Panasonic CS-TZ20TKEW Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Air Conditioner
  5. CS-TZ20TKEW
  6. Service manual

Panasonic CS-TZ20TKEW Service Manual

Hide thumbs Also See for CS-TZ20TKEW:
Table of Contents

Advertisement

Quick Links

Please file and use this manual together with the service manual for Model No. CU-2E12SBE, CU-2E15SBE, CU-2E18SBE,
CU-3E18PBE, CU-3E23SBE, CU-4E23PBE, CU-4E27PBE, CU-5E34PBE, CU-2RE15SBE, CU-2RE18SBE, CU-3RE18SBE,
Order No. PAPAMY1601016CE, PAPAMY1601015CE, PAPAMY1301048CE, PAPAMY1303046CE.
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturer's specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of
manufacturer.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
R32 REFRIGERANT
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the
installation, maintenance and/or service of this product.
AMP Air Conditioning
IMPORTANT SAFETY NOTICE
PRECAUTION OF LOW TEMPERATURE
– This Air Conditioner contains and operates with refrigerant R32.
CS-TZ20TKEW
CS-TZ25TKEW
CS-TZ35TKEW
CS-TZ42TKEW
CS-MTZ16TKE
WARNING
CAUTION
www.ampair.co.uk | sales@ampair.co.uk
Order No: PAPAMY1702032CE
CU-TZ20TKE
CU-TZ25TKE
Destination
Europe
Turkey
in the Schematic
© Panasonic Corporation 2017

Advertisement

Table of Contents
loading

Related Manuals for Panasonic CS-TZ20TKEW

Summary of Contents for Panasonic CS-TZ20TKEW

  • Page 1 THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL. Refer to Commonwealth, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the installation, maintenance and/or service of this product. © Panasonic Corporation 2017 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE Safety Precautions ..........3 14.8 Indication Panel ..........79         14.9 Quiet Operation (Cooling Mode/Cooling   Precaution for Using R32 Refrigerant ....5     Area of Dry Mode) ........79   Specifications ............. 9  ...

  • Page 3: Safety Precautions

    1. Safety Precautions  Read the following “SAFETY PRECAUTIONS” carefully before installation.  Electrical work must be installed by a licensed electrician. Be sure to use the correct rating of the power plug and main circuit for the model to be installed. ...
  • Page 4 WARNING Use the attached accessories parts and specified parts for installation. Otherwise, it will cause the set to fall, water leakage, fire or electrical shock. Install at a strong and firm location which is able to withstand weight of the set. If the strength is not enough or installation is not properly done, the set will drop and cause injury.
  • Page 5 2. Precaution for Using R32 Refrigerant  The basic installation work procedures are the same as conventional refrigerant (R410A, R22) models. However, pay careful attention to the following points: WARNING Since the working pressure is higher than that of refrigerant R22 models, some of the piping and installation and service tools are special.
  • Page 6 CAUTION 2-5. No ignition sources  No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has contained flammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion. He/She must not be smoking when carrying out such work.
  • Page 7 CAUTION Leak detection methods  Electronic leak detectors shall be used to detect flammable refrigerants, but the sensitivity may not be adequate, or may need re- calibration. (Detection equipment shall be calibrated in a refrigerant-free area.)  Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant used. ...
  • Page 8 CAUTION Labelling  Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant.  The label shall be dated and signed.  Ensure that there are labels on the equipment stating the equipment contains flammable refrigerant. Recovery ...

  • Page 9: Specifications

    3. Specifications Indoor CS-TZ20TKEW CS-TZ25TKEW Model Outdoor CU-TZ20TKE CU-TZ25TKE Performance Test Condition EUROVENT EUROVENT Phase, Hz Single, 50 Single, 50 Power Supply Min. Mid. Max. Min. Mid. Max. 0.75 2.00 2.40 0.85 2.50 3.00 Capacity BTU/h 2560 6820 8180 2900...
  • Page 10 Indoor CS-TZ20TKEW CS-TZ25TKEW Model Outdoor CU-TZ20TKE CU-TZ25TKE Type Hermetic Motor (Rotary) Hermetic Motor (Rotary) Compressor Motor Type Brushless (6 poles) Brushless (6 poles) Output Power Type Cross-Flow Fan Cross-Flow Fan Material ASG20K1 ASG20K1 Motor Type DC / Transistor (8-poles) DC / Transistor (8-poles) Input Power 47.3...

  • Page 11: Remote Control

    Indoor CS-TZ20TKEW CS-TZ25TKEW Model Outdoor CU-TZ20TKE CU-TZ25TKE Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 9.52 (3/8) Standard length m (ft) 5.0 (16.4) 5.0 (16.4) Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
  • Page 12 Indoor CS-TZ35TKEW CS-TZ42TKEW Model Outdoor CU-TZ35TKE CU-TZ42TKE Performance Test Condition EUROVENT EUROVENT Phase, Hz Single, 50 Single, 50 Power Supply Min. Mid. Max. Min. Mid. Max. 0.85 3.50 3.90 0.85 4.20 4.60 Capacity BTU/h 2900 11900 13300 2900 14300 15700 Kcal/h 3010 3350...
  • Page 13 Indoor CS-TZ35TKEW CS-TZ42TKEW Model Outdoor CU-TZ35TKE CU-TZ42TKE Type Hermetic Motor (Rotary) Hermetic Motor (Rotary) Compressor Motor Type Brushless (6 poles) Brushless (6 poles) Output Power Type Cross-Flow Fan Cross-Flow Fan Material ASG20K1 ASG20K1 Motor Type DC / Transistor (8-poles) DC / Transistor (8-poles) Input Power 47.3 47.3...
  • Page 14 Indoor CS-TZ35TKEW CS-TZ42TKEW Model Outdoor CU-TZ35TKE CU-TZ42TKE Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2) Standard length m (ft) 5.0 (16.4) 5.0 (16.4) Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2) I/D &...
  • Page 15 Indoor CS-MTZ16TKE Model Outdoor CU-3RE18SBE Performance Test Condition EUROVENT Phase, Hz Single, 50 Power Supply Min. Mid. Max. 1.30 1.60 2.30 Capacity BTU/h 4440 5460 7860 Running Current – 2.30 – Input Power Annual Consumption – – 5.20 3.40 3.24 dB-A 38 / 27 / 22 Indoor Noise (H / L / QLo)
  • Page 16 Indoor CS-MTZ16TKE Model Outdoor CU-3RE18SBE Height (I/D) mm (inch) 290 (11-7/16) Dimension Width (I/D) mm (inch) 799 (31-15/32) Depth (I/D) mm (inch) 197 (7-25/32) Weight Net (I/D) kg (lb) 8 (18) Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) Inner Diameter 16.7 Drain Hose...

