Panasonic TH-50PX75U Service Manual

Panasonic TH-50PX75U Service Manual

High definition plasma television
Hide thumbs Also See for TH-50PX75U:
Table of Contents

Advertisement

Specifications

Power Source
Power Consumption
Maximum
Standby condition
Plasma Display panel
Drive method
Aspect Ratio
Contrast Ratio
Visible screen size
(W × H × Diagonal)
(No. of pixels)
Sound
Audio Output
Channel Capability (Digital/Analog) VHF/UHF: 2 - 69, CATV: 1 - 135
Operating Conditions
Connection Terminals
INPUT 1-2
COMPONENT VIDEO
INPUT 1-2
HDMI 1-2 AUDIO IN
Card slot
AV PROG. OUT
AC 120 V, 60 Hz
499 W
0.2 W
AC type
16 : 9
(max) 10000 : 1
127 cm
43.6 " × 24.5 " × 50.0 " (1,106 mm × 622 mm × 1,269 mm)
1,049,088 (1,366 (W) × 768 (H)) [4,098 × 768 dots]
20 W [10 W + 10 W] (10 % THD)
Temperature: 32 °F - 104 °F (0 °C - 40 °C)
Humidity: 20 % - 80 % RH (non-condensing)
VIDEO:
S-VIDEO:
AUDIO L-R:
Y:
P
, P
:
B
R
AUDIO L-R:
TYPE A Connector × 2
AUDIO L-R:
SD CARD slot × 1
VIDEO:
AUDIO L-R:
High Definition Plasma Television
TH-50PX75U
GP10DHU Chassis
RCA PIN Type × 1 1.0 V [p-p] (75 ohm)
Mini DIN 4-pin Y: 1.0 V [p-p] (75 ohm) C: 0.286 V [p-p] (75 ohm)
RCA PIN Type × 2 0.5 V [rms]
1.0 V [p-p] (including synchronization)
± 0.35 V [p-p]
RCA PIN Type × 2 0.5 V [rms]
RCA PIN Type × 2 0.5 V [rms]
RCA PIN Type × 1 1.0 V [p-p] (75 ohm)
RCA PIN Type × 2 0.5 V [rms]
© 2007 Matsushita Electric Industrial Co., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO.MTNC070303CE
B34 Canada: B07
Unauthorized
copying
and

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic TH-50PX75U

  • Page 1: Specifications

    ORDER NO.MTNC070303CE B34 Canada: B07 High Definition Plasma Television TH-50PX75U GP10DHU Chassis Specifications Power Source AC 120 V, 60 Hz Power Consumption Maximum 499 W Standby condition 0.2 W Plasma Display panel Drive method AC type Aspect Ratio 16 : 9...
  • Page 2: Table Of Contents

    TH-50PX75U DIGITAL AUDIO OUT PCM/Dolby Digital, Fiber Optic FEATURES 3D Y/C FILTER CLOSED CAPTION V-Chip Photo Viewer HDAVI Control 2 Dimensions (W × H × D) Including pedestal 47.7 ” × 33.1 ” × 14.6 ” (1,210 mm × 839 mm × 369 mm) TV Set only 47.7 ”...
  • Page 3 TH-50PX75U 14.6. C2-Board 15.26. D-Board (2 of 6) Schematic Diagram 14.7. C3-Board 15.27. D-Board (3 of 6) Schematic Diagram 14.8. SC-Board 15.28. D-Board (4 of 6) Schematic Diagram 14.9. SU-Board 15.29. D-Board (5 of 6) Schematic Diagram 14.10. SD-Board 15.30. D-Board (6 of 6) Schematic Diagram 14.11.
  • Page 4: Applicable Signals

    TH-50PX75U 1 Applicable signals...
  • Page 5: Safety Precautions

    TH-50PX75U 2 Safety Precautions 2.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
  • Page 6: Prevention Of Electro Static Discharge (Esd) To

    TH-50PX75U 3 Prevention of Electro Static Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"...
  • Page 7: About Lead Free Solder (Pbf)

    TH-50PX75U 4 About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
  • Page 8: Service Hint

    TH-50PX75U 5 Service Hint Remove the Rear Cover Board Name Function Board Name Function Power Supply Format Converter, Plasma AI, Sub-Field Processor DC-DC Converter Data Driver (Lower Right) Speaker out, Sound Processor Data Driver (Lower Center) AV Terminal, AV Switch...
  • Page 9: Plasma Panel Replacement Method

    TH-50PX75U Plasma panel replacement method 6.1. Remove the rear cover 1. See Service Hint (Section 5) 6.2. Remove the rear terminal cover 1. Remove the screws (×8 2. Remove the rear terminal cover. 4. Remove the screws (×5 5. Remove the molding props (×9 6.
  • Page 10: Remove The Tuner Unit

    TH-50PX75U 6.6. Remove the D-Board 6.4. Remove the Tuner unit 1. Remove the tuner unit. (See section 6.4.) 1. Unlock the cable clampers to free the cable. 2. Disconnect the connectors (D5 and D25). 2. Disconnect the connectors (A1, A5, A6, A7, A12 and A52).
  • Page 11: Remove The Sd-Board

    TH-50PX75U 2. Unlock the cable clampers to free the cable. 3. Disconnect the connector (SC2). 4. Disconnect the flexible cable (SC20). 5. Remove the screws (×9 ) and remove the SC-Board. 6.8. Remove the SD-Board 1. Remove the screws (×3 6.10.
  • Page 12: Remove The Ss-Board

    TH-50PX75U 6.14. Remove the C1-Board 6.12. Remove the SS-Board 1. Remove the tuner unit. (See section 6.4.) 1. Disconnect the connectors (SS11, SS12 SS23, SS24, 2. Remove the stand bracket (R). (See section 6.13.) SS33, SS34 and SS35). 3. Remove the flexible cables holder fastening screws (×10 2.
  • Page 13: Remove The C3-Board

    TH-50PX75U 6.16. Remove the C3-Board 1. Remove the tuner unit. (See section 6.4.) 2. Remove the stand bracket (L). (See section 6.13.) 3. Remove the flexible cables holder fastening screws (×6 4. Disconnect the flexible cables (CB9, CB10 and CB11).
  • Page 14: Remove The Plasma Panel Section From The Cabinet Assy

    TH-50PX75U 5. Disconnect the connectors (K1 and K2) and remove the K- Board. 3. For leaving the plasma panel from the front frame, pull the bottom of the cabinet assy forward, lift, and remove. 6.22. Remove the Plasma panel section from the Cabinet assy (glass) 1.
  • Page 15: Replace The Plasma Panel (Finished)

    TH-50PX75U 6.23. Replace the plasma panel (finished) 1. Place the new plasma panel (finished) on the flat surface of the table (covered by a soft cloth), with the plasma panel surface facing downward. 2. Attach the C1-Board, C2-Board and the C3-Board, connect the flexible cables (×22) from the plasma panel to the C1-...
  • Page 16: Caution Statement

    TH-50PX75U 7 Caution statement 7.1. Caution statement. Caution: Please confirm that all flexible cables are assembled correctly. Also make sure that they are locked in the connectors. Verify by giving the flexible cables a very slight pull.
  • Page 17: Location Of Lead Wiring

