SERVICE MANUAL LCD Television
Contents
Safety Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chassis Block Diagrams . . . . . . . . . . . . . . . . . . . . . . 4-5
IC Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
On-screen Service Menu System . . . . . . . . . . . . . . 9-15
Service Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Mechanical Disassembly . . . . . . . . . . . . . . . . . . . . 17-22
Cabinet Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Chassis Electrical Parts List. . . . . . . . . . . . . . . . . . 25-36
Printed Wiring Board . . . . . . . . . . . . . . . . . . . . . . . 37-41
N5CV
FILE NO.
Model No. LCD-42XF4
Service Ref. No. LCD-42XF4-00
Product Code:113011616
Original Version
Chassis Series: UH3-L
Give complete "SERVICE REF. NO." for parts order
or servicing. It is shown on the rating label at the
cabinet back of the unit.
This T.V. receiver will not work properly in for-
eign countries where the television transmis-
sion system and power source differ from the
design specifications. Refer to the specification
table.
(Argentina)
VIDEO MODE
POWER
RECALL DISPLAY MUTE AUDIO MODE
SLEEP
ECO
PIP
CHANGE
MAIN/SUB
BACK
CH
CH
ZOOM SURROUND
BASS SOUND

Advertisement

Table of Contents
loading

Summary of Contents for Sanyo LCD-42XF4

  • Page 1: Table Of Contents

    FILE NO. SERVICE MANUAL LCD Television Model No. LCD-42XF4 (Argentina) Service Ref. No. LCD-42XF4-00 VIDEO MODE POWER RECALL DISPLAY MUTE AUDIO MODE SLEEP CHANGE MAIN/SUB IMAGE BACK ZOOM SURROUND BASS SOUND Contents Product Code:113011616 Original Version Safety Notice ....... . . 2 Specifications .
  • Page 2: Safety Notice

    Safety Notice Safety Precautions The following precautions must be observed. 1: Comply with all caution and safety-related notes provided on the cabinet back, cabinet bottom, inside the cabinet or on the chassis. 2: When replacing a chassis in the cabinet, always be certain that all the protective devices are installed properly, such as, control knobs, adjustment covers or shields, barriers, etc..
  • Page 3: Specifications

    Audio Monitor Output: L/R Stereo Output (RCA jack) x 1 set Headphone Jack : Mini stereo jack x1 Dimensions (W x H x D) Model LCD-42XF4: 1049 x 758 x 270 mm (including stand) Weight (NET) Model LCD-42XF4: < 25.2kg (include stand)
  • Page 4: Chassis Block Diagrams

    Chassis Block Diagram MAIN SIGNAL PROCESSING CIRCUIT...
  • Page 5: Chassis Block Diagrams

    Chassis Block Diagram POWER SUPPLY IC (STRW6753)
  • Page 6: Ic Block Diagrams

    IC Block Diagrams (On the ASSY, PWB, MAIN) IC900 MST6U89DL-LF VDDC MCLKE VDDP MVREF LVA4P UDQM LVA4M LDQM LVA3P DQS[0] LVA3M MDATA[0] LVACKP MDATA[1] LVACKM MDATA[2] LVA2P MDATA[3] LVA2M VDDM LVA1P MDATA[4] LVA1M MDATA[5] LVA0P MDATA[6] LVA0M MDATA[7] VDDP VDDM LVB4P MDATA[8] LVB4M...
  • Page 7 IC Block Diagrams (On the ASSY, PWB, MAIN) IC800 HY5DU281622FTP...
  • Page 8: Ic Block Diagrams

    IC Block Diagrams (On the ASSY, PWB, MAIN) IC403 YDA138A20...
  • Page 9: On-Screen Service Menu System

    On-screen Service Menu System General This set has an On-screen Service Menu System included in the CPU that allows remote operation for most of the service adjustments. On-screen Service Menu System Quick operation is needed to enter Service Mode. How to enter the Service Menu Press and hold the MENU button on Side Controls.
  • Page 10: On-Screen Service Menu System