  • Page 17: Indoor Unit

    Example: The indoor units’ combination below is possible to connect to CU-2RE15SBE. (Total nominal capacity of indoor units is between 4.0kW to 5.7kW) 1) Two CS-TZ20TKEW only. (Total nominal cooling capacity is 4.0kW) Remarks for CU-3RE18SBE 1. The total nominal cooling capacity of indoor units that will be connected to outdoor unit must be within connectable capacity range of indoor unit.

  • Page 18: Outdoor Unit

    Example: The indoor units’ combination below is possible to connect to CU-2E15SBE. (Total nominal capacity of indoor units is between 3.2kW to 5.7kW) 1) Two CS-TZ20TKEW only. (Total nominal cooling capacity is 4.0kW) Remarks for CU-3E23SBE 1. The total nominal cooling capacity of indoor unit that will be connected to outdoor unit must be within connectable capacity range of indoor unit.
  • Page 19 ROOM 1.6kW CS-MTZ16TKE ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 2.0kW CS-TZ20TKEW ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● 2.5kW CS-TZ25TKEW ●...
  • Page 20 4. Features  Inverter Technology Wider output power range Energy saving Quick Cooling Quick Heating More precise temperature control  Environment Protection Non-ozone depletion substances refrigerant (R32)  Long Installation Piping Long piping up to 15 meters (3/4 ~ 1.75HP) and 20 meters (2.0HP) during single split connection only ...

  • Page 21: Location Of Controls And Components

    5. Location of Controls and Components Indoor Unit Air Filters Front panel Auto OFF/ON button • Use when remote control is misplaced or malfunction occurs. Aluminium Fin Air Purifying Filter INDICATOR POWER (Green) Horizontal Airflow TIMER (Orange) direction louver • Manually adjustable. Remote Control receiver Vertical Airflow...
  • Page 22 6. Dimensions Indoor Unit <Top View> <Side View> <Front View> <Side View> Air intake direction Left piping Right piping Air outlet hole hole direction <Bottom View> <Remote Control> 92.8 <Rear View> 41-61 <Remote Control Holder> Liquid side Gas side Relative position between the indoor unit and the installation plate <Front View> 496.6 16.4 Installation...
  • Page 23 Outdoor Unit 6.2.1 CU-TZ20TKE CU-TZ25TKE CU-TZ35TKE <Top View> Space necessary for installation 67.6 (104.7) 570.3 104.9 60.5 100 mm 100 mm 1000 mm 2-way valve at Liquid side Anchor Bolt Pitch (High Pressure) 320 x 570 3-way valve at Gas side (Low Pressure) <Side View>...

  • Page 24: Refrigeration Cycle Diagram

    7. Refrigeration Cycle Diagram INDOOR OUTDOOR LIQUID EXPANSION TEMP. SIDE MUFFLER VALVE STRAINER SENSOR 2-WAY VALVE PIPE TEMP. INTAKE SENSOR 2 TEMP. SENSOR CONDENSER PIPE TEMP. PIPE SENSOR 1 TEMP. SENSOR HEAT EXCHANGER (EVAPORATOR) SIDE 4-WAYS VALVE 3-WAY MUFFLER VALVE TANK SENSOR COMPRESSOR...
  • Page 25 8. Block Diagram Indoor Unit AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 26 Outdoor Unit 8.2.1 CU-TZ20TKE CU-TZ25TKE AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 27 8.2.2 CU-TZ35TKE AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 28 8.2.3 CU-TZ42TKE AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...