    TH-50PX75U 8 Location of Lead Wiring 8.1. Lead of Wiring (1)
  • Page 18: Lead Of Wiring

    TH-50PX75U 8.2. Lead of Wiring (2)
  • Page 19: Lead Of Wiring

    TH-50PX75U 8.3. Lead of Wiring (3)
  • Page 20 TH-50PX75U 8.4. Lead of Wiring (4)
  • Page 21 TH-50PX75U 8.5. Lead of Wiring (5)
  • Page 22 TH-50PX75U 8.6. Lead of Wiring (6)
  • Page 23: Self-Check Function

    TH-50PX75U 9 Self-check Function Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 9.1. Check of the IIC bus lines 9.1.1. How to access Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds.
  • Page 24: Power Led Blinking Timing Chart

    TH-50PX75U 9.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.
  • Page 25: No Power

    TH-50PX75U 9.3. No Power First check point There are following 2 states of No Power indication by power LED. 1. No lit 2. Red is lit then turns red blinking a few seconds later. (See 9.2.)
  • Page 26: No Picture

    TH-50PX75U 9.4. No Picture...
  • Page 27: Local Screen Failure

    TH-50PX75U 9.5. Local screen failure Plasma display may have local area failure on the screen. Fig-1 is the possible defect P.C.B. for each local area. Fig-1...
  • Page 28: Service Mode

    TH-50PX75U 10 Service Mode 10.1. How to enter into Service Mode While pressing [VOLUME ( - )] button of the main unit, press [RECALL] button of the remote control three times within 3 seconds. 10.1.1. Key command “1” button...Main items Selection in forward direction “2”...
  • Page 29: Contents Of Adjustment Mode

    TH-50PX75U 10.1.2. Contents of adjustment mode · Value is shown as a hexadecimal number. · Preset value differs depending on models. · After entering the adjustment mode, take note of the value in each item before starting adjustment. Main item...
  • Page 30: Service Tool Mode

    TH-50PX75U 10.2. Service tool mode 10.2.1. How to access 1. Select “SRV-TOOL” in Service Mode. 2. Press [OK] button on the remote control. 10.2.2. Display of SOS History SOS History (Number of LED blinking) indication. From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment.
  • Page 31: Adjustment Procedure

    TH-50PX75U 11 Adjustment Procedure 11.1. Driver Set-up 11.1.2. Adjustments Adjust driver section voltages referring the panel data on the 11.1.1. Item / Preparation panel data label. 1. Input a white signal to plasma video input. Check or adjust the following voltages with the multimeter.
  • Page 32: Initialization Pulse Adjust

    TH-50PX75U 11.2. Initialization Pulse Adjust 1. Input the White signal to plasma video input. 2. Set the picture controls as follows. Picture menu : Vivid Normal : Set Aspect : Full 3. Connect Oscilloscope to TPSC1 (SC). Check and adjust that the stand down pulse(T2) period are each within specification.
  • Page 33: Adjustment Volume Location

    TH-50PX75U 11.4. Adjustment Volume Location 11.5. Test Point Location...
  • Page 34: White Balance Adjustment

    TH-50PX75U 12 White Balance Adjustment 12.1. White balance adjustment Name of measuring instrument Connection Remarks · W/B pattern Component input Panel surface · Color analyzer (Minolta CA-100 or equivalent) Procedure Remarks · Ensure aging is adequate. · Make sure the front panel to be used on the final set is fitted.
  • Page 35 TH-50PX75U...
  • Page 36: Hotel Mode

    TH-50PX75U 13 Hotel mode 1. Purpose item Function Mode Select hotel mode ON/OFF Restrict a function for hotels. Input Select input signal modes. 2. Access command to the Hotel mode setup menu Set the input, when each time power is switched on.
  • Page 37: Conductor Views

    TH-50PX75U 14 Conductor Views 14.1. P-Board P-BOARD (FOIL SIDE) ETXMM655MEH TH-50PX75U TH-50PX75U P-BOARD ETXMM655MEH P-BOARD ETXMM655MEH...
  • Page 38 TH-50PX75U Parts Location Parts Location P-BOARD (FOIL SIDE) P-BOARD (COMPONENT SIDE) TRANSISTOR PHOTO COUPLER TRANSISTOR PHOTO COUPLER IC251 Q301 PC201 IC501 Q301 PC201 IC351 Q302 PC202 Q302 PC202 MODULE IC401 Q351 PC301 Q351 PC301 IC451 Q352 PC302 Q352 PC302 MC201...
  • Page 39 TH-50PX75U P-BOARD (COMPONENT SIDE) ETXMM655MEH TH-50PX75U TH-50PX75U P-BOARD ETXMM655MEH P-BOARD ETXMM655MEH...
  • Page 40: Gs, K And S-Board

    TH-50PX75U 14.2. GS, K and S-Board S-BOARD (FOIL SIDE) TXN/S1LPTU SW2500 C2500 TNPA4237 REVERSE FOR ORDER S-BOARD (COMPONENT SIDE) TXN/S1LPTU TNPA4237 GS-BOARD (FOIL SIDE) K-BOARD (FOIL SIDE) TXNGS1LPTU TXN/K1LPTU TNPA4280 REVERSE FOR SUFFIX. TNPA4236 REVERSE FOR SUFFIX. SW3754 SW3755 SW3756...
  • Page 41: A-Board

    TH-50PX75U 14.3. A-Board A-BOARD (FOIL SIDE) TNPH0692ACS TNPH0692 B R4772 R4771 R4766 R5618 R5607 R5610 C5601 R5613 R5611 C5605 R5612 R4773 TP3501 R4769 R5600 C8035 R8037 R5602 IC5600 C5600 TP4811 TP4804 TP4810 TP3519 R5606 C8013 C8014 C5606 C5608 R8379 TP4808...
  • Page 42 TH-50PX75U Parts Location Parts Location A-BOARD (FOIL SIDE) A-BOARD (COMPONENT SIDE) IC IC TRANSISTOR TP4512 TP8511 TRANSISTOR Q4003 TP4513 TP8512 IC1100 Q1108 Q4004 TP1106 IC2008 Q1107 TP1100 TP4514 TP8513 Q4005 TP1107 IC3001 Q1114 TP1101 IC1101 Q1109 TP4515 TP8514 Q4006 IC3101...
  • Page 43 TH-50PX75U A-BOARD (COMPONENT SIDE) TNPH0692ACS TNPH0692 A C8375 C4773 ZA4700 ZA4701 R4756 L8314 L3511 R8391 R8392 C8386 C8376 C8377 C8378 C8379 C8380 C8381 C8382 C8383 C8384 L5602 C8385 L3501 C5643 R3568 TP3516 C4704 IC8302 TP3518 R8378 FL4800 FL4801 FL4802 R3569...
  • Page 44: D-Board

