AVE TCPIP232 Operation Manual

Client server
Hide thumbs Also See for TCPIP232:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
T T T T T CPIP232
CPIP232
CPIP232
CPIP232
CPIP232
Client Ser
Client Ser v v v v v er
Client Ser
Client Ser
Client Ser
OPERATION MANUAL
er
er
er
er
September 2012

Advertisement

Table of Contents
loading

Related Manuals for AVE TCPIP232

  • Adapter AVE TCPIP232 Operation Manual
    Adapter AVE TCPIP232 Operation Manual
    Pos/atm adapter; atm tcp/ip interface; stand alone or with vssi-pro/vsi-pro/vsi-pro max; pos tcp/ip interface; stand alone or with vsi-pro /vsi-pro max (48 pages)

Summary of Contents for AVE TCPIP232

  • Page 1 T T T T T CPIP232 CPIP232 CPIP232 CPIP232 CPIP232 Client Ser Client Ser v v v v v er Client Ser Client Ser Client Ser OPERATION MANUAL September 2012...
  • Page 2 Email: ave-uk@multiview.net http://www.americanvideoequipment.com Email: ave@avethailand.com www.multiview.net http://www.ave.co.th (Thai) http://www.avethailand.com (English) AVE Europe LTD 123 Millennium Business Park Ballycoolin, Dublin 15, Ireland Tel:353 1 684 7450 Fax: 353 1 684 7451 Email; sales@ave-europe.eu Website: www.ave-europe.eu Copyright C AVE Thailand Co., Ltd. 2012...

  • Page 3: Table Of Contents

    Figure 5. TCPIP232 Client Server Connecting with Serial Terminal Software ..... 7 Figure 6. TCPIP232 Client Server PC/DVR Programming Cable (021-037-SF) ..7 Figure 7. TCPIP232 Client Server Connecting with Telnet Direct to PC ...... 8 Figure 8. TCPIP232 Client Server Connecting with Telnet through Router ....8 Figure 9.

  • Page 4: Introduction

    IP address with a single Port number which then is translated by the Server Mode to output data of up to 16 POS in the AVE Protocol of Generic ASCII, VSI-ADD or Vnet via RS- 232 or RS-485 to compatible DVRs..

  • Page 5: Tcpip232 Client Server Connections

    Text Insertion from the Server mode. The Server has received a data packet from the Client configured as a Master / Hydra mode that connects with up to16 AVE RS-485 network devices like the VSI-Pro Max. For this mode you must set the Client as the Master / Hydra and turn Multiple ports OFF and Packet output must set to be VSI-ADD or VNET.

  • Page 6: Client Mode Connect With Dvr With Multiple Listening Port

    The DVR supports multiple IP Ports for receiving data packets from up to 16 Clients. 192.168.0.200 Listening on port 10101 - 10116 CAT-5 CAT-5 CAT-5 CAT-5 Rounter/Network Switcher TCPIP232 Client TCPIP232 Client TCPIP232 Client 192.168.0.101 192.168.0.102 192.168.0.116 Destination IP Destination IP Destination IP 192.168.0.200 192.168.0.200...

  • Page 7: Tcpip232 Client Server Settings

    TCPIP232 Client Server PC/DVR Cable(AVE P/N: 021-037-SF) This is and RS232 Cable to program the IP Address on TCPIP232 and then remove and plug to the DVR to insert ASCII text on Video for stand alone application.

  • Page 8: Tcpip232 Client Server Programming Via Telnet

    Power up your TCPIP232 Client Server and your computer and open the Telnet Client pro- gram on the computer and then Telnet to the default IP 192.168.0.222 Port 23 of the TCPIP232 Client Server. Telnet Client program will appear and ask for the Password that the default telnet password of TCPIP232 Client Server is 9999.
  • Page 9 Power up your TCPIP232 Client Server and your computer and open the Telnet Client pro- gram on the computer and then Telnet to the default IP 192.168.0.222 Port 23 of the TCPIP232 Client Server. Telnet Client program will appear and ask for the Password that the default telnet password of TCPIP232 Client Server is 9999.
  • Page 10 Telnet and Exit the Telnet mode which means the TCPIP232 Client Server will reboot with the new Hydra mode. When the TCPIP232 Client Server is in the Hydra mode the Telnet programming mode is no longer supported. Therefore any further changes will need to be done via the Serial Programming mode.

