  • Page 1 Rev. 1809171208 Part No. 161500-18-007 Copyright 2017 Winnebago Industries, Inc. All rights reserved.
  • Page 3 TABLE OF CONTENTS 1 – INTRODUCTION About this Manual ..........................1-1 Safety Messages Used in this Manual ....................1-1 Pre-Delivery Inspection ........................1-2 Before Driving ..........................1-2 Front Axle Tire Alignment ....................... 1-2 Service and Assistance ........................1-2 Reporting Safety Defects ........................1-2 Occupant and Cargo Carrying Capacity Label .................
  • Page 4 Table Of Contents Child Restraints ..........................3-2 Keys ..............................3-3 Remote Keyless Entry ........................3-3 Hazard Warning Flashers ........................3-4 Air Conditioner/Heater – Automotive (Dash) .................. 3-4 Collision Avoidance System ......................3-4 Radio In-Dash/Rearview Monitor System ..................3-4 Infotainment Center/GPS ........................3-6 Battery Boost Switch ........................
  • Page 5 Table Of Contents Electrical Generator – 120-Volt ......................6-5 Electrical System – House 12-Volt DC .................... 6-7 House/Coach Battery Disconnect Switch ..................6-8 Battery Access ..........................6-8 Battery Care ............................6-9 Circuit Breakers and Fuses – House 12-Volt DC ................6-11 7 –...
  • Page 6 Table Of Contents Murphy Bed ............................9-9 Dining Table ........................... 9-10 Flex Bed ............................9-11 Bed – Adjustable ..........................9-12 Roller Shades (Manual) – Solar/Blackout ..................9-12 Wood Furniture and Cabinetry ....................... 9-13 10 – SLIDEOUT ROOMS Slideout Room Lock System ......................10-1 Slideout Room Operation –...
  • Page 7 Table Of Contents Windows ............................12-7 Skylight Vent ..........................12-8 Power Roof Ventilator ........................12-9 Power Roof Ventilator ........................12-10 Storage Compartment Doors ......................12-10 Roof Ladder ..........................12-11 Awning – Power ........................... 12-11 Bike Rack ............................12-12 Effects of Prolonged Occupancy ....................12-12...

  • Page 9: About This Manual

    The instructions included in this manual are intended as a guide, and in no way DANGER indicates a hazardous situation extend the responsibilities of Winnebago which, if not avoided, will result in death or Industries beyond the standard written serious personal injury.

  • Page 10: Pre-Delivery Inspection

    National Highway Traffic Safety Administration any problems before delivery. (NHTSA) in addition to notifying Winnebago Industries, Inc. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety...

  • Page 11: Occupant And Cargo Carrying Capacity Label

    INTRODUCTION a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or Winnebago Industries, Inc. To contact NHTSA, you may either call the Vehicle Safety Hotline toll-free at: 1-888-327-4236; (TTY: 1-800-424-9153) or go to http://www.safercar.gov...

  • Page 12: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.

  • Page 13: Specifications And Capacities

    ( 26.4 gal.) Notes: All information is based upon the most recent data available. Visit the Winnebago Industries, Inc. web page – www.winnebagoind.com – for the most current product information. The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit.

  • Page 14: Owner And Vehicle Information

    Motorhome Serial Number ___________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 15: General Warnings

    SECTION 2 – SAFETY AND PRECAUTIONS GENERAL WARNINGS DRIVING SAFETY • Only seats equipped with seat belts are to be occupied while the vehicle is moving. WARNING • Make sure all passengers have seat belts fastened. Lap belts should fit low on the hips and upper thighs.

  • Page 16: Fuel And Propane Gas

    SECTION 2 – SAFETY AND PRECAUTIONS • Do not adjust tilt steering in a moving vehicle. • Do not operate the cruise control on icy or WARNING extremely wet roads, winding roads, in heavy traffic, or in any other traffic situation where a constant speed cannot be maintained.

  • Page 17: Propane Gas Leaks

    SECTION 2 – SAFETY AND PRECAUTIONS • Portable fuel-burning equipment, including asphyxiation is greater when the appliance is wood and charcoal grills and stoves shall not used for long periods of time. Failure to comply be used inside the recreational vehicle. The could result in death or serious injury.

  • Page 18: Carbon Monoxide Warning

    RV application. We fuel. It will detect CO gas from any combustion recommend obtaining a replacement from your ® Winnebago Industries dealer.

  • Page 19: Smoke Alarm

    RV application. We that is also listed for RV application. We recommend obtaining a replacement from your recommend obtaining a replacement from your ® Winnebago Industries dealer. ® Winnebago Industries dealer. Further Information...

  • Page 20: Fire Extinguisher

    Extinguisher, the replacement must be the same type and size as the one originally supplied in your coach. We recommend obtaining a replacement only from your Winnebago ® Industries dealer or a reliable RV parts supplier.

  • Page 21: Maintenance

    SECTION 2 – SAFETY AND PRECAUTIONS MAINTENANCE • Do not remove the radiator cap while engine and radiator are still hot. Always check coolant level visually at the see-through coolant reservoir. Escape Window • Never get beneath a vehicle that is held up by (Lift both red safety latch handles UP a jack only.

  • Page 22: Slideout Rooms

    SECTION 2 – SAFETY AND PRECAUTIONS To open, release all four latches and push window out. 1. Side Latches (2) - Pull down toward bottom of window frame. 2. Bottom Latches (2) - Pull toward the left-hand side of the window frame. 3.

  • Page 23: Formaldehyde Information

    SECTION 2 – SAFETY AND PRECAUTIONS WARNING WARNING This vehicle, like other vehicles, may Keep all persons clear of the slideout contain small amounts of one or more room and moving parts while extending or substances which are listed by the state retracting.