    TH-50PX75U 14.4. D-Board D-BOARD (FOIL SIDE) TZTNP01LNTU C058 C825 R134 C057 R828 C056 R827 C516 C564 C523 IC001 R859 Q046 D811 R875 IC002 C565 R840 D802 C524 C517 L501 C832 C522 C838 C561 L502 R108 R505 R109 C528 C045 R850...
  • Page 45 TH-50PX75U D-BOARD (COMPONENT SIDE) TZTNP01LNTU R128 D110 R237 Q010 IC011 R854 C037 IC500 C061 C875 C047 C841 R525 R523 R524 C534 R536 C859 R553 C533 C532 R562 C842 C858 FL504 R402 FL803 IC003 PA800 R566 R565 R563 R561 R564 C855...
  • Page 46: C1-Board

    TH-50PX75U 14.5. C1-Board Parts Location C1-BOARD IC7101 IC7102 C1-BOARD (FOIL SIDE) TXNC11HMTU 1 2 3 TNPA4169 REVERSE FOR ORDER C1-BOARD (COMPONENT SIDE) TXNC11HMTU IC101 R110 R184 ZA105 C1MM1 ZA104 R165 IC102 ZA106 R113 ZA101 R195 R108 C105 C104 R172 CR NO.7...
  • Page 47: C2-Board

    TH-50PX75U 14.6. C2-Board Parts Location C2-BOARD IC7201 IC7202 IC7203 C2-BOARD (FOIL SIDE) TXNC21HMTU TNPA4170 1 C2 REVERSE FOR ORDER C2-BOARD (COMPONENT SIDE) TXNC21HMTU ZA204 C232 C231 R210 C2MM1 R242 ZA202 C230 C204 R244 TNPA4170 1 C2 C206 IC203 C202 R251...
  • Page 48: C3-Board

    TH-50PX75U 14.7. C3-Board Parts Location C3-BOARD IC7301 IC7302 IC7303 IC7304 C3-BOARD (FOIL SIDE) TXNC31HMTU 1 2 3 TNPA4171 REVERSE FOR ORDER C3-BOARD (COMPONENT SIDE) TXNC31HMTU FL301 ZA304 R326 R341 C326 C3MM2 R327 R330 C3MM1 C329 ZA302 C331 C333 C327 C334...
  • Page 49: Sc-Board

    TH-50PX75U 14.8. SC-Board SC-BOARD (FOIL SIDE) TXNSC1HMTU TP48 TP29 TP30 TP50 TP40 TP31 C440 TP042 C692 C450 SC45 SC46 C693 SC41 SC43 L690 R696 Q806 C620 R697 Q805 Q690 C641 C808 R658 C721 R629 Q661 Q421 Q422 Q423 Q424 Q401...
  • Page 50 TH-50PX75U Parts Location Parts Location SC-BOARD (FOIL SIDE) SC-BOARD (COMPONENT SIDE) TRANSISTOR TP41 PHOTO COUPLER Q6571 Q6801 TP42 Q6803 Q6572 IC6471 PC6480 IC6791 Q6805 TP43 Q6573 IC6472 PC6701 IC6803 TP45 Q6574 Q6806 IC6481 PC6702 TP46 Q6581 Q6821 IC6500 PC6703 TRANSISTOR...
  • Page 51 TH-50PX75U SC-BOARD (COMPONENT SIDE) TXNSC1HMTU ZA402 C692 R886 R887 R888 C693 C440 SC46 SC45 C450 Q641 Q643 Q645 Q651 SCMM1 D690 Q642 Q648 Q649 SC41 SC43 TPSC1 R696 R645 R646 R648 R649 R651 Q647 R647 R721 Q781 Q782 Q646 C620...
  • Page 52: Su-Board

    TH-50PX75U 14.9. SU-Board Parts Location SU-BOARD IC6901 IC6902 IC6903 IC6904 IC6905 IC6906 IC6910 IC6911 TEST POINT TPSU1 TPSU2 TPSU3 TPSU4 SU-BOARD (FOIL SIDE) TXNSU1HMTU TNPA4188 REVERSE FOR ORDER 1 2 3 SU-BOARD (COMPONENT SIDE) TXNSU1HMTU C6930 C6928 D6903 D6906 C6935...
  • Page 53: Sd-Board

    TH-50PX75U 14.10. SD-Board Parts Location SD-BOARD IC6951 IC6952 IC6953 IC6954 IC6955 IC6956 IC6960 IC6961 TEST POINT TPSD1 TPSD2 TPSD3 TPSD4 SD-BOARD (FOIL SIDE) TXNSD1HMTU TNPA4189 REVERSE FOR ORDER 1 2 3 SD-BOARD (COMPONENT SIDE) TXNSD1HMTU D6955 C6983 C6980 D6953 C6977...
  • Page 54: Ss-Board

    TH-50PX75U 14.11. SS-Board Parts Location SS-BOARD (FOIL SIDE) TRANSISTOR TRANSISTOR VOLUME TP19 TP20 Q6001 VR6000 TP21 Q6002 TP22 Q6003 TP24 Q6004 TP25 Q6021 TP26 Q6022 TP27 Q6023 TP28 Q6024 TP29 Q6041 TP30 Q6042 TP10 TP31 Q6043 TP11 TP33 Q6051 TP12...
  • Page 55 TH-50PX75U Parts Location SS-BOARD (COMPONENT SIDE) TRANSISTOR TRANSISTOR Q6101 Q6171 Q6102 Q6172 IC6131 Q6001 TPSOS8 Q6103 Q6181 IC6151 Q6002 TPSS1 Q6104 Q6222 IC6191 Q6003 TPVDA Q6105 Q6251 IC6211 Q6004 TPVe Q6106 Q6256 IC6221 Q6021 TPVSUS Q6111 Q6271 IC6241 Q6022 Q6112...
  • Page 56: Ss2 And Ss3-Board

    TH-50PX75U 14.12. SS2 and SS3-Board SS2-BOARD (FOIL SIDE) SS2-BOARD (COMPONENT SIDE) TNPA4202S TNPA4202S TNPA4202 1 SS2 TNPA4202 1 SS2 REVERSE FOR ORDER SS23 SS23 ORDER SS52 SS52 SS3-BOARD (FOIL SIDE) SS3-BOARD (COMPONENT SIDE) TNPA4203S TNPA4203S TNPA4203 1 SS3 TNPA4203 REVERSE...
  • Page 57: Schematic And Block Diagram

    TH-50PX75U 15 Schematic and Block Diagram 15.1. Schematic Diagram Note...
  • Page 58: Main Block Diagram

    TH-50PX75U 15.2. Main Block Diagram TUNER DC-DC CONVERTER SPEAKER OUT,SOUND PROCESSOR DC/DC DC/DC DC/DC AV TERMINAL,AV SWITCH K REMOTE/LED 3.3V 1.8V 1.5V DIGITAL SIGNAL PROCESSOR POWER LED DDR2x2 MICON REMOTE RECEIVER HDMI INTERFACE VCXO X'tal [27MHz] FRONT CH0DATA PRO. POWER SW...
  • Page 59: P-Board Block Diagram

    TH-50PX75U 15.3. P-Board Block Diagram COLD AC IN RF601 3A 100-120V TO SC2 MC602 D605 F201 MC202 50/60Hz L603 Vsus 180V Vsus VSUS POWER SUPPLY RECTIFIER K601 K602 POWER CONTROL 2 T201 VR251 L601 L602 <Exchange board only> VSUS LIVE...
  • Page 60: P-Board (1 Of 2) Schematic Diagram

