1
SPECIFICATIONS
Video system:
NTSC
Power voltage:
DC 14.0/28.0 V
(DC 10.8-32.0 V)
Ground:
Negative
Current consumption: 0.8 A or less (at DC 28.0 V)
1.5 A or less (at DC 14.0 V)
Power consumption:
about 15 W
Timer operation:
300 ± 30 seconds
Video input signal:
VS 1 Vp-p (75 ohm)
Ambient temperature during use:
−
Vibration resistance:
4.4G or less
Monitor:
6" tube, 90
Central resolution:
400 TV lines or more (H)
300 TV lines or more (V)
Dimensions(mm):
155 (W) x 140 (H) x 170 (D)
6" 1/8 (W) x 5" 1/2 (H) 6" 11/16 (D)
(Not including mounting brackets,
andswitch protrusion)
Weight:
About 1.7 kg
NOTE
* We cannot supply PWB with component parts in principle.
When a circuit on PWB has failure, please repair it by com-
ponent parts base.
Parts which are not mentioned in service manual are not
supplied.
* Specifications and design are subject to change without
notice for further improvement.
* Please note that component life of CRT is clearly defined
in his owners manual as 3000 hours.
We normally recommend all of you to replace CRT after a
use of 3000 hours to maintain his product performance
well.
Clarion Co., Ltd.
50 Kamitoda, Toda-shi, Saitama 335-8511 Japan
Service Dept.: 5-66 Azuma , Kitamoto-shi, Saitama 364-0007 Japan
Tel: +81-48-541-2335 / 2432 FAX: +81-48-541-2703
2
10
℃
to 50
℃
゜
deflection B/W CRT
Service Manual
CAMERA & MONITOR SYSTEM
6-inch Monitor
CJ-763E-01
Model
COMPONENTS
1.
CJ-763E-01
2.
Sun visor
3.
Mounting bracket
4.
Parts bag (Bracket cover)
4-1.
Bracket cover
5.
Power cord
5-1.
Fuse 3A
5-2.
Fuse 1A
6.
Owner's Manual
7.
Installation Manual
8.
Installation Manual
9.
Parts bag (Screw)
9-1.
M6 x 14 hex bolts with washer
9-2.
M6 x 20 hex bolts with washer
9-3.
M6 flanged hex nuts
9-4.
6 x 20 Self-tapping screws
9-5.
Plate nuts
(for 6 x 20 self-tapping screws)
To engineers in charge of repair or
inspection of our products.
Before repair or inspection, make sure to follow the
instructions so that customers and Engineers in
charge of repair or inspection can avoid suffering
any risk or injury.
1. Use specified parts.
The system uses parts with special safety features against
fire and voltage. Use only parts with equivalent character-
istics when replacing them.
The use of unspecified parts shall be regarded as remod-
eling for which we shall not be liable. The onus of product
liability (PL) shall not be our responsibility in cases where
an accident or failure is as a result of unspecified parts
being used.
- 1 -
Correction day: 29.Sep.2005
Published by Service Dept.
298-6295-00 Sep.2005 P
Printed in Japan
-----------
1
922-2286-02
1
922-2289-01
1
922-2290-01
1
-----------
2
652-0149-08
1
120-0030-00
1
120-0010-00
1
280-8219-00
1
284-0215-00
1
284-0215-01
1
921-9319-02
1
-----------
6
-----------
4
-----------
4
-----------
4
-----------
4
CJ-763E
