- Page 1 HCC-CW-201A CWDM Analyzer Operation Guide...
- Page 2 HCC-CW-201A Table of Contents Description ................................3 Features ................................... 3 Specifications ................................4 Safety Information ..............................5 Preparing for Operation ............................6 Unpacking the instrument ............................6 Front keys definition ............................... 6 Rear panel definition ............................... 7 Function Modules ..............................10 Description of functions ............................
-
Page 3: Description
10 CWDM channels. HCC-CW-201A can replace high-cost Spectrometers and conduct quick and reliable measurements in all environments. Thanks for its light, compact and sturdy design, HCC-CW-201A is the ideal tool for CWDM installation and maintenance technicians. -
Page 4: Specifications
HCC-CW-201A Specifications Wavelength (nm) 1431 ~ 1611 Power Range (dBm) -40 ~ +10 Channel Number Channel Spacing 20nm Central Wavelength Channel Band-pass ITU ±6.5nm Channel Power Resolution ±0.01 dB Channel Power Accuracy ±0.5 dB Maximum Input Power 13 dBm Return Loss >45 dB... -
Page 5: Safety Information
If the instrument is mainly used at one location, e.g. in a laboratory or test department, the AC adapter can be used to power it instead of batteries. There is a DC input jack on the left side of the HCC-CW-201A instrument casing into which the output cable of the AC adapter is plugged. -
Page 6: Preparing For Operation
Packing material We suggest that you keep the original packing material. Using the original packing material is your guarantee of protecting the instrument during transit. Checking the package contents The standard accessories of HCC-CW-201A are as follows: • Main unit •... -
Page 7: Rear Panel Definition
HCC-CW-201A Rear panel definition 9V Power adaptor interface USB Interface OPM Interface CWDM Interface Battery Auto power off. You can set the function through the menu Internal clock. Adaptor connection display Display the real time The margin of battery The name of saved data The series number of fiber www.PrecisionRatedOptics.com | 888-545-1254... - Page 8 HCC-CW-201A Function Operation Interface ON/OFF Press to turn on or off the meter The starting interface is CWDM testing mode to display the dBm value. Press to switch the units: dBm/dB/mW; Press left/right key to Power meter function switch among the CWDM value list, histogram figure, OPM power value.
- Page 9 HCC-CW-201A In the menu mode, press to go into the time setting mode and press to set the time. After Time time setting, please press to save the configuration, press to exit the menu. In the menu mode, press to set the OPM parameters.
-
Page 10: Function Modules
HCC-CW-201A Function Modules: Two modes: Testing Mode and Menu Mode The testing mode includes CWDM power meter, OPM power meter mode. Menu mode includes the following 9 items. 1) CWDM Parameters 2) Back light 3) Time 4) OPM Parameters 5) View History... -
Page 11: Description Of Functions
HCC-CW-201A Description of functions Auto power off Auto power off function is that no operation for 10 mins, it will auto power off. In the menu mode, press choose auto off mode, press to open or close this function. CWDM power meter mode: 10 channels CWDM power display. -
Page 12: Menu Mode
HCC-CW-201A Save the CWDM value As it is shown in Fig. 9, in the OPM mode, Press up/down keys to choose the needed wavelength: 850nm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm. It will display the power of the real wavelength in dBm/ dB/mW. If it displays "LOW" or "HIGH”, it exceeded the testing range. -
Page 13: Back Light Setting
HCC-CW-201A • Reference value setting: Take the dBm as the unit and it will display the real value of power; Take dB as the unit and it will display a reference value according to the saved reference value. Reference value: Display value=Testing value Reference value •... -
Page 14: Opm Parameters/Opm Setting
HCC-CW-201A Fig 16 OPM Parameters/OPM setting Reference value setting: Take the dBm as the unit and it will display the real value of power; Take dB as the unit and it will display a reference value according to the saved reference value. Reference value: Display value =Testing value, Reference... -
Page 15: Auto Off
HCC-CW-201A Auto off As is shown in Fig .21, after choosing Auto off menu, press to open/close this function. Fig 21 Name File Name Get into the New file menu, as is shown in Fig. 22, press left/right to move cursor to the designated position;... -
Page 16: About
HCC-CW-201A Note: As shown in Fig. 24, 25, if you need to save a series of CWDM power value into a file. Firstly you need to create a file or open the existing file, then in the testing mode, press to check the CWDM values dBm/dB/mW. -
Page 17: Warranty
Misuse, negligence, or accident Returning Product To return product, you may contact Precision Rated Optics to obtain additional information if necessary. To serve you better, please specify the reasons for the return. All delivery and mails should be sent to the following... - Page 18 Precision Rated Optics, Inc Corporate Office Billing & Processing PO Box 877 Trexlertown, PA 18087 Precision Rated Optics, Inc Product Distribution Center Manufacturing & Testing 9999 Hamilton Blvd Breinigsville, PA 18031...