    On-screen Service Menu System Service Adjustment Data Table Item Name Initial data Description 575i SUB-CONT MST6U89 575i SUB-BRIGHT MST6U89 DVD Input 575i SUB-COLOR MST6U89 Input Video Format: 575i 575i SUB-TINT (Difference) MST6U89 575i SUB-SHARP MST6U89 575p SUB-CONT MST6U89 575p SUB-BRIGHT MST6U89 DVD Input 575p SUB-COLOR MST6U89 Input Video Format:...
  • Page 11 On-screen Service Menu System Description Item Name Initial data 1080P ( 50 ) SUB-SHARP MST6U89 1080P ( 60 )SUB-CONT MST6U89 DVD Input 1080P ( 60 ) SUB-BRIGHT MST6U89 Input Video Format: 1080P(60) 1080P ( 60 ) SUB-COLOR (Difference) MST6U89 1080P ( 60 ) SUB-TINT MST6U89 1080P (...
  • Page 12 On-screen Service Menu System Description Item Name Initial data RFPAL-N SUB-TINT (Difference) MST6U89 RFPAL-N SUB-SHARP MST6U89 RFN SUB-CONT MST6U89 RFN SUB-BRIGHT MST6U89 RFN SUB-COLOR MST6U89 Input Alteration:RF(NTSC) RFN SUB-TINT (Difference) MST6U89 RFN SUB-SHARP MST6U89 RFPAL-M SUB-CONT MST6U89 RFPAL-M SUB-BRIGHT MST6U89 RFPAL-M SUB-COLOR MST6U89 Input Alteration:RF(PAL-M) RFPAL-M SUB-TINT...
  • Page 13 On-screen Service Menu System Description Item Name Initial data White-1080I (60)B MST6U89 DVD Input:1080I (60) Black-1080I (60)R (Difference) MST6U89 Black-1080I (60)G MST6U89 Black-1080I (60)B MST6U89 White-720P50 R MST6U89 White-720P50 G MST6U89 White-720P50 B MST6U89 DVD Input:720P (50) Black-720P50 R (Difference) MST6U89 Black-720P50 G MST6U89...
  • Page 14 On-screen Service Menu System Description Item Name Initial data Black-AVPAL-M G MST6U89 Black-AVPAL-M B MST6U89 White-AVN R MST6U89 White-AVN G MST6U89 White-AVN B MST6U89 VIDEO Input →NTSC Black-AVN R (Difference) MST6U89 Black-AVN G MST6U89 Black-AVN B MST6U89 BASEWhite-AVPAL-N R MST6U89 BASEWhite-AVPAL-N G MST6U89 BASEWhite-AVPAL-N B...
  • Page 15: Service Adjustments

    Service Adjustments CAUTION ! Do not attempt to adjust service adjustments not listed below otherwise it may cause loss of performance and for correct operation. Setting the Initial data This adjustment is controlled by the CPU (IC8000) through the IIC Bus Data Line in the chassis, and those adjustment data are memorized the memory IC (IC8002).
  • Page 16: Mechanical Disassembly

    Mechanical Disassembly [ Disassembly Diagram ] CABINET FRONT MOUNTING PANEL PANEL HOLDER CHASSIS BASE TERMINAL BASE BUTTON UNIT DEC. RC SPEAKER CABINET BACK STAND BASE -16-...
  • Page 17: Mechanical Disassembly

    Mechanical Disassembly 1. Stand Removal Remove 10 screws and remove the Stand. Stand -17-...
  • Page 18 Mechanical Disassembly 2. Cabinet Back Removal Remove 20 screws and take the Cabinet Back off. Note: Cabinet Back can be removed even if it does not remove a stand. -18-...
  • Page 19 Mechanical Disassembly 3. Circuit Board Removal Remove 6 screws and take ASSY, PWB, POWER off. Remove 6 screws on the circuit board and then take ASSY, PWB, MAIN off . ASSY, PWB, MAIN ASSY, PWB, POWER Remove 3 screws and take ASSY, PWB, KEY off . Remove 2 screws and take TERMINAL BOARD off .
  • Page 20: Lcd Panel Removal

    Mechanical Disassembly 4. LCD Panel Removal Remove 5 screws and take HOLDER CHASSIS BASE off. Remove 12 screws and take MTG STAND BRKT off. HOLDER CHASSIS BASE MTG STAND BRKT Remove 16 screws and take HOLDER off, then take PANEL off. HOLDER HOLDER PANEL HOLDER...
  • Page 21: Speaker Removal

    Mechanical Disassembly 5. SPEAKER Removal Remove 8 screws and take SPEAKER off. SPEAKER SPEAKER -21-...
  • Page 22: Cabinet Parts List

    Key No. Part No. Description Key No. Part No. Description 1AA2CAM0609-B CABINET FRONT-N5CV 1LG2BAA0008-- BADGE,SANYO*43.5X10L43.5 1AA2BUM0562-- BUTTON UNIT-N5BP 1AA2SDM0180-- STAND BASE-N5BP 1AA0CBM0040-- ASSY,CABINET BACK-N5CP 1AV0U10B44900 ASSY,REMOCON JXMTL 1AA2RCM0306-- RC-BATTERY LID-JXMTL...
  • Page 23 Oct./2007 NEWSAN S. A. Una empresa del grupo SANYO Electric Co.
  • Page 24: Chassis Electrical Parts List