  • Page 24: Roof And Ladders

    This • Never ignore warning labels or weight limits is the extent of coverage provided by Winnebago defined on your ladder. The following Industries. Winnebago Industries, however, will warning label is located on or near the ladder:...

  • Page 25: Roadside Emergency

    DO NOT stomp on the brake. This abruptly proper towing equipment to use. shifts the vehicle’s weight forward, making it ® Winnebago Industries does not assume nose-dive and pull toward the blown-out side. responsibility for damage incurred while towing •...

  • Page 26: Wheel Mounting Nuts (Lug Nuts)

    SECTION 2 – SAFETY AND PRECAUTIONS NOTICE Do not lift on bumper. Damage will result to front end body parts. Steel Wheel Lug Nut and Washer WARNING (Hex Flange Nut with Split Cone Washer) Stay out from beneath the motorhome WHEEL TRIM –...

  • Page 27: Wheels – Stylized Polished

    SECTION 2 – SAFETY AND PRECAUTIONS When re-installing the front liner, make sure to align the stem clearance notch on the back of the liner with the valve stem. WARNING If the notch is not aligned with the valve stem, the valve stem may be damaged which could deflate the tire causing steering or handling problems.
  • Page 28 SECTION 2 – SAFETY AND PRECAUTIONS 2. Slide the lug wrench onto the adapter and Chrome Lug Nut rotate counter-clockwise to loosen the lug Chrome Washer nuts. Note: Do not place the wheel nuts in sand or dirt. The threads of the wheel bolts and wheel nuts could be otherwise damaged when being installed.

  • Page 29: Wheels – Stylized Aluminum

    SECTION 2 – SAFETY AND PRECAUTIONS • Once the vehicle is prepared for stylized wheel installation, use the chrome washer, chrome lug nut, and chrome adapter with lug wrench to re-install the stylized chrome wheel. Stylized Aluminum Wheel Note: Reference the chassis manufacturer’s user guide provided in your InfoCase for complete instructions and cautions on changing a wheel.

  • Page 30: Jump Starting

    SECTION 2 – SAFETY AND PRECAUTIONS WARNING DO NOT operate the vehicle with less than all 6 nuts installed and properly torqued. JUMP STARTING If your coach will not start from the chassis battery, try using the Battery Boost switch to divert power from the house batteries to the starter.

  • Page 31: Seats – Driver/Co-Pilot

    Winnebago damaged by pinching them in the doors or in the ®...

  • Page 32: Child Restraints

    SECTION 3 – DRIVING YOUR MOTORHOME accident if they are seated in a child restraint system which is not properly secured. Children are always safer in the rear seats (behind the cab WARNING area). A child restraint system is designed to be Snug and low belt positions are essential.

  • Page 33: Keys

    SECTION 3 – DRIVING YOUR MOTORHOME Tether Anchor Loop (Located on floor directly behind the 1. Lower the dinette table. forward facing dinette seat) 2. Hook the Tether to the Anchor Loop. Pull tether strap to tighten. 3. Fasten the lap belt and pull snug. -Typical View, (Your coach may differ in appearance) Further Information...

  • Page 34: Hazard Warning Flashers

    SECTION 3 – DRIVING YOUR MOTORHOME Make a habit of having the keys with you • Vehicle and Motorcycle Forward Collision when you exit the vehicle and if opening the cab Warning - Displays only when a vehicle in door first before opening the entry door the same lane is detected.

  • Page 35: Driving Your Motorhome

    SECTION 3 – DRIVING YOUR MOTORHOME Satellite Radio NOTE: The camera polarity setting needs to be set to “Battery” for automatic camera –If Equipped viewing when the vehicle is put into Your coach may be equipped with a reverse. The “Camera Polarity” setting ®...

  • Page 36: Infotainment Center/Gps

    SECTION 3 – DRIVING YOUR MOTORHOME • Bluetooth Microphone • IR Receiver • MENU - press to go to main menu • NAVI - press to access navigation system • DIM - press to adjust screen brightness • FAV - press to directly Radio Power Switch access favorite audio (Located on lower dash area)

  • Page 37: Battery Boost Switch

    SECTION 3 – DRIVING YOUR MOTORHOME Radio Power Switch See the receiver manufacturer’s information in your InfoCase for programming and operating The Radio Power switch lets you connect the instructions. dash radio to the coach batteries with the ignition switch turned off for listening while parked. This GPS (Navigation) SD prevents accidental draining of the chassis Card Reader...

  • Page 38: Engine Cooling System

    SECTION 3 – DRIVING YOUR MOTORHOME Battery Boost Switch (Located on lower driver side dash) • Press and Hold in while turning ignition key for emergency starting power. Diesel Exhaust Fluid Fill (Located under front hood) -Typical installation shown ENGINE COOLING SYSTEM Do not remove the radiator cap while engine Further Information and radiator are still hot.

  • Page 39: Valve Stem Access

    SECTION 3 – DRIVING YOUR MOTORHOME VALVE STEM ACCESS ® (Mercedes-Benz Sprinter Chassis) Front Wheel Valve Stem Access on 18-Hole Steel Wheel with Push-On Full Wheel Trim –If Equipped 1. Obtain a double angle push/pull truck tire gauge. 6. When tire pressure testing is complete, reinstall the valve stem cap (with the cap still retained in the cap tool end).
  • Page 40 SECTION 3 – DRIVING YOUR MOTORHOME NOTE: If the valve stem cap and valve stem extension unscrew as an assembly, pull Inner the assembly out of the cap tool end, rear remove valve stem cap, insert valve stem dual extension into cap tool, and reinstall Tool valve stem extension onto valve stem until snug.