  • Page 29: Wiring Connection Diagram

    9. Wiring Connection Diagram Indoor Unit TERMINAL FUSE301 AC306 BOARD T3.15A L250V (BLK) AC303 (WHT) AC304 NOISE FILTER (RED) CIRCUIT TEMP. FUSE UP DOWN 102ºC 250V 4.5A LOUVER MOTOR G301 COMMUNICATION (OUTER) (GRN) CIRCUIT GROUNDING TERMINAL UP DOWN LOUVER MOTOR RECTIFICATION EVAPORATOR (INNER)
  • Page 30 Outdoor Unit 9.2.1 CU-TZ20TKE CU-TZ25TKE REMARKS YELLOW (YEL) BLACK; (BLK) WHITE; (WHT) SINGLE PHASE TO INDOOR UNIT POWER SUPPLY YELLOW; (YLW) (BLK) (WHT) (RED) ORANGE; (ORG) YELLOW/GREEN; (YLW/GRN) BLUE (BLU) RED (RED) BLUE; (BLU) (TRADEMARK) REACTOR TERMINAL RED; (RED) BOARD (BLK) (WHT) (RED)
  • Page 31 9.2.2 CU-TZ35TKE REMARKS YELLOW (YEL) BLACK; (BLK) WHITE; (WHT) SINGLE PHASE TO INDOOR UNIT POWER SUPPLY YELLOW; (YLW) (BLK) (WHT) (RED) ORANGE; (ORG) YELLOW/GREEN; (YLW/GRN) BLUE (BLU) RED (RED) BLUE; (BLU) (TRADEMARK) REACTOR TERMINAL RED; (RED) BOARD (BLK) (WHT) (RED) COMPRESSOR TERMINAL BROWN;...
  • Page 32 9.2.3 CU-TZ42TKE REMARKS YELLOW (YEL) BLACK; (BLK) WHITE; (WHT) SINGLE PHASE TO INDOOR UNIT POWER SUPPLY YELLOW; (YLW) (BLK) (WHT) (RED) ORANGE; (ORG) YELLOW/GREEN; (YLW/GRN) BLUE (BLU) RED (RED) BLUE; (BLU) (TRADEMARK) REACTOR TERMINAL RED; (RED) BOARD (BLK) (WHT) (RED) COMPRESSOR TERMINAL BROWN;...

  • Page 33: Electronic Circuit Diagram

    10. Electronic Circuit Diagram 10.1 Indoor Unit TERMINAL FUSE301 AC306 BOARD T3.15A L250V (BLK) F301 AC303 (WHT) AC304 NOISE FILTER (RED) CIRCUIT 1000p 1000p TEMP. FUSE 102ºC 250V 4.5A G301 COMMUNICATION (GRN) CIRCUIT GROUNDING NONE 5.1k NONE TERMINAL RECTIFICATION EVAPORATOR NONE CIRCUIT SW01...
  • Page 34 10.2 Outdoor Unit 10.2.1 CU-TZ20TKE CU-TZ25TKE SINGLE PHASE TO INDOOR UNIT POWER SUPPLY (BLK) (WHT) (RED) REACTOR TERMINAL BOARD (BLK) (WHT) (RED) RAT2 RAT1 (GRY) (GRY) 15.8k CN-TH FUSE104 OUTDOOR AIR TEMP. (WHT) (15A 250V) SENSOR (THERMISTOR) t° DATA (RED) t°...
  • Page 35 10.2.2 CU-TZ35TKE SINGLE PHASE TO INDOOR UNIT POWER SUPPLY (BLK) (WHT) (RED) REACTOR TERMINAL (BLK) (WHT) (RED) BOARD RAT2 RAT1 (GRY) (GRY) 15.8k 15.0k FUSE104 (15A 250V) CN-TH OUTDOOR AIR TEMP. (WHT) SENSOR (THERMISTOR) DATA (RED) t° t° PIPING TEMP. SENSOR COMMUNICATION CN-TANK NOISE...
  • Page 36 10.2.3 CU-TZ42TKE SINGLE PHASE TO INDOOR UNIT POWER SUPPLY (BLK) (WHT) (RED) REACTOR TERMINAL (BLK) (WHT) (RED) BOARD RAT2 RAT1 (GRY) (GRY) 15.8k 15.0k FUSE104 (15A 250V) CN-TH OUTDOOR AIR TEMP. DATA (WHT) SENSOR (THERMISTOR) (RED) t° t° PIPING TEMP. SENSOR CN-TANK (THERMISTOR) (WHT)

  • Page 37: Printed Circuit Board

    11. Printed Circuit Board 11.1 Indoor Unit 11.1.1 Main Printed Circuit Board AC303 AC304 AC306 CN-FM CN-STM1 CN-STM3 CN-DISP CN-RMT CN-CNT CN-TH JP1 (Random Auto Restart enable/disable) AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 38 11.1.2 Indicator Printed Circuit Board CN-DISP AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 39 11.2 Outdoor Unit 11.2.1 CU-TZ20TKE CU-TZ25TKE POWER TRANSISTOR (IPM) CN-HOT CN-TH CN-TANK CN-STM CN-MTR1 CURRENT CN-MTR2 TRANSFORMER (CT) AC-BLK AC-WHT DATA AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 40 11.2.2 CU-TZ35TKE POWER TRANSISTOR (IPM) CN-HOT CN-STM CN-TH CN-TANK CURRENT TRANSFORMER CN-MTR1 (CT) CN-MTR2 AC-BLK DATA AC-WHT AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 41 11.2.3 CU-TZ42TKE POWER TRANSISTOR (IPM) CN-HOT CURRENT TRANSFORMER CN-TANK (CT) CN-TH AC-BLK CN-MTR1 CN-MTR2 CN-STM AC-WHT DATA AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...

  • Page 42: Installation Instruction

    12. Installation Instruction (5/4) = (M / (2.5 × (LFL) × h 12.1 Select the Best Location = Required minimum room area, in m 12.1.1 Indoor Unit = Refrigerant charge amount in appliance, in kg LFL = Lower flammable limit (0.306 kg/m ...

  • Page 43: How To Fix Installation Plate

    12.2 Indoor Unit 12.2.1 How to Fix Installation Plate The mounting wall shall be strong and solid enough to prevent it from vibration. Ceiling Wall Wall More than 1 More than 1 More Indoor unit 2 screw than 2 Installation 222 mm plate 1 184 mm...
  • Page 44 12.2.2 To Drill a Hole in the Wall and Install a Sleeve of Piping Wall Indoor Outdoor Insert the piping sleeve to the hole. Fix the bushing to the sleeve. 15 mm Approx. 5 - 7 mm Cut the sleeve until it extrudes about 15 mm from the wall.