    Chassis Electrical Parts List Product safety should be considered when a component replacement is made in any area of a receiver. Components indicated by a mark in this parts list and the circuit diagram show components whose value have special significance to product safety. It is particularly recommended that only parts specified on the following parts list be used for components replacement pointed out by the mark.
  • Page 25 Safety Safety Ref. No. Part No. Description Ref. No. Part No. Description C817 CE1C100MKNANG ELECT 10U M 16V C405 CKXAV1C104EAG CERAMIC 0.1U K 16V C817 CE1C100M1WANG ELECT 10U M 16V C405 CKXLB1C104YAG CERAMIC 0.1U K 16V C818 CKXAV1C104EAG CERAMIC 0.1U K 16V C405 CK1C104KGQBNG CERAMIC...
  • Page 26 Safety Safety Ref. No. Part No. Description Ref. No. Part No. Description C841 CKXAV1C104EAG CERAMIC 0.1U K 16V C864 CK1C104KGQBNG CERAMIC 0.1U K 16V C841 CKXLB1C104YAG CERAMIC 0.1U K 16V C865 CE1C100MKNANG ELECT 10U M 16V C841 CK1C104KGQBNG CERAMIC 0.1U K 16V C865 CE1C100M1WANG ELECT 10U M 16V...
  • Page 27 Safety Safety Ref. No. Part No. Ref. No. Part No. Description Description C921 CK1C104KGQBNG CERAMIC 0.1U K 16V D002 DD1SS352----G DIODE 1SS352-(TPH3) C922 CKXAV1C104EAG CERAMIC 0.1U K 16V D100 DD1SS352----G DIODE 1SS352-(TPH3) C922 CKXLB1C104YAG CERAMIC 0.1U K 16V D101 DD1SS352----G DIODE 1SS352-(TPH3) C922 CK1C104KGQBNG CERAMIC...
  • Page 28 Safety Safety Ref. No. Part No. Description Ref. No. Part No. Description RB904 1AV4R1A41014G R-NETWORK 100X4 0.063W L804 1AV4L26B2770G INDUCTOR,220 OHM RB904 1LB4R1YA101JG R-NETWORK 100X4 0.063W L804 1LB4L26B0740G INDUCTOR , 220 OHM RB904 1LB4R1ZA101JG R-NETWORK 100X4 0.063W L805 1AV4L26B2770G INDUCTOR,220 OHM RB905 1AV4R1A41014G R-NETWORK 100X4 0.063W L805 1LB4L26B0740G INDUCTOR , 220 OHM...
  • Page 29 Safety Safety Ref. No. Part No. Description Ref. No. Part No. Description R510 RGF1003JTCANL MT-GLAZE 100K JA 1/10W R049 RGF4702JTCANL MT-GLAZE 47K JA 1/10W R511 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W R050 RGF1002JTCANL MT-GLAZE 10K JA 1/10W R513 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W R051 RGF4702JTCANL MT-GLAZE 47K JA 1/10W...
  • Page 30 Safety Safety Ref. No. Part No. Description Ref. No. Part No. Description R736 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W R931 RGF1000JTCANL MT-GLAZE 100 JA 1/10W R738 RGKR000ZTFANL MT-GLAZE 0.000 ZA 1/3W R932 RGF1000JTCANL MT-GLAZE 100 JA 1/10W R739 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W R935 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W R740 RGF4701JTCANL MT-GLAZE...
  • Page 31 Safety Safety Ref. No. Part No. Description Ref. No. Part No. Description Q1902 TXXLBB006---P TR MMBTSC3928R C6018 CEXLB1V102VDN ELECT 1000U M 35V Q1902 7T200220 TR 2SC2412K(P)-6 C6019 CEXLB1V102VDN ELECT 1000U M 35V R1901 RGF1000JTCANL MT-GLAZE 100 JA 1/10W C602 CKXAA2E471AHN CERAMIC 470P K 250V R1902 RGF2200JTCANL MT-GLAZE...
  • Page 32 Safety Safety Description Ref. No. Part No. Description Ref. No. Part No. L602 1LB4F35B0260N LINE FILTER C643 CCXAV1H561ABG CERAMIC 00056U J 50.0V C643 CC1H561JGQCNG CERAMIC 560P J 50V L606 1LB4L26B0980N INDUCTOR,0.8UH L607 1LB4L26B0980N INDUCTOR,0.8UH C647 CEXLB2W221UFN ELECT 220U M 450V C648 CG2G104KAPANN MT-POLYEST 0.1U K 400V L608...
  • Page 33 Safety Safety Ref. No. Part No. Description Ref. No. Part No. Description R6049 RGF1002JTCANL MT-GLAZE 10K JA 1/10W R658 RCXLBA106KZAN SOLID 10M KA 1/2W R605 RGB4703JTBANL MT-GLAZE 470K JA 1/4W R659 RCA1005KPCANN SOLID 10M KA 1/2W R6050 RGB1002JTBANL MT-GLAZE 10K JA 1/4W R659 RCXLBA106KZAN SOLID 10M KA 1/2W R6059 RGF1002JTCANL...
  • Page 34: Printed Wiring Board