  • Page 41: Tires

    SECTION 3 – DRIVING YOUR MOTORHOME checked and adjusted after you have fully loaded the motorhome according to your personal needs. Thereafter, the alignment should be periodically inspected to help prevent uneven tire wear. Any excessive or abnormal tire wear may indicate worn or misaligned suspension or steering, unbalanced tire, or other tire/suspension problem.

  • Page 43: Refrigerator

    SECTION 4 – APPLIANCES AND SYSTEMS Switch on the Refrigerator The appliances installed in your motorhome are manufactured by reputable RV appliance When you start up the refrigerator, turn the makers and have been tested by independent thermostat to the 5 position. Allow the laboratories to meet all applicable standards and refrigerator to cool down to temperature before codes set for RV appliances.

  • Page 44: Microwave/Convection Oven

    SECTION 4 – APPLIANCES AND SYSTEMS To Light Range Top Burners Unlike homes, the amount of oxygen supply is limited due to the size of the recreational vehicle, • Push in desired control knob and turn to and proper ventilation when using the cooking IGNITE position - and maintaining the knob appliances avoids dangers of asphyxiation.

  • Page 45: Oneplace® Systems Monitor Panel

    SECTION 4 – APPLIANCES AND SYSTEMS Water And Holding Tank Levels Press the Tank Levels switch to show NOTICE approximate levels on the LCD screen. Do not store items in oven. If oven would turn on stored items can ignite resulting in fire and or property damage.

  • Page 46: Solar Charge Panel

    SECTION 4 – APPLIANCES AND SYSTEMS Battery Charge Meter Press the Battery Levels switch to check the level of charge (voltage) in the chassis and house batteries. Water Pump Switch Refer to Section 7 - Plumbing for additional information on the water pump and initial start- Battery Levels Switch NOTE: Some models may be equipped with a To get an accurate reading:...
  • Page 47 SECTION 4 – APPLIANCES AND SYSTEMS separate solar charge controller is not needed and will reduce the effectiveness of the portable solar panel. Solar Charge Controller (Located near monitor panel) -Typical View Single Solar Port 3-Port Solar Cap (Located inside rear driver side exterior compartment) The Port Solar Cap (located on the roof) is intended to make it easy to add additional solar...

  • Page 48: Water Heater – Gas/ Electric

    SECTION 4 – APPLIANCES AND SYSTEMS For Electric Operation WATER HEATER – GAS/ Press the Water Heater Electric switch to ON. ELECTRIC The shoreline must be connected or generator –If Equipped running for electric operation. The Gas/Electric Water Heater has a dual power feature.
  • Page 49 SECTION 4 – APPLIANCES AND SYSTEMS warnings, decalcification instructions, and • Rotary Switch maintenance information before operating the • ECO Water Heater. 1. Be sure the Water Heater is filled with • Comfort water before starting the Water Heater. To fill the Water Heater, turn the Water Pump •...

  • Page 50: Pressure-Temperature Relief Valve

    SECTION 4 – APPLIANCES AND SYSTEMS Decalcification Lime scale occurs especially as a result of CAUTION precipitation from “hard” water. The appliance must be decalcified regularly depending on water hardness and hot water consumption. Hot water can escape from tank causing See the Water Heater manufacturer’s injury.

  • Page 51: Furnace – Propane Gas

    SECTION 4 – APPLIANCES AND SYSTEMS 4. After approximately 30 seconds, the furnace FURNACE – PROPANE GAS burner should light. –If Equipped 5. The furnace should now cycle off and on automatically as the thermostat demands just To Start Up like a household furnace.

  • Page 52: Heat Pump

    SECTION 4 – APPLIANCES AND SYSTEMS HEAT PUMP –If Equipped Your coach may be equipped with an air source Heat Pump built into the air conditioning system. Because the Heat Pump operates on electricity, it provides economical heat inside your coach and helps reduce the use of propane gas for heating in cooler weather.

  • Page 53: Air Conditioner Filter

    SECTION 4 – APPLIANCES AND SYSTEMS cause the air conditioner unit to shut down, particularly in high humidity conditions. Further Information Refer to the manufacturer’s user guide provided in your InfoCase for complete operating instructions. AIR CONDITIONER FILTER The washable foam air conditioner filter is located in the ceiling-mounted return A/C grille in the lounge area of the coach.

  • Page 55: Propane Gas Supply

    SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY Remote Tank Gauge & Tank Fill Overflow The propane gas system supplies fuel for the Sender Port Port gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.
  • Page 56 SECTION 5 – PROPANE GAS • Main Tank • Overflow Shutoff Switch Valve Main Tank Shutoff Switch (Located in driver side compartment) • Propane Tank Fill Valve -Typical View Propane Gas Access NOTE: Both switches must be ON to allow (Located in driver side compartment) -Typical View propane supply to the coach.

  • Page 57: Safe Use Of The Propane Gas System

    SECTION 5 – PROPANE GAS run on propane only, we recommend that you request straight propane only. DAN GE R Butane burns about 30 percent hotter than propane and can overheat some appliances, particularly refrigerators, All pilot lights, appliances, and their and cause permanent damage.

  • Page 58: Propane Gas Warnings And Precautions

    SECTION 5 – PROPANE GAS system components should be performed only by your dealer or a qualified propane gas DAN GE R service center. • Never attempt to connect natural gas to the propane gas system. IF YOU SMELL PROPANE •...

  • Page 59: Propane Gas Pressure Regulator

    SECTION 5 – PROPANE GAS • Never use an open flame to test for propane gas leaks. Replace all protective covers and Primary caps on propane system after filling. Make 30 PSI sure valve is closed and door latched securely. Pressure Regulator •...

