3.4

LED Indicator Information

Long Burning
On 0.2s, Off 1.9s, Repeat
On 0.2s, Off 0.2s, On 0.2s, Off 1.7s Repeat
On 0.2s, Off 0.2s, Repeat
3.5 UIM Card Installation
1. Ensure the USB modem is plug off. Remove the back cover.
2. Hold the UIM card with the cut corner oriented as shown and
then slide it into the card holder face down.
3. Replace the back cover.
3.6 MicroSD Card Installation
1. Ensure the USB modem is plug off. Remove the back cover.
2. Hold the MicroSD card with the oriented as shown and then
slide it into the card holder face up.
3. Replace the back cover.
D-Link DWM-162R User Manual
LED Indications Dongle Working Status
System initializing
No Signal / Searching
Idle with Signal
In used