  • Page 45: Indoor Unit Installation

    12.2.3 Indoor Unit Installation ● Do not turn over the unit without it’s shock absorber during pull out the piping. It may cause intake grille damage. ● Use shock absorber during pull out the piping to protect the intake grille from damage. Piping Piping Intake grille...

  • Page 46: Connect The Cable To The Indoor Unit

    Exchange the drain hose and the cap Rear view for left piping installation Connection cable Piping More than 950mm Drain hose (1/2 ~ 1.75Hp) or 1150mm (2.0 ~ 2.5Hp) Drain hose Connection cable Drain cap Drain hose Adjust the piping slightly downwards.
  • Page 47 Secure the connection cable onto the control board with the holder. Ensure the colour of wires of outdoor unit and the terminal Nos. are the same to the indoor’s respectively. Earth wire shall be Yellow/Green (Y/G) in colour and longer than other AC wires for safety reason. Terminal Board Tape Earth Wire...

  • Page 48: Install The Outdoor Unit

    12.3 Outdoor Unit 12.3.1 Install the Outdoor Unit  After selecting the best location, start installation to Indoor/Outdoor Unit Installation Diagram. Fix the unit on concrete or rigid frame firmly and horizontally by bolt nut (ø10 mm). When installing at roof, please consider strong wind and earthquake. Please fasten the installation stand firmly with bolt, screws or nails.
  • Page 49 12.3.2.3 Connecting the Piping to Outdoor Multi Decide piping length and then cut by using pipe cutter. Liquid side Remove burrs from cut edge. Make flare after inserting the Hall Union Flare Nut flare nut (locate at valve) onto the copper pipe. Align center Auxiliary pipe Connection pipe (male side)

  • Page 50: Evacuation Of The Equipment

    AIR PURGING METHOD IS PROHIBITED FOR R32 SYSTEM 12.3.3 Evacuation of the Equipment WHEN INSTALLING AN AIR CONDITIONER, BE SURE TO EVACUATE THE AIR INSIDE THE INDOOR UNIT AND PIPES in the following procedure. Do not purge the air with refrigerants but use a vacuum pump to vacuum the installation. There is no extra refrigerant in the outdoor unit for air purging.

  • Page 51: Connect The Cable To The Outdoor Unit

    12.3.4 Connect the Cable to the Outdoor Unit Remove the control board cover from the unit by loosening the screw. Cable connection to the power supply through Isolating Devices (Disconnecting means). Connect approved type polychloroprene sheathed power supply cord 3 x 1.5 mm (3/4 ~ 1.75HP), 3 x 2.5 mm (2.0 ~ 2.5HP) type designation 60245 IEC 57 or heavier cord to the terminal board, and...

  • Page 52: Piping Insulation

    12.3.5 Piping Insulation Please carry out insulation at pipe connection portion as mentioned in Indoor/Outdoor Unit Installation Diagram. Please wrap the insulated piping end to prevent water from going inside the piping. If drain hose or connecting piping is in the room (where dew may form), please increase the insulation by using POLY-E FOAM with thickness 6 mm or above.
  • Page 53 12.3.9 Evaluation of the Performance  Operate the unit at cooling/heating operation mode for fifteen minutes or more.  Measure the temperature of the intake and discharge air.  Ensure the difference between the intake temperature and the discharge is more than 8°C during Cooling operation or more than 14°C during Heating operation.
  • Page 54 13. Installation and Servicing Air Conditioner using R32 13.1 About R32 Refrigerant For air conditioning refrigerants such as R410A, the refrigerants were collected back in order to prevent their air dissipation, to curbe the global warming impact, in case they were released into the atmosphere. In the “4th Environmental Basic Plan”, 80% reduction of greenhouse gas emissions by 2050 is required, and due to this requirement, further reduction in the emission of high greenhouse effect gas, such as CFCs, is required.
  • Page 55 2. Characteristic of Pressure As shown in Table 2, R32 does not have much difference in vapor pressure at the same refrigerant temperature comparing to R410A, but comparing to R22, it is higher at 1.6 times more. Thus, the same as in case of R410A, it is necessary to do installation and service using high-pressure tools and components.

  • Page 56: In Services

    13.3 Refrigerant piping installation • Tools used in services 13.3.1 Required Tools R32 refrigerant air conditioners use the common parts as R410A air conditioners for two-way valves and three-way valves (diameters of service ports); thus, they maintain commonality in the maintenance of the compressive strength, the size of pipe flaring, and the size of flare nuts as R410A.
  • Page 57 3. Torque wrenches (diameters 1/2, 5/8) Manifold gauges / Charging hoses In order to strengthen the compressive strength, the diameters of wrenches change depending on the flare nut sizes. Torque wrenches Differences in charging hoses Differences in torque wrenches (common R410A) Normal 5.1 MPa 3.4 MPa...
  • Page 58 7. HFC refrigerant_Electric gas leakage tester 9. Refrigerant cylinders R32 refrigerant is often used for other mixed Refrigerant cylinders for R410A are painted in pink, refrigerant (R410A, R404A, R407C etc.). Therefore, and the ones for R32 are painted in other colors that the usage of existing HFC detectors is possible, but in might subject to change according to the international order to detect more accurately, we recommend to...
  • Page 59 11. Tools used for refrigerant piping installations and services Tools for R410A Common with R32 Possibility of usage for R22 ○ ○ Pipe cutters, reamers or scrapers ○ ○ Flare tools (clutch type) ○ ○ Torque wrench (1/4, 3/8) ○ ×...
  • Page 60 13.4 New installation, Relocation, Repairing of Refrigerant Cycle System The Procedures Relocation Repairing refrigerant cycle Installation Indoor / outdoor units and piping Pump down Refrigerant recovery • Displacing pipes and wires, and displacing indoor / outdoor units Prevention of impurity •...
  • Page 61 13.5 Piping installation of R32 13.5.1 Pipe materials used and flaring Copper pipes are used for refrigerant piping. Pipes Pipe thickness which comply with JIS Regulations need to be used. Room air conditioners which use R410A and R32 O and OL materials Thickness (mm) have higher pressure;...