  • Page 60: Propane Vaporization In Cold Weather

    SECTION 5 – PROPANE GAS Regulator Freeze-up Adjusting the temperature on the gas/electric refrigerator may be a first step. Using less hot Regulator freeze-ups are caused by the water will also help, as well as refraining from presence of moisture in fuel. This moisture will using the gas cooktop.

  • Page 61: Electrical Cautions

    SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motorhome that is • 12-volt DC system (battery current);...
  • Page 62 SECTION 6 – ELECTRICAL 30 Amp Receptacle WARNING • Swivel cover section to access cord notch This connection is for 110/125 Volt AC, 60 Hz 30 Ampere supply. Do not exceed circuit rating. Exceeding the circuit rating may cause a fire and result in death or serious injury.

  • Page 63: Inverter Unit – 1000W

    SECTION 6 – ELECTRICAL INVERTER UNIT – 1000W NOTICE –If Equipped The inverter changes 12-volt DC battery power into 120-volt AC power for use by 120- Do not store items around the inverter volt AC equipment inside the coach. The inverter unit.

  • Page 64: Converter

    SECTION 6 – ELECTRICAL Thermal Overload CONVERTER A thermal overload will “break” the 120-volt The power converter changes 120-volt AC AC power to the converter section of the power current from the auxiliary generator or the center if the power converter becomes shoreline into 12-volt DC current for use by 12- overheated.

  • Page 65: Electrical Outlets – House 120-Volt Ac

    SECTION 6 – ELECTRICAL • Push to Reset circuit after monthly testing or ground fault tripping. • Push to Test at least monthly. 120-Volt Circuit Breakers Should break circuit. Press -Typical View Reset button to reconnect. NOTE: Typical view of breaker panel. Breaker arrangement may vary according to GFCI Outlet (Ground Fault Protector)

  • Page 66: Generator Hourmeter

    SECTION 6 – ELECTRICAL LP Generator Start/Stop Buttons (Located on monitor panel) Generator Power Cord -Typical View Receptacle Generator Hourmeter The Generator hourmeter registers the total number of hours that the Generator has been WARNING operated. Press the GenSet Meter button once to get reading.

  • Page 67: Electrical System – House 12-Volt Dc

    SECTION 6 – ELECTRICAL To Stop the Generator • Park the vehicle so that the wind will carry the exhaust away from the vehicle. Also, note the • Press the Display ON/Gen OFF button. position of other vehicles to be sure their exhaust will not enter your vehicle.

  • Page 68: House/Coach Battery Disconnect Switch

    SECTION 6 – ELECTRICAL The house batteries supply power to 12-volt equipment located in the living area of the motorhome. This includes the following 12-volt powered components (if equipped): interior 12- volt lighting, range exhaust fan, propane furnace fan, fresh water pump, systems monitor panel, refrigerator, roof vent fans, and 120-volt electrical generator starter.

  • Page 69: Battery Care

    SECTION 6 – ELECTRICAL House Batteries Chassis Battery Connector (Located to the right of the accelerator pedal) CAUTION Further Information Step cover must be closed and latched. See the chassis manual provided in your Failure can cause injury. InfoCase for details on access and servicing. Chassis Battery NOTICE The chassis (starting) battery is located in a...
  • Page 70 SECTION 6 – ELECTRICAL The two best defenses against sulfating Further precautions are: and insufficient charge are to: • Check the state of charge periodically to avoid discharge or sulfating. 1. Turn off the House/Coach Battery Disconnect switch to avoid parasitic discharge (the trickle To ensure that the battery will always accept discharge caused by directly connected and hold a charge, follow these simple...

  • Page 71: Circuit Breakers And Fuses – House 12-Volt Dc

    Chassis Battery If your coach is going to be unoccupied for ® two weeks or more, Winnebago Industries recommends disconnecting the chassis battery in your coach to avoid battery discharge. Unplug the Chassis Battery Connector Functional...
  • Page 72 SECTION 6 – ELECTRICAL Automotive Chassis 12-Volt Circuit Breakers (Located on outboard side of passenger seat) * Shown with cover removed -Typical View 6-12...

  • Page 73: Fresh Water System

    SECTION 7 – PLUMBING Always fill the fresh water tank at an approved FRESH WATER SYSTEM potable water filling facility or a known purified drinking water source. The Fresh Water System provides water to the galley sink, shower, bathroom lavatory, toilet, The tank is filled through the City Water and water heater.
  • Page 74 SECTION 7 – PLUMBING 7. Turn the Fresh Water valve to Normal position to use the water pump. The Tank Fill position is only for pressure filling the water tank from the city water hose connection. Water Tank Gravity Fill -Typical View 3.

  • Page 75: Water Pump

    SECTION 7 – PLUMBING • Disconnect hose from the coach and replace • Insert hose into fill opening and turn water cap on the Fresh Water Inlet. supply on. Tank is full when water flows from the tank vent tube beneath coach and out of the NOTE: Ensure the Fresh Water valve is in Gravity Fill door.

  • Page 76: Water Pump Switch

    SECTION 7 – PLUMBING 2. Turn Water Pump switch to “OFF” position. 3. Fill water tank. 4. Open all faucets, hot and cold. 5. Turn ON the Water Pump switch. 6. Close each faucet as it begins to deliver a steady stream of water (close cold water first).

  • Page 77: Cold Water Filter

    SECTION 7 – PLUMBING COLD WATER FILTER –If Equipped To obtain filtered cold water for drinking or cooking, simply open the galley sink cold water faucet. NOTE: Only the galley cold water faucet is filtered. The cold waterline flows through an activated carbon filter that removes chlorine and odors for Water Pump taste-free drinking water.

