Model No. PCTL92101
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial
Number
Decal
If you require SERVICE for
this product, please call
SEARS:
1-800-4 MY HOME
(469-4663)
If you are MISSING PARTS or
require INFORMATION on how
to operate this product, call
1-888-936-ICON
(4266)
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
®
USER'S MANUAL
Visit our website at
www.weiderfitness.com
Advertisement
Table of Contents
Related Manuals for ProForm PCTL92101
Summary of Contents for ProForm PCTL92101
- Page 1 Model No. PCTL92101 Serial No. Find the serial number in the location shown below. Write the serial number in the space above for reference. Serial Number Decal If you require SERVICE for this product, please call SEARS: 1-800-4 MY HOME...
-
Page 2: Table Of Contents
HOW TO FOLD AND MOVE THE TREADMILL ........ -
Page 3: Important Precautions
2. Use the treadmill only as described. 3. Place the treadmill on a level surface, with at least 2 m (8 ft.) of clearance behind it. Do not place the treadmill on any surface that blocks air openings. - Page 4 SAVE THESE INSTRUCTIONS The decals shown below have been placed on your treadmill. If a decal is missing, or if it is not legible, please call our toll-free customer service department to order a free replacement decal (see the front cover of this manual).
-
Page 5: Before You Begin
The model number of the treadmill is PCTL92101. The serial number can be found on a decal attached to the treadmill (see the front cover of this manual for the location). -
Page 6: Assembly
This is a normal condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner. - Page 7 Rear Foot Spacer. Carefully lower the treadmill. 7. Make sure that all parts are tightened before you use the treadmill. Keep the included allen wrench in a secure place. The allen wrench is used to adjust the walking belt (see page 23). To protect the floor or carpet from damage, place a mat under the treadmill.
- Page 8 If you purchase the optional chest pulse sensor (see page 19), follow the steps below to install the receiver in- cluded with the chest pulse sensor. 1. Make sure that the power plug is unplugged. Remove the six or seven indicated Screws (46) from the back of the Console Base Back (116).
-
Page 9: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking plat- form. Such substances will deteriorate the walking belt and cause excessive wear. -
Page 10: Features
Six certified personal trainer programs are also offered. Each program automatically controls the speed and in- cline of the treadmill as it guides you through an effec- tive workout. The console also features advanced iFIT.com interac- tive technology. IFIT.com technology is like having a personal trainer right in your home. - Page 11 To change the speed setting quickly, press the Quick Speed buttons. Note: After the buttons are pressed, it may take a moment for the treadmill to reach the Position selected speed setting. To stop the walking belt, press the Stop button.
- Page 12 When you are finished exercising, remove the key. Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest level. The incline must be at the lowest level when the treadmill is raised to the storage po- sition or the treadmill will be damaged.
- Page 13 The console features two low intensity programs, two medium intensity programs, and two high in- tensity programs. The profiles on the console show how the speed and incline of the treadmill will change during the programs. The numbers beside the profiles show the maximum speed and incline settings for the programs.
- Page 14 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the LINE OUT jack on your CD player.
- Page 15 B. A. Plug one end of the audio cable into the jack on the front of the treadmill near the power cord. Plug the other end of the cable into the included adapter. Plug the adapter into the LINE OUT jack on your stereo.
- Page 16 Follow the steps below to use an iFIT.com CD or video. Note: The instructions included in the CD case describe how to use the CD with a variety of ANT. IN PROFORM treadmills. Some instructions may not VIDEO AUDIO RF OUT apply to this treadmill.
- Page 17 During the CD or video program, an electronic “chirping” sound will alert you when the speed and/or incline of the treadmill is about to change. CAUTION: Always listen for the “chirp” and be prepared for speed and/or incline changes. In...
- Page 18 Our new internet site at www.iFIT.com allows you to access a large selection of programs that interactively control your treadmill to help you achieve your specific exercise goals. In addition, you can play iFIT.com audio and video programs directly from the internet. By adding an optional upgrade module to the console, you can use virtually endless features on our internet site.
- Page 19 THE INFORMATION MODE/DEMO MODE The console features an information mode that keeps track of the total number of hours that the treadmill has been operated and the total number of miles that the walking belt has moved. The information mode also allows you to switch the console from miles per hour to kilometers per hour.
-
Page 20: How To Fold And Move The Treadmill
2. Move your right hand to the position shown and hold the treadmill firmly. Using your left hand, pull the latch knob to the left and hold it. Raise the treadmill until the latch pin is aligned with the hole in the catch. Insert the latch pin into the catch. - Page 21 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the pin.
-
Page 22: Trouble-Shooting
PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in. - Page 23 SOLUTION: a. With the key in the console, press one of the Incline buttons. While the incline is changing, re- move the key. After a few seconds, re-insert the key. The treadmill will automatically rise to the maximum incline level and then return to the minimum level. This will recalibrate the incline.
-
Page 24: Conditioning Guidelines
For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”... - Page 25 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
-
Page 26: Part List
PART LIST—Model No. PCTL92101 To locate the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. No. Qty. Description Motor Belt Pulley/Flywheel/Fan Motor Nut Motor/Pulley/ Flywheel/Fan Incline Motor Bolt Console Ground Wirer Incline Motor... -
Page 27: Ordering Replacement Parts
Friday 8h00 until 18h30 Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER OF THE PRODUCT (PCTL92101) • The NAME OF THE PRODUCT (PROFORM • The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual) •... -
Page 28: Limited Warranty
Television Ads Colour Magazine Ads Price Product Innovation Printed in Canada © 2001 ICON Health & Fitness, Inc. PURCHASE DATE: No Opinion Exercise Cycle Treadmill Weight Bench Stepper Other Fitness Motoring Computer General THANK YOU FOR YOUR TIME © 2001 ICON of Canada, Inc. Printed in USA... - Page 29 EXPLODED DRAWING—Model No. PCTL92101 R0801A...
- Page 30 EXPLODED DRAWING—Model No. PCTL92101 R0801A...