  • Page 62: Point

    13.6 Installation, Relocation, and Service 13.6.1 Air purge and gas leak test for new installation (using new refrigerant pipes) using vacuum pump (From the point of view of global environment protection, do not release CFCs into the atmosphere during installation work) 1.
  • Page 63 13.6.2 Process of refrigerant recovery 1. Connect the center charging hose of manifold gauge to the in-let side of recovery device. 2. Connect the valves of the discharge side of recovery device and liquid side of refrigerant cylinder with red hose (charging hose).
  • Page 64 13.6.3 Relocation 1. Removing the air conditioning unit a) Recovery of outdoor unit refrigerant by pumping down Press “forced cooling button” (as a general rule, since 1998 the name of cooling testing button is changed, and this name is unified within the air conditioning industry), and then you are able to start cooling operation in which the room temperature is low, and you can recover the refrigerant from the outdoor unit.
  • Page 65 13.6.6 Re-insertion of refrigerant in service When re-insertion is needed, follow the procedures to ensure the insertion of new refrigerant at correct amount. 1. Attach charging hose (blue) to the service port of the outdoor unit. 2. Attach charging hose (red) to the vacuum pump. Fully open the 2-way and 3-way valves. 3.
  • Page 66 13.7 Repairing of refrigerant cycle / Brazing point 13.7.1 Preparation for repairing of refrigerant cycle / brazing Brazing which is a technique needed for repairing refrigerant cycle requires advanced technique and experience, and this brazing procedure can only be performed by the workers who completed “Gas Welding Skill Training” regulated by the Occupational Safety and Health Act, and went through the training programs of refrigerant operations.
  • Page 67 2. Cylinder without adjustment valve side gauge pressure is adjusted by the adjuster. Check the both side valves of the torch and open the cylinder valve to check the remaining refrigerant in the cylinder. Caution: Do not attach oil component on the connection port of the adjuster. Especially, use an oxygen cylinder adjuster which is no oil substance type.
  • Page 68 13.7.5 Types of flame Types of flame change based on the proportion of propane and oxygen. [Neutral Flame] Perform brazing with this flame (This is a flame when oxygen and propane are mixed at proper proportion, and has lesser effect on the brazed metals) White core flame 10 ~ 15 mm...
  • Page 69 13.7.7 Selection of brazing material Use BAg brazing material (silver solder) to increase the welding performance. Tensile strength Composition of ingredients (%) Temperature (°C) Characteristics (Reference) Category Standard Brazing Base Number applications Solidus Liquidus Kgf•cm temp material Liquidity is good at low temperature, 49.0 14.5...
  • Page 70 13.7.10 Checking of brazing (insert) points 1. No impurity on the brazing point Gap 0.025 ~ 0.05 mm If dirt or oil is attached on the brazing point, the brazing filler metal does not reach to junction, and Inner diameter ø6.45 it may cause poor welding.
  • Page 71 (Reference) Melting temperature of copper • • • • • • • Approx. 1083°C Maximum temperature obtained in propane and oxygen • • • • • • • Approx. 1083°C The important point is to heat the bonding part uniformly within a short period of time until reaching to the brazing temperature in the following manner.

  • Page 72: Code, No Cooling / No Warming

    13.8 <Reference> Analysis method for no error code, no cooling / no warming 13.8.1 Preparation for appropriate diagnosis In order to obtain appropriate operation characteristics, minimum 15 minutes or more operation time [testing operation (rated operation)] is required. 1. Method of rated operation (rated operation) For the models which have two buttons of “emergency operation and forced cooling operation”, press forced cooling button once.
  • Page 73 1. Measuring temperature 1) Indoor unit suction temperature, release temperature, temperature difference, → Measure by thermometer 2) 2-way valve pipe temperature in cooling mode is low temperature (benchmark：5 ~ 10°C), in heating mode is medium temperature (benchmark：25 ~ 35°C). 3) 3-way valve pipe temperature in cooling mode is low temperature (benchmark：7 ~ 15°C) in heating mode is high temperature (benchmark：38 ~ 50°C).

  • Page 74: Basic Function

    14. Operation Control 14.1 Basic Function Inverter control, which equipped with a microcomputer in determining the most suitable operating mode as time passes, automatically adjusts output power for maximum comfort always. In order to achieve the suitable operating mode, the microcomputer maintains the set temperature by measuring the temperature of the environment and performing temperature shifting.

  • Page 75: Automatic Operation

    14.1.5 Automatic Operation  This mode can be set using remote control and the operation is decided by remote control setting temperature, remote control operation mode and indoor intake air temperature.  During operation mode judgment, indoor fan motor (with speed of Lo-) is running for 30 seconds to detect the indoor intake air temperature.

  • Page 76: Outdoor Fan Motor Operation

    [Heating]  According to indoor pipe temperature, automatic heating fan speed is determined as follows. RPM Increased RPM Maintain RPM Reduced Indoor Pipe Temp. B. Feedback control  Immediately after the fan motor started, feedback control is performed once every second. ...

