- Page 1 INSTALLATION MANUAL POWERWAVE M2/S2 Please read this manual completely before installing or using the solar module...
- Page 2 Please read this manual thoroughly before starting the installation. The information in this manual is described on the basis of PowerWave Energy Pty Ltd’s knowledge and experience. Such information and suggestions do not constitute a warranty. PowerWave Energy Pty Ltd reserves the right to make changes to the product, specifications, or to the manual without prior notice.
- Page 3 There is one terminal box installed on the back of the module. Two cables lead out from the box with a connector at the end of each cable. PowerWave M2/S2 series solar module Fig. 1 (b) Module design diagram (Fig.
-
Page 4: Installation Conditions
Each module has a serial number for traceability. For example: M 140811 002 -0002 Mass production of PowerWave Date of manufacture Production order number Sequence number III. INSTALLATION CONDITIONS The PV modules shall be installed under the conditions described hereinafter:... - Page 5 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 For the junction box without potting materials: Look over the cable connection polarity and the bypass diodes carefully (Fig.4A), make sure they are in the right position and that there is no damage or loose parts.
- Page 6 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 (c) There are several ways to mount the modules, an example of acceptable mounting is shown in Fig 5. Prepare eight 8mm screws with washers and nuts on it. (Step A) Put the module on the mounting structure carefully, one person should hold the module while a second person adjusts the module to fit the mounting.
- Page 7 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 6A. Series Connection 6B. Parallel Connection Module Connections Fig. 6 Grounded module with lugs Fig.7 131 Millaroo Drive, Helensvale, Gold Coast, QLD., AUSTRALIA Tel: +61 (07) 3067 2149 POWERWAVE installation | 7 Fax: +61 (07) 5657 1873...
- Page 8 INSTALLATION MANUAL M2/S2 INSTALLATION MANUAL PowerWave M2/S2 Grounded module with screws Fig. 8 Grounded module with screws Fig. 8 Grounded photovoltaic array Fig. 9 131 Millaroo Drive, Helensvale, POWERWAVE installation | 8 Gold Coast, QLD., AUSTRALIA...
- Page 9 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 V. WIRING AND OVER CURRENT PROTECTION (a) Wire Type: PV module interconnections should be 90 wet-rated conductors. An acceptable wire type is USE-2, single conductor cable, for exposed applications. The type of the cable is PV1-F and 1×4mm , where the ambient temperature is -40℃...
-
Page 10: Electrical Ratings
INSTALLATION MANUAL M2/S2 INSTALLATION MANUAL PowerWave M2/S2 2. If the roof structure more than 30 years old, please specify the rafter, truss sizes and spacing, to a qualified engineer as engineering calculations may be required if the roof structure is non-standard. - Page 11 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 Type Name or Model No. : PWM2-60 (210,215,220,225,230,235,240,245,250,255.260.265.270) Rated Maximum Power [W] : Maximum System Voltage [VDC] : 1000 Tolerance of Rating : 0~+6W Rated Short Circuit Current Isc [A] : 8.46 8.58 8.76...
- Page 12 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 Type Name or Model No. : PWM2BL-60 (210,215,220,225,230,235,240,245,250,255) Rated Maximum Power [W] : Maximum System Voltage [VDC] : 1000 Tolerance of Rating : 0~+6W Rated Short Circuit Current Isc [A] : 8.46 8.58 8.76...
- Page 13 INSTALLATION MANUAL PowerWave M2/S2 INSTALLATION MANUAL M2/S2 Type Name or Model No. : PWS2-72 (260,265,270,275,280,285,290,295,300,305,310,315,320,325,330) Rated Maximum Power [W] : Maximum System Voltage [VDC]： 1000 Tolerance of Rating : 0~+6W Rated Short Circuit Current Isc [A] : 8.69 8.80 8.92 9.02...
- Page 14 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 Maximum Power Voltage Vmp [V] : 29.4 29.6 29.8 30.0 30.1 30.2 Over-current protection rating [A]: Application Class (IEC 61730) : Class A / B / C Protection Class : Class II Type Name or Model No. :...
- Page 15 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 Maximum Power Current Imp [A] : 7.31 7.43 7.55 7.67 7.81 7.95 Maximum Power Voltage Vmp [V] : 29.4 29.6 29.8 30.0 30.1 30.2 Over-current protection rating [A]: Application Class (IEC 61730) :...
- Page 16 INSTALLATION MANUAL INSTALLATION MANUAL M2/S2 PowerWave M2/S2 Fire Safety Class C: When the fire rating is dependent on a specific mounting structure, specific spacing, or specific means of attachment to the roof or structure, details of the specific parameter or parameters shall be included in the instructions.