    TH-50PX75U 15.4. P-Board (1 of 2) Schematic Diagram PFC MODULE <Exchange board only> RECTIFIER <Exchange board only> PFC MODULE <Exchange board only> P-BOARD ETXMM655MEH (1/2) TH-50PX75U TH-50PX75U P-Board (1 of 2) Schematic Diagram P-Board (1 of 2) Schematic Diagram...
  • Page 61: P-Board (2 Of 2) Schematic Diagram

    TH-50PX75U 15.5. P-Board (2 of 2) Schematic Diagram PFC/BIAS CONTROL MODULE <Exchange board only> Vsus POWER CONTROL 2 <Exchange board only> COLD COLD P-BOARD ETXMM655MEH (2/2) Vsus POWER SUPPLY <Exchange board only> COLD SC-BOARD (SC2) SS-BOARD (SS11) D-BOARD SS-BOARD A-BOARD...
  • Page 62: Gs, K And S-Board Block And Schematic Diagram

    TH-50PX75U 15.6. GS, K and S-Board Block and Schematic Diagram RM2501 K-BOARD TXN/K1LPTU PNA4701M05TV REMOTE RECEIVER D2512 MAZ80430LL C2512 C2521 6.3V 0.01u D2520A LN1271RALTR D2524 C2515 MA8056MTX POWER LED 0.01u R2517 R2525 Q2510 R2516 2SD0601A0L SW2500 Q2511 R2542 2SD0601A0L POWER SW...
  • Page 63: A-Board (1 Of 5) Block Diagram

    TH-50PX75U 15.7. A-Board (1 of 5) Block Diagram MAIN5V IC4508 IC4506 HOTPLUG SUB3.3V SUB5V CVDD 1.8V AVR 1.8V Q4501 Q4500 VOUT VOUT TV_SUB_ON_DELAY IC4501 CONT CONT 5 MAIN5V EEPROM IC4509 Q4504 DVDD 1.8V VOUT CONT 5 IC4500 MAIN3.3V EEPROM Q4505...
  • Page 64: A-Board (2 Of 5) Block Diagram

    TH-50PX75U 15.8. A-Board (2 of 5) Block Diagram MONITOR OUT JK3000 MONITOR AV2_C Q3124 Q3123 VIDEO2 AV2_Y DC-DC CONVERTER A_MON_MUTE SPEAKER OUT,SOUND PROCESSOR Q3125 AV2_S_DET AV TERMINAL,AV SWITCH AV2_V DIGITAL SIGNAL PROCESSOR AV2_L IC3101 MICON AV2_R AUDIO SW DTV9V HDMI INTERFACE...
  • Page 65: A-Board (3 Of 5) Block Diagram

    TH-50PX75U 15.9. A-Board (3 of 5) Block Diagram DC-DC CONVERTER SPEAKER OUT,SOUND PROCESSOR AV TERMINAL,AV SWITCH DIGITAL SIGNAL PROCESSOR MICON HDMI INTERFACE PEAKS LITE 2 D2066 AMP_MUTE SUB5V TP3504 TP3505 STB5V SUB_5V SUB9V IC3500 TP3506 TP3507 DTV9V Q2053 Q2066 STB_RST...
  • Page 66: A-Board (4 Of 5) Block Diagram

    TH-50PX75U 15.10. A-Board (4 of 5) Block Diagram GS52 IC5704 DC-DC CONVERTER RESET DTV9V SPEAKER OUT,SOUND PROCESSOR AV TERMINAL,AV SWITCH DIGITAL SIGNAL PROCESSOR IC8502 MICON HDMI INTERFACE 128/256 bit NOR FLASH PEAKS LITE 2 HDMI_SPDIF SD CARD I/F CPU BUS I/F...
  • Page 67: A-Board (5 Of 5) Block Diagram

    TH-50PX75U 15.11. A-Board (5 of 5) Block Diagram DC-DC CONVERTER SPEAKER OUT,SOUND PROCESSOR AV TERMINAL,AV SWITCH DIGITAL SIGNAL PROCESSOR MICON HDMI INTERFACE PEAKS LITE 2 IC1100 IC8503 IC1101 MAIN MICON Genx4 EEPROM SUB3.3V EEPROM STB3.3V SDA3 SDA0 SDA1 SCL3 EEPROM_WP...
  • Page 68: A-Board (1 Of 12) Schematic Diagram

    TH-50PX75U 15.12. A-Board (1 of 12) Schematic Diagram A-BOARD TNPH0692ACS (1/12) Peaks-Lite2,DDR IC8001 MN2WS0039A Peaks Lite 2 B PORT FOR ADV7493 (Sub Video Input or Address) LOSD OUT (for HQ1) FOR HQ1L VIDEO to (10/12) to (3/12) CPU BUS I/F...
  • Page 69: A-Board (2 Of 12) Schematic Diagram

    TH-50PX75U 15.13. A-Board (2 of 12) Schematic Diagram A-BOARD TNPH0692ACS (2/12) Peaks-Lite2,DDR IC8001 MN2WS0039A Peaks Lite 2 MCLK AE23 IC8001 IC8002 TSTSEL AC21 IC8001 C3ABSG000039 DDR2 #0 DDR2#0 512M 1.8V_DDRI/F 84FBGA LITE2 DDR2 CH0DM0 CH0DM0 --------------- MMDM0 IC8001 IC8002 IC8002...
  • Page 70: A-Board (3 Of 12) Schematic Diagram

    TH-50PX75U 15.14. A-Board (3 of 12) Schematic Diagram A-BOARD TNPH0692ACS (3/12) DIGITAL(NAND,BOOT,ETC) to(1/12) AA_ED0 From PEAKS-LiteII AA_ED1 R4090 AA_ED2 EXB2HV560JV AA_ED3 AA_ED4 SUB3.3V C8506 TP8550 AA_ED5 0.1u AA_ED6 AA_ED7 LiteII R8556 AA_ED8 TP8551 AA_ED9 R4091 to (1/12) AA_ED10 EXB2HV560JV VI2CLK2...
  • Page 71: A-Board (4 Of 12) Schematic Diagram

    TH-50PX75U 15.15. A-Board (4 of 12) Schematic Diagram PEAKS-LITE2 POWER R5622 100k L5604 A-BOARD TNPH0692ACS (4/12) C5619 L5605 DTV9V G1C100MA0077 J0JHC0000075 R5637 C5630 C5632 C5631 POWER SUPPLY R5608 R5609 R5614 C5617 C5626 C5616 C5610 0.1u CUVP C5624 0.047u SUB1.8V R5630 TP5602 47.5k...
  • Page 72: A-Board (5 Of 12) Schematic Diagram