  • Page 77: Airflow Direction

    14.4 Airflow Direction  There are two types of airflow, vertical airflow (directed by horizontal vane) and horizontal airflow (directed by vertical vanes).  Control of airflow direction can be automatic (angles of direction is determined by operation mode, heat exchanger temperature and intake air temperature) and manual (angles of direction can be adjusted using remote control).

  • Page 78: Timer Control

    Side View (Outer Vane) Closed Stopper Position Reference point Step 1 135º Step 2 Step 3 Step 4 Step 5 Figure 2 * The horizontal vane angle tolerance is within +/- 5 degree. 14.4.2 Horizontal Airflow  The horizontal airflow direction louver can be adjusted manually by hand. 14.5 Timer Control ...

  • Page 79: Sleep Mode Operation

    14.6 Sleep Mode Operation SLEEP To maximise comfort while sleeping (CANCEL)  This operation provides you with a comfortable environment while sleeping. It will automatically adjust the sleep pattern temperature during the activation period.  The indoor unit indicator will dim when this operation is activated. This is not applicable if the indicator brightness has been manually dimmed.

  • Page 80: Powerful Mode Operation

    14.10 Quiet Operation (Heating) A. Purpose To provide quiet heating operation compare to normal operation. B. Control condition a. Quiet operation start condition When “POWERFUL/QUIET” button at remote control is pressed. b. Quiet operation stop condition When one of the following conditions is satisfied, quiet operation stops: a.

  • Page 81: Cooling Operation

    15. Operation Control (For Multi Split Connection) During multi split connection, indoor unit’s operation controls are same with single split connection unless specified in this chapter. 15.1 Cooling operation 15.1.1 Thermostat control  Capability supply to indoor unit is OFF (Expansion valve closed) when Intake Air Temperature — Internal setting temperature <...

  • Page 82: Auto Restart Control

    15.4 Automatic Operation  This mode can be set using remote control and the operation is decided by remote control setting temperature, remote control operation mode, indoor intake and outdoor air temperature.  During operation mode judgment, indoor fan motor (with speed of -Lo) and outdoor fan motor are running for 30 seconds to detect the indoor intake and outdoor air temperature.

  • Page 83: Protection Control

    16. Protection Control 16.1 Protection Control for All Operations 16.1.1 Restart Control (Time Delay Safety Control)  The Compressor will not turn on within 3 minutes from the moment operation stops, although the unit is turned on again by pressing OFF/ON button at remote control within this period. ...
  • Page 84 Compressor = OFF 103°C 88°C Compressor Frequency Reduce 99°C 87°C Compressor Frequency Maintain 96°C 86°C Free Comp. temperature 16.1.5 Low Pressure Prevention Control (Gas Leakage Detection)  Control start conditions For 5 minutes, the compressor continuously operates and outdoor total current is between 0.75A and 0.95A. During Cooling and Soft Dry operations: Indoor suction temperature - indoor piping temperature is below 4°C.

  • Page 85: Outdoor Air Temperature Control

    16.2 Protection Control for Cooling & Soft Dry Operation 16.2.1 Outdoor Air Temperature Control  The compressor operating frequency is regulated in accordance to the outdoor air temperature as shown in the diagram below.  This control will begin 1 minute after the compressor starts. ...

  • Page 86: Dew Prevention Control

    16.2.5 Dew Prevention Control 1  To prevent dew formation at indoor unit discharge area.  This control will be activated if: Outdoor air temperature and Indoor pipe temperature judgment by microcontroller is fulfilled. When Cooling or Dry mode is operated more than 20 minutes or more. ...

  • Page 87: Low Pressure Protection Control

    16.3.4 Low Temperature Compressor Oil Return Control  In heating operation, if the outdoor temperature falls below -10°C when compressor starts, the compressor frequency will be regulated up to 600 seconds. 16.3.5 Cold Draught Prevention Control  When indoor pipe temperature is low, cold draught operation starts where indoor fan speed will be reduced. 16.3.6 Deice Operation ...

  • Page 88: Servicing Mode

    17. Servicing Mode 17.1 Auto OFF/ON Button AUTO OPERATION MODE The Auto operation will be activated immediately once the Auto OFF/ON button is pressed. This operation can be used to operate air conditioner with limited function if remote control is misplaced or malfunction. TEST RUN OPERATION (FOR PUMP DOWN/SERVICING PURPOSE) The Test Run operation will be activated if the Auto OFF/ON button is pressed continuously for more than 5 seconds.
  • Page 89 REMOTE CONTROL RECEIVING SOUND OFF/ON MODE The Remote Control Receiving Sound OFF/ON Mode will be activated if the Auto OFF/ON button is pressed continuously for more than 16 seconds (4 “beep” sounds will occur at 16th seconds to identify the Remote Control Receiving Sound Off/On Mode is in standby condition) and press “AC Reset”...

  • Page 90: Remote Control Button

    17.2.2 Operation mode during Heating Only Operation  The table below shows the operation mode comparison when Heating Only Operation Mode Activated and Deactivated. Operation Heating Only Operation Mode Activated Heating Only Operation Mode Deactivated Mode After 30s sampling, the unit will judge the operation After 30s sampling, regardless of the indoor intake or mode base on remote controller temperature setting and AUTO...
  • Page 91 17.3.2 RESET (RC)  To clear and restore the remote control setting to factory default. Press once to clear the memory. 17.3.3 RESET (AC)  To restore the unit’s setting to factory default. Press once to restore the unit’s setting. 17.3.4 TIMER ▲...
  • Page 92 To enter zone 2 area: (Press continuously for T ≥ 5 secs) Once T ≥ 5secs Normal display Enter Zone1 Enter Zone2 mode [range (50~99)] Function & Options list: Note: The functions described in the table may not be applicable to the model and may subject to change without further notice.

