Owner's Manual
with Assembly Instructions
For Models W6199, W6200, X2247, X2248
• Please read this manual and save it with your original
sales receipt.
• Required tools: Phillips Screwdriver, Slotted Screwdriver and
Safety Scissors (all not included); Assembly Tool (included).
• Use only with a Power Wheels
rechargeable battery with built-in thermal fuse and
a Power Wheels
6 Volt (4,0 Amp/hr.) charger (both included).
®
6 Volt (4,0 Amp/hr.)
®
Advertisement
Table of Contents
Related Manuals for Fisher-Price W6199
Summary of Contents for Fisher-Price W6199
- Page 1 Owner's Manual with Assembly Instructions For Models W6199, W6200, X2247, X2248 • Please read this manual and save it with your original sales receipt. • Required tools: Phillips Screwdriver, Slotted Screwdriver and Safety Scissors (all not included); Assembly Tool (included). • Use only with a Power Wheels 6 Volt (4,0 Amp/hr.) ® rechargeable battery with built-in thermal fuse and a Power Wheels 6 Volt (4,0 Amp/hr.) charger (both included). ®...
-
Page 2: Electrical Hazard
IMPORTANT INFORMATION ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - N ever modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - U se of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. - U se of Power Wheels components in products other than Power Wheels ® ® vehicles could cause overheating, fire or explosion. • T he battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery. • Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only. • Read the safety instructions on the battery. • Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part. • HOT motors. Handle carefully. RIDING HAZARD WARNING • Prevent Injuries and Deaths • Direct Adult Supervision Required. - Page 3 - 4 years of age. Do not exceed vehicle, please call our toll-free service lines at the maximum weight capacity of 50 lb (23 kg). 1-800-348-0751. Trained customer service • Your new vehicle requires adult assembly. Please set representatives are available to take your call in aside 45 minutes for assembly. English or French. Habla Español? Si usted tiene alguna pregunta ó necesita asistencia llame gratis • Use this vehicle ONLY outdoors. Most interior flooring 1-800-348-0755 para los Estados Unidos. Tenemos can be damaged by riding this vehicle indoors. representantes que hablan español para atender Fisher-Price will not be responsible for damage to ® su llamada. the floor if the vehicle is used indoors. • For your convenience, Power Wheels maintains ® • You must charge your battery for 18-30 hours an independently owned and operated Authorized before you use your vehicle for the first time. We Service Center Network with more than 300 authorized recommend charging your battery before beginning service centers nationwide. Our authorized service assembly. Please see the Battery Charging section for centers will repair or replace parts under warranty at detailed instructions.
- Page 4 PARTS • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. • Metal parts have been coated with a lubricant to protect them during shipment. Wipe all metal parts with a paper towel to remove any excess lubricant. Battery Retainer Grille (Engine Cover) Vehicle Steering Column 6 Volt Charger Hood Dash Windshield Steering Wheel Bottom Steering Wheel Top 6 Volt Battery Steering Wheel Cap Assembly Tool Windshield Frame Shifter Spark Plug Wires Fasteners Shown Actual Size...
-
Page 5: Parts Picture
PARTS PICTURE PARTS PICTURE Note: Some of the parts shown are assembled to both sides of the vehicle. W6199pr-0920... -
Page 6: Battery Charging
BATTERY CHARGING ELECTRICAL HAZARD CAUTION ELECTRICAL HAZARD WARNING Use the charger in dry locations only. • Battery can fall out and injure a child • Make sure you charge the battery for at least 18 hours if vehicle tips over. Always use using the enclosed Power Wheels 6 volt charger ® battery retainer. before operating your vehicle for the first time. Charge the battery for at least 14 hours after each use of the • PREVENT FIRE vehicle. Never charge the battery longer than 30 hours. - N ever modify the electrical system. Failure to follow these instructions may damage your Alterations could cause a fire battery and will void your warranty. resulting in serious injury and could • Use only a Power Wheels 6 volt (4,0 Amp/Hr.) ® also ruin the electrical system. charger with “6V” connector (input 120 VAC, 60Hz, with an output of 6 VDC) to charge your Power Wheels ® - U se of the wrong type battery 6 volt battery. or charger could cause a fire or explosion resulting in serious injury. - Page 7 BATTERY CHARGING Battery must be upright while charging. Charger Connector Battery Connector Battery Connector • Plug the battery connector into the charger connector. • Plug the charger into a standard wall outlet. IMPORTANT! If you are recharging your battery, you Notes: will first need to lift the hood and remove the battery - I f power flow to the wall outlet is controlled by retainer (pretend engine cover). Disconnect the battery connector from the motor harness connector. a switch, make sure the switch is “ON”. - U se the charger only in a wall outlet. Do not plug the charger into a ceiling outlet. • You do not need to remove the battery from your vehicle to recharge it. • Before charging the battery, examine the battery case for cracks and other damage which may cause sulfuric acid (electrolyte) to leak during the charging process. If damage is detected, do not charge the battery or use it in your vehicle. Battery acid is very corrosive and can cause severe damage to surfaces it contacts. • Do not place the battery on a surface (such as kitchen counter tops) which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you place your battery.
