteristics Measurement

    Optical Filter Characteristics Measurement Procedure Optical filter characteristics can be measured from the measured waveform of the light input to the optical filter from the light source, as well as from the measured waveform light output from the optical filter. Filter Measurement (Single Channel) You can analyze a waveform whose number of modes is 1.
  • Page 188 7.9 Optical Filter Characteristics Measurement Analysis parameter setting screen Note See appendix 6, “Optical Filter Analysis Function” for a description of the optical filter analysis algorithms and parameters. Filter Bottom Analysis This is used if the optical filter is of a notch type rather than a pass band type. Press ANALYSIS.
  • Page 189 7.9 Optical Filter Characteristics Measurement Filter Measurement for WDM (Multi Channel) You can analyze multi-mode waveforms. WDM Filter Peak Analysis Press ANALYSIS. The soft key menu for analyzing measured waveforms appears. Press the ANALYSIS 2 soft key. The analysis function selection menu is displayed.
  • Page 190 7.9 Optical Filter Characteristics Measurement Analysis parameter setting screen Note See appendix 6, “Optical Filter Analysis Function” for a description of the optical filter analysis algorithms and parameters. WDM Filter Bottom Analysis This is used if the optical filter is of a notch type rather than a pass band type. Press ANALYSIS.
  • Page 191 The following configuration and general procedure is used to measure WDM optical filter characteristics. A pass band type WDM optical filter is used as an example. Reference spectrum AQ6370B Wideband light source ex. TRACE A Spectrum measurement after passing through the filter...
  • Page 192 7.9 Optical Filter Characteristics Measurement Writing the Waveform of the Light Source Input to the Optical Filter on Trace Input the emitted light from the light source that is input to the optical filter into the instrument. Press TRACE followed by the ACTIVE TRACE soft key, then select A. Press the VIEW A soft key and select DISP.
  • Page 193 7.9 Optical Filter Characteristics Measurement Explanation Setting WDM Filter Analysis Parameters The WDM FIL-PK analysis function parameters may be broadly divided into the two types shown below. Parameter settings may be changed as desired according to the details of the particular analysis.
  • Page 194 7.9 Optical Filter Characteristics Measurement • When MEAN is selected Each mode peak is detected as a channel. The 3dB center wavelength of each channel is the reference wavelength. 3 dB MEAN WL • When GRID FIT is selected The mode peak detected within GRID WL [PLUSMINUS SYMBOL] (TEST BAND/2) is set as the channel.
  • Page 195 7.9 Optical Filter Characteristics Measurement • When GRID is selected The wavelengths registered in the GRID table wavelength are recognized as channels. GRID WL is set as the reference wavelength. GRID WL THRESH LEVEL This parameter is used to set the threshold level for channel detection. MODE DIFF This parameter sets the minimum value for the peak/bottom difference during channel peak detection.

  • Page 196: Editing The Grid Table

    7.10 Editing the Grid Table Procedure Editing a Standard Grid Table Press SYSTEM. Press the GRID EDITOR soft key. The Grid table edit screen appears. Setting the Frequency Spacing Press one of the keys from 200 GHz SPACING to 12.5 GHz SPACING. Depending on the selected soft key, a frequency spacing table of 200 GHz, 100 GHz, 50 GHz, 25 GHz, or 12.5 GHz can be used.
  • Page 197 7.10 Editing the Grid Table Editing a Custom Grid Table Press SYSTEM. Press the GRID EDITOR soft key. The Grid table edit screen appears. Press the CUSTOM soft key. The custom Grid table edit screen appears. Setting the Start/Stop Wavelength Press the START WL or STOP WL soft key.
  • Page 198 7.10 Editing the Grid Table Setting Channel Point Wavelength Continuing on from step 3, place the cursor on the channel point you wish to change using the rotary knob, arrow keys, or numeric key pad. Press the VALUE EDIT soft key. The setting screen for changing the channel point wavelength is displayed.
  • Page 199 7.10 Editing the Grid Table Explanation Grid Table A grid table lists wavelengths (frequencies) that are referenced by part of the analysis function when it is executed. There is a standard Grid table and a custom Grid table. Standard Grid Table This Grid table is created with pre-defined wavelength (frequency) ranges.

  • Page 200: Measurement Of Level Fluctuations In Single-Wavelength Light (0 Nm Sweeping)

    7.11 Measurement of Level Fluctuations in Single- Wavelength Light (0 nm Sweeping) Procedure This function measures changes over time in the level of a specific wavelength level. It is useful for purposes such as optical axis alignment when connecting an optical fiber to a light source.
  • Page 201 7.11 Measurement of Level Fluctuations in Single-Wavelength Light (0 nm Sweeping) Sweep width setting Sweep time setting Note • When the sweep range is set to 0 nm, the horizontal axis is set as the time axis as a result. •...
  • Page 202 7.11 Measurement of Level Fluctuations in Single-Wavelength Light (0 nm Sweeping) Explanation The following is the structure in which the spatial light of an He-Ne gas laser (1152.274 nm) is input to an optical fiber. AQ6370B He-Ne gas laser Spatial light...

  • Page 203: Go/No-Go Judgment (Template)

    7.12 Go/No-Go Judgment (Template) Procedure This function compares preset reference data (template data) with a measured waveform, and makes a Go/No-Go judgment. Creating Template Data on the Instrument Press ADVANCE followed by the TEMPLATE soft key. Press the TEMPLATE EDIT soft key. The template creation screen is displayed. Press the LINE SELECT soft key.
  • Page 204 7.12 Go/No-Go Judgment (Template) Executing Go/No Go Judgment After creating or loading template data, press ADVANCE followed by the TEMPLATE soft key. Press the TYPE soft key. The judgment condition setting menu is displayed. Press the UPPER, LOWER, or UPPER &LOWER soft key once. Press the RETURN soft key.
  • Page 205 7.12 Go/No-Go Judgment (Template) Setting the Shift Amount and Shifting the Template The template data wavelength/level can be shifted without changing the template data. The procedure for doing this is shown below. Press ADVANCE followed by the TEMPLATE soft key. Press the TEMPLATE SHIFT soft key.
  • Page 206 7.12 Go/No-Go Judgment (Template) Switching to RELATIVE Mode Press ADVANCE followed by the TEMPLATE soft key. Press the TEMPLATE EDIT soft key. The edit menu is displayed. Press the MODE ABS/REL soft key to select REL. The instrument enters Relative mode.
  • Page 207 7.12 Go/No-Go Judgment (Template) Switching to ABSOLUTE Mode Press ADVANCE followed by the TEMPLATE soft key. Press the TEMPLATE EDIT soft key. The edit menu is displayed. Press the MODE ABS/REL soft key, then select ABS. The instrument enters Absolute mode. The results and template are shifted 3 nm to the left on screen.
  • Page 208 7.12 Go/No-Go Judgment (Template) Turning the Template Data Display ON/OFF Press ADVANCE followed by the TEMPLATE soft key. Press the TEMPLATE DISPLAY soft key. The display ON/OFF switch menu is displayed. Press the soft keys for each of the three lines (UPPER LINE DISPLAY, LOWER LINE DISPLAY, and TARGET LINE DISPLAY), and select ON or OFF.
  • Page 209 7.12 Go/No-Go Judgment (Template) Explanation Go/No Go Judgment The following are the three types of template. • Upper limit line • Lower limit line • Target line Upper and lower limit lines are used for Go/No Go judgment. For target line only, the function displays the targeted spectrum on the measurement screen without comparing it to the measured waveform.
  • Page 210 7.12 Go/No-Go Judgment (Template) Upper Limit Line and Lower Limit Line Judgment FAIL Judgment conditions (lower limit line) <= (measured data) -> Go (PASS) (upper limit line) < (measured data) -> No Go (FAIL) (measured data) < (lower limit line) -> No Go (FAIL) Upper Limit Line Lower Limit Line 1547.5...
  • Page 211 7.12 Go/No-Go Judgment (Template) Template Data • Template data consist of wavelength and level data. Up to 50,001 points of data may be defined. • An upper limit, lower limit, and target line can be set. • The on-screen template data display range and the Go/No Go test function execution range follow the display scale wavelength range.
  • Page 212 7.12 Go/No-Go Judgment (Template) Template Data Types ABSOLUTE Templates ABSOLUTE template data specify both wavelengths and levels as absolute values. The waveform and template data change in conjunction with changes to the center wavelength or display sweep width on the display scale. 1547.5 1550 1552.5...
  • Page 213 7.12 Go/No-Go Judgment (Template) Extrapolating Template Data In cases where the display scale is outside the defined range for template data, the template data outside the range can be extrapolated. The following three types of extrapolation are available in these situations. •...
  • Page 214 50,001 template data points can be defined. Save the template data created on an external PC to a USB storage device for loading in the instrument. <- Header for the AQ6370B <- Header indicating template data <- Header indicating the template type (ABSOLUTE or RELATIVE) <- Extrapolation type (A or B or None)

  • Page 215: Specifying An Analysis Range

    7.13 Specifying an Analysis Range Analysis between Line Markers Power Measurement between Line Markers You can determine the totalized power for the area enclosed by wavelength line marker 1 and wavelength line marker 2. Set wavelength line marker 1 and wavelength line marker 2 at either end of the range where you want to measure the totalized power.
  • Page 216 7.13 Specifying an Analysis Range Analysis in the Zoom Area Power Measurement in the Zoom Area Optical power can be measured by integrating the measured waveform level measurements in the zoom area. Zoom in on the measured waveform. Set the range you want to measure to the display scale.
  • Page 217 7.13 Specifying an Analysis Range Explanation When the line marker search function and zoom area search functions are enabled at the same time, the intersection of the two ranges is the range for analysis. The following shows the POWER measurement analysis range when both the SEARCH/ ANA L1-L2 and SEARCH/ANA ZOOM AREA soft keys are ON.