  • Page 93: Troubleshooting Guide

    18. Troubleshooting Guide 18.1 Refrigeration Cycle System In order to diagnose malfunctions, make sure that there are no Normal Pressure and Outlet Air Temperature (Standard) electrical problems before inspecting the refrigeration cycle. Gas Pressure Outlet air Temperature Such problems include insufficient insulation, problem with the (kg/cm (°C) power source, malfunction of a compressor and a fan.
  • Page 94 18.1.1 Relationship Between the Condition of the Air Conditioner and Pressure and Electric Current Cooling Mode Heating Mode Condition of the Electric current Electric current air conditioner Low Pressure High Pressure Low Pressure High Pressure during operation during operation Insufficient refrigerant ...

  • Page 95: Breakdown Self Diagnosis Function

    18.2 Breakdown Self Diagnosis Function 18.2.1 Self Diagnosis Function (Three Digits Alphanumeric Code)  When the latest abnormality code on the main Once abnormality has occurred during operation, unit and code transmitted from the remote the unit will stop its operation, and Timer LED controller are matched, power LED will light blinks.

  • Page 96: Error Codes Table

    18.3 Error Codes Table Diagnosis Abnormality / Abnormality Protection Problem Check location display Protection control Judgment Operation No memory of failure — Normal operation — — Indoor fan only  Indoor/outdoor wire terminal Indoor/outdoor operation can Indoor/outdoor After operation for ...
  • Page 97 Diagnosis Abnormality / Abnormality Protection Problem Check location display Protection control Judgment Operation  Check indoor/outdoor Wrong wiring and connection wire and connection Abnormal wiring or — — connecting pipe, expansion pipe piping connection  Expansion valve and lead wire valve abnormality and connector ...
  • Page 98 18.4 Self-diagnosis Method 18.4.1 H11 (Indoor/Outdoor Abnormal Communication) Malfunction Decision Conditions  During startup and operation of cooling and heating, the data received from outdoor unit in indoor unit signal transmission is checked whether it is normal. Malfunction Caused  Faulty indoor unit PCB.
  • Page 99 18.4.2 H12 (Indoor/Outdoor Capacity Rank Mismatched) Malfunction Decision Conditions  During startup, error code appears when different types of indoor and outdoor units are interconnected. Malfunction Caused  Wrong models interconnected.  Wrong indoor unit or outdoor unit PCBs mounted. ...
  • Page 100 18.4.3 H14 (Indoor Intake Air Temperature Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the indoor intake air temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection. ...
  • Page 101 18.4.4 H15 (Compressor Temperature Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor compressor temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection.  Faulty sensor.
  • Page 102 18.4.5 H16 (Outdoor Current Transformer) Malfunction Decision Conditions  An input current, detected by Current Transformer CT, is below threshold value when the compressor is operating at certain frequency value for 3 minutes. Malfunction Caused  Lack of gas  Broken CT (current transformer) ...
  • Page 103 18.4.6 H19 (Indoor Fan Motor – DC Motor Mechanism Locked) Malfunction Decision Conditions  The rotation speed detected by the Hall IC during fan motor operation is used to determine abnormal fan motor (feedback of rotation > 2550 rpm or < 50 rpm) Malfunction Caused ...
  • Page 104 18.4.7 H23 (Indoor Pipe Temperature Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the indoor heat exchanger temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection. ...
  • Page 105 18.4.8 H27 (Outdoor Air Temperature Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor air temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection. ...
  • Page 106 18.4.9 H28 (Outdoor Pipe Temperature Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor pipe temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection. ...
  • Page 107 18.4.10 H30 (Compressor Discharge Temperature Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor discharge pipe temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection. ...
  • Page 108 18.4.11 H32 (Outdoor Heat Exchanger Temperature Sensor 2 Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor heat exchanger temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection.
  • Page 109 18.4.12 H33 (Unspecified Voltage between Indoor and Outdoor) Malfunction Decision Conditions  The supply power is detected for its requirement by the indoor/outdoor transmission. Malfunction Caused  Wrong models interconnected.  Wrong indoor unit and outdoor unit PCBs used.  Indoor unit or outdoor unit PCB defective.
  • Page 110 18.4.13 H34 (Outdoor Heat Sink Temperature Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor heat sink temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection. ...
  • Page 111 18.4.14 H36 (Outdoor Gas Pipe Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor gas pipe temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection. ...
  • Page 112 18.4.15 H37 (Outdoor Liquid Pipe Temperature Sensor Abnormality) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor liquid pipe temperature sensor are used to determine sensor errors. Malfunction Caused  Faulty connector connection. ...
  • Page 113 18.4.16 H97 (Outdoor Fan Motor – DC Motor Mechanism Locked) Malfunction Decision Conditions  The rotation speed detected by the Hall IC during fan motor operation is used to determine abnormal fan motor. Malfunction Caused  Operation stops due to short circuit inside the fan motor winding. ...
  • Page 114 18.4.17 H98 (Error Code Stored in Memory and no alarm is triggered / no TIMER LED flashing) Malfunction Decision Conditions  Indoor high pressure is detected when indoor heat exchanger is detecting very high temperature when the unit is operating in heating operation. ...
  • Page 115 18.4.18 H99 (Indoor Freeze Prevention Protection: Cooling or Soft Dry) Error Code will not display (no Timer LED blinking) but store in EEPROM Malfunction Decision Conditions  Freeze prevention control takes place (when indoor pipe temperature is lower than 2°C) Malfunction Caused ...
  • Page 116 18.4.19 F11 (4-way Valve Switching Failure) Malfunction Decision Conditions  When indoor heat exchanger is cold during heating (except deice) or when indoor heat exchanger is hot during cooling and compressor operating, the 4-way valve is detected as malfunction. Malfunction Caused ...
  • Page 117 18.4.20 F17 (Indoor Standby Units Freezing Abnormality) Malfunction Decision Conditions  When the different between indoor intake air temperature and indoor pipe temperature is above 10°C or indoor pipe temperature is below -1.0°C. Remark: When the indoor standby unit is freezing, the outdoor unit transfers F17 error code to the corresponding indoor unit and H39 to other indoor unit(s).
  • Page 118 18.4.21 F90 (Power Factor Correction Protection) Malfunction Decision Conditions  To maintain DC voltage level supply to power transistor.  To detect high DC voltage level after rectification. Malfunction Caused  During startup and operation of cooling and heating, when Power Factor Correction (PFC) protection circuitry at the outdoor unit main PCB senses abnormal DC voltage level for power transistors.
  • Page 119 18.4.22 F91 (Refrigeration Cycle Abnormality) Malfunction Decision Conditions  The input current is low while the compressor is running at higher than the setting frequency. Malfunction Caused  Lack of gas.  3-way valve close. Troubleshooting AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 120 18.4.23 F93 (Compressor Rotation Failure) Malfunction Decision Conditions  A compressor rotation failure is detected by checking the compressor running condition through the position detection circuit. Malfunction Caused  Compressor terminal disconnect  Faulty Outdoor PCB  Faulty compressor Troubleshooting AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 121 18.4.24 F95 (Outdoor High Pressure Protection: Cooling or Soft Dry) Malfunction Decision Conditions  During operation of cooling or soft dry, when outdoor unit heat exchanger high temperature data is detected by the outdoor unit heat exchanger thermistor. Malfunction Caused ...
  • Page 122 18.4.25 F96 (IPM Overheating) Malfunction Decision Conditions  During operating of cooling and heating, when IPM temperature data (100°C) is detected by the IPM temperature sensor. Multi Models only Compressor Overheating: During operation of cooling and heating, when the compressor OL is activated. Heat Sink Overheating: During operation of cooling and heating, when heat sink temperature data (90°C) is detected by the heat sink temperature sensor.
  • Page 123 18.4.26 F97 (Compressor Overheating) Malfunction Decision Conditions  During operation of cooling and heating, when compressor tank temperature data (112°C) is detected by the compressor tank temperature sensor. Malfunction Caused  Faulty compressor tank temperature sensor  2/3 way valve closed ...
  • Page 124 18.4.27 F98 (Input Over Current Detection) Malfunction Decision Conditions  During operation of cooling and heating, when an input over-current (X value in Total Running Current Control) is detected by checking the input current value being detected by current transformer (CT) with the compressor running.
  • Page 125 18.4.28 F99 (DC Peak Detection) Malfunction Decision Conditions During startup and operation of cooling and heating, when inverter DC peak data is received by the outdoor internal DC Peak sensing circuitry. Malfunction Caused  DC current peak due to compressor failure. ...

