- Page 1 User’s Manual LoudSpeak’r BTS01 Portable Bluetooth® Speaker...
-
Page 2: Introduction Features
Welcome | Thank you for buying LoudSpeak’r (BTS01) Introduction Features - Bluetooth 2. 1 + EDR - Rechargeable Li-ion battery - Hands free speakerphone with up to 5 hours of calls/ - Wireless range of up to 30 ft.* playback - ProTune Speaker System with - Auxiliary input to play music RealBass Technology... -
Page 3: What's Included
What’s Included Unpack LoudSpeak’r and make sure all accessories are put aside so they will not be lost. Mini USB Cable Portable Speaker Page 3... -
Page 4: Table Of Contents
Content Introduction Features What’s Included Safety Information Important Safety Instructions Getting Started Location of Main Unit Controls Operational Instructions Charging Power Up Using the Audio Line in Connection Pairing Your Bluetooth Device Connecting to a Paired Bluetooth Device Music Playback Functions Hands Free Speakerphone LED Light Indicator Troubleshooting... -
Page 5: Safety Information Important Safety Instructions
Safety Information Important Safety Instructions Please read all safety and operating instructions carefully before installation and use. Keep these instructions handy for future reference. Take special note of all warnings listed in this user’s manual and on LoudSpeak’r. 1. Water and Moisture - LoudSpeak’r should not be used near water. For example: near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. -
Page 6: Getting Started Location Of Main Unit Controls
Getting Started Location of Main Unit Controls Previous track Play/Pause Next track Volume up Power ON/OFF LED indicators Volume down Microphone Stereo speaker Passive radiator subwoofer AUX-in jack USB charging jack switch Page 6... - Page 7 During Bluetooth Music Playback 1. Previous track 2. Play/Pause 3. Next track During Phone Calls 1. and 3. Mute/Unmute the microphone 2. During ringing: Answer incoming call/Reject incoming call (long press) During the call: End current call/Toggle audio between the phone and speaker (long press) General 4.
-
Page 8: Operational Instructions Charging
Operational Instructions Charging - Charge your LoudSpeak’r through any USB jack or wall charger. - The LED indicator will begin to blink blue. - Full charge time is two hours and the LED indicator will stop blinking. Power Up - Slide the switch on the back of the speaker to the ON position. -
Page 9: Pairing Your Bluetooth Device
Operational Instructions Pairing Your Bluetooth Device Note: Please see page 16 of this manual for Bluetooth compatibility information. Step 1: On your Loudspeak’r: - Make sure the speaker is powered off, and the master switch on the rear is in the ON position. -
Page 10: Connecting To A Paired Bluetooth Device
Operational Instructions Connecting to a Paired Bluetooth Device - You will only need to pair your Bluetooth device with the speaker one time. - The next time your Bluetooth device and the speaker are in range of each other, and the Bluetooth feature is turned on, they will automatically connect. -
Page 11: Hands Free Speakerphone
Operational Instructions Hands Free Speakerphone Outgoing calls To place a call, simply initiate the call from your compatible Bluetooth phone and the call will automatically be routed through your paired LoudSpeak’r. Incoming calls - Press to answer the call on your speaker. - Press and hold to reject the call. -
Page 12: Troubleshooting
Troubleshooting Symptom Solution Music is not streaming over Make sure your Bluetooth device has Bluetooth A2DP profile. Check if both devices are paired and connected over Bluetooth. Restart the LoudSpeak’r to auto- connect with your Bluetooth device. No power Make sure LoudSpeak’r is fully charged. -
Page 13: Compliance With Fcc Regulations
Compliance with FCC Regulations Caution! The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 14: Warranty Information Limited Warranty
Warranty Information Limited Warranty The AT&T brands are used under license. Any repair, replacement, or warranty service, and all questions about this product should be directed to Concept 101 LLC at www.att.com/electronics or call 1 (888) 920-8680 from the USA or Canada. - Page 15 Obtaining Service: To obtain service, product literature, supplies or accessories please call 1 888-920-8680, or visit our website, www.att.com/electronics, to create a ticket for exchange/repair. Please make sure to provide the date of purchase, model number and a brief description of the problem.
-
Page 16: Specifications
Specifications - Full-range dual 35mm driver + passive radiator - Distortion <= 10% - Frequency response: 200 Hz - 15k Hz - Li-ion battery: 700mAh - Playtime: up to 5 hours - Charging time: 2 hours - Bluetooth 2. 1 + EDR - Bluetooth compatibility: Bluetooth 2.0 or above device with A2DP/ AVRCP/HFP/HSP * Up to 30 ft. - Page 17 www.att.com/electronics © 2017 Concept 101 LLC. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Concept 101 LLC, New York, New York 10018. D Issue 10.1 AT&T 9/2017. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. iPhone and iPad are registered trademarks of Apple Inc., registered in the U.S.