- Page 8 ASSEMBLY Steering WARNING Column Children can be harmed by small parts, sharp edges and sharp points Guide in the vehicle's unassembled state, or by electrical items. Care should be Steering taken in unpacking and assembly of Linkage the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. Square Steering Dash Opening Column Vehicle Guide BOTTOM VIEW • Position the vehicle on its side. • Remove the cap on the end of the steering column. Dispose of the cap. • Fit the straight end of the steering column up through the square opening in the vehicle and out through the large round hole in the dash. Make sure the steering column is positioned between the guides on the FRONT VIEW underside of the vehicle.
- Page 9 ASSEMBLY Steering Wheel Cap Steering Wheel Shifter Activity Panel • Using safety scissors, separate the activity panel and the instrument panel. Dispose of the plastic connector. • Insert and "snap" the base of the shifter into the • Fit the steering wheel cap into the center of the steering activity panel. wheel. Make sure the screw holes are aligned. • Insert two #8 x 1" (2,5 cm) screws into the steering wheel cap and tighten. Instrument Panel Lock Nut BOTTOM VIEW • Position the vehicle on its side. • Fit a (1 cm) lock nut onto the end of the " DASH VIEW steering column. • While supporting the steering column tighten the lock • Fit the tabs on the bottom of the instrument panel into nut with the assembly tool.
- Page 10 ASSEMBLY Windshield Activity Panel Dash Slots FRONT SIDE VIEW • Fit the tabs on the back of the windshield into the slots in the top of the dash. • Fit the tabs on the bottom of the activity panel into the notches in the dash opening to the right or the Windshield steering wheel. • Insert two #6 x " (1,3 cm) screws into the holes in the top of the activity panel and tighten. Windshield • Lift the top of the windshield assembly towards the front of the vehicle. • Insert two #8 x 1" (2,5 cm) screws into the holes in each hinge and tighten. Grille Windshield Frame • Fit the windshield onto the windshield frame. • Insert five #6 x " (1,3 cm) screws into the holes in the windshield assembly and tighten. • Fit the tabs on the bottom of the grille into the slots on the front of the vehicle. • Press near the top of the grille to "snap"...
- Page 11 ASSEMBLY Battery Retainer (Engine Cover) Hood Spark Plug Wire Set Spark Plug Wire End Slots Hole • “Snap” the ends of the spark plug wires set into the holes on the battery retainer (engine cover). IMPORTANT! You must install your Power Wheels battery ® in your vehicle before assembling the battery retainer under the hood. Please refer to "Battery Installation" on page 12 for detailed instructions. • Fit the tabs on the hood into the slots in front of the windshield. Decorative Labels • Lower the hood. • Please refer to the Decoration instructions included on a separate sheet to apply decorative labels to your product. • Before applying the labels, wipe the surface of the Traction vehicle with a clean, dry cloth to remove any dust Band or oils.
-
Page 12: Battery Installation And Battery Retainer (Engine Cover) Assembly
Battery Installation and Battery retainer (Engine Cover) Assembly IMPORTANT! Use only a Power Wheels 6 volt ® (4,0 amp/hr.) battery. Use of any other battery will damage your vehicle. Battery Retainer (Engine Cover) Battery Connector Battery Motor Harness Connector • Fit the battery retainer over the battery, motor harness connector and battery connector. • Insert two #8 x 1" (2,5 cm) screws into the holes in the battery retainer and tighten. • Lift the hood. Hood • Place the battery in the battery compartment. Make Hood Latches sure the battery connector extends toward the motor harness connector. Battery Connector Motor Harness Connector... -
Page 13: Battery Care
BATTERY CARE VEHICLE CARE If a battery leak develops, avoid contact with the • Check all screws and their protective coverings regularly leaking acid and place the damaged battery in a plastic and tighten as required. Check plastic parts on a regular bag. See next section for proper disposal. basis for cracks or broken pieces. If acid comes in contact with skin or eyes, flush with • During snowy or rainy weather, the vehicle should be cool water for at least 15 minutes and call a physician. stored inside or under a protective cover. If acid is internally ingested, give water, milk of • Avoid operating the vehicle in wet or snowy conditions, magnesia or egg whites immediately. Never give emetics and do not spray the vehicle with a hose. Water or or induce vomiting. Call a physician. moisture in the motors or electrical switches can cause them to corrode, and could cause switch or • Do not allow the battery to run down completely motor failure. -
Page 14: Safe Driving Rules
Safe Driving Rules Before children use this vehicle, an adult should carefully RIDING HAZARD evaluate the driving area as well as the child’s skill level and ability to drive the vehicle safely. Teach appropriate WARNING safety rules to your child before allowing operation of this vehicle. These rules should also be reviewed with other playmates who want to drive the vehicle. • Prevent Injuries and Deaths • A child who is not sitting on the seat could fall off, • Direct Adult Supervision Required. cause a tip over or block the driver’s view. • Never Ride At Night. • Only operate the vehicle in the daytime in a well-lit area. • K eep Children Within Safe • Driving near steep inclines can cause: Riding Areas. - T he vehicle to gain unsafe speed, even if the pedal is These areas must be: released to stop. - T he vehicle to tilt and tip over - a way from swimming pools - T he wheels to lose traction, causing the vehicle to slip. -
Page 15: Vehicle Operation