  • Page 78: Disinfecting Your Fresh Water System

    SECTION 7 – PLUMBING 4. Let the system stand at least 4 hours when DISINFECTING YOUR FRESH disinfecting with 50 ppm residual chlorine. (If WATER SYSTEM a shorter time period is desired, then a 100 ppm chlorine concentration should be ®...
  • Page 79 SECTION 7 – PLUMBING detected in the water discharged. Do not forget the hot water faucets. (You may need to leave a hot water faucet WARNING open for some time to flush the water heater with clean water. You may also want to turn Chlorine is poisonous.

  • Page 80: Shower Hose Vacuum Breaker

    SECTION 7 – PLUMBING SHOWER HOSE VACUUM TOILET BREAKER –If Equipped The toilet in your motorhome is very similar After using the shower, you may notice water to the household type, except that it is designed to dripping from the shower faucet assembly. The use only a small amount of water per flush.

  • Page 81: Drainage System (P-Traps)

    SECTION 7 – PLUMBING See winterizing instructions at the end of this Water Saver Flush Normal Flush section to prepare the toilet for storage in freezing conditions. Further Information See the toilet manufacturer’s operation information provided in your InfoCase for complete operating, care, and maintenance information.
  • Page 82 SECTION 7 – PLUMBING NOTE: DO NOT OPEN BOTH VALVES AT ONCE. Do not open the Gray Waste Tank Drain valve until the black tank is drained and dump valve closed to avoid sewage back-up into gray tank. Gray water also rinses any black water solids from the drain hose.

  • Page 83: Waste Water System (Waste Pump)

    SECTION 7 – PLUMBING 3. Attach a garden hose from a city water tank about half full with water, and drive a few hydrant to the Black Waste Tank Flush Inlet miles to dislodge the solids. A few starts and fitting on the left sidewall.

  • Page 84: Dumping Holding Tanks

    SECTION 7 – PLUMBING 2. Remove dust cap from sewage drain outlet and connect sewage drain hose. Be sure it is firmly attached. Waste Pump (Located behind water service center - accessible through utility compartment) -Typical View Sewage Drain Outlet/Dust Cap (Located in driver side compartment) NOTE: If Waste Pump stalls, check breaker in -Typical View...
  • Page 85 SECTION 7 – PLUMBING NOTE: DO NOT OPEN BOTH VALVES AT ONCE. Do not open the Gray Waste Tank Drain valve until the black tank is drained and Black Waste Tank Drain valve is closed to avoid sewage back-up into gray tank. Gray water also rinses any black water solids from the sewage drain hose.

  • Page 86: Holding Tank Heater

    SECTION 7 – PLUMBING 2. Leave Black Waste Tank Drain valve open leaving solids in the tank. Should this while flushing tank. accidentally happen, disconnect the hose, fill the tank about half full with water, and drive a few 3. Attach a garden hose from a city water miles to dislodge the solids.

  • Page 87: Waterline & Water Tank Drain Valves

    SECTION 7 – PLUMBING engine must be running (such as when driving down the road). This will prevent excessive Water Tank Drain Valve discharge of the house battery. NOTE: The holding tank heater pads are electrical resistant-type heating elements. This type of heating element typically uses a large amount of current while operating.

  • Page 88: Winterizing Procedures

    SECTION 7 – PLUMBING water inlet and gently press the backflow valve “button” in the center of the inlet to CAUTION drain any water trapped in the inlet line. Leave bypass valve handle in NORMAL FLOW position if draining water and blowing out waterlines.
  • Page 89 SECTION 7 – PLUMBING base of the water heater tank, accessible from the outside of the coach (requires socket and ratchet). Water Heater Drain Plug Water Heater Power Switch (Remove with socket) (Located behind water heater access panel on exterior of coach) •...
  • Page 90 Turn Winterization Valve 3 from “Normal” the system. A “blow-out” plug can be position to “Line Drain” position to blow out ® purchased at any Winnebago Industries the hot water recirculation line. Leave in this dealer. position until all water has been drained below the coach.
  • Page 91 SECTION 7 – PLUMBING After Disconnecting Air Pressure Method 2 – Antifreeze Fill 11. If Equipped with Cold Water Filter: Empty Procedure the cold water filtration canister of any water trapped during the blow-out procedure. (Fill plumbing lines with RV water system Remount empty canister on to filter assembly.
  • Page 92 SECTION 7 – PLUMBING 2. Drain Fresh Water Tank and Waterlines. Open all waterline drain valves and drain fresh water tank. (See “Water System Drain Valve Locations” chart at the end of this section for locations of drain valves on your model).
  • Page 93 SECTION 7 – PLUMBING Set Up Winterization Valves If your coach is equipped with the Tankless Water Heater, skip step 5 and proceed to step 6. See “Water System Drain Valve Locations” chart at the end of this section for location of bypass valve on your model.
  • Page 94 SECTION 7 – PLUMBING Refer to the “Water System Drain Valve 16. Replace the protective cap onto the end of the Locations” chart at the end of this antifreeze siphon tube to keep out insects or section for valve locations on your debris when not in use.

  • Page 95: Water System Drain Valve Locations

    SECTION 7 – PLUMBING 6. If no antifreeze is visible at the drain outlet, add 1 to 2 additional gallons to the shower or galley sink drain and repeat step 4. WATER SYSTEM DRAIN VALVE LOCATIONS Model System Drain Valve Locations Waterlines •...
  • Page 96 SECTION 7 – PLUMBING Waterlines • Two (2) valves located in water service center. Water Tank • One (1) valve located in water service center. Water Heater • Water Heater with Tank - Drain plug on outside of coach behind service door. Use socket to remove drain plug. •...