  • Page 218: Correcting Displayed Values

    7.14 Correcting Displayed Values Procedure Setting the Wavelength Shift Amount Press SYSTEM. Press the WL SHIFT soft key. The wavelength shift setting screen is displayed. Enter a wavelength shift amount using the rotary knob, arrow keys, or numeric key pad. Press ENTER.
  • Page 219 7.14 Correcting Displayed Values Determining the Level Shift Amount Even if NA of the optical fiber used is unknown, the level shift amount enabling correct level measurements can be determined. Set up a light source such as a DFB-LD with a spectrum width that is narrower than the instrument’s resolution (with a wavelength of 1310 nm or 1550 nm).
  • Page 220 7.14 Correcting Displayed Values Absolute Level Accuracy The instrument’s absolute level is calibrated with a 9.5 μm single-mode optical fiber. In terms of actual capability, even single-mode optical fibers that do not have a core diameter of 9.5 μm provide nearly the same level of accuracy. Multimode (GI) fiber provides a relatively accurate spectrum if the light source is low- coherent light such as white light, natural light, or an LED. If the light source has high coherency as in the case of a laser beam, interference will occur inside the optical fiber, and the intensity distribution of light radiating from the fiber tip will vary according to the fiber form.

  • Page 221: Usb Storage Media

    Chapter 8 Saving/Loading Data USB Storage Media Supported USB Storage Media The instrument supports USB 1.0 or USB 2.0 compliant USB memory devices or hard disks. For details, contact your nearest Yokogawa representative. Removing USB Storage Media Always follow the procedure below when removing USB storage media. Press FILE.

  • Page 222: Temporarily Saving And Redisplaying Traces To And From Internal Memory

    Temporarily Saving and Redisplaying Traces to and from Internal Memory Procedure You can save waveforms being displayed by the instrument to the instrument's internal memory, and redisplay data that has been saved to the internal memory. Temporarily Saving Trace Data to Internal Memory Press MEMORY.
  • Page 223 8.2 Temporarily Saving and Redisplaying Traces to and from Internal Memory Redisplaying Trace Data Press MEMORY. The soft key menu for the internal memory appears. Press the RECALL soft key. The internal memory list and trace list are displayed. Select a source memory number using the rotary knob, arrow keys, or numeric key pad.
  • Page 224 8.2 Temporarily Saving and Redisplaying Traces to and from Internal Memory Displaying and Changing the Memory List Press MEMORY. The soft key menu for the internal memory appears. Press the MEMORY LIST soft key. The internal memory list and trace list are displayed.
  • Page 225 8.2 Temporarily Saving and Redisplaying Traces to and from Internal Memory Explanation Up to 64 data can be saved. It is often useful to temporarily save waveform data for redisplay at a later time. The following data can be saved. Types of Data Display in List (ATTR Field) Measured waveforms...

  • Page 226: Saving/Loading Displayed Data

    Saving/Loading Displayed Data Procedure Waveforms displayed by the instrument and waveforms temporarily saved to internal memory can be saved to a USB storage medium or the internal memory, and loaded from the USB storage medium. CAUTION Do not remove the USB storage medium or turn the power OFF while the USB storage medium access indicator is blinking.
  • Page 227 8.3 Saving/Loading Displayed Data Selecting the Save Destination and Data Format Press the MEMORY soft key and specify a save destination of INT (internal memory) or EXT (USB storage medium). Press the FILE TYPE soft key and specify a data format of BIN (binary) or CSV (ASCII format).
  • Page 228 8.3 Saving/Loading Displayed Data Entering a File Name (When Saving to an Arbitrary File Name) If a file name is not entered, it is automatically assigned in the form WXXXX.CSV or WXXXX.WV8 (where XXXX is a serial number). For creating a directory and sorting the file list, see the next page. 9. Using the rotary knob, move the cursor to the line in the file list displaying NEW FILE.
  • Page 229 8.3 Saving/Loading Displayed Data Creating a Directory and Sorting Files Perform the following procedure if needed. Press the MAKE DIRECTORY soft key. The menu for creating directories is displayed. 17. Press the DIRECTORY NAME soft key. The text entry window and corresponding soft key menu are displayed.
  • Page 230 8.3 Saving/Loading Displayed Data Loading Trace Data Setting the Type of the File to Be Loaded to TRACE Press FILE. The soft key menu for saving and loading data appears. Press the ITEM SELECT soft key. The menu for selecting the type of files to be saved is displayed.
  • Page 231 8.3 Saving/Loading Displayed Data Selecting a Trace from the Loaded Data Press the FILE->TRACE @ soft key (where @ is the currently selected trace number). The trace selection menu is displayed. Press the soft key corresponding to the trace to be assigned. Executing the Load Press the EXECUTE soft key.
  • Page 232 8.3 Saving/Loading Displayed Data Saving the Data Temporarily Saved to Internal Memory Setting the Type of the File to Be Saved to MEMORY Press FILE. Press the ITEM SELECT soft key. The soft key menu switches. Press the MEMORY soft key. MEMORY is selected, and the screen returns to the previous stage.
  • Page 233 8.3 Saving/Loading Displayed Data Selecting a Memory Number to Save Press the CURSOR soft key, then set the cursor selection to UP (on the memory list side). Select the memory number of the data to save using the rotary knob, arrow keys, or numeric key pad.
  • Page 234 8.3 Saving/Loading Displayed Data Executing the Save To overwrite an existing file, move the cursor to the file name to be overwritten. 15. Press the EXECUTE soft key. The save executes. When the RETURN soft key is pressed, the data is saved. The screen returns to the previous stage.
  • Page 235 8.3 Saving/Loading Displayed Data Loading from the Temporary Save Memory Setting the Type of the File to Be Loaded to MEMORY Press FILE. Press the ITEM SELECT soft key. The soft key menu switches. Press the MEMORY soft key. MEMORY is selected, and the screen returns to the previous stage.
  • Page 236 8.3 Saving/Loading Displayed Data Selecting a Memory Number to Save Press the CURSOR soft key, then set the cursor selection to DOWN (on the memory list side). Select the memory number of the load destination using the rotary knob, arrow keys, or numeric key pad.
  • Page 237 8.3 Saving/Loading Displayed Data Explanation You can save data from traces A–G to internal memory or a USB storage medium, or assign previously saved data to trace A–G and display it. Also, you can save (MEMORY) data that was temporarily saved to internal memory or a USB storage medium, or register previously saved data to the temporary save memory.
  • Page 238 8.3 Saving/Loading Displayed Data CSV Data Format CSV data is saved in the following format. 70BCSV Header // AQ6370B OPTICAL SPECTRUM ANALYZER // "CTRWL",1553.200000 "SPAN", 20.000000 "START WL",1543.200000 "STOP WL",1563.200000 "WLFREQ", 0 "REFL",-10.0 "LSCL",10.0 "RESLN",0.200 "AVG", 1 "SMPLAUTO", 0 Measurement condition parameters "SMPL", 1001...
  • Page 239 8.3 Saving/Loading Displayed Data Measurement sensitivity "HIGH 1" Measurement identifier "MEAS" Vertical axis scale mode (0: dBm, 1: dBm/nm) "LSUNT",0 Noise mask setting "NMSKV","OFF" (NMSKV:VERTICAL, NMSKH:HOLIZONTAL) Resolution correction setting (0: OFF, 1: ON) "RESCORE",0 Wavelength resolution RMS coefficient "RESPARM",10372 Frequency resolution RMS coefficient "FREQPARM",10372 The reference level and main level scale are saved to one of the following depending on the vertical scale.
  • Page 240 8.3 Saving/Loading Displayed Data Measurement Identifier The data below is saved as a waveform identifier depending on the waveform type. Format Waveform Format Waveform Format Waveform Type Type Type "MEAS" WRITE "E-D" E-D(LOG) "C+FL" C+F(LIN) "MAXH" MAX HOLD "C+D" C+D(LOG) "C-FL"...

