1 0F9952 1 ASSY ROTOR 2390 80KB3 CPL
0F3417 1 ASSY ROTOR 390 2P 100K BRSHLS
0F2984 1 ASSY ROTOR 390 2P 150K BRSHLS
2 0F9949 1 ASSY STATOR 80KW 1PH 2P BRSHLS
0F3418 1 ASSY STATOR 390 2P 100K BRSHLS
0F2985 1 ASSY STATOR 390 2P 150K BRSHLS UL
0F9950 1 STATOR 2390 80 GB3 CPL
0F9951 1 STATOR 2390 80 KB3 CPL
0G6319 1 STR 2390 80 JB3 CPL
0F6183 1 ASSY STR 390 100KW 2P 3PH 208V
0F6187 1 ASSY STR 100KW 1PH 2P BRSHLS
0F6184 1 ASSY STR 390 150KW 2P 3PH 208V
0F6212 1 ASSY STR 150KW 1PH 2P BRSHLS
0G2023 1 ASSY STR 390 150KW 2P 3PH 240V
0F8757 1 STR-2390-150LB4 CPL
3 068405C 1 EXITER FIELD 2" LG SPD CONN
4 0F3013 1 ASSY EXCITER 2.0" STACK 2P
5 072878 1 KEY SQ 3/8 X 3-1/4 STEEL
6 0C9708 REF HYPOT TEST PROCEDURE (NOT SHOWN)
7 0F3726B 1 ASSY FLYWHEEL CPL
8 0F2689 1 RING PRESSURE 390 STATOR CAN
9 023454 1 KEY WOODRUFF #E
10 059980 4 SCREW HHC M10-1.5 X 25 C10.9
11 046526 4 WASHER LOCK M10
12 0A2601 1 SCREW HHC M16-2.0 X 45 G8.8
13 072879 1 SPACER .69 X 2.75 X .37 ST/ZNC
14 022473 8/12 WASHER FLAT 1/4-M6 ZINC
15 022097 4/6 WASHER LOCK M6-1/4
16 0C2454 11 SCREW THF M6-1 X 16 N WA Z/JS
17 092950 1 COLLAR SLIP FIT 390 MM
18 04576100CF 4 STUD M14-2.0 X 760 G5 ZINC
19 052646 4 WASHER FLAT M14
20 043123 4 WASHER LOCK M14
21 051779 4 NUT HEX M14-2.0 G8 YEL CHR
22 022392 2 PIN DOWEL 1/2 X 1-1/4
23 052259 2 WASHER FLAT M12
24 051769 3 WASHER LOCK M12
25 0E7230 3 SCREW HHC M12-1.75 X 80 G10.9
26 0F3033 1 SHIELD ALT EXCITER 390
0F9492 1 SHIELD ALT EXCITER 5.4/6.8 (1 PHASE)
27 0F2722 1 COVER EXCITER SHIELD
28 077043F 1 CONDUIT FLEX 1.25" ID
29 020151 1 CLAMP VINYL .312 X .203 Z
30 023365 3 WASHER SHAKEPROOF INT #8
31 033133 1 SCREW HHM #8-32 X 3/8
32 033143 2 SCREW HHM #8-32 X 7/8
33 086032 2 LUG RT-ANG #10/10-12
34 090063 1 BRIDGE SUPPORT DIODE 15"
35 090064 1 CAP END ROTOR 390MM
36 090152 1 ASSY BRIDGE RECTIFIER
37 022661L 1 SLEEVING UL #0 .330 ID (3" LG)
38 028739A 2 TIE WRAP UL 3.9" X .10" BLK
39 085662D 1 TIE WRAP UL 17.7 X .35 BLK HT
40 068113A 1 REAR BEARING CARRIER CPL
41 068406 1 SCREW HHC M12-1.75 X 60 G10.9
42 0F7272 6 SCREW 1/4-20 X 5/8" TAPTITE SS
43 023484N 1 BUSHING SNAP SB-2.5-31
023484N 2 BUSHING SNAP SB-2.5-31 (FOR 5.4/6.8 1 PHASE)
44 0F6819 1 MOUNT CT'S 5.4L 100KW
45 REF. 2/3 TRANSFORMER
46 0C2428 2 SCREW PHTT #6-32 X 1/2 ZYC
47 022155 2 WASHER LOCK #6
48 042568 4/6 SCREW HHC M6-1.0 X 20 G8.8
49 049813 4/6 NUT HEX M6 X 1.0 G8 YEL CHR
50 * 052624 1 BEARING BALL 6212 SEALED
51 0F7030 1 SHROUD UPPER ALTERNATOR EXCITR
52 0F7047 1 SHROUD CENTER ALTERNATR EXCITR
53 0F7029 1 SHROUD LOWER ALTERNATOR EXCITR
60 0F3834 1 ASSY SCROLL 390 X 60MM CPL
KIT PARTS I/N'S: 61 THRU 69
61 0F3846B 2 SHROUD ALT SHEET METAL CPL 2P
62 0F3892 2 SCREEN, 390 SAE ALT 60MM WIDE
63 0A2496A 2 BRACKET SAE SCROLL TENSIONER
64 056326 8.4 FT. VINYL TRIM 1/8" GAP
65 022097 6 WASHER, SPLIT 1/4"-M6
66 022473 6 WASHER FLAT 1/4 ZINC
67 045757 2 SCREW HHC M6-1.0 x 25 LONG
68 047411 4 SCREW HHC M6-1.0 X 16 G8.8
69 0A2110 12 SCREW SWAGE 1/4-20 X 1/2 Z/YC
* ROTOR REPLACEMENT PARTS.
** 1 PHASE UNITS REQUIRE SEPERATION OF LEADS.
QTY. REQ: 1 PHASE / 3 PHASE
