TABLE OF CONTENTS
Location of PCB Boards ............................................ 1-2
Versions Variation ...................................................... 1-2
Specifications ............................................................ 1-3
Measurement Setup .................................................. 1-4
Service Aids .............................................................. 1-5
ESD & Safety Instruction .......................................... 1-6
Lead-free soldering Information ................................ 1-7
Setting procedure & Repair Instructions........................ 2
Disassembly Instructions & Service positions .............. 3
Block & Wiring Diagram ................................................ 4
DISP+LED+VOL Board.................................................. 5
MAIN Board.................................................................... 6
Power Board .................................................................. 7
MP3 IN Board ................................................................ 8
Scart Board .................................................................... 9
Mechanical Exploded View & Part List ........................ 10
Revision List ................................................................ 11
1 - 1
Chapter
HTS3376
/12
GB
3139 785 34971
Advertisement
Table of Contents
Related Manuals for Philips HTS3376/12
Summary of Contents for Philips HTS3376/12
- Page 1 Scart Board ..............9 Mechanical Exploded View & Part List ......10 Revision List ..............11 Copyright 2009 Philips Consumer Electronics B.V. Eindhoven, The Netherlands © All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
-
Page 2: Location Of Pcb Boards
1 - 2 LOCATION OF PCB BOARDS VERSION VARIATION: Type/Versions HTS3376 Features Output Power - 1000W Voltage (220~240V) MP3 Link SERVICE SCNARIO MATRIX: HTS3376 Type/Versions Board in used MAIN Board Power Board DISP+LED+VOL Board Scart Board MP3 IN Board *C = Component Level Repair... -
Page 3: Specifications
1 - 3 SPECIFICATIONS Playback media Speakers DVD-Video, DVD+R/+RW, DVD-R/-RW, DVD+R DL, CD-R/ System ............full range satellite CD-RW, Audio CD, Video CD/SVCD, Picture CD, MP3-CD, Speaker impedance ... 4 ohm (centre), 4 ohm (Front/Rear) WMA-CD, DivX-CD, USB ash drive Speaker drivers ................. - Page 4 1 - 4 MEASUREMENT SETUP Tuner FM Bandpass LF Voltmeter 250Hz-15kHz e.g. PM2534 e.g. 7122 707 48001 RF Generator e.g. PM5326 S/N and distortion meter e.g. Sound Technology ST1700B Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz). Use Audio Signal Disc SBC429 4822 397 30184 (replaces test disc 3)
- Page 5 1 - 5 SERVICE AIDS Service Tools: Universal Torx driver holder .........4822 395 91019 Torx bit T10 150mm ...........4822 395 50456 Torx driver set T6-T20 .........4822 395 50145 Torx driver T10 extended ........4822 395 50423 Compact Disc: SBC426/426A Test disc 5 + 5A ......4822 397 30096 SBC442 Audio Burn-in test disc 1kHz ....4822 397 30155 SBC429 Audio Signals disc .........4822 397 30184 Dolby Pro-logic Test Disc ........4822 395 10216...
- Page 6 1 - 6...
- Page 7 1 - 7...
- Page 8 2 - 1 2 - 1 System , Region Code , etc. Setting Produre 1)System Reset 7) Upgrading new software a) Press “SETUP“ button on R/C,TV will show setup menu a) Copy “software les” into a CD-R b) Select the menu using the on R/C b) Open the CD Door,then insert the CD-R program disc c) Go preference page to do system reset...
- Page 9 2 - 2 2 - 2 REPAIR INSTRUCTIONS (ONE)
- Page 10 2 - 3 2 - 3 REPAIR INSTRUCTIONS (TWO)
- Page 11 2 - 4 2 - 4 REPAIR INSTRUCTIONS (THREE)
- Page 12 3 - 1 3 - 1 DISASSEMBLY INSTRUCTIONS Dismantling of the Front Panel Assemble 3) Loosen 6 screws and remove the Top Cover by lifting the rear portion upwards before sliding it out towards the rear. - 1 screw “A” each on the left & right side as shown in gure 4. 1) Open the DVD Tray by using the Open/Close Button while the Set is ON and disconnect the mains supply after removing the Tray - 4 screws “B”...