  • Page 241: Saving/Loading Setting Data

    Saving/Loading Setting Data Procedure The measurement conditions set on the instrument and soft key set statuses are saved in binary format. CAUTION Do not remove the USB storage medium or turn the power OFF while the USB storage medium access indicator is blinking. This can damage the data on the medium or the device itself.
  • Page 242 8.4 Saving/Loading Setting Data Selecting the Save Destination Medium Press the MEMORY soft key and specify INT (internal memory) or EXT (USB storage medium). A file list of the selected medium is displayed. Entering the Name of the File to Be Saved If a file name is not entered, it is automatically assigned in the form SXXXX.ST8 (where XXXX is a serial number starting from 0000).
  • Page 243 8.4 Saving/Loading Setting Data Executing the Save To overwrite an existing file, move the cursor to the file name to be overwritten. 11. Press the EXECUTE soft key. The save executes. When the RETURN soft key is pressed, the data is saved. The screen returns to the previous stage.
  • Page 244 8.4 Saving/Loading Setting Data Selecting the File to Be Loaded Press the MEMORY soft key and specify INT (internal memory) or EXT (USB storage medium). A file list of the selected medium is displayed. Select a file to load from the file list using the rotary knob or the arrow keys. You can also press the FILE SORT soft key to sort the files.
  • Page 245 8.4 Saving/Loading Setting Data Explanation You can save instrument setting data to internal memory or a USB storage medium, or load previously saved setting data and modify the settings. Extension The extension used when loading is .ST8. File Name You can have a file name automatically assigned, or specify an arbitrary name for the save.

  • Page 246: Saving/Loading Analysis Results Data

    Saving/Loading Analysis Results Data Procedure You can save analysis results including the time and waveform data of the original save in ASCII or binary format. CAUTION Do not remove the USB storage medium or turn the power OFF while the USB storage medium access indicator is blinking.
  • Page 247 8.5 Saving/Loading Analysis Results Data Selecting the Save Destination Medium and Data Format Press the MEMORY soft key and specify INT (internal memory) or EXT (USB storage medium). A file list of the selected medium is displayed. Press the FILE TYPE soft key and specify a data format of DT8 (ASCII) or CSV (ASCII format).
  • Page 248 8.5 Saving/Loading Analysis Results Data Entering the Name of the File to Be Saved If a file name is not entered, it is automatically assigned in the form DXXXX.DT8 or DXXXX.CSV (where XXXX is a serial number starting from 0000). For creating a directory and sorting the file list, see the page 8-9.
  • Page 249 8.5 Saving/Loading Analysis Results Data Loading Analysis Data Setting the Type of the File to Be Loaded to DATA Press FILE. Press the ITEM SELECT soft key. The soft key menu switches. Press the DATA soft key. DATA is selected, and the screen returns to the previous stage.
  • Page 250 8.5 Saving/Loading Analysis Results Data Executing the Load Press the EXECUTE soft key. The file is loaded. When the RETURN soft key is pressed, the file is not loaded. The screen returns to the previous stage. 8-30 IM 735302-01E...
  • Page 251 8.5 Saving/Loading Analysis Results Data Explanation Extensions The extensions used when saving are as follows. DAT (ASCII format): .DT8 CSV (ASCII format): .CSV File Name You can have a file name automatically assigned, or specify an arbitrary name for the save.
  • Page 252 8.5 Saving/Loading Analysis Results Data Data Format You can save in ASCII format. Saves as text data. Saves the file in CSV (comma separated value) ASCII format. Data Format DT8 format is as follows. Label "70BDAT " " " Date/time of save 2006 Apr 07 16:42 "<NF ANALYSIS>...
  • Page 253 8.5 Saving/Loading Analysis Results Data CSV format is as follows. Label 70BDAT2 TEST Date/time data saved 2005 Apr 07 16:42 <NF ANALYSIS> TH[dB],20.00 MODE DIFF[dB],3.00 OFST(IN)[dB],0.00 OFST(OUT)[dB],0.00 ASE ALGO,AUTO-FIX Analysis results FIT AREA,AUTO header MASK AREA,--- and data FIT ALGO,LINEAR NO.,WAVELENGTH[nm],INPUT LVL[dBm],OUTPUT LVL[dBm], ASE LVL[dBm],RESOLN[nm],GAIN[dB],NF[dB] 1,1544.4983,-29.320,-2.260,-22.281,0.102,27.017,8.533...

  • Page 254: Saving/Loading Program Data

    Saving/Loading Program Data Procedure Programs created with the program function are saved in binary format. CAUTION Do not remove the USB storage medium or turn the power OFF while the USB storage medium access indicator is blinking. This can damage the data on the medium or the device itself.
  • Page 255 8.6 Saving/Loading Program Data Selecting the Save Destination and Data Format Press the MEMORY soft key and specify a save destination of INT (internal memory) or EXT (USB storage medium). Selecting a Memory Number to Save Press the CURSOR soft key, then set the cursor selection to UP (on the program list side).
  • Page 256 8.6 Saving/Loading Program Data Entering the Name of the File to Be Saved If a file name is not entered, it is automatically assigned in the form PXXXX.PG8 (where XXXX is a serial number starting from 0000). For creating a directory and sorting the file list, see the page 8-9. Press the CURSOR soft key, then set the cursor selection to DOWN (on the file list side).
  • Page 257 8.6 Saving/Loading Program Data Loading a Program File Setting the Type of the File to Be Loaded to PROGRAM Press FILE. Press the ITEM SELECT soft key. The soft key menu switches. Press the PROGRAM soft key. PROGRAM is selected, and the screen returns to the previous stage.
  • Page 258 8.6 Saving/Loading Program Data Selecting a Program Number to Save Press the CURSOR soft key, then set the cursor selection to DOWN (on the program list side). Select the program number of the load destination using the rotary knob, arrow keys, or numeric key pad.
  • Page 259 8.6 Saving/Loading Program Data Explanation Extension The extension used when saving is as follows. BIN (binary format): .PG8 File Name You can have a file name automatically assigned, or specify an arbitrary name for the save. If you do not assign a file name, a file name is automatically assigned as follows. File name: PXXXX.PG8 XXXX is a serial number from 0000 to 9999 Note...

  • Page 260: Saving Screen Image Data

    Saving Screen Image Data Procedure You can save the screen as an image file. CAUTION Do not remove the USB storage medium or turn the power OFF while the USB storage medium access indicator is blinking. This can damage the data on the medium or the device itself.
  • Page 261 8.7 Saving/Loading Image Data Selecting the Save Destination and Data Format Press the MEMORY soft key and specify a save destination of INT (internal memory) or EXT (USB storage medium). Selecting the Color and File Format Press the MODE soft key and specify B&W (black and white) or COLOR. Press the FILE TYPE soft key to select BMP or TIFF.
  • Page 262 8.7 Saving/Loading Image Data Entering the Name of the File to Be Saved If a file name is not entered, it is automatically assigned in the form GXXXX.BMP or GXXXX.TIF (where XXXX is a serial number starting from 0000). For creating a directory and sorting the file list, see the page 8-9. Press the CURSOR soft key, then set the cursor selection to DOWN (on the file list side).
  • Page 263 8.7 Saving/Loading Image Data Explanation Extensions The extensions used when saving are as follows. BMP (bit-mapped format): .BMP TIFF: .TIF File Name You can have a file name automatically assigned, or specify an arbitrary name for the save. If you do not assign a file name, a file name is automatically assigned as follows. File name: GXXXX.BMP or GXXXX.TIF XXXX is a serial number from 0000 to 9999 Note...