    TH-50PX75U 15.16. A-Board (5 of 12) Schematic Diagram IIC2 JK3000 to(3/12)(11/12)(12/12) MON_V DTV9V K1U939A00003 D3076 MAZ81400ML AD_SCL2 AD_SCL2 MONITOR OUT AD_SDA2 D3077 AD_SDA2 MAZ81400ML 3.3V:V-AVSW/ADV4422/FE/DVB-TNR MONITOR D3078 MON_L 5V :A-AVSW/A-TNR MAZ81400ML C3123 MON_R R3145 R3123 MON_L 1.8k AAM_L V2_C C3124...
  • Page 73: A-Board (6 Of 12) Schematic Diagram

    TH-50PX75U 15.17. A-Board (6 of 12) Schematic Diagram MAIN9V TP2037 Q2301 R2331 2SB0709A0L 2.2k D2302 C2301 R2302 MA2J11100L R2330 2.2k SOUND15V SOUND12V 0.1u Q2042 L2310 2SD0601A0L R2301 J0JJC0000011 D2301 2.2k VOUT MA2J11100L 150mA R2115 R2305 C2349 C2302 0.1u 0.1u C2352...
  • Page 74: A-Board (7 Of 12) Schematic Diagram

    TH-50PX75U 15.18. A-Board (7 of 12) Schematic Diagram P-BOARD P-BOARD (P6) (P7) C3530 TP3501 470u TP3518 TP3500 TP3519 STB5V SOUND15V F15V STB5V TP3504 SUB5V L3506 TP3505 1.8A G1C100M00044 D3514 B0BC6R600005 IC3500 SUB+5V/SUB+9V EHMDD9851 ON:0-0.5V DTV9V 1.8A TP3506 TP3507 ON:0-0.5V OFF:2-Vin...
  • Page 75: A-Board (8 Of 12) Schematic Diagram

    TH-50PX75U 15.19. A-Board (8 of 12) Schematic Diagram Power Supply to (3/12)(4/12)(5/12) A-BOARD TNPH0692ACS (8/12) GenX4 RST STB_RST Lite2 to(1/12) GenX4,EEPROM UART(LITE2-GenX4) SBI2 SBI2 SBO2 SBO2 ADV7493 STB3.3V to(10/12) FOR DEBUGER AG_HDMI_MUX_SEL AG_HDMI_MUX_SEL R1182 R1195 AG_HDMI_MUX_EN AG_HDMI_MUX_EN C1105 100k AG_HDMI_REP_EN 6.3V...
  • Page 76: A-Board (9 Of 12) Schematic Diagram

    TH-50PX75U 15.20. A-Board (9 of 12) Schematic Diagram A-BOARD TNPH0692ACS (9/12) Q4503 2SD0601A0L ADV7493,HDMI-Mux AG_HDMI_5V_DET1 R4530 R4533 MAIN5V R4527 D4527 D4526 B0HCMM000014 B0HCMM000014 TP4508 R4663 DDCA_SCL L4506 R4664 J0JHC0000078 DDCA_SDA L4507 J0JHC0000078 R4536 4.7k TP4505 R4501 Q4501 R4503 2SD0601A0L R4525...
  • Page 77: A-Board (10 Of 12) Schematic Diagram

    TH-50PX75U 15.21. A-Board (10 of 12) Schematic Diagram R4620 SUB3.3V C4618 Peaks Lite II 0.01u Vout to(1/12) L4518 C4607 C4609 C4620 6.3V J0JHC0000078 CN_to_H VI1P9 VI1P9 UVIN9 to (5/12) IC4508 MAIN_Y/CVBS VI1P8 MAIN_Y/CVBS VI1P8 UVIN8 R4661 C0CBCAD00082 MAIN_PB/C VI1P7 C4615...
  • Page 78: A-Board (11 Of 12) Schematic Diagram

    TH-50PX75U 15.22. A-Board (11 of 12) Schematic Diagram A-BOARD TNPH0692ACS (11/12) Front End SUB5V FL8308 J0MAB0000164 C8394 C8396 0.1u SUB3.3V R8337 TP8315 R8330 AD_SCL_FE RF_V R8335 RF_V TP8313 Q8303 RF_L B1CBHD000002 RF_L to(5/12) R8331 Q8301 TP8314 AD_SDA_FE 2SB0709A0L RF_R RF_R...
  • Page 79: A-Board (12 Of 12) Schematic Diagram

    TH-50PX75U 15.23. A-Board (12 of 12) Schematic Diagram A-BOARD TNPH0692ACS (12/12) LVDS etc FACTORY STB3.3V STB3.3V IIC_CONT/SRQ R4152 TP8503 AD_SCL0 LITE2_SCL0 (Device Control) TP8504 AD_SDA0 LITE2_SDA0 (Device Control) TP8505 AR_PANEL_SCL Panel_SCL (Panel Dpr.E2PROM) TP8506 AR_PANEL_SDA Panel_SDA (Panel Dpr.E2PROM) TP8501 SBI0...
  • Page 80: D-Board Block Diagram

    TH-50PX75U 15.24. D-Board Block Diagram DIGITAL SIGNAL PROCESSOR FORMAT CONVERTER P1.2V P2.5V P3.3V PLASMA AI IC9901 SUB-FIELD PROCESSOR IC9900 DDR SDRAM(128M) PD1-Mplus P2.5V PLASMA AI/SUB FIELD PROCESSOR/PEAKS DATA DRIVER FORMAT CONVERTER/RGB PROCESSOR PICTURE P1.2V OUTPUT DRVCLKU0-U3 R 10bit CTI/TINT R0-R9...
  • Page 81: D-Board (1 Of 6) Schematic Diagram

    TH-50PX75U 15.25. D-Board (1 of 6) Schematic Diagram D-BOARD TZTNP01LNTU (1/6) P15V C9867 C9870 R9883 R9895 100k C9861 C9880 C9885 0.1u 8200p 1000p CUVP P3.3V R9890 47.5k L9800 PGOOD G1C2R2Z00007 R9880 R9891 C9877 C9865 12.7k REFIN1 R9886 OUT1-1 C9886 Q9807...
  • Page 82: D-Board (2 Of 6) Schematic Diagram

    TH-50PX75U 15.26. D-Board (2 of 6) Schematic Diagram D-BOARD TZTNP01LNTU (2/6) FACTORY STB3.3V ON/OFF A-BOARD (A5) IC9011 C0EBF0000431 RESET STB5V_M STB 3.3V STB3.3V R9874 STB5V D9110 R9140 R9139 P15V_MOTO STB3.3V B0JCGD000002 VOUT C9034 C9035 C9033 C9036 STB5V_M 0.1u 0.1u C9037 0.01u...
  • Page 83: D-Board (3 Of 6) Schematic Diagram

    TH-50PX75U 15.27. D-Board (3 of 6) Schematic Diagram P3.3V VCCI SC_PULSE LVDS_INPUT R9510 C9531 FP_CPH2 IC9500 IC9500 C9516 IC9500 CPH2 IC9500 16V 0.1u FP_OC1 IC9500 IC9500 IC9500 VCCIO2 VCCINT IC9500 IC9500 P2.5V_ASIC P1.2V C9517 FL9504 FP_CLK IC9500 IC9500 IC9500 VCCIO2...
  • Page 84: D-Board (4 Of 6) Schematic Diagram

