Page 1: Lcd Monitor
： Model PM15LCD 4:3 DIGITAL LCD-Monitor 15 LCD MONITOR OPERATING MANUAL... -
Page 2: Table Of Contents
Contents PREFACE SAFETY PRECAUTIONS FRONT BACK/SIDE CONNECTIONS OF LCD INSTALLTION DRAWINGS REMOTE CONTROL FUNCTIONS CONFIGURATION OF THE LCD TROUBLESHOOTING AND ADVICE SPECIFICATIONS Power Cable Connection Connecting Antenna Video Connection S-Video Connection Y Pb Pr Connection PC-RGB Connection Remote control instructions in TV mode Battery Installation Battery Usage Caution Enter picture menu... -
Page 3: Preface
1. PREFACE Thank you for buying this TV ! Please read this manual thoroughly before operating the monitor. Make sure the monitor was not damaged in transit. Should the monitor is damaged, do no install it and contact your dealer. Check that you have all the accessories according to the model. 2. - Page 4 Heating sources and humidity Keep the monitor dry and away from humidity. Keep the monitor away from heat sources Cleaning and maintenance Unplug the monitor before cleaning it. Do not use solvents or liquids to clean the monitor. Only clean the monitor with a soft and dry cloth. In case of troubleshooting, do not use spare parts other than those suggested by the manufacturer.
-
Page 5: Front Back/Side Connections Of Lcd
3. FRONT BACK/SIDE CONNECTIONS OF LCD Front View Back View and Control Connections “ ” 1.Press POWER Switch on the LCD TV when at standby mode or vice versa. “ ” “ ” 2.Press UP or DOWN to menu “ ”... -
Page 6: Installtion Drawings
4. TV INSTALLTION DRAWINGS Power Cable Connection Connect the power cord correctly as shown. Press the POWER switch of your LCD VT to switch on the LCD TV. The power indicator on the front panel lights up in green. DC IN 12V Connecting Antenna ANTENNA OUTDOOR... -
Page 7: Video Connection
Video Connection TV Back TV Back Connect the VIDEO and AUDIO output jack of the DVD or VCR to the AV IN jacks on the set using the RCA cable. Select the AV input source with using the SOURCE button on the remote control. S-Video TV Back TV Back... -
Page 8: Y Pb Pr Connection
Y Pb Pr Connection Connect the YPbPr output of the DVD or VCR to the YPbPr input on the set. The picture quality is improved; compared to connecting a regular VCR to the video input. Connect the Audio output of the DVD or VCR to the Audio input jacks on the set using the RCA cable. -
Page 9: Remote Control Functions
5. REMOTE CONTROL FUNCTIONS 5. REMOTE CONTROL FUNCTIONS 6.1 Remote control instructions in TV mode POWER Switch on LCD TV when at standby mode or vice versa. SOURCE Press to cycle through the input source in following. MUTE Press to mute the sound. Press again or press V+ to unmated. MENU Brings up the main menu to the screen. -
Page 10: Battery Installation
5.2 Battery Installation a)Open the cover b)A size batteries, When inserting the batteries, make sure correct polarities as per”+“and ”-“marks on the batteries and within the battery compartment c)Replace the battery cover 5.3 Battery Usage Caution To prevent battery leakage which may result in bodily injury or damage to the remote: 1.Install all batteries correctly, and as marked on the remote control. -
Page 11: Configuration Of The Lcd
6. CONFIGURATION OF THE LCD 6.1 Enter picture menu 1. Press MENU key to open the main menu, 2. Press V-/+ to select: 3. Press V- enter setting picture menu, the outline border turns green. 4. Then press to select options in the picture menu 5. -
Page 12: Enter Timer Menu
6.3 Enter Timer menu 1. Press MENU key to open the menu, 2. Press V-/+ in main menu to move menu bar, select 3. Press V- enters other setting menu. 4. Then press to select option in submenu 5. After setting, press MENU to quit. Or wait for several seconds it will be quit automatically. Option: 1. -
Page 13: Troubleshooting And Advice
7. TROUBLESHOOTING AND ADVICE Before calling our SAS centre, please check if you can solve the troubleshooting by yourself. Troubleshooting No signal Please check that all cables and cord's are correctly plugged in. Adjust the contrast, the color and the brightness No color shades May be result from a lighting signal from car, motor, neon light and Stain show on the... -
Page 14: Specifications
8. SPECIFICATIONS Screen Size Display Type Resolution(Pixel) Brightness Color Contrast Ratio Aspect Ratio Power Source Video Input Format Antenna Input Audio Output Video S-Video Input Audio (S-Video/Video/YPbPr/PC) Weight Dimensions (with stand) This manual is only for your reference, any change to the design and specification will not be advised.