  • Page 264: Saving/Loading Template Data

    Saving/Loading Template Data Procedure You can save or load template file in CSV format. CAUTION Do not remove the USB storage medium or turn the power OFF while the USB storage medium access indicator is blinking. This can damage the data on the medium or the device itself.
  • Page 265 8.8 Saving/Loading Template Data Selecting the Save Destination and Data Format Press the MEMORY soft key and specify a save destination of INT (internal memory) or EXT (USB storage medium). Selecting a Template to Save Press the @@@@->FILE soft key (where @@@@ is UPPER, LOWER, or TARGET).
  • Page 266 8.8 Saving/Loading Template Data Entering the Name of the File to Be Saved If a file name is not entered, it is automatically assigned in the form TXXXX.CSV (where XXXX is a serial number starting from 0000). For creating a directory and sorting the file list, see the page 8-9. Press the CURSOR soft key, then set the cursor selection to DOWN (on the file list side).
  • Page 267 8.8 Saving/Loading Template Data Loading a Template File Setting the Type of the File to Be Loaded to TEMPLATE Press FILE. Press the ITEM SELECT soft key. The soft key menu switches. Press the TEMPLATE soft key. TEMPLATE is selected, and the screen returns to the previous stage.
  • Page 268 8.8 Saving/Loading Template Data Selecting a Template Press the FILE->@@@@ soft key (where @@@@ is UPPER, LOWER, or TARGET). The template selection screen appears. Press the soft key corresponding to the template to be loaded to. Executing the Load Press the EXECUTE soft key. The file is loaded as the specified template. When the RETURN soft key is pressed, the file is not loaded.
  • Page 269 File Size The file size differs depending on the data. Data Format You can save the file in CSV format. Data Format Header indicating the AQ6370B, AQ6370B Header indicating template data TEMPLATE, Template type (ABSOLUTE or RELATIVE) TYPE,ABSOLUTE Extrapolation type (A, B, or NONE)

  • Page 270: Creating Files

    Creating Files Procedure You can change file names, copy files, and perform other file manipulations. CAUTION Do not remove the USB storage medium or turn the power OFF while the USB storage medium access indicator is blinking. This can damage the data on the medium or the device itself.
  • Page 271 8.9 Creating Files Selecting All Files Press the FILE SELECT soft key. The file selection menu is displayed. Press the ALL SELECT soft key. All files are selected. Press the ALL CLEAR soft key to clear the file selection. Deleting a File/Directory Select a file or directory to delete using the procedure in step 4.
  • Page 272 8.9 Creating Files Copying a File/Directory Select a file or directory to copy using the procedure in step 4. Press the COPY soft key. Display the copy destination file list using steps 3 and 4. If the copy source and copy destination media are not the same, press the MEMORY soft key to select the copy destination medium.
  • Page 273 8.9 Creating Files Changing a File/Directory Name Select a file or directory name to change using the procedure in step 4. Press the RENAME soft key. The menu for setting names appears. Press the FILE NAME soft key. The text entry window and corresponding soft key menu are displayed.
  • Page 274 8.9 Creating Files Creating a Directory Display the directory file list for creating directories using the procedure in step 4. Press the MAKE DIRECTORY soft key. The menu for setting names appears. Press the DIRECTORY NAME soft key. The text entry window and corresponding soft key menu are displayed.
  • Page 275 8.9 Creating Files Explanation File/Directory Name When changing file/directory names, only use the characters allowed by MS-DOS for file and directory names. The maximum file name length is 56 characters (including the extension). The following characters can be used in file names. !#$%&’()- 0123456789@ ABCDEFGHIJKLMNOPQRSTUVWXYZ^...

  • Page 276: Registering Soft Keys

    Chapter 9 Other Operations Registering Soft keys Procedure Press SYSTEM. The soft key menu regarding the system appears. Press the USER KEY DEFINE soft key. A registration screen (USER KEY DEFINE MODE) key is displayed. To exit the soft key registration mode, press UNDO/LOCAL. Press the panel key corresponding to the soft key to register.

  • Page 277: Data Initialization

    Data Initialization Procedure Press SYSTEM. The soft key menu regarding the system appears. Press the MORE 1/4 soft key to display 4/4. Press the PARAMETER INITIALIZE soft key. The initialization item setting menu is displayed. Set the initialization type according to the items to be initialized. Press the EXECUTE soft key.
  • Page 278 9.2 Data Initialization The initial values for each setting are shown below. SWEEP Function Initial Value Maximum Value Minimum Value SEGMENT POINT***** 50001 SWEEP MKR L1-L2 OFF/ON SWEEP INTERVAL *****s MINIMUM=0 99999 MINIMUM=0 CENTER Function Initial Value Maximum Value Minimum Value CENTER WL ****.***nm 1150.000 1700.000...
  • Page 279 9.2 Data Initialization SETUP Function Initial Value Maximum Value Minimum Value RESOLUTION @@@@nm 1.000 2.000 0.020 NORM/HOLD NORM/AUTO NORMAL SENS/MODE HIGH1 HIGH2 HIGH3 CHOP MODE OFF/SWITCH AVG TIMES *** SAMPLING POINT AUTO <SAMPLING POINT AUTO> SAMPLING POINT ***** 50001 calculated value, OFF <SAMPLING POINT AUTO>...
  • Page 280 TRACE E UP/LOW SPLIT TRACE F UP/LOW DISPLAY TRACE G UP/LOW UPPER HOLD OFF/ON HOLD LOWER HOLD OFF/ON // AQ6370B OPTICAL LABEL SPCTRUM ANALYZER // NOISE MASK ***dB OFF(-999) MASK LINE VERT / HRZN HRZN TRACE Function Initial Value Maximum Value...
  • Page 281 9.2 Data Initialization MARKER Function Initial Value Maximum Value Minimum Value MARKER ACTIVE OFF/ON SET MARKER 1024 WL=1700.000 WL=600.000 LINE MARKER 1 OFF/ON FREQ=499.65410 FREQ=176.34850 WL=1700.000 WL=600.000 LINE MARKER 2 OFF/ON FREQ=499.65410 FREQ=176.34850 LOG=30.0 LOG=-90.0 LINE MARKER 3 OFF/ON LINEAR=1000mW LINEAR=1.00pW LOG=30.0 LOG=-90.0...
  • Page 282 9.2 Data Initialization Function Initial Value Maximum Value Minimum Value ALGO THRESH ENVELOPE/THRESH/RMS/PK-RMS THRESH **.**dB 20.00 50.00 0.01 THRESH2 **.**dB 20.00 50.00 0.01 1.00 10.00 1.00 MODE FIT OFF/ON MODE DIFF *.**dB 3.00 50.00 0.01 SMSR MODE SMSR1/SMSR2 SMSR1 SMSR MASK ±*.**nm 0.00 99.99 0.00...
  • Page 283 9.2 Data Initialization Function Initial Value Maximum Value Minimum Value SMSR MODE SMSR1/SMSR2 SMSR1 SMSR SMSR MASK ±*.**nm 0.00 99.99 0.00 POWER OFFSET LEVEL *.**dB 0.00 10.00 -10.00 THRESH LEVEL *.**dB 3.00 50.00 0.01 THRESH LEVEL *.**dB 3.00 50.00 0.01 MODE DIFF *.**dB 3.00 50.00...
  • Page 284 9.2 Data Initialization Function Initial Value Maximum Value Minimum Value SW OFF/ON SW OFF/ON SW OFF/ON ALGO THRESH/RMS THRESH THRESH LEVEL *.**dB 3.00 50.00 0.01 1.00 10.00 1.00 MODE FIT OFF/ON MODE DIFF *.**dB 3.00 50.00 0.01 SW OFF/ON ALGO THRESH/RMS THRESH THRESH LEVEL *.**dB 3.00...
  • Page 285 9.2 Data Initialization Function Initial Value Maximum Value Minimum Value SW OFF/ON ALGO PEAK/BOTTOM/BOTTOM LVL/ BOTTOM GRID THRESH LEVEL *.**dB 20.00 50.00 0.01 MODE DIFF *.**dB 3.00 50.00 0.01 CH SPACE ±*.**nm 0.40 50.00 0.00 SEARCH AREA ±*.**nm 0.01 10.00 0.01 ALGO MEAN...
  • Page 286 9.2 Data Initialization Function Initial Value Maximum Value Minimum Value SW OFF/ON SW OFF/ON ALGORHYTHM NOTCH(B) NOTCH(P)/NOTCH(B) THRESH LEVEL *.*dB 50.0 SW OFF/ON THRESH LEVEL *.***dB -10.000 30.000 -90.000 SW OFF/ON THRESH LEVEL *.*dB 50.0 TEST BAND *.**nm 0.20 99.99 0.01 SW OFF/ON TEST BAND *.**nm...
  • Page 287 9.2 Data Initialization FILE Function Initial Value Maximum Value Minimum Value DRIVE INT/EXT TRACE@ → FILE TRACE FILE TYPE BIN/CSV CURSOR UP/DOWN DOWN FILE TYPE BIN/CSV MEMORY LIST PARAMETER LBL/CONDTN MODE B&W/ COLOR COLOR GRAPHICS FILE TYPE BMP/TIFF DATE&TIME OFF/ON LABEL OFF/ON DATA AREA...
  • Page 288 9.2 Data Initialization PROGRAM Function Initial Value Maximum Value Minimum Value EXECUTE1 ** 01 (Program number) EXECUTE2 ** 02 (Program number) EXECUTE3 ** 03 (Program number) EXECUTE4 ** 04 (Program number) EXECUTE5 ** 05 (Program number) EXECUTE6 ** 06 (Program number) EXECUTE7 ** 07 (Program number) EXECUTE8 **...
  • Page 289 REFERENCE WAVELENGTH 193.1000 299.7924 176.3486 ****.****THz REMOTE INTERFACE @@@@ GP-IB MY ADDRESS ** GP-IB2 PORT ADDRESS ** SYSTEM CONTROLER OFF/ON COMMAND FORMAT @@@@ AQ6370B TLS ADDRESS BOUD RATE @@@@ 9600BPS 115200BPS 1200BPS PARITY @@@@ NONE FLOW @@@@ NONE COMMAND FORMAT @@@@...