    TH-50PX75U 15.28. D-Board (4 of 6) Schematic Diagram D-BOARD TZTNP01LNTU (4/6) DD_CLRD2 D-CLRD2 DD_ODED2 D-ODED2 DD_PCD4 D-PCD4 DD_PCD3 D-PCD3 FP_URH URH_C2 DD_LED2 D-LED2 FP_NUEL NUEL_C2 R9403 FP_UEH UEH_C2 EXB2HV470JV FP_USL USL_C2 FP_USH USH_C2 FP_UML UML_C2 FP_UMH UMH_C2 DD_CLRD1 D-CLRD1 R9363...
  • Page 85: D-Board (5 Of 6) Schematic Diagram

    TH-50PX75U 15.29. D-Board (5 of 6) Schematic Diagram D-BOARD TZTNP01LNTU (5/6) FL9900 FL9901 FL9902 P2.5V F1J1E104A148 L8R2.5V P1.2V L8R1.2V P3.3V L8R3.3V F1J1E104A148 F1J1E104A148 L8R_MONOUT1 L8_DCK to DDR L8R3.3V IC9900 TDO_TO_FPGA C9921 IC9900 IC9900 VDD33 IC9900 0.1u L8R_DQ0 FPCLK IC9900 IC9900...
  • Page 86: D-Board (6 Of 6) Schematic Diagram

    TH-50PX75U 15.30. D-Board (6 of 6) Schematic Diagram DDR-Terminate DDR-SDRAM IC9901 VSS_Thermal IC9901 VSSQ IC9901 R9944 EXB38V470JV IC9901 VSS_Thermal L8R_DQ20 L8DR_DQ20 IC9901 VSSQ IC9901 L8R_DQ21 L8DR_DQ21 IC9901 VSS_Thermal IC9901 VSSQ IC9901 L8R_DQ23 L8DR_DQ23 IC9901 VSS_Thermal L8R_DQ22 L8DR_DQ22 IC9901 VSSQ IC9901...
  • Page 87: C1, C2 And C3-Board Block Diagram

    TH-50PX75U 15.31. C1, C2 and C3-Board Block Diagram TO D31 TO D32 49 - 16 64 63 55 - 15 DATA TO C32 DATA 30bit 36bit DA0-DC11 DA12-DC21 DATA DRIVE DATA DRIVE 5V_DET LOWER CENTER LOWER RIGHT(FRONT VIEW) 5V_DET (FRONT VIEW)
  • Page 88: C1-Board (1 Of 3) Schematic Diagram

    TH-50PX75U 15.32. C1-Board (1 of 3) Schematic Diagram C1-BOARD TXNC11HMTU (1/3) C7140 R7173 R7172 EXB38V471JV EXB38V471JV 100p C1_5V PANEL DATA C7138 C7137 DRIVER R7156 D7110 R7138 R7137 D7109 B0HCMM000014 R7155 B0HCMM000014 R7157 R7154 C7135 C7134 100V 100V 0.47u VDA_75V 0.47u...
  • Page 89: C1-Board (2 Of 3) Schematic Diagram

    TH-50PX75U 15.33. C1-Board (2 of 3) Schematic Diagram C1-BOARD TXNC11HMTU (2/3) C7108 R7127 EXB38V471JV 100p C1_5V PANEL DATA C7111 C7110 DRIVER R7132 D7105 D7106 R7112 R7111 B0HCMM000014 R7131 B0HCMM000014 R7130 R7133 C7117 C7118 100V 100V 0.47u VDA_75V 0.47u R7145 R7166...
  • Page 90: C1-Board (3 Of 3) Schematic Diagram

    TH-50PX75U 15.34. C1-Board (3 of 3) Schematic Diagram C1-BOARD TXNC11HMTU (3/3) D-BOARD (D31) TERM C1_5V FL7101 C7141 J0HABH000013 5V_DET R7183 EXB38V220JV R7110 EXB38V220JV CLKD_23P CLKD_01P CLKD_24P CLKD_0P CLKD_02P CLKD_25P CLKD_11N R7103 CLKD_12N EXB38V220JV CLKD_1N CLKD_33N CLKD_2P R7195 CLKD_34N EXB38V470JV CLKD_35N...
  • Page 91: C2-Board (1 Of 2) Schematic Diagram

    TH-50PX75U 15.35. C2-Board (1 of 2) Schematic Diagram C2-BOARD TXNC21HMTU (1/2) C7216 R7240 R7241 EXB38V471JV 100p EXB38V471JV C2_5V C7228 C7227 PANEL DATA DRIVER R7231 D7206 R7257 R7256 D7205 B0HCMM000014 R7230 B0HCMM000014 R7232 R7229 C7224 C7225 100V 100V 0.47u VDA_75V 0.47u...
  • Page 92: C2-Board (2 Of 2) Schematic Diagram

    TH-50PX75U 15.36. C2-Board (2 of 2) Schematic Diagram D-BOARD (D32) C7230 FL7202 ZA7201 ZA7202 ZA7203 ZA7204 J0HABH000013 TERM K4AD01Z00001 K4AD01Z00001 K4AD01Z00001 K4AD01Z00001 C2_5V C3-BOARD (C32) C7201 C2_5V FL7201 J0HABH000013 5V_DET C1-BOARD SOS8_C2 SOS8_SS (C10) URH_C2 UEL_C2 5V_DET UEH_C2 5V_DET USL_C2...
  • Page 93: C3-Board (1 Of 2) Schematic Diagram

    TH-50PX75U 15.37. C3-Board (1 of 2) Schematic Diagram C3_5V C2-BOARD (C22) C7326 C3_5V C7328 0.1u FL7301 J0HABH000013 R7343 C3_5V R7345 C7330 SS-BOARD C3_5V EXB38V471JV EXB38V471JV (SS33) R7334 0.1u EXB38V102JV CLKU_3N R7327 R7341 EXB38V220JV CLKU_31N 5V_DET AA_DDA5 CLKU_30N SOS8_C3 R7344 SOS8_SS...
  • Page 94: C3-Board (2 Of 2) Schematic Diagram

    TH-50PX75U 15.38. C3-Board (2 of 2) Schematic Diagram C3-BOARD TXNC31HMTU (2/2) R7336 C7325 R7337 EXB38V102JV EXB38V102JV 100p R7342 4.7k CB11 C3_5V PANEL DATA C7323 C7322 DRIVER R7319 D7306 R7372 R7371 D7305 B0HCMM000014 B0HCMM000014 R7318 R7320 R7317 C7320 C7319 100V VDA_75V 100V 0.47u...
  • Page 95: Sc, Su And Sd-Board Block Diagram

    TH-50PX75U 15.39. SC, SU and SD-Board Block Diagram FOR FACTORY USE SC31 COLD FLOATING GND SC SCAN DRIVE IC6791 TPSC1 SIGNAL WAVE 155V Q6881 TPVBK VSET Q6882 DC/DC CONV. +16V_F SU SCAN OUT (UPPER) VOUT VSUS Q6883 TO P2 VSUS...
  • Page 96: Sc-Board (1 Of 3) Schematic Diagram