  • Page 11: Tcpip232 Client Server Menu Settings

    Press the “Up” or “Down” button to move the cursor to the menu you need to program and press the “Enter” button to enter the selected submenu. The TCPIP232 Client Server setting menu will appear like below if the “Mode” select in “Mode Setting” menu (refer to page 10) is select to be “Client”.

  • Page 12: Ip Address Settings

    - Exit IP Address Settings To define an IP Address, Subnet Mask and Gateway of the TCPIP232 Client Server, press the “Up” or “Down” button to move the cursor to “IP Address” and press the “Enter” button. The “IP Address Settings” sub menu will appear like below.

  • Page 13: Mode Settings

    IP Address To define the IP Address of the TCPIP232 Client Server, press the “Up” or “Down” button to move the cursor to “IP Address” and press the “Enter” button. The cursor will start to flash. Press the “Up” or “Down” or press the number button on your keyboard to define the IP Ad- dress from 0 - 255 and then press the “Enter”...
  • Page 14 Hydra Mode The Hydra Mode is a special type of a Client mode that supports the AVE RS-485 Network protocol to connect up to 16 VSI-Pro Max with one device. In this mode it can be configured to send all 16 POS data to the Server Mode using only one IP:Port or assign a single IP address and unique:Port to each POS.
  • Page 15 To select the Mode of the TCPIP232 Client Server. Press the “Up” or “Down” button to move the cursor to “Mode” and press the “Enter” button. The cursor will start flashing. Press the “Up” , “Down” to change the mode to “Client” , “Server” or “Hydra” and Press the “Enter” button when the desired value is displayed, Mode setting menu will appear like below if Mode is selected to be “Client”.
  • Page 16 Protocol To select the protocol of TCPIP232 Client Server. Press the “Up” or “Down” button to move the cursor to “Protocol” and press the “Enter” button. The cursor will start flashing. Press the “Up” , “Down” to change the Protocol to “TCP” or “UDP” and press the “Enter” button when the...

  • Page 17: Telnet Settings

    Confirm Password again. The Telnet password default is 9999. Change Password New Password: Exit Press the “Up” or “Down” button to move the cursor to “Exit” and press the “Enter” button to exit from the LAN Settings menu and back to TCPIP232 Client Server Main Menu.

  • Page 18: Pos Settings

    “Enter” button. Output The Output controls data from the TCPIP232 Client Server ON or OFF. Typically this is sent to an RS232/RS485 device or a Network device. To make your selection, press the “Up” or “Down” button to move the cursor to “OUTPUT” and press “Enter”.
  • Page 19 POS.The Exception String can also be used without a defined range. Example of this would be to assign a word “ VOID” as an exception. TCPIP232 Client Server will look for that string so range definition is not necessary. However,exception string “ VOID”...

  • Page 20: Alarm Notification

    - Exit Alarm NO The TCPIP232 Client Server allows you up to 16 alarms that may be used with any of the user programmed exceptions. However there are only 2 hardwired alarm outputs and these correspond to Alarm 1 & 2 only. The other 14 alarms can be used to send trigger text, serial data out or flash the screen.

  • Page 21: Communication Settings

    Exit Press the “Up” or “Down” button to move the cursor to “Exit” and press “Enter” button for exit from POS setting menu and back to TCPIP232 Client Server main menu. Communication Settings To select Communication Setting menu by press the “Up” or “Down” button to move the cursor to “Communication”...

