HEAT CONTROLLER, INC.
Wall Mounted
Mini-Split System
Inverter Single-Zone
Air Conditioning/Heat Pump
AS-W093E7Y0 [VMH09SB-1]
AS-W123E7Y0 [VMH12SB-1]
Before servicing the unit, read the
"safety precautions" in this manual.
Only for authorized service personnel.

Advertisement

Table of Contents
loading

Related Manuals for Heat Controller AS-W093E7Y0

Summary of Contents for Heat Controller AS-W093E7Y0

  • Page 1 HEAT CONTROLLER, INC. Wall Mounted Mini-Split System Inverter Single-Zone Air Conditioning/Heat Pump AS-W093E7Y0 [VMH09SB-1] AS-W123E7Y0 [VMH12SB-1] Before servicing the unit, read the “safety precautions” in this manual. Only for authorized service personnel.

  • Page 2: Specification

    1. Specification AS-W093E7Y0 AS-W123E7Y0 Models [VMH09SB-1] [VMH12SB-1] Cooling Capacity 0.90~2.70~3.70 0.90~3.52~4.04 (Min~Rating~Max) Btu/h 3,070~9,200~12,620 3,070~12,000~13,800 Heating Capacity 0.90~3.52~5.00 0.90~4.54~5.49 (Min~Rating~Max) Btu/h 3,070~12,000~17,060 3,070~15,500~18,720 Power Input Cooling/Heating 690/915 1120/1370 Running Current Cooling/Heating 3.2/4.2 5.0/5.9 Starting Current Cooling/Heating 3.2/4.2 5.0/5.9 3.91 3.14 Btu/h.W...

  • Page 3: Piping Diagrams

    2. Piping Diagrams Indoor Unit Outdoor Unit Liquid Side 2-Way Valve Heat Heat Exchanger Exchanger (Evaporator) (Condenser) Gas Side Reversing Valve Accumulator 3-Way Valve Cooling Compressor Heating LOC. Description PCB Connector Thermistor for indoor air temperature CN_TH1(INDOOR) Thermistor for evaporating temperature Thermistor for discharge pipe temperature CN_D_PIPE(Outdoor) Thermistor for condensing temperature...

  • Page 4: Wiring Diagrams

    3. Wiring Diagrams Indoor Unit CN_HUB/UV CN_L/R(BL) CN_L/R(BL) CN_DISP2(BL) CN_12V CN_DISP(WH) CN_MOTOR1 CN_TH1 CN_TH2 - 4 - Copyright ©2008 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 5: Outdoor Unit

    Outdoor Unit CN-TH1 CN-SUMP HEATER CN-D_PIPE CN-FAN2 CN-4WAY CN-TEST CN-PC CN-FLASH CN-D/A CN-EEV - 5 - Copyright ©2008 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...

  • Page 6: Exploded View

    4. Exploded View Indoor Unit 135316 Option Parts 152313 135314 152302 131410 733010 342800 359011 135311 354210 346810 35211B 268711A 135516 147581 352150 Indoor Air, Evaporater 146811 Thermistor 263230A 267110 249951 268711B Note) * Please ensure GCSC since the replacement parts may be changed depending upon the buyer's request. Please check the correct parts in View RPL(Replacement Part List) on GCSC.
  • Page 7 Outdoor Unit 437211 EEV Coil 661400 349480 137213B 435300 137213A 554031 435301 263230D 549610 Outdoor Air, Condenser Thermistor 546810 559010 435511 552200 430960B 649950 55211G 430960A D-pipe Thermistor 447910 268711F 552116 263230E 552202 552560 561410 554160 553000 261704 550140 552203B W49810 552203A Note) * Please ensure GCSC since the replacement parts may be changed depending upon the buyer's request.
  • Page 8 Specifications and performance data subject to change without notice. HEAT CONTROLLER, INC. 1900 WELLWORTH AVENUE • JACKSON, MICHIGAN 49203 THE QUALITY LEADER IN CONDITIONING AIR MFL42286408...