-
Page 13: Service Positions
3 - 2 3 - 2 Dismantling of the DISP+LED+VOL&MP3 IN Board SERVICE POSITIONS 1) Loosen 10 screws “E” on the top of DISP+LED+VOL&MP3 IN Board as shown in gure 8. Service position A Figure 8 Dismantling of the Power Board 1) Loosen 4 screws “F”... -
Page 14: Block Diagram
4 - 1 4 - 1 BLOCK DIAGRAM Sanyo / Sony pick up VF D Display AS A DVD Loader B+5V IC V 5888 V- CL K VF D DR IV ER V- CS PT6311 Loader motor driver V- DAT A KE Y 1080P 3.3V... - Page 15 4 - 2 4 - 2 WIRING DIAGRAM...
-
Page 16: Disp+Led+Vol Board
5 - 1 5 - 1 FTD DISPLAY PIN ASSIGNMENT DISP+LED+VOL BOARD TABLE OF CONTENTS FTD Display Pin Assignment ............. 5-1 Circuit Diagram ................. 5-2 PCB Layout Top & Bottom View ............5-3 PIN CONNECTION... - Page 17 5 - 2 5 - 2 CIRCUIT DIAGRAM C380 B1 C384 C1 C387 A2 C390 B2 C395 C4 DP351 A2 Q351 C1 R3051 B1 R3054 B1 R3057 C1 R3060 C1 R3063 B1 R3068 A3 R3072 C1 RB351 C4 RB357 C1 TA351 A1 TA354 C1 ZD310 C1...
- Page 18 5 - 3 5 - 3 PCB LAYOUT - TOP VIEW C386 C391 DP351 A2 ESD4 ESD6 J351 J353 J355 J357 J359 LD351 RB355 A1 RB357 B1 SN351 B3 TA352 TA354 VR351 A3 C389 C392 ESD1 ESD5 ESD7 J352 J354 J356 J358 J363...
-
Page 19: Table Of Contents
6 - 6 - INTERNAL IC DIAGRAM - TAS5508B Power Supply MCLK PWM_MPP and MR XTL_OUT PWM Section PWM_MPP and ML XTL_IN Soft Soft Loud Comp DRC Emph Interpolate SRC NS PWM Blquads Tone Block PWM AP and AM1 L Front PLL_FLTM PLL_FLTP Soft... -
Page 20: Circuit Diagram(Part One)
6 - 2 6 - 2 CIRCUIT DIAGRAM - part one C401 A1 R425 A1 Q402 A3 R4020 A3 C4013 A4 C4031 A4 C4043 A4 R488 A4 C410 B1 C421 B1 C4049 B2 R411 B2 R421 B2 C4054 B3 R4002 B3 R452 B3 R499 B3 C4021 B4... -
Page 21: Circuit Diagram(Part Two)
6 - 3 6 - 3 CIRCUIT DIAGRAM - part two C0201 C2 C0214 C4 C0230 D1 C0248 B4 C104 A4 C208 A2 C223 D1 C236 A4 C261 D1 C718 B3 C737 A3 C812 A2 C827 B2 C840 B2 CE212 D1 CE807 D1 CN802 B1 FB205 C4... -
Page 22: Circuit Diagram(Part Three)
6 - 4 6 - 4 CIRCUIT DIAGRAM - part three C301 A1 C317 A3 C326 A1 C346 B3 C357 B1 C511 B4 C903 D1 C920 D1 CE302 D2 CE311 D2 CE320 D2 CE329 D3 FB312 B1 FE309 D3 JK302A B1 R3019 A2 R314 A1 R328 B2... -
Page 23: Pcb Layout Top View
6 - 5 6 - 5 PCB LAYOUT - TOP VIEW C317 JK701 A1 R711 C736 R254 R4018 A2 L416 C218 L201 R292 C331 R286 C342 R352 R722 C825 L501 R834 C912 R209 R601 IC404 C3 C4006 C4 C470 R433 R471 IC801 D1 R826... -
Page 24: Pcb Layout Bottom View
6 - 6 6 - 6 PCB LAYOUT - BOTTOM VIEW C0241 A1 R4030 A1 C4025 A2 D414 R4045 A2 C0603 A3 R4060 A3 C4000 B1 C485 C4001 B2 CE315 B2 C0230 B3 CE323 B3 C0246 B4 C728 FE301 B4 C506 C0215 C3 C236... - Page 25 7 - 1 7 - 1 INTERNAL IC DIAGRAM - AZ431 CATHODE POWER BOARD TABLE OF CONTENTS Internal IC Diagram ................7-1 Circuit Diagram .................. 7-2 ANODE PCB Layout Top View ............... 7-3 PCB Layout Bottom View ..............7-4...
