Model No. PFTL99806.3
Serial No.
Write the serial number in the space
above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT
THE STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form PFTL99806.3

Summary of Contents for Pro-Form PFTL99806.3

  • Page 1 Model No. PFTL99806.3 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete cus- tomer satisfaction. If you have questions, or if parts are missing, PLEASE DO NOT CONTACT THE STORE;...

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    13. To purchase a surge suppressor, see your local PROFORM dealer or call the tele- phone number on the front cover of this man- ual and order part number 146148, or see your local electronics store.
  • Page 4 21. Do not change the incline of the treadmill by placing objects under the treadmill. 22. When folding or moving the treadmill, make sure that the frame is held securely by the pin on the latch knob. 23. Inspect and properly tighten all parts of the treadmill regularly.
  • Page 5 Power Lines Service Entrance Conductors Service Entrance Equipment Power Service Grounding Electrode System (e.g. Interior Metal Water Pipe) WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. Read all instructions before using.

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM PERSPECTIVE ES treadmill. The PERSPECTIVE ES treadmill offers an impressive selection of features de- signed to make your workouts at home more enjoyable and effective. And when you’re not exercising, the...

  • Page 7: Assembly

    This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 8 Star Washers (not shown). Do not tighten the Bolts yet. With the help of a second person, lower the treadmill off the cardboard stand. 3. Identify the Right Upright Sleeve (96) and the Left Upright Sleeve (95). Slide the Right Upright Sleeve onto the Right Upright (74), and slide the Left Upright Sleeve onto the Left Upright (73).
  • Page 9 4. With the help of a second person, hold the con- sole assembly near the Uprights (73, 74). Connect the Upright Wire Harness (75) to the Console Wire Harness (71). See the inset draw- ing. The connectors should slide together easily and snap into place.
  • Page 10 75 ohm terminal (see page 12). 10. Make sure that all parts are properly tightened before you use the treadmill. Keep the included hex key in a secure place; the hex key is used to adjust the walking belt (see page 23). To protect the floor or car- pet from damage, place a mat under the treadmill.
  • Page 11 If you purchase the optional chest pulse sensor (see page 20), follow the steps below to install the re- ceiver included with the chest pulse sensor. 1. Make sure that the power cord is unplugged. Remove the indicated 3/4" Screws (4) from the Pulse Receiver Cover (70) on the back of the Console Assembly (A).
  • Page 12 Before operating the television, you must connect a 75 ohm CATV cable to the 75 ohm terminal on the treadmill, a VCR or DVD player to the audio/video input jack, or a personal audio/video player to the audio/video jack below the television on the console. Note: Use CATV cable to connect to an external source such as a cable box, analog cable, satellite TV box, or VCR.

  • Page 13: Operation And Adjustment

    (see drawing 1 at the right). To purchase a surge suppressor, see your local PROFORM dealer or call the telephone number on the front cover of this manual and order part number 146148, or see your local electronics store.
  • Page 14 Loss programs, seven Aerobic Fitness programs, and seven Performance programs. Each program automati- Clip cally controls the speed and incline of the treadmill as it guides you through an effective workout. Whether you select the manual mode or a preset pro- gram, you can enjoy the shows of your choice on the personal television while you get in shape.
  • Page 15 THE INFORMATION MODE on page 19 to turn off the demo mode. Next, stand on the foot rails of the treadmill. Find the clip attached to the key (see the drawing on page 14) and slide the clip onto the waistband of your clothes.
  • Page 16 Press the Display button repeatedly to select the desired display mode. As you walk or run on the treadmill, the screen can display the following exercise information: • The elapsed time. Note: When a program is se- lected, the screen will show the time remaining in the program instead of the elapsed time.
  • Page 17 When only three seconds remain in the first seg- ment of the program, a series of tones will sound. If the speed and/or the incline of the treadmill is about to change, the new speed setting and/or in- cline setting will appear on the screen to alert you.
  • Page 18 IMPORTANT: Before operating the television, you must connect a 75 ohm CATV cable to the 75 ohm terminal on the treadmill, a VCR or DVD player to the three audio/video RCA jacks, or a personal audio/video player to the audio/video jack below the television on the console.
  • Page 19 The console features a display demo mode, de- signed to be used if the treadmill is displayed in a store. While the demo mode is turned on, the con- sole will function normally when you plug in the power cord, switch the circuit breaker to the reset position, and insert the key into the console.
  • Page 20 THE OPTIONAL CHEST PULSE SENSOR An optional chest pulse sensor offers hands-free oper- ation as it monitors your heart rate during your work- outs. To purchase the optional chest pulse sensor, call the toll-free telephone number on the front cover of this manual.

  • Page 21: How To Fold And Move The Treadmill

    HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. Pivot the frame downward and release the latch knob. Note: To release the latch knob, it may be necessary to push the frame forward as you pull the latch knob to the left.

  • Page 22: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 23 Be careful to keep the walking belt centered. Then, plug in the power cord, insert the key, and run the treadmill for a few min- utes. Repeat until the walking belt is properly tight- ened.
  • Page 24 PROBLEM: The console displays remain lit when you remove the key from the console SOLUTION: a. The console features a display demo mode, designed to be used if the treadmill is displayed in a store. If the displays remain lit when you remove the key, the demo mode is turned on. To turn off the demo mode, hold down the Stop button for a few seconds.

  • Page 25: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Before beginning any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings.

  • Page 26: Part List

    PART LIST—Model No. PFTL99806.3 To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Foot Rail Cover Left Foot Rail Isolator Screw 3/4" Screw Ground Wire Screw Walking Platform...
  • Page 27 Key No. Qty. Description Handrail Latch Assembly Latch Warning Decal AV Wire Nut Filter Wire Right Grip Rear Roller Washer Incline/Controller Wire Incline Stop Bracket Stop Bracket Spacer Right Foot Rail Pulse Plate TV Cable Nut TV Cable Star Washer Key No.

  • Page 30: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