  • Page 22: Rs232 Settings

    , “8,EVEN” , “7,ODD” or “7,EVEN” and press “Enter” when the desired value is displayed. Handshaking Handshaking is an input that require TCPIP232 Client Server to stop sending data until TCPIP232 Client Server receive ready signal from external device to continue sending data again.

  • Page 23: Rs485 Settings

    “Down” button to move the cursor to “Protocol” and press “Enter”.The cursor will start flashing. Press the “Up” or “Down” button to make your selection “Regcom 9600” , “Regcom 57600” or “Vnet” and press “Enter” when the desired value is displayed. (AVE RS485 Network Protocol is refer to page 24) Baudrate To set the baud rate for your particular device, press the “Up”...

  • Page 24: Packet Output

    Packet Output If Mode select to be “Client” or “Hydra” in Mode Settings menu(refer to page 13) then Packet Output will appear. To select Packet Output Settings menu by Press the “Up” or “Down” button to move the cursor to “Packet Output” and press “Enter” button. The Packet Output Settings menu will appear.

  • Page 25: Typical Examples Of Packet Outputs

    Typical Examples of Packet Outputs ASCII+CR = ASCII Text is end with Carriage return Ex Packet output of “NO SALE” ‘N’ 0x4E ‘O’ 0x4F ‘ ‘ 0x20 ‘S’ 0x53 ‘A’ 0x41 ‘L’ 0x4C ‘E’ 0x45 0x0D Internet packet = N[0x4E]O[0x4F] ‘...

  • Page 26: About Firmware

    To select About Firmware by Press the “Up” or “Down” button to move the cursor to “About Firmware” and press “Enter” button. The Firmware information will appear on the screen. Press “Enter” button for exit from Firmware information screen and back to TCPIP232 Client Server main menu.

  • Page 27: Rs-485 Pin Out

    Note: If the RS485 port is RJ45 connector just use CAT-5 LAN cable(Straight Through) TCPIP232 Client Server PC/DVR Cable(AVE P/N: 021-037-SF) This is and RS232 Cable to program the IP Address on TCPIP232 and then remove and plug to the DVR to insert ASCII text on Video for stand alone application.

  • Page 28: Ave Rs485 Network Protocol

    AVE RS485 Network Protocol TCPIP232 Client Server is able to interface with multiple devices on AVE RS485 Network that TCPIP232 Client Server is a Master unit and connect to the Slave devices with maxi- mum connection is 16 units. Before connecting to the RS485 network, you must program the TCPIP232 Client Server Adapter to be the same protocol of the RS485 network so the ID will not duplicate with an- other devices.
  • Page 29 EX The Master polls the Slave address 7 Master: <07H(ADD,Bit9 =1)><05H(ENQ,Bit9 = 0)> If the data is not available at address 7 then Slave: <07H(ADD,Bit9 =1)><15H(NAK,Bit9 = 0)> If the data is available at address 7 then Slave: <07H(ADD,Bit9 =1)><4EH(N,Bit9 = 0)><4FH(O,Bit9 = 0)> <20H(SPACE,Bit9 = 0)><53H(S,Bit9 = 0)><41H(A,Bit9 = 0)>...

  • Page 30: Warranty

    Product. RETURNS. AVE products are fully inspected and carefully packed to ensure you are delivered a quality product in good condition. If you are not fully satisfied with our product, returns of standard stocking items with no restocking fee can be made within thirty (30) days of invoice to Buyer.
  • Page 31 NOTES:...
  • Page 32 AVE (Thailand) Co., Ltd. 147 Soi On-Nut 44 Sukhumvit 77 Rd., Suan Luang Bangkok, 10250 Thailand Tel: 662-331-9364, 331-9285 Fax: 662-331-9365 Email: ave@avethailand.com www.avethailand.com (English) www.ave.co.th (Thai) AVE Multiview USA 2300 Central Parkway C Houston, Texas, 77092 Tel: 281-443-2300 Fax: 281- 443-8915 Email: aveus@ave-us.com...