  • Page 290: Help

    Help Procedure Displays a menu for displaying help. Press HELP. An explanation for the displayed menu appears. Select the soft key of the help text to display, then press the SELECT soft key. The help information is displayed. To quit, press the QUIT HELP soft key. Menu after pressing HELP Selection of soft keys for displaying help...

  • Page 291: Registering And Loading Character Strings

    Registering and Loading Character Strings In menus such as File Name that have PRESET WORD soft keys, you can register input character strings and load previously registered strings. Procedure Registering Strings After a string has been entered in the string name entry screen, press the PRESET WORD soft key.

  • Page 292: Other Settings

    Other Settings Procedure UNCAL mark and Warning Display Settings Press SYSTEM. Press the MORE 1/4 soft key two times to display the MORE 3/4 screen. Press the UNCAL WARNING OFF ON soft key. The settings turns ON and OFF each time you press the key. When ON, the UNCAL mark and a warning is displayed.
  • Page 293 9.5 Other Settings Setting the Screen Image Data Output Destination You can specify the output destination used when the COPY key is pressed. Press SYSTEM. Press the MORE 1/4 soft key. The MORE 2/4 screen is displayed. Press the HARD COPY DEVICE soft key. The output destination selection menu is displayed.

  • Page 294: Upgrading The Firmware

    Chapter 10 Maintenance 10.1 Upgrading the Firmware Procedure Preparing for Upgrade Downloading the Firmware Download the updating software from the Yokogawa Web site. Save the downloaded software to a USB memory device. http://www.yokogawa.co.jp/tm/ Removing the Ethernet Cable Confirm that the instrument is not connected to a network. The upgrade cannot be performed if connected to a network.
  • Page 295 10.1 Upgrading the Firmware Press the YES (REBOOT) soft key. Step 1 of the version upgrade begins. When step 1 of the upgrade is finished, the instrument restarts automatically. When the instrument restarts, step 2 of the upgrade begins at the same time. When step 2 of the upgrade is finished, the power turns OFF automatically.

  • Page 296: Mechanical Inspection

    10.2 Mechanical Inspection WARNING When performing inspection, turn OFF the MAIN POWER switch on the rear panel and remove the power cable. CAUTION • If any foreign particles become trapped in the various connectors, malfunction or damage can result. • If any of the various types of connectors do not fit snugly, the instrument may not operate normally.

  • Page 297: Operational Inspection

    10.3 Operational Inspection Checking the Operations of Each Switch With the power to the instrument turned ON, operate each switch once briefly to check that the unit functions properly. Checking the Operations of the Built-In Thermal Printer (Optional) Open the cover of the printer inside the unit. Check that the printer paper has been placed properly.

  • Page 298: Inspection Of Wavelength Accuracy

    10.4 Inspection of Wavelength Accuracy Perform a check of the instrument’s wavelength accuracy. Use a light source such as a gas laser whose wavelength accuracy is known. AQ6370B AQ6370 OPTICAL SPECTRUM ANALYZER Light source 9.5/125 µ m SM optical fiber...

  • Page 299: Inspection Of Level Accuracy

    10.5 Inspection of Level Accuracy Perform a check of the instrument’s level accuracy. Use a light source of 1310 nm or 1550 nm. AQ6370B AQ6370 OPTICAL SPECTRUM ANALYZER Light source 9.5/125 µ m SM optical fiber Optical power meter Procedure Execute the alignment adjustment function on the unit’s internal monochromator.

  • Page 300: Replacing Fuses

    If you need to replace a fuse due to an equipment failure, first determine the cause of the failure and solve the problem before replacing the fuse. The AQ6370B uses ordinary fusing-type 5-amp fuses with a 100–120 V power supply, and use time lag-type 3.15-amp fuses with a 200–240 V power supply.

  • Page 301: Daily Maintenance

    10.7 Daily Maintenance Cleaning the Exterior of the Instrument When removing dirt from the case or operation panel, remove the power cord from the power outlet, then wipe gently with a clean, dry cloth. Do not use volatile chemicals since this might cause discoloring and deformation.
  • Page 302 10.7 Daily Maintenance Cleaning the Optical Output WARNING The instrument has a built-in reference light source for wavelength calibration, and infrared light is always being output from the optical output connector. Never look into the optical output connector. Infrared light entering the eyes can cause severe injury and loss of vision.

  • Page 303: Care During Storage

    10.8 Care during Storage If the instrument is stored for a long time, sufficient care should be taken of the following: • Wipe off any dust, fingerprints, or other dirt that has adhered to the instrument. • Perform the inspections given in section 10.2, “Operational Inspection” to check that the instrument operates properly.

  • Page 304: Recommended Replacement Parts

    10.9 Recommended Replacement Parts Yokogawa warrants the instrument based on the period and stipulations described on the warranty sheet. As stated in the warranty, the following parts (parts with limited lifespan) are not included in the warranty. For replacement of parts, please contact your nearest Yokogawa representative.

  • Page 305: Warning Display Function

    10.10 Warning Display Function Message Cause of Warning No.1 - 49: Message generation after the execution of functions Unsuitable Resolution Data may not be extracted completely, because the resolution setting is not appropriate for the span and the sampling number. Unsuitable Level Scale A level scale larger than 5 dB/DIV has been set in the range fixed mode (SENS:NORM HOLD).If a level scale is set to 5 dB/DIV or...
  • Page 306 10.10 Warning Display Function Message Cause of Warning USB Storage is write protected The USB storage device is write protected. File not found The specified file cannot be read because it has not been found. Or, the file does not exist on the disk. Illegal directory name Directory cannot be created because the name is not valid.
  • Page 307 10.10 Warning Display Function Message Cause of Warning Auto offset error! Obtained an abnormal value during AUTO OFFSET operation. Auto offset error! Obtained an abnormal value during AUTO OFFSET operation. Auto temperature control error! Problem with the light detector temperature control. Measurement sequence error! The sweep stopped because measurement sequence fell into disorder during the sweep.
  • Page 308 10.10 Warning Display Function Message Cause of Warning Option is not connected No external device is connected. GPIB2 not system controller System controller connected to the GP-IB2 port has been set to an external computer. Disk full No file can be created due to insufficient free space on the USB storage medium.
  • Page 309 Chapter 11 Specifications 11.1 Specifications Item Specifications µ µ µ Applicable fiber SM (9.5/125 m), GI (50/125 m, 62.5/125 Measurement wavelength range 600 to 1700 nm Span 0.5 nm to 1100 nm (entire wavelength range), 0 nm 1, 2, 3 Wavelength accuracy ±0.02 nm (1520 to 1580 nm) ±0.04 nm (1450 to 1520 nm, 1580 to 1620 nm)
  • Page 310 11.1 Specifications Item Specifications Function Marker/Search Delta markers (1024 points maximum), vertical/horizontal line markers, peak search, 2nd peak search, bottom search, 2nd bottom search, auto search (ON/OFF), search between vertical axis line markers, search within zoom area Analysis Spectral width analysis (threshold, envelope, RMS, Peak RMS, notch), WDM (OSNR) analysis, EDFA-NF analysis, filter peak/bottom analysis, WDM filter peak/bottom analysis, DFB-LD analysis, FP-LD analysis, LED analysis, SMSR analysis, power analysis, PMD analysis, Pass/Fail judgment from template, auto analysis, analysis between vertical axis...
  • Page 311 11.1 Specifications Item Specifications Immunity Conforming standards EN61326-1 Table 2 (For use in industrial locations) Effect in immunity environment Wavelength measurement sensitivity: Within ±0.1 nm Cable conditions Same as above emission cable conditions. 1: Horizontal axis scale: In wavelength display mode µ...

  • Page 312: External Dimensions

    11.2 External Dimensions Unit : mm (approx. inch) REAR VIEW ( 0.58 ) 14.8 458.8 ( 18.06 ) ( 1.26 ) 12.3 12.3 ( 0.48 ) ( 16.77 ) ( 0.48 ) If not specified, the tolerance is ±3%. However, in cases of less than 10 mm, the tolerance is ±0.3 mm. 11-4 IM 735302-01E...