Vehicle Operation Help your child practice steering to learn how far and how quickly to turn the steering wheel when driving, and automatically knows how to stop. To Drive To Stop Forward • Your vehicle has a patented, electronic braking system that automatically stops the vehicle when your child’s foot is lifted from the pedal. Reverse • Push the top button to drive forward. • Press down on the foot pedal. The vehicle moves forward at a maximum of 2 mph (4 km/hr). IMPORTANT! To prevent damage to the motors, stop the vehicle before switching between forward and reverse. • Push the bottom button to drive in reverse. • Press down on the foot pedal. The vehicle moves backwards at a maximum of 2 mph (4 km/hr). W6199pr-0920... -
Page 16: Limited Warranty
LIMITED WARRANTY FCC STATEMENT Bumper-to-Bumper* Limited Warranty (United States Only) This equipment has been tested and found to comply *One year limited warranty from the date of with the limits for a Class B digital device, pursuant to purchase on the Power Wheels vehicle. ® Part 15 of the FCC Rules. These limits are designed Six month limited warranty on the to provide reasonable protection against harmful interference in a residential installation. This equipment 6 volt battery. generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the For the original purchaser, this one year limited warranty instructions, may cause harmful interference to radio... -
Page 17: Problems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels Consumer Relations, toll-free at 1-800-348-0751. ® Or, contact your local Power Wheels authorized service center. For the location nearest you, please visit us on-line at ® www.powerwheels.com. PROBLEM POSSIBLE CAUSE SOLUTION Vehicle does not run Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours. Check all connectors. Make sure the battery connector is tightly plugged into the charger connector, and that the charger is plugged into the wall. Make sure power flow to the wall outlet is “ON” . Charger is not working There is no sure way to tell if your charger is working unless you have a volt meter. If you suspect there is a problem with your charger, contact your local Power Wheels ® authorized service center. They can test your charger for you. Tripped thermal fuse T he built-in thermal fuse may "trip" and shut down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. Once a fuse has "tripped,"... - Page 18 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Vehicle was running Tripped thermal fuse T he built-in thermal fuse may "trip" and shut down opera- but suddenly tion of the vehicle if the vehicle is overloaded or the driving stopped (cont.) conditions too severe. Once a fuse has "tripped," remove your foot from the pedal and wait approximately 25 seconds before operating the vehicle again. To avoid repeated auto- matic shutdowns, do not overload the vehicle by exceeding the 50 lb (23 kg) maximum weight capacity or by towing anything behind the vehicle. Do not drive up hills or run into fixed objects, which can cause the wheels to stop spinning while power is still being supplied to the motors. If a thermal fuse continually trips, contact your local Power Wheels ® authorized service center. Short run time Undercharged battery Charge the battery. A new battery should have been (Less than 1 - 3 hours charged for at least 18 hours before using the vehicle for per charge) the first time. After first-time use, recharge the battery for at least 14 hours after each use. Never charge the battery longer than 30 hours. Check all wires and connectors. Make sure the battery connector is tightly plugged into the charger connector, and that the charger is plugged into the wall. Make sure power flow to the wall outlet is “ON” . Overcharged battery Do not charge the battery longer than 30 hours. If you suspect that your battery is damaged as a result of...
- Page 19 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Vehicle runs Vehicle is overloaded Make sure you do not overload the vehicle by allowing sluggishly (cont.) more than one rider at one time, exceeding the 50 lb. maximum weight capacity, or by towing objects behind the vehicle. If the vehicle is overloaded, the built-in thermal fuse in the battery may "trip." Once a fuse has "tripped," remove your foot from the pedal and wait approximately 25 seconds before operating the vehicle again. Adjust the driving conditions to prevent repeated automatic shutdowns. Driving conditions are too stressful Use only on generally level ground. Sometimes the vehicle Loose wire or connector Check all wires around the motors and all connectors to doesn’t run, but other make sure they are tight. times it does Motor or electrical switch damage Contact your local Power Wheels ® authorized service center for diagnosis and repair. When the foot pedal Loose wire or connector Check all wires around the motors and all connectors is pressed, the vehicle to make sure they are tight. won’t run without a push “Dead Spot” on motor Contact your local Power Wheels ®...
- Page 20 18 hours! Charge the battery immediately after each use. Charge the battery once a month, even if the vehicle is not used or stored. Do not return your vehicle to the store! We're a toll-free phone call away, and we can help. If you are missing parts or need assistance, please call: 1-800-348-0751 Or contact your local independently owned and operated Power Wheels Authorized Service Center. ® For the location nearest you, visit us on-line at www.powerwheels.com. Jeep and the Jeep grille design are registered trademarks of Chrysler Group LLC. ® ® Jeep Wrangler and its trade dress are used under license from Chrysler Group LLC. © Chrysler Group LLC 2011. ® Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2011 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc., unless otherwise indicated. PRINTED IN MEXICO W6199pr-0920...