    TH-50PX75U 15.40. SC-Board (1 of 3) Schematic Diagram SC-BOARD TXNSC1HMTU (1/3) TPVSUS L6591 G0ZZ00002183 VSUS P-BOARD (P2) Vsus VSUS VSUS C6411 C6412 C6413 C6414 C6415 C6416 C6431 220V 220V 220V 220V 192V 220V 220V 250V 200u 200u 200u 200u 200u...
  • Page 97: Sc-Board (2 Of 3) Schematic Diagram

    TH-50PX75U 15.41. SC-Board (2 of 3) Schematic Diagram COLD FLOATING GND R6721 EXB38V220JV PC6701 AB_FOC1D B3PBA0000233 AB_FOC1U AA_OC1 VSCN_F TPSC1 AB_FCLKD AB_FCLKU R6710 R6700 2.2k L6690 R6696 G0ZZ00002183 R6711 FLOATING GND 2.2k D6820 R6701 MA2J11100L 15V_F COLD C6726 VSCN_F AA_CLK R6867 3.9k...
  • Page 98: Sc-Board (3 Of 3) Schematic Diagram

    TH-50PX75U 15.42. SC-Board (3 of 3) Schematic Diagram SC41 SU-BOARD (SU41) VSET VSET0 Q6821 R6821 2SD1263AP0LB SU-BOARD VSET:330V SC45 (SU45) D6822 C6822 TP40 MA2J11100L R6825 R6829 400V R6833 D6827 200k 100k AB_FSIU D6824 MAZ83300ML D6828 AB_FSIU MAZ83300ML MAZ83300ML R6822 R6823...
  • Page 99: Su-Board (1 Of 2) Schematic Diagram

    TH-50PX75U 15.43. SU-Board (1 of 2) Schematic Diagram SU-BOARD TXNSU1HMTU (1/2) To 1st 96pins of To 2nd 96pins of SCAN ELECTRODES SCAN ELECTRODES AB_731 AB_742 AC_667 AC_678 AD_603 AD_614 AB_730 AB_743 AC_666 AC_679 AD_602 AD_615 AB_729 AB_744 AC_665 AC_680 AD_601...
  • Page 100: Su-Board (2 Of 2) Schematic Diagram

    TH-50PX75U 15.44. SU-Board (2 of 2) Schematic Diagram SU-BOARD TXNSU1HMTU (2/2) To 3rd 96pins of To 4th 96pins of SCAN ELECTRODES SCAN ELECTRODES AE_539 AE_550 AF_475 AF_486 AG_411 AG_422 AE_538 AE_551 AF_474 AF_487 AG_410 AG_423 AE_537 AE_552 AF_473 AF_488 AG_409...
  • Page 101: Sd-Board (1 Of 2) Schematic Diagram

    TH-50PX75U 15.45. SD-Board (1 of 2) Schematic Diagram SD-BOARD TXNSD1HMTU (1/2) DOWN To 1st 96pins of To 2nd 96pins of SCAN ELECTRODES SCAN ELECTRODES AB_347 AB_358 AC_283 AC_294 AD_219 AD_230 AB_346 AB_359 AC_282 AC_295 AD_218 AD_231 AB_345 AB_360 AC_281 AC_296...
  • Page 102: Sd-Board (2 Of 2) Schematic Diagram

    TH-50PX75U 15.46. SD-Board (2 of 2) Schematic Diagram SD-BOARD TXNSD1HMTU (2/2) DOWN To 3rd 96pins of To 4th 96pins of SCAN ELECTRODES SCAN ELECTRODES AE_155 AE_166 AF_91 AF_102 AG_27 AG_38 AE_154 AE_167 AF_90 AF_103 AG_26 AG_39 AE_153 AE_168 AF_89 AF_104...
  • Page 103: Ss, Ss2 And Ss3-Board Block Diagram

    TH-50PX75U 15.47. SS, SS2 and SS3-Board Block Diagram SS52 TPVSUS TPSS1 SIGNAL WAVE TO P11 190V Vsus Q6001-Q6003 VSUS Vsus Gen. OUTPUT IC6131 SS23 Q6141-Q6142 Q6021-Q6023 Q6146-Q6147 OUTPUT FET DRIVER TPVe SS21 TPVDA Q6256 TO P12 Q6222A Q6041-Q6043 ENERGY RECOVERY...
  • Page 104: Ss-Board (1 Of 2) Schematic Diagram

    TH-50PX75U 15.48. SS-Board (1 of 2) Schematic Diagram P-BOARD R6031 (P11) TPVSUS R6032 SS11 L6271 G0ZZ00002183 R6033 D6032 MA2J11100L VSUS C6011 C6012 C6013 C6014 C6015 C6016 C6031 R6034 250V 220V 220V 220V 220V 220V 220V 200u 200u 200u 200u 200u...
  • Page 105: Ss-Board (2 Of 2), Ss2 And Ss3-Board Schematic Diagram

    TH-50PX75U 15.49. SS-Board (2 of 2), SS2 and SS3-Board Schematic Diagram SS-BOARD TXNSS1HMTU (2/2) D6277 MA3X152D0L R6247 C6287 150k R6246 0.1u R6277 C6276 C6247 R6273 R6283 150k R6276 4.7u 0.1u Q6271 2SD0601A0L D6278 D6275 MA3X152D0L MAZ80680ML R6274 R6249 C6288 150k...
  • Page 106 TH-50PX75U NOTE...
  • Page 107: Exploded Views & Replacement Parts List

    TH-50PX75U 16 Exploded Views & Replacement Parts List 16.1. Exploded Views...
  • Page 108: Packing Exploded Views (Accessories Box)

    TH-50PX75U 16.2. Packing Exploded Views (Accessories box)
  • Page 109: Replacement Parts List Notes

    TH-50PX75U 16.3. Replacement Parts List Notes...
  • Page 110: Mechanical Replacement Parts List (Pdp Tv)

    TH-50PX75U 16.4. Mechanical Replacement Parts List (PDP TV) Note: Ref. No. Part No. Part Name & Remarks Description All parts except parts mentioned [PAVCA] in the Remarks XYN4+F10FJ SCREW column are supplied by PAVC-CSG. XYN4+F10FJK SCREW XYN4+F30FJK SCREW Parts mentioned [PAVCA] are supplied by PAVCA.
  • Page 111: Mechanical Replacement Parts List (Stand)

    TH-50PX75U 16.5. Mechanical Replacement Parts List (Stand) Note: All parts except parts mentioned [PAVCA] in the Remarks column are supplied by PAVC-CSG. Parts mentioned [PAVCA] are supplied by PAVCA. Ref. No. Part No. Part Name & Remarks Description TBL2AX00171 STAND ASSY...
  • Page 112: Electrical Replacement Parts List

