INSTRUCTION MANUAL
Portable Cut-Off
LW1400
LW1401
DOUBLE INSULATION
Read before use.

Advertisement

Table of Contents
loading

Related Manuals for Makita LW1401

Summary of Contents for Makita LW1401

  • Page 1 INSTRUCTION MANUAL Portable Cut-Off LW1400 LW1401 DOUBLE INSULATION Read before use.

  • Page 2: Specifications

    SPECIFICATIONS Model: LW1400 LW1401 Wheel diameter 355 mm Max. wheel thickness 3 mm Hole diameter 25.4 mm No load speed 3,800 min Dimensions With European type safety 530 mm x 295 mm x 640 mm 500 mm x 295 mm x 640 mm...

  • Page 3: Cut-Off Machine Safety Warnings

    Disconnect the plug from the power source carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges Damaged or entangled cords ments, changing accessories, or storing power increase the risk of electric shock. tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
  • Page 4 The outside diameter and the thickness of your Kickback is the result of power tool misuse and/or accessory must be within the capacity rating incorrect operating procedures or conditions and can be of your power tool. Incorrectly sized accessories avoided by taking proper precautions as given below. cannot be adequately guarded or controlled.

  • Page 5: Functional Description

    1. Lock pin base. This will help prevent tipping over and possible For LW1401 Unhook the lock chain from the hook. Always hook the lock chain to the hook when not in use.
  • Page 6 1. Screw 2. Guide plate tion for ease of operator comfort during extended use. Apply caution when locking tool in "ON" For LW1401 Remove the two hex bolts using a socket wrench. Move For tool with lock-off button the guide plate to the desired position and secure it with To prevent the switch trigger from being accidentally the hex bolts.
  • Page 7 1. Guide plate 2. Lever 1. Screw 2. Spark guard For LW1401 The spark guard is factory-installed with its lower edge contacting the base. Operating the tool in this position NOTICE: When performing right miter cut, always set the guide plate at 0 - 170 mm position.
  • Page 8 Opening center cap type safety guard For the tools equipped with center cap type safety guard. CAUTION: Be sure to tighten the toolless clamp or hex bolt securely. bolt, use the socket wrench provided with the tool to assure proper tightening. 1.

  • Page 9: Cutting Capacity

    To install the cut-off wheel, follow the removal proce- 102 x 194 mm 70 x 233 mm wheel to the ring and return the safety guard. For LW1401 119 x 119 mm 106 x 106 mm Raise the safety guard. Turn the hex bolt counterclock- wise using a socket wrench while holding down the wheel.

  • Page 10: Carrying Tool

    1. Spacer block 1. Vise plate 2. Workpiece diameter 3. Guide plate 4. Spacer block width When cutting workpieces over 85 mm wide at an angle, attach a straight piece of wood (spacer) over 190 mm Long workpieces must be supported by blocks on long x 45 mm wide to the guide plate as shown in the either side so that it will be level with the base top.

  • Page 11: Maintenance

    CAUTION: perform inspection or maintenance. These accessories or attachments are recommended for use with your Makita tool NOTICE: The use of any other alcohol or the like. Discoloration, deformation or accessories or attachments might present a risk of cracks may result.
  • Page 12 M a k i t a C o r p o r a t i o n 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885456C931 20170106 www.makita.com...