  • Page 313: Appendix

    Appendix 1 GRID Table for WDM Wevelength Some analytical functions refer to the GRID table for analysis(See the following table.) The AQ6370B contains the nominal center frequencies specified by the ITU-T (International Telecommunication Union-Telecommunication sector) G692 as the GRID table. It also contains two tables: the standard GRID table created according to the pre- defined wavelength (frequency) range and the custom GRID table that users can edit freely.
  • Page 314 Appendix 2 Data Calculation Algorithms for Spectrum Widths The AQ6370B can calculate spectrum widths of waveforms being displayed. This section provides four types of spectrum width calculation methods as well as algorithms for the NOTCH width calculation. THRESH Method This method is used to obtain the spectrum widths of two points, which are lower than the peak level by a threshold value (THRESH [dB]) specified by a parameter, as well as their center wavelengths.
  • Page 315 Appendix 2 Data Calculation Algorithms for Spectrum Widths In the case of two or more mode peaks Threshold Value Δ ( ”MODE FIT” ON ) Δ ( ”MODE FIT” OFF ) ’ ’ • If “MODE FIT” is ON, set the wavelengths of the mode peaks, which are outmost from the threshold value (THRESH[dB]) among the mode peaks, to .
  • Page 316 Appendix 2 Data Calculation Algorithms for Spectrum Widths ENVELOPE Method This method is used in conjunction with a straight line (envelope) connecting mode peaks to obtain the spectrum widths of the two points, which are lower than the peaks by a configured threshold value (THRESH [dB]), as well as their center wavelengths.
  • Page 317 Appendix 2 Data Calculation Algorithms for Spectrum Widths In the case of two valid mode peaks. Threshold Value • Set the levels (LOG) of the two valid mode peaks to LG1 and LG2 in order from the left. • Obtain in the following manner.

  • Page 318: Appendix 2 Data Calculation Algorithms For Spectrum Widths

    Appendix 2 Data Calculation Algorithms for Spectrum Widths In the case of three or more valid mode peaks. Threshold Value • Set the levels (LOG) of three or more valid mode peaks to LG1, LG2 • • • LGn in order from the left.
  • Page 319 Appendix 2 Data Calculation Algorithms for Spectrum Widths RMS Method Use the RMS method to obtain the spectrum width and its center wavelength. Following table shows the details of parameters for the RMS method. Parameter Abbreviation Default Value Setting Range Unit Description THRESH...
  • Page 320 Appendix 2 Data Calculation Algorithms for Spectrum Widths PEAK RMS Method Use the PEAK RMS method to obtain the spectrum width and its center wavelength. Following table shows the details of the parameters for the PEAK RMS method. Parameter Abbreviation Default Value Setting Range Unit...
  • Page 321 Appendix 2 Data Calculation Algorithms for Spectrum Widths NOTCH Width Measurement Obtain a bottom level. Then, obtain the NOTCH width for the bottom level and its center wavelength. Following table shows the details of parameters for NOTCH analyses. Parameter Abbreviation Default Value Setting Range Unit Description THRESH...
  • Page 322 Appendix 2 Data Calculation Algorithms for Spectrum Widths When “TYPE” is PEAK. Lp-TH • Obtain the minimum level “LGmin.” Also, set the wavelength of this point to λmin. • Obtain LG0 at the peak level (LOG) on the left of LGmin. Also, set the wavelength of this point to λ • Obtain LG1 at the peak level (LOG) on the right of LGmin. Also, set the wavelength of this point to λ...

  • Page 323: Appendix 3 Details Of Each Analytical Functions

    Appendix 3 Details of Each Analytical Functions This section describes the algorithms for analyses using the ANALYSIS 1 soft key in the ANALYSIS. ANALYSIS 1 provides such functions as collective analysis of various light sources, POWER analysis, SMSR analysis, and PMD analysis. SMSR Analysis Function Use the optical spectrum after the measurement of DFB-LD to analyze the SMSR (Side Mode Suppression Ratio) of DFB-LD.
  • Page 324 Appendix 3 Details of Each Analytical Functions SMSR2 Of the highest mode peak level and the mode peaks on either side, whichever is higher is defined as the side mode. Mode Peak( A) SMSR Side Mode( B) Algorithms of analysis for the SMSR1 mode are as follows. •...
  • Page 325 Appendix 3 Details of Each Analytical Functions POWER Analysis Function This function allows the user to add up level values of measured waveforms, thereby enabling the calculation of total power. It would be more convenient if the between line markers search function and the zoom area search function were also used for the POWER analysis.
  • Page 326 Appendix 3 Details of Each Analytical Functions PMD Analysis Function Measured waveforms are used to analyze PMD values. Following table shows the details of the parameter for PMD analysis. Parameter Abbreviation Default Value Setting Range Unit Description THRESH 10.00 0.01 to 50.00 Threshold value Algorithms of the analysis are as follows.
  • Page 327 Appendix 3 Details of Each Analytical Functions DFB-LD Analysis Function The following parameters for DFB-LD light sources are analyzed collectively. • -XdB WIDTH • SMSR Following table shows the details of parameters for DFB-LD analysis. Parameter Abbreviation Default Value Setting Range Unit Description ENVELOPE /...
  • Page 328 Appendix 3 Details of Each Analytical Functions FP-LD Analysis Function The following parameters for FP-LD light sources are analyzed collectively • SPECTRUM WIDTH • MEAN WAVELENGTH • TOTAL POWER • MODE NO. Following table shows the details of parameters for FP-LD analysis. Parameter Abbreviation Default Value Setting Range Unit...
  • Page 329 Appendix 3 Details of Each Analytical Functions LED Analysis Function The following parameters for LED light sources are analyzed collectively. • SPECTRUM WIDTH • MEAN WAVELENGTH • TOTAL POWER Following table shows the details of parameters for LED analysis. Parameter Abbreviation Default Setting Range...

  • Page 330: Appendix 4 Detailed Explanations Of Wdm Analysis Function

    Appendix 4 Detailed Explanations of WDM Analysis Function This function provides the analyses of NOISE level and SNR in each mode within the measurement range of WDM waveforms. Items for analysis NO.: Channel No. i WAVELENGTH: Center wavelength λi of the channel LEVEL: Level (peak level – noise level) Li of the channel OFFSET WL: Relative wavelength to the wavelength of the reference channel (REF) OFFSET LVL:...
  • Page 331 Appendix 4 Details of WDM Analysis Function Related to SNR Analysis Parameter Default Setting Range Unit Description AUTO-FIX MANUAL-FIX AUTO-CTR Selection of algorithms for noise level NOISE ALGO AUTO-FIX MANUAL-CTR measurement. A range of waveform data for use in noise level analysis is specified as a range centering on channel wavelengths.
  • Page 332 Appendix 4 Details of WDM Analysis Function Related to display Parameter Default Setting Range Unit Description Setting of the format to display wavelengths, levels, noises, and SNRs, which are the results of analyses. ABSOLUTE: display of absolute values RELATIVE: display of relative values compared to ABSOLUTE GRID.
  • Page 333 6. Obtain the measurement resolution RBi of each channel from the values stored in the AQ6370B. 7. According to the setting of the parameter FITTING ALGO, generate fitting waveforms...
  • Page 334 Appendix 4 Details of WDM Analysis Function Automatic Parameter Setting Function This unit provides the noise area/mask area automatic setting function. To activate the automatic setting, set the algorithm to AUTO-FIX or AUTO-CTR. AUTO-FIX Noise Algorithm Obtain the left and right noise areas (NA_Ri, NA_Li) of each channel according to the number of detected WDM channels as follows: When the number of WDM channels “n”...
  • Page 335 Appendix 4 Details of WDM Analysis Function Fitting Algorithm While the setting to AUTO-CTR, LINEAR is used for the fitting algorithm, which is calculated as follow. • Obtain ELi and ERi as the level (LOG) of each position of the noise areas NA_Li and NA_Ri.
  • Page 336 Appendix 4 Details of WDM Analysis Function Setting of the Parameter “DUAL TRACE” This function enables more precise analyses by measuring waveforms with different measurement resolutions at trace A and trace B and also by performing measurements with resolutions different in noise level from the signal level of each channel. When “DUAL TRACE”...
  • Page 337 Appendix 4 Details of WDM Analysis Function Items to be Displayed When DISPLAY is Set ABSOLUTE Results of analyses are displayed in absolute values. Explanations of display items Channel number WAVELENGTH: Center wavelength of the channel LEVEL: Level of the channel (peak level – noise level) OFFSET WL: Relative wavelength to the wavelength of the reference channel (REF) OFFSET LVL:...
  • Page 338 Appendix 4 Details of WDM Analysis Function RELATIVE Of the analytical results, wavelength values are displayed as relative values to the values in the grid table. Explanations of display items Channel number GRID WL: GRID wavelength of the channel MEAS WL: Center wavelength of the channel REL WL: Relative wavelength to the GRID wavelengths of the channel MEAS LVL: Level of the channel (peak level –...
  • Page 339 Appendix 4 Details of WDM Analysis Function DRIFT(MEAS) Wavelengths measured previously are used as references to display wavelength/level changes (drifts). Explanations of display items Channel number REF WL: Reference wavelength of the channel (previous wavelength measured) MEAS WL: Center wavelength of the channel DIFF MAX (wavelength): Maximum value of the relative wavelength to the reference wavelength of the channel DIFF MIN (wavelength):...
  • Page 340 Appendix 4 Details of WDM Analysis Function DRIFT(GRID) Grid wavelengths are used as references to display wavelength/level changes (drifts). Note that reference levels are previous measurement levels. Explanations of display items Channel number GRID WL: Reference wavelength of the channel (grid wavelength) MEAS WL: Center wavelength of the channel DIFF MAX (wavelength): Maximum value of the relative wavelength to the reference...
  • Page 341 Appendix 5 Details of Optical Amplifier Analysis Function This function enables the analysis of gains and NF (noise figures) of optical fiber amplifiers. Items to be analyzed Center wavelength of each channel. -> Center frequency during the frequency λ mode. LINi Signal optical power of each channel (after OFFSET compensation) LOUTi Output optical power of each channel (after OFFSET compensation)