- Page 26 7 - 2 7 - 2 CIRCUIT DIAGRAM BD901 A1 C910 D3 C923 D2 C936 B2 C947 C3 C957 A4 C965 C3 C974 B4 C985 B3 D904 B4 D915 C2 D927 C4 L901 C1 Q903 C3 Q913 A2 R906 C3 R916 A1 R926 C3 R935 B3...
- Page 27 7 - 3 7 - 3 PCB LAYOUT - TOP VIEW BD901 B1 C906 A3 C920 A2 C959 A3 C966 B4 C975 C4 CN906 C4 D917 B2 D927 B4 IC905 B4 J907 C2 J913 A4 J920 A4 J926 C4 L902 B1 NTC901 D1 R901 A4 R943 B2...
- Page 28 7 - 4 7 - 4 PCB LAYOUT - BOTTOM VIEW C907 B1 C928 A1 C938 A2 C947 B2 C955 B1 C967 B2 C983 B2 D904 B1 D928 B1 Q907 B1 R905 D4 R911 B1 R919 A1 R926 A2 R934 A3 R939 B2 R956 B1 R965 B2...
-
Page 29: Mp3 In Board
8 - 1 8 - 1 MP3 IN BOARD TABLE OF CONTENTS Circuit Diagram .................. 8-1 PCB Layout Top & Bottom View ............8-2... - Page 30 8 - 2 8 - 2 CIRCUIT DIAGRAM C383 A3 FB351 A1 FB352 A1 FB355 A3 FB356 A3 FB357 A3 JK351 A2 R3079 A1 R3080 A1 RB352 A1 RB354 A2 USB351 A3 RB352 JK 351 FB 351 C383 MP3L USB 351 R 3079 RB354 FB 355...
- Page 31 8 - 3 8 - 3 PCB LAYOUT - TOP VIEW PCB LAYOUT - BOTTOM VIEW J360 J361 JK351 RB352 A1 RB354 A1 USB351 A2 C383 FB351 FB352 FB355 FB356 FB357 R3079 R3080...
-
Page 32: Scart Board
9 - 1 9 - 1 SCART BOARD TABLE OF CONTENTS Circuit Diagram ................. 9-2 PCB Layout Scart PCB View ............. 9-3... - Page 33 9 - 2 9 - 2 CIRCUIT DIAGRAM C710 C712 C714 FB707 B1 FB709 B1 FB711 A2 JK703 A2 R708 RB702 A1 C711 C713 C715 FB708 B1 FB710 A2 FB714 C2 R707 RB701 B1...
- Page 34 9 - 3 9 - 3 PCB LAYOUT - SCART PCB VIEW C710 C712 C714 FB707 A2 FB709 B3 FB711 A1 JK703 A2 R708 RB702 B1 C711 C713 C715 FB708 A1 FB710 A1 FB714 A1 R707 RB701 B3...
- Page 35 10 - 1 10 - 1 Mechanical Exploded View...
- Page 36 DIODE 1N4007 Loc. Alt Part No. safety Description GT01 996510027047 EMC BKT TIN T=0.3mm MAIN UNIT IC101 996510021063 IC 16P SAA6581T SO16 PHILIPS IC201 996510012499 IC 28P 996510027083 DVD DOOR ABS BLK IC202 # 996510021075 IC48P KH29LV320DBTC-70G 996510021087 VOLUME KNOB...
- Page 37 10-3 Loc. Alt Part No. safety Description Loc. Alt Part No. safety Description MAIN PCB POWER PCB Q403 996510000578 XISTR NPN KTC3875-Y D922 994000005249 DIODE SB360 3A 60V DO-201AD Q404 996510000578 XISTR NPN KTC3875-Y D923 994000000943 DIODE UF3003 3A 200V Q405 996500028742 XISTR NPN 2SD882P...
-
Page 38: Revision List
11 - 1 REVISION LIST Version 1.1 *Initial release #=Alternative Codes =Safety Symbol...