  • Page 97: Audio/Video System Basic Operation

    SECTION 8 – ENTERTAINMENT • Press the MODE button on the TV or the AUDIO/VIDEO SYSTEM BASIC SOURCE button on the remote to select OPERATION “INPUT 2”. • The TV screen will NOTE: For your convenience, we have also display the DVD player included a handy, tear-out version of this logo when the correct “A/V System Basic Operation”...

  • Page 98: Dvd Player With Deluxe Sound

    SECTION 8 – ENTERTAINMENT 4. Select TV channels and adjust volume using • The TV screen will the TV remote. display the DVD player logo when the correct Further Information input is selected. See the manufacturer’s quick reference guide Play DVD provided in your InfoCase for complete feature descriptions and operating instructions.

  • Page 99: Dvd Player With Deluxe Sound

    SECTION 8 – ENTERTAINMENT Further Information • The DVD may load directly to the main title/menu screen or it may begin to play See the manufacturer’s quick reference guide previews. You may be able to skip previews if provided in your InfoCase for complete feature desired by pressing the NEXT button on the descriptions and operating instructions.

  • Page 100: Exterior Speakers

    SECTION 8 – ENTERTAINMENT TV Sound through Deluxe Sound The DVD player is a selectable function of the multi-featured audio system. The player unit Speakers contains many features including: DVD/CD/ –If Equipped MP3 player, AM/FM tuner, USB, Bluetooth, and When watching TV programs alone, the TV Weatherband with weather alert.

  • Page 101: Tv Antenna – Digital

    SECTION 8 – ENTERTAINMENT Further Information • Signal Meter See the stereo radio information provided in • Attenuator Dial Power Switch your InfoCase for complete operating instructions. TV ANTENNA – DIGITAL ® (Jack Digital HDTV Over-the-Air Antenna) –If Equipped Your coach is featured with a digital antenna, which provides crystal clear digital HD reception of over-the-air channels in addition to superior broad reception range.

  • Page 102: Tv Signal Amplifier

    SATELLITE DISH AND CABLE cabinet in the bedroom for the rear TV (if TV CONNECTIONS (INPUT) equipped). ® See your authorized Winnebago Industries –If Equipped dealer for proper installation and sealing of roof The portable satellite dish and cable television mounted components.

  • Page 103: Cab Seat Lounge Cushion

    SECTION 9 – FURNITURE AND SOFTGOODS CAB SEAT LOUNGE CUSHION –If Equipped (Typical View – Your coach may differ in appearance) The driver and co-pilot seats may feature a Lounge Seat Cushion which provides increased seat height and added comfort while in the lounge seating position.

  • Page 104: Bunk Ladder

    SECTION 9 – FURNITURE AND SOFTGOODS WARNING Do not exceed 225 lbs. maximum weight capacity. Misuse of ladder could result in death or serious injury. See Operators Manual before using ladder. • Maximum Capacity: 225 lbs. • Do not overload. Ladder is intended for one person.

  • Page 105: U-Shaped Dinette With Flip-Up Footrests

    SECTION 9 – FURNITURE AND SOFTGOODS U-SHAPED DINETTE WITH FLIP-UP FOOTRESTS –If Equipped (Typical View – Your coach may differ in appearance) Flip-Up Footrests NOTE: Ensure top of ladder is properly engaged onto retainer brackets and ladder is resting firmly on floor before using. 1.
  • Page 106 SECTION 9 – FURNITURE AND SOFTGOODS 2. To Store: Pull footrest all the way up until the 2. Pull the table leg tube from the table socket locking arms release and lower into stored and store beneath dinette seat. position. •...

  • Page 107: Dinette/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS Once the table is reattached to the table leg 3. Release the table leg from the floor support tube, tighten the handle completely then back off bracket. approximately 1/2 turn. Periodically repeat this adjustment procedure to ensure that it is properly adjusted.

  • Page 108: Dining Table

    SECTION 9 – FURNITURE AND SOFTGOODS 6. Then lower the table to rest on the cleats DINING TABLE attached to each dinette bench. Lower dinette seat cushions. –If Equipped (Typical View – Your coach may differ in appearance) • Remove one (1) dining table from storage compartment in passenger side bed cabinet.

  • Page 109: Sofa/Sleeper

    SECTION 9 – FURNITURE AND SOFTGOODS 3. Pull sofa support back in downward motion. SOFA/SLEEPER –If Equipped (Typical View – Your coach may differ in appearance) WARNING Stow sofa extensions before retracting slide rooms. Failure to observe can cause injury and will cause equipment damage. 4.

  • Page 110: Extendable Sectional – L-Shaped Dinette

    SECTION 9 – FURNITURE AND SOFTGOODS 3. Remove seat cushion from sectional EXTENDABLE SECTIONAL – extension by using the provided pull strap L-SHAPED DINETTE (located on the back side of the seat cushion). –If Equipped (Typical View – Your coach may differ in appearance) Dinette Conversion 1.

  • Page 111: Murphy Bed

    SECTION 9 – FURNITURE AND SOFTGOODS 5. Install seat back cushion (stored beneath front dinette cushion). Seat Back Cushion Storage Location 9. Reverse steps to store dinette. 6. Remove dinette table and pedestal leg from rear wardrobe cabinet. 7. Insert dinette pedestal leg into metal receiver NOTICE in the floor.

  • Page 112: Dining Table

    SECTION 9 – FURNITURE AND SOFTGOODS WARNING Raise Murphy Bed before retracting slide rooms. Failure to observe can cause injury and will cause equipment damage. Manually Raise the Murphy Bed • Push the Murphy Bed Switch DOWN to lower If the Murphy Bed is malfunctioning you may the bed until the bed is in the fully down need to manually raise the Murphy Bed.