    Printed Wiring Board MAIN BOARD (Parts Side) R890 K405 SC01 R014 L101 A100 R008 C030 C014 C029 R822 C012 R001 C013 IC403 C011 C007 C006 C001 R018 C017 C103 Q101 R105 R106 L809 K503 C111 L100 L102 K500 R032 Q501 R537 R043 C114...
  • Page 35 Printed Wiring Board MAIN BOARD (Solder Side) R891 R888 R011 R889 C023 C024 C022 R012 R015 C010 R005 R007 R006 C015 R016 R013 C106 C100 R009 C104 C101 C102 R100 R101 R102 C020 A100 C021 C019 R010 R800 R883 C831 R999 C819 C822...
  • Page 36 Printed Wiring Board POWER BOARD (Parts Side) L603 L602H1 JP601 L602H2 L603H1 JP604 L603H2 F601 AC250V 5A L602H4 JP602 L602H3 L603H4 JP603 L603H3 J601 R658 D601 Q601 R634 D603 R633 R654 C661 C648 Q602 C660 Q603 C617 R657 J635 D638 L601H10 L601H11 Q606...
  • Page 37 Printed Wiring Board POWER BOARD (Solder Side) JP604 JP601 C610 F601 R602 AC250V 5A C602 J601 JP602 JP603 R658 D603 Q601 D601 R636 R632 R634 D610 R654 R633 R605 C647 R606 R604 C648 R644 C629 C661 C630 R643 R6898 R656 C632 C621 Q603...
  • Page 38: Printed Wiring Board

    Printed Wiring Board KEY BOARD (Parts Side) SW1955 SW1956 SW1950 SW1951 SW1952 SW1953 SW1954 A30C5 U1901 J1902 J1903 1LG4B10Y0170B ??? *** PWB.KEY.N5CV KEY BOARD (Solder Side) R1959 SW1956 SW1952 SW1951 SC003 U1901 SW1950 SW1954 SW1953 D1901 SW1955 J1903 SC001 J1902 1LG4B10Y0170B A30C5 PWB.KEY.N5CV...
  • Page 39 Allowable error (±5%) N: Metalized carbon SERVICE mark. 7. Parts specified with "X" are not installed in this model. LCD-42XF4-00 Kind (M.carbon) S: Oxied metalized 8. Parts specified with "J" are just jumper wires. W: Wire wounding REF. NO.
  • Page 40 R6000 1/10GF470C R6001 1/10GJ4.7KC R6002 C6024 1/10GJ47C R667 16KK0.22LZB C6222 1/10GJ1KC :16KK 0.22GQ R6005 R6006 R6007 1/10GF560C 1/10GJ68C 1/10GZ0C C6025 C6223 P-GND JP6228 IC610 R6008 D650 1/10GJ2.2KC UPC1093J PC123Y52 R6009 K604 1/10GJ2.2KC K603 J10AU025N C653 CL608 250KK470XH CL609 P-GND R6010 CL607 CL606 C652...
  • Page 41 ON/OFF DOWN TV/AV MENU POWER SW DOWN SW1950 R1902 C1903 SW1951 SW1952 SW1953 SW1954 SW1956 1/10GJ220C 6.3KK10MB SW1955 S10B0900J S10B0900J S10B0900J S10B0900J S10B0900J S10B0900J S10B0900J U1901 C1902 U20C11701 6.3KK10MB R1903 1/10GJ220C U1901_GND K19A_7 SC1902 K19A CL1951 CL1952 CL1953 CL1954 CL1955 CL1956 CL1901 B4J10XB070N...
