Product Specification Electrical 1.1.1 Transmitter The transmitter consists of Broadcom solution (BCM20730), and its related circuit as following. 1.1.1.1 Power Control Requirements: Put AAA size battery pack into mouse. Ender user can use the battery switch on the lower case to control power on or off. 1.1.1.2 RF Link: Push the pairing button on the lower case to into pairing mode.
Page 3
a. White paper of DFS b. Formica 0909 (black color board) 1.1.1.8 Cut off Voltage Cut off Voltage: 2.0V 1.1.1.9 Power consumption: (V bat =3V,on white paper) Status Moving Rest 1 Rest 2 Switch Off Disconnect Power consumption <0.1(mA) <8 (mA) <1.2 (mA) <0.8 (mA) <0.8mA...
Page 4
Start guide for Mouse(Model HSA-D002M) Insert your AAA x2 to Mouse Turn functional indicator to Green on bottom of product successfully operated...
Pairing method: L button + M button + R button + switch on (Timeout after 10 seconds from entering pairing mode) FCC Statement: Federal Communications Commission (FCC) Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference and 2) this device must accept any interference received, including interference that may cause undesired operation of the device.
Industry Canada (IC) Statement Canada, Industry Canada (IC) This Class B digital apparatus complies with Canadian ICES-003 and RSS-247. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1)this device may not cause interference, and (2)this device must accept any interference, including interference that may cause undesired operation of the device.
Page 7
1. CE EMC must comply with EN55022/55032/EN55024 latest std. 2. Operating temperature -5 degree C ~ 60 degree C 3. Altitude of operation Up to 3000m HP Inc. Manufacturer Address 1501 Page Mill Road Palo Alto, CA 94304, USA Country of...
