INSTALLATION MANUAL
Important Safeguards
(For your safety, please follow the instructions below.)
In this Instruction Manual, the following symbols are shown for safe and proper use
of your automatic faucet and in order to alert you to the possibility of personal injury
and damage to your property.
The symbols and their meanings are as follows.
Ignoring these symbols may cause
Warning
personal injury and/or property damage.
*Some models may have different components from the ones illustrated below.
Warning
Do not place the Automatic Faucet in a high humidity
area such as shower room or sauna.
This may cause damage.
Do not use in
humid area
Do not strike or kick the Automatic Faucet.
This may cause damage or water leakage.
Do not strike
Never attempt to disassemble, reassemble, repair
or modify the Automatic Faucet, unless you are an
electrician, or qualified service person.
Do not
This may cause property damage or personal injury.
disassemble
0GU3013ER 2007.03
AUTOMATIC FAUCET
Specification
Item
RYOHAN™
Model
number
Helix™ Wall mount
Duration of
water discharge
Power supply
Battery life
Detection range
from the sensor
Water supply
maximum water pressure:
pressure
check local building codes for maximum water
Water supply connection
Ambient temperature
Humidity
Flow rate
Discharge quantity
Max. 0.25 gallon per cycle (0.95 L/cycle)
Single supply faucet
EcoPower type
TEL3GMY
TEL3GW#CP
60 seconds (TEL3 - 60)
-
-
5-1/8"~7-7/8" (130~200 mm)
sensor is self-adjusting
minimum required water pressure:
14.5 PSI (100 kPa) ( Flowing)
125 PSI (862 kPa)
pressure allowed
1/2" NPSM
o o
32~104 F(0~40 C)
Max. 90% RH
0.8 gallon per minutes (3 L/min.)