  • Page 342: Appendix 5 Details Of Optical Amplifier Analysis Function

    Appendix 5 Details of Optical Amplifier Analysis Function Algorithm for analysis 1 Apply the WDM analysis to the signal optical waveform data of TRACE A to perform channel detection. Note, however, that the parameter DISPLAY MASK is not used. 2 Obtain the center wavelength i of each channel and signal optical level LIN’i of λ...
  • Page 343 Appendix 5 Details of Optical Amplifier Analysis Function Automatic Parameter Setting Function The AQ6370B provides a fit area/mask area automatic setting function. AUTO-FIX ASE algorithm The fitting algorithm is LINEAR. Since the algorithm is LINEAR, the mask area setting will not be required.

  • Page 344: Appendix 6 Details Of Optical Filter Analysis Function

    Appendix 6 Details of Optical Filter Analysis Function FILTER PEAK Analysis Function This function enables the collective analysis of measured waveforms of optical filters via multiple parameters. It can be used for filter analysis only if the number of modes is one. Items and algorithms for analysis are the same as in the AQ6317 series.
  • Page 345 Appendix 6 Details of Optical Filter Analysis Function List of Parameters Item Parameter Default Setting Range Unit Description PEAK LEVEL ON or OFF ON/OFF switchover of display. PEAL WL ON or OFF ON/OFF switchover of display. ON or OFF ON/OFF switchover of display THRESH Selection of algorithm for spectrum ALGO...
  • Page 346 Appendix 6 Details of Optical Filter Analysis Function Details of Analyses (1)PEAK LVL (2)PEAK WL (6) RIPPLE WIDTH TH[dB] (5) CROSS TALK (5) CROSS TALK (4)SPEC WD (3)MEAN WL λcs [nm] λcs [nm] (1) Peak level (PEAK LVL): value of the level at the waveform peak position (2) Peak wavelength (PEAK WL): value of the wavelength at the waveform peak position...
  • Page 347 Appendix 6 Details of Optical Filter Analysis Function FILTER BOTTOM Analysis Function This function enables the collective analysis of multiple parameters via the measured waveforms of optical filters. It is used for filter analysis if the number of modes is one. Items and algorithms for analysis are the same as in the AQ6317 series.
  • Page 348 Appendix 6 Details of Optical Filter Analysis Function Details of Analysis λcs [nm] λcs [nm] (5) CROSS (5) CROSS (4)NOTCH WD TALK TALK (3)MEAN WL TH[dB] (1)BOTTOM LVL (2)BOTTOM WL (1) Bottom level (BTM LVL): Value of level at the waveform bottom position (2) Bottom wavelength (BTM WL): Value of wavelength at the waveform bottom position...
  • Page 349 Appendix 6 Details of Optical Filter Analysis Function WDM FILTER PEAK Analysis Function This function enables the collective analysis of multiple items for each channel via the measured waveforms of multi-channel optical filters. It also enables filter analysis for multi-mode waveforms, which is different from FILTER PEAK analysis.
  • Page 350 Appendix 6 Details of Optical Filter Analysis Function Algorithms for analysis Channel Detection, Nominal Wavelength Parameter THRESH MODE DIFF ALGO TEST BAND Procedure PEAK • Channel: Each mode peak detected via a mode search (Except for the mode peaks at levels which are lower than the mode at the highest level by THRESH[dB] or less.) •...
  • Page 351 Appendix 6 Details of Optical Filter Analysis Function PEAK LVL/PEAK WL Parameter THRESH MODE DIFF Procedure • Apply WDM analysis to the waveform data of an active trace and perform channel detection. Note that the parameter DISPLAY MASK is not used. •...
  • Page 352 Appendix 6 Details of Optical Filter Analysis Function XdB stop band xdB stop-band Port A Port B λi Wavelength nominal wavelength Parameter THRESH Procedure Obtain the width (xdB_stop-band) that centers on the reference wavelength i of each λ channel and that is located below by the parameter THRESH_LEVEL both on the left and on the right.
  • Page 353 Appendix 6 Details of Optical Filter Analysis Function Ripple Test Band Maximum Level Ripple in Test Band Port A Minimum Level in Test Band Port B λi Wavelength nominal wavelength Parameter TEST BAND Procedure • Perform the peak search and bottom search within the range of parameter Test_Band/2 by centering on the reference wavelength i of each channel, and obtain λ...
  • Page 354 Appendix 6 Details of Optical Filter Analysis Function Cross Talk Minimum Level Test Band in Test Band Port A Cross Talk(L) Cross Talk(R) Maximum Level in Test Band Port B Test Band Wavelength Spacing Spacing λi nominal wavelength Parameter SPACING TEST BAND Procedure •...
  • Page 355 Appendix 6 Details of Optical Filter Analysis Function WDM FILTER BOTTOM Analysis Function This function enables the collective analysis of multiple items of each channel via the measured waveforms of multi-channel optical filters. It also enables filter analysis for multi-mode waveforms, which is different from the FILTER BOTTOM analysis.
  • Page 356 Appendix 6 Details of Optical Filter Analysis Function Algorithm for analysis NOMINAL WAVELENGTH Parameter ALGO MODE DIFF THRESH TEST BAND Procedure • BOTTOM Channel: Each mode bottom detected by a mode search (Except for the mode bottoms at levels which are above the mode at the lowest level by THRESH[dB] or more.) Reference wavelength: Wavelength of each mode bottom.
  • Page 357 Appendix 6 Details of Optical Filter Analysis Function BOTTOM WL / BOTTOM LVL Parameter THRESH MODE DIFF Procedure Obtain the wavelength ’i of the mode bottom of each channel and its signal optical level λ LBi. XdB_NOTCH_WIDTH/CENTER WAVELENGTH Parameter ALGO Procedure According to the settings of the parameter ALGO, obtain the xdB notch width (xdB_Notch_Width) of each channel and its center wavelength/frequency...
  • Page 358 Appendix 6 Details of Optical Filter Analysis Function XdB_STOP-BAND Port B Port A xdB stop-band Wavelength λ nominal wavelength Parameter THRESH Procedure Obtain the width (xdB_stop-Band) that centers on the nominal wavelength i of each λ channel and that is located below by the parameter THRESH_LEVEL both on the left and on the right.
  • Page 359 Appendix 6 Details of Optical Filter Analysis Function RIPPLE Port B Test Band Maximum Level Port A in Test Band Ripple Minimum Level in Test Band λ Wavelength nominal wavelength Parameter TEST BAND Procedure • Perform the peak search and bottom search within the range of parameter Test_Band/2 by centering on reference wavelength i of each channel, and obtain the λ...
  • Page 360 Appendix 6 Details of Optical Filter Analysis Function CROOS TALK Test Band Port B Minimum Level Cross Talk(L) in Test Band Cross Talk(R) Test Band Port A Maximum Level in Test Band Wavelength Spacing Spacing λ nominal wavelength Parameter SPACING TEST BAND Procedure •...
  • Page 361 Appendix 7 Soft Key Tree Diagram The following is an overview of the instrument's menus. Some menus are omitted. SWEEP Auto sweep (5.1, 10.5) Repeat sweep (5.12-5.14, 5.17, 7.11) Single sweep (5.12-5.14, 5.17) Sweep stop (5.12, 5.14) Segment measuring (5.12) Segment unit setting (5.12) Sweep between line markers (5.13) Sweep interval setting (5.12)
  • Page 362 Appendix 7 Soft Key Tree Diagram LEVEL LEVEL (2/2) LEVEL (1/2) Reference level setting (2.5, 5.1, 5.4, 7.12) LOG scale setting (5.2, 5.4) Linear scale setting (5.2, 5.4) Linear scale bottom settings (5.2) Setting the peak level to the reference level (2.2, 5.4) Automatic setting of reference level (5.4) Vertical axis units setting (5.2) Vertical axis setting (5.2)
  • Page 363 Appendix 7 Soft Key Tree Diagram SETUP SETUP (2/2) SETUP (1/2) 10-1 10-2 Measurement resolution setting (5.7, 7.11, 10.5) Measurement sensitivity, CHOP mode settings (5.9) CHOP mode setting (5.9) Averaging times setting (5.10) Automatic sampling points setting (5.7, 5.8) Manual sampling points setting (5.8) Sampling interval setting (5.8) Setting the measured wavelength to air/vacuum (5.2) Horizontal axis units setting (5.2)
  • Page 364 Appendix 7 Soft Key Tree Diagram ZOOM Zoom display center wavelength (frequency) setting (6.1, 7.12) Zoom display span setting (6.1) Zoom display start point setting (6.1) Zoom display stop point setting (6.1) Setting the peak wavelength to the center wavelength of zoom display (2.2, 6.1) Overview display position setting (6.1) Overview size setting (6.1)
  • Page 365 Appendix 7 Soft Key Tree Diagram TRACE (MORE 1/2) Active trace setting (5.11, 6.2-6.7, 7.8, 7.9) Show/hide active trace setting (5.11, 6.2-6.7, 7.8, 7.9) Setting write mode on the active trace (5.11, 6.2, 7.8, 7.9) Setting fixed mode on the active trace (6.2, 7.8, 7.9) Setting MAX/MIN hold mode on the active trace (6.3) Active trace sweep average setting(6.4) Trace-to-trace calculation settings (trace C, F, G only) (6.5-6.7, 7.9)
  • Page 366 Appendix 7 Soft Key Tree Diagram TRACE(MORE 2/2) Copy trace (6.11) Copy source trace setting (6.11) Copy target trace setting (6.11) Execute copy (6.11) Trace clearing (6.11) App-54 IM 735302-01E...
  • Page 367 Appendix 7 Soft Key Tree Diagram MARKER Moving marker display ON/OFF (6.8) Setting moving markers to fixed markers (6.8, 6.12) Clearing fixed markers (6.8, 6.12) Setting the moving marker wavelength (frequency) to measurement center (2.2, 5.5, 6.8) Setting the moving marker wavelength (frequency) to display scale center (2.2, 6.8) Setting the moving marker level to reference level (2.2, 5.4, 6.8) Clear all displayed moving and fixed markers (6.8, 6.12) Line markers ON/OFF (6.8)
  • Page 368 Appendix 7 Soft Key Tree Diagram PEAK SEARCH Executing peak search (6.12) Executing bottom search (6.12) Moving the moving marker from the current position to the next peak/bottom value (6.12) Moving the moving marker from the current position to the next peak/bottom value to the right (6.12) Moving the moving marker from the current position to the next peak/bottom value to the left (6.12)
  • Page 369 Appendix 7 Soft Key Tree Diagram ANALYSIS 10-1 10-2 10-3 10-4 10-5 10-6 10-7 Spectrum width analysis algorithm settings/execution (7.1, 7.2) Analysis function settings (7.3–7.6, 7.13) (DFB-LD, FP-LD, LED, SMSR, POWER, PMD) Analysis function settings (7.7-7.9) (WDM, FILTER-PK, FILTER-BTM, WDM FIL-PK, WDM FIL-BTM) Executing the specified analysis (chapter 7) Spectrum width analysis threshold setting (7.1) Analysis parameter settings (7.1-7.9)
  • Page 370 Appendix 7 Soft Key Tree Diagram MEMORY Temporarily saving a trace (8.2) Loading temporarily saved trace (8.2) Clearing temporarily saved traces (8.2) Displaying temporarily saved traces in a list (8.2) Changing list display contents (8.2) App-58 IM 735302-01E...
  • Page 371 Appendix 7 Soft Key Tree Diagram FILE For TRACE 5-3-1 1 Saving data (chapter 8) Setting the save destination for trace data (8.3) Entering a file name (8.3) Setting the trace to save (8.3) Setting the data format (8.3) 2 Loading data (7.12, chapter 8) Setting the loading source for trace data (8.3) Setting the loading destination trace (8.3) Switching list/thumbnail display (8.3)
  • Page 372 Appendix 7 Soft Key Tree Diagram For MEMORY MEMORY Setting the MEMORY data save destination (8.3) Entering a file name (8.3) Switching the cursor target window (8.3) (setting the source/destination memory number) Setting the data format (8.3) Switching the MEMORY list display contents (8.3) Setting the MEMORY data loading source (8.3) Switching the cursor target window (8.3) (setting the source/destination load file)
  • Page 373 Appendix 7 Soft Key Tree Diagram For GRAPHIC For PROGRAM PROGRAM Setting the save destination for program data (8.6) Entering a file name (8.6) Switching the cursor target window (8.6) (setting the source/destination program number) Setting the loading source for program data (8.6) Switching the cursor target window (8.6) (setting the source/destination load file) GRAPHIC...