  • Page 113: Flex Bed

    SECTION 9 – FURNITURE AND SOFTGOODS • Insert pedestal leg into the metal receiver on the floor. Metal Receiver Pedestal 1. Pull center bed board out into the fully extended position, assuring that the edge of • Place dining table securely onto the pedestal the bed board is pulled over the two end leg.

  • Page 114: Bed – Adjustable

    SECTION 9 – FURNITURE AND SOFTGOODS 2. Lay fitted cushion over the extended bed board. • To return bed to the down position, pull strap Reverse steps to store bed back into twin bed all the way up and release in the lowered position.

  • Page 115: Wood Furniture And Cabinetry

    People are drawn to the natural beauty of and the wood is considered part of the natural ® wood. At Winnebago Industries , our craftsmen aging process and is not to be considered defect work with the art found in each piece of wood to or damage.

  • Page 117: Slideout Room Lock System

    The ignition key must be placed in the on or run position to operate the slideout room(s). The park brake must be applied for the room(s) to run. Winnebago recommends running the engine whenever you run the slideout rooms in or out, the engine alternator should insure the rooms have adequate 12-volt DC power to operate correctly.
  • Page 118 SECTION 10 – SLIDEOUT ROOMS To Retract Slideout Room Before Retracting! WARNING • Be sure the coach is level and the Parking Brake is set. CRUSH HAZARD. Keep people and • Ensure exterior compartment doors are closed objects clear of the inside and outside of the slideout room when operating.

  • Page 119: Slideout Room – Extreme Weather Precaution

    SECTION 10 – SLIDEOUT ROOMS • Press the Slideout Room “RETRACT/IN” • The circuit breaker may be tripped. The switch and hold until the room is fully circuit breaker, labeled “Slideout Power” is retracted, then release the switch. located on a panel on an interior wall of the passenger side storage compartment just •...

  • Page 120: General Slideout Care

    SECTION 10 – SLIDEOUT ROOMS operating guide included in your InfoCase for further instructions and troubleshooting information. GENERAL SLIDEOUT CARE • Keep slideout room seals clean. • Clean the floors inside the coach before retracting the slideout room to avoid floor scratches or carpet pile snags.

  • Page 121: Sealants – Inspection And General Information

    • Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.

  • Page 122: Exterior Automotive Paint Finish

    SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the initial 60-day cure stage, a coat of wax or amount of cargo you can carry and remain within polish can help protect the surface from these GVWR and GAWR limits.
  • Page 123 SECTION 11 – MAINTENANCE AND STORAGE Washing Procedure These types of road conditions may cause surface damage to your motorhome. If • Rinse area to be washed with cold water to possible, it is best to avoid these types of remove surface residue.

  • Page 124: Exterior Graphic Care

    SECTION 11 – MAINTENANCE AND STORAGE Polishing and/or Waxing be repaired or covered as quickly as possible to avoid penetration by moisture, especially in NOTE: When your motorhome is new or has freezing climates. been repainted for any reason, no polish If the fiberglass has been damaged and or wax should be applied to the finish contains cracks, tears, or holes, use plastic...

  • Page 125: Plastic Parts – Cleaning

    EXTERIOR LIGHTS stronger cleaning products. Use the following cautionary lists as a guide when selecting ® Most Winnebago Industries vehicles have cleaning products to use on plastic parts. polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical solvents and cleaners.

  • Page 126: Cabinetry – Cleaning

    SECTION 11 – MAINTENANCE AND STORAGE Draperies, Curtains, and cleaning products are not formulated for use on fabrics and may cause excessive shrinkage or Bedspreads fading. Always test any cleaning product on a These items may be woven from a variety of hidden area of fabric before using on visible fabrics.

  • Page 127: Tables And Countertops

    SECTION 11 – MAINTENANCE AND STORAGE cloth. For more stubborn stains, ethyl alcohol, TABLES AND COUNTERTOPS acetone, or another non-halogenated solvent may be used with care. Work surfaces are covered with a plastic or thermo-formed laminate that resists solvents, Stubborn Dirt and Burnt Grease stains, and abrasions.

  • Page 128: Range And Refrigerator

    SECTION 11 – MAINTENANCE AND STORAGE • Rinse thoroughly with warm water and wipe NOTE: Floor cleaners containing waxes, dry quickly to avoid spots and streaks. brighteners, or gloss agents are not recommended. • For stubborn stains, use a mild abrasive ®...

  • Page 129: Bathroom

    SECTION 11 – MAINTENANCE AND STORAGE Asphalt, candle grease, chewing gum, fat, oil, Lavatory Sink - Fiberglass tar, and shoe polish: General Cleaning • Gently remove with a blunt instrument and Clean often with hot water and soap. If a treat with a soft nylon pad and non-abrasive cleanser is necessary, make sure the product is floor cleaner.

  • Page 130: Vehicle Storage – Removal

    SECTION 11 – MAINTENANCE AND STORAGE Clean and Prep Coach for Storage 10. Close all windows and roof vents. Protect all appliance vent openings from contamination 1. Turn off the propane gas tank. by animals or insects (e.g. bird nest, wasp 2.

  • Page 131: Chassis Service And Maintenance

    SECTION 11 – MAINTENANCE AND STORAGE NOTE: Always purge a new filter with clean running water before using. See filter manufacturer’s directions included with the filter cartridge. 10. Check the toilet for proper operation. 11. Add water to the holding tank using the toilet flush pedal and galley sink faucet.

  • Page 132: Coach Maintenance Chart

    SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System ...
  • Page 133 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: ...
  • Page 134 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants ...

  • Page 135: Loading The Vehicle

    SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motorhome’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available space when loading your motorhome.
  • Page 136 SECTION 12 – MISCELLANEOUS Weighing not exceed the corresponding Axle Weight Rating specified on the Vehicle Certification There is typically a scale operator to direct Label. you, but the basic routine is to take three separate weights - front axle, whole vehicle, and rear axle. Corner Weighing (Side-to-Side) You will first drive only your front wheels The most accurate method of weighing a...