    TH-50PX75U 16.6. Electrical Replacement Parts List Note: Ref. No. Part No. Part Name & Remarks Description All parts except parts mentioned [PAVCA] in the Remarks C2173 ECJ2FF1C475Z C 0.047UF, Z, column are supplied by PAVC-CSG. C2183 F1J1A106A043 C 0.010UF, K, Parts mentioned [PAVCA] are supplied by PAVCA.
  • Page 113 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C3001 ECJ1VB1A105K C 0.01UF, Z, 50V C4566 ECJ1XB1C393K C 0.039UF, K, C3003 ECJ1VB1A105K C 0.01UF, Z, 50V C4568 F1G1C104A081 C 0.10UF, K, 16V...
  • Page 114 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C5609,10 EEEHB1C470P C 47PF, J, 16V C6472 ECJ2XC1H101J C 100PF, J, 50V C5613 F1H0J1050012 C 1UF, K, 16V C6480 ECJ2XB1H104K C 0.1UF, K, 50V...
  • Page 115 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C6873 ECJ2VB1H103K C 0.01UF, K, 50V C8002-05 ECJ1VB0J105K C 1UF, K, 6.3V C6884 ECJ2VB1H103K C 0.01UF, K, 50V C8006-08 F1G1A104A012 C 0.01UF, K, 10V...
  • Page 116 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description C8513 ECJ0EB1C103K C 0.010UF, K, CF6281 D4DA91000001 THERMISTOR C8517 F1G1A104A012 C 0.01UF, K, 10V C8519 ECJ0EB1C103K C 0.010UF, K, K1KB31BA0064 31P CONNECTOR...
  • Page 117 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description D6277,78 MA3X152A0L DIODE D6838 B0BC027A0234 ZENER DIODE D6280 MAZ80510LL ZENER DIODE D6839 B0ECKP000047 DIODE D6281,82 B0JCME000037 DIODE D6841 B0HCKS000002 DIODE D6401,02...
  • Page 118 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description IC6131 C0ZBZ0000895 JS4023 D0YAR0000007 M 0.0 OHM, J,0.063W IC6151 C0ZBZ0001324 JS4025 D0YAR0000007 M 0.0 OHM, IC6191 C0ZBZ0000895 J,0.063W IC6211 C0ZBZ0001325 JS4501 D0YAR0000007 M 0.0 OHM,...
  • Page 119 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description L7701 J0JCC0000143 CHIP INDUCTOR PAVCA Q6001-04 2PG0010000RP TRANSISTOR L8001-05 J0JHC0000045 CHIP INDUCTOR Q6021-23 2PG0010000RP TRANSISTOR L8006 J0JCC0000100 CHIP INDUCTOR Q6031 B1ADRD000001...
  • Page 120 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description Q6883 2SC1473AEA TRANSISTOR R1182 ERJ2GEJ273 M 27KOHM ,J,0.063W Q8301 2SB0709ARL TRANSISTOR R1183,84 ERJ2GEJ220 M 22 OHM, Q8302,03 B1CBHD000002 J,0.063W Q9010 2SD0601ARL...
  • Page 121 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R2106 ERJ2GEJ103 M 10KOHM, R2352 ERJ2GEJ473 J,0.063W 47KOHM,J,0.063W R2107,08 ERJ2GEJ102X M 1KOHM, R2353 ERJ2GEJ104 M 100KOHM, J,0.063W J,0.063W R2110 ERJ2GEJ103 M 10KOHM,...
  • Page 122 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R3148 ERJ2GEJ184 M 180KOHM, R4134-37 ERJ2GEJ101 M 100 OHM, J,0.063W J,0.063W R3149,50 ERJ2GEJ101 M 100 OHM, R4152 J0JCC0000100 CHIP INDUCTOR J,0.063W...
  • Page 123 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R4613,14 ERJ2GEJ220 M 22 OHM, R5601 J0JCC0000100 CHIP INDUCTOR J,0.063W R5602,03 D0YAR0000007 M 0.0 OHM, R4615 ERJ3EKF1600 M 160 OHM, 1/16W J,0.063W...
  • Page 124 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R6034 ERJ6ENF2702 M 27KOHM, 1/10W R6257 ERJ6GEYG103 M 10KOHM,J,1/10W R6041 ERJT08J7R5V M 7.5OHM,J, R6258 ERJ6GEYG222 0.33W 2.2KOHM,J,1/10W R6043 ERJT08J7R5V M 7.5OHM,J,...
  • Page 125 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R6532,33 ERJ6GEYF473 M 47KOHM,J,1/10W R6709 ERJ6GEYJ101V M 100 OHM,J,1/10W R6551 ERJT06J100V M 10 OHM,F,0.25W R6710-14 ERJ6GEYG222 R6552,53 ERJ6GEYF473 M 47KOHM,J,1/10W 2.2KOHM,J,1/10W...
  • Page 126 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R6845-47 ERJ6GEYJ623 M 62KOHM,J,1/10W R6972-74 ERJ3GEYJ220 M 22 OHM,J,1/16W R6848 ERJ6GEYG103 M 10KOHM,J,1/10W R6975,76 J0JCC0000100 CHIP INDUCTOR R6849,50 ERJ6ENF6802 M 68KOHM, 1/10W...
  • Page 127 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R7701 ERJ3GEYJ680 M 68 OHM,J,1/16W R8338 ERJ3EKF1202 M 12KOHM, 1/16W R7702 J0JCC0000100 CHIP INDUCTOR R8340 ERJ2GEJ103 M 10KOHM, J,0.063W R7703-05 ERJ3GEYJ680...
  • Page 128 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R8565 ERJ2GEJ103 M 10KOHM, R9121 ERJ3GEYJ104 J,0.063W 100KOHM,J,1/16W R8566 EXB28V103JX RESISTOR ARRAY R9122,23 D0GB103JA057 M 10KOHM,J,1/16W R8568 EXB28VR000X RESISTOR ARRAY R9126...
  • Page 129 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description R9403 EXB2HV470JV RESISTOR ARRAY R9915-18 J0JCC0000100 CHIP INDUCTOR R9501 D0GB103JA057 M 10KOHM,J,1/16W R9919 D0GB102JA057 M 1KOHM,J,1/16W R9503 ERJ3GEYJ470 M 47 OHM,J,1/16W...
  • Page 130 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description ZA7301-04 K4AD01Z00001 TERMINAL C611 KZE1H560 ELECTROLYTIC CAPACITOR ZA9001 K4CD01000011 AV TERMINAL C612-14 KMQ2W221L C 220U 450V C615 ECKENA101KBR C 100P 250V...
  • Page 131 TH-50PX75U Ref. No. Part No. Part Name & Remarks Ref. No. Part No. Part Name & Remarks Description Description MC501 MLTZB100 MODULE R359 ERJ6ENF2102 M 21KOHM, 1/10W MC502 MLJHA103 MODULE R362 ERJ12YJ332 M 3.3KOHM,J, 1/2W MC601 MLLPD103 MODULE R363,64 ERJ6GEYF333...
  • Page 132 TH-50PX75U Ref. No. Part No. Part Name & Remarks Description R637 RCR6J825 METAL GLAZE FIXED RESISTOR R638 RCRU5J155 METAL GLAZE FIXED RESISTOR R701 ERJ6GEYG182 1.8KOHM,J,1/10W R702 ERJ6GEYG222 2.2KOHM,J,1/10W R703 ERJ6GEYG182 1.8KOHM,J,1/10W R704 ERJ6GEYG222 2.2KOHM,J,1/10W R706 ERJ6GEYG182 1.8KOHM,J,1/10W R707 ERJ6GEYG222 2.2KOHM,J,1/10W...

Table of Contents