  • Page 374: Appendix 7 Soft Key Tree Diagram

    Appendix 7 Soft Key Tree Diagram PROGRAM (See IM735301-17E) 2-2-6-1 2-2-1 2-2-6-2 2-2-2 2-2-3 2-2-6-3 2-2-4 2-2-6-4 2-2-5 2-2-6-5 2-2-6 2-2-6-6 2-2-7 2-3-1 2-3-2 Program execution Program execution Registering programs to soft keys Editing programs Entering program names Editing lines 2-2-1 Setting program lines 2-2-2...
  • Page 375 Appendix 7 Soft Key Tree Diagram ADVANCE Template settings (7.12) GO/NO GO ON/OFF (7.12) Displaying templates (7.12) Setting the template type (7.12) Editing templates (7.12) Setting the template shift amount (7.12) Index App-63 IM 735302-01E...
  • Page 376 Appendix 7 Soft Key Tree Diagram SYSTEM(MORE 1/4) 7-2-1 7-2-2 7-2-3 7-2-4 7-2-5 7-2-6 7-2-7 Executing monochromator alignment adjustment (3.6) Wavelength calibration (3.7) Wavelength calibration using the internal light source (3.7) Wavelength calibration using a laser type external reference light source (3.7) Wavelength calibration using a gas cell type external reference light source (3.7) Wavelength calibration setting for wavelength calibration using an external...
  • Page 377 Appendix 7 Soft Key Tree Diagram SYSTEM(MORE 2/4) Communication interface settings (see IM 735301-17E) GP-IB interface settings (see IM 735301-17E, 5.17) Setting the GP-IB1 port address Setting the GP-IB2 port address (5.17) System controller function ON/OFF (5.17) Command mode setting Setting the turnable laser source address for the control target (5.17) RS-232 interface settings (see IM 735301-17E) Ethernet interface settings (see IM 735301-17E)
  • Page 378 Appendix 7 Soft Key Tree Diagram SYSTEM(MORE 3/4, MORE 4/4) UNCAL, warning display ON/OFF (9.5) Buzzer settings (9.5) Setting the number of level data digits (4.4) Semitransparent display ON/OFF (4.4) Date/time setting (4.5) Setting the display color (4.4) Removing the USB storage medium (3.3, 8.1) Initializing settings (9.2) Displaying the software version and upgrading (10.1) Displaying the patch list (10.1)

  • Page 379: Appendix 8 End User License Agreement

    Appendix 8 END USER LICENSE AGREEMENT • You have acquired a device (“DEVICE”) that includes software licensed by YOKOGAWA ELECTRIC CORPORATION from Microsoft Licensing Inc. or its affiliates (“MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online” or electronic documentation (“SOFTWARE”) are protected by international intellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights reserved. • IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT (“EULA”), DO NOT USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY CONTACT YOKOGAWA ELECTRIC CORPORATION FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND. ANY USE OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATION OF ANY PREVIOUS CONSENT). • GRANT OF SOFTWARE LICENSE. This EULA grants you the following license: • You may use the SOFTWARE only on the DEVICE. • NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLERANT. YOKOGAWA ELECTRIC CORPORATION HAS INDEPENDENTLY DETERMINED HOW TO USE THE SOFTWARE IN THE DEVICE, AND MS HAS RELIED UPON YOKOGAWA ELECTRIC CORPORATION TO CONDUCT SUFFICIENT TESTING TO DETERMINE THAT THE SOFTWARE IS SUITABLE FOR SUCH USE. • NO WARRANTIES FOR THE SOFTWARE. THE SOFTWARE is provided “AS IS” and with all faults. THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE, ACCURACY, AND EFFORT (INCLUDING LACK OF NEGLIGENCE) IS WITH YOU.