  • Page 137: Car Or Trailer Towing

    SECTION 12 – MISCELLANEOUS The load on each wheel or dual-wheel set preceding items “Loading the Vehicle” and should not exceed one-half of the corresponding “Weighing Your Loaded Vehicle” for GAWR. For example, if the GAWR for the rear explanation of weight ratings. axle is 12,000 lbs., then the load on each rear dual Because of individual vehicle use and loading set (left rear duals or right rear duals) should not...

  • Page 138: Trailer Wiring Connector

    SECTION 12 – MISCELLANEOUS force applied to the motorhome brakes, the more TRAILER WIRING force will be applied to the rear vehicle’s braking CONNECTOR system. We do not recommend the usage of a “surge- Your coach is pre-wired for trailer or car style”...

  • Page 139: Stabilizing Jacks

    10 percent is the minimum value that provides stable towing of a trailer. ® NOTE: Some Winnebago Industries models equipped with a Class 3 hitch may have a label limiting vertical tongue load to 350 12-5...

  • Page 140: Step (Entry) – Electric

    SECTION 12 – MISCELLANEOUS “Stabilizer Down” Light (Located on dash) -Typical View Stabilizing Jacks Shown in Down Position Further Information -Typical View See the manufacturer’s user guide provided in your InfoCase for complete operating instructions, safety precautions, and troubleshooting tips. WARNING STEP (ENTRY) –...

  • Page 141: Windows

    SECTION 12 – MISCELLANEOUS Stationary Extended Mode - Step Switch OFF (Step Remains Extended) With the Step power switch in the OFF position, the step will extend when the screen door is opened and will stay extended whether the door is opened or closed. This position is normally used to keep the step extended when parked at a campsite or whenever people will be going in and out the vehicle...

  • Page 142: Skylight Vent

    SECTION 12 – MISCELLANEOUS Vertical Slider Windows –If Equipped Vertical windows have spring-loaded catches on both sides of the window that pop out to hold the window in its fully raised position. Press both catches inward while opening and closing the window.

  • Page 143: Power Roof Ventilator

    SECTION 12 – MISCELLANEOUS To Open Skylight Vent NOTICE Always close the skylight completely before driving. Do not open the skylight when the vehicle is in motion. • Skylight dome can be “locked” into several open positions Further Information See the skylight vent manufacturer’s operating instructions supplied in your InfoCase for further instructions, care, and cleaning information.

  • Page 144: Power Roof Ventilator

    SECTION 12 – MISCELLANEOUS Further Information Dome Crank See the power ventilator manufacturer’s operating instructions supplied in your InfoCase for further instructions, care, and cleaning information. POWER ROOF VENTILATOR –If Equipped Arrow • Slide to OPEN Auto before turning on fan On/Off Power Roof Ventilator •...

  • Page 145: Roof Ladder

    SECTION 12 – MISCELLANEOUS complete latching of the compartment doors if they are simply “dropped shut” or closing force is WARNING applied only to the center of the door. Do not exceed 225-lb. maximum weight capacity. To ensure that exterior storage compartment Misuse of ladder could result in death or serious injury.

  • Page 146: Bike Rack

    SECTION 12 – MISCELLANEOUS 6. Reverse steps to store bike rack. Maximum Capacity of Bike Rack: CAUTION 100 lbs. Pinch Hazard. Ensure there are no • Bike Stabilizers people who could be harmed or objects that can be damaged. Failure to heed this warning could result in severe injury and/ or property damage.
  • Page 147 SECTION 12 – MISCELLANEOUS You can help reduce excessive moisture inside the motorhome by taking the following steps: Ventilate with outside air Partially open one or more windows and a roof vent to circulate outside air through the coach. In cold weather, this ventilation may increase use of the furnace, but it will greatly reduce the condensation inside the coach.
  • Page 149 INDEX About this Manual ..........................1-1 Air Conditioner Filter ........................... 4-11 Air Conditioner/Heater – Automotive (Dash) ..................3-4 Audio/Video System Basic Operation ....................8-1 Awning – Power ..........................12-11 Bathroom .............................. 11-9 Battery Access ............................6-8 Battery Boost Switch ..........................3-7 Battery Care ............................
  • Page 150 Index Electrical Generator – 120-Volt ......................6-5 Electrical Outlets – House 120-Volt AC ....................6-5 Electrical System – House 120-Volt AC ....................6-1 Electrical System – House 12-Volt DC ....................6-7 Emergency Exits ............................. 2-7 Engine Cooling System .......................... 3-8 Engine Overheat ............................
  • Page 151 Index Power Roof Ventilator ........................12-10 Power Roof Ventilator .......................... 12-9 Pre-Delivery Inspection .......................... 1-2 Pressure-Temperature Relief Valve ......................4-8 Propane Gas Leak Detector ........................2-3 Propane Gas Leaks ..........................2-3 Propane Gas Pressure Regulator ......................5-5 Propane Gas Supply ..........................5-1 Propane Gas Warnings and Precautions ....................
  • Page 152 Index Storage Compartment Doors ......................12-10 Suspension Alignment and Tire Balance ....................3-11 Tables and Countertops ........................11-7 Tires ..............................3-11 Toilet – Electric Flush ..........................7-8 Toilet ............................... 7-8 Towing Guidelines ..........................12-4 Trailer Wiring Connector ........................12-4 TV Antenna – Digital ..........................8-5 TV Digital Satellite System Wiring ......................

This manual is also suitable for:

View 24gView 24vView 24j

Table of Contents