  • Page 126: Disassembly And Assembly Instructions

    19. Disassembly and Assembly Instructions WARNING High Voltage is generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with repair work. Failure to heed this caution may result in electric shocks. 19.1 Indoor Electronic Controllers, Cross Flow Fan and Indoor Fan Motor Removal Procedures 19.1.1...
  • Page 127 9 Detach connectors as labeled from the 8 Pull out the main electronic controller. Then pull out main electronic controller controller gently. halfway. AC303 5 Detach the Earth wire screw, lead wires AC306 (Black) and AC304 (Red) CN-FM from the terminal board. 7 Remove screw to remove terminal board complete.
  • Page 128 19.1.4 To Remove Control Board Figure 6 19.1.5 To Remove Cross Flow Fan and Indoor Fan Motor Figure 7 15 Remove the bearing by pulling it out gently. 14 Remove the 2 screw from the evaporator Figure 8 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 129 Figure 9 Figure 10 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...

  • Page 130: Outdoor Electronic Controller Removal Procedure

    19.2 Outdoor Electronic Controller Removal Procedure 19.2.1 CU-TZ20TKE CU-TZ25TKE CU-TZ35TKE Caution! When handling electronic controller, be careful of electrostatic discharge. Remove the 5 screws of the Top Panel. Remove the Control Board as follows: Screws Top Panel Release 3 Terminal Screws Connectors, L, N and Earth Wire Screw.
  • Page 131 19.2.2 CU-TZ42TKE Caution! When handling electronic controller, be careful of electrostatic discharge. Remove the 5 screws of the Top Panel. Remove the Control Board as follows: Fig. 1 Fig. 4 Remove the 8 screws of the Front Panel. Fig. 2 Remove the screw of the Terminal Board Fig.

  • Page 132: Technical Data

    Unit setting: Standard piping length, Hi Fan, Cool mode at 16°C Voltage: 230V 20.1.1 CS-TZ20TKEW/CU-TZ20TKE Indoor (°C) Outdoor DB (°C) 2228 2052 374 2239 2065 372 2247 2035 374 2184 2047 435 2458 2210 297 2291 2160 395 2000 1993 510 2458 1651 379 2418 1650 411 2430 1646 400 2528 1688 347 2707 1795 285 2511 1696 390 2239 1590 512 15.7 1990 1970 400 2005 1985 383 1985 1965 419 1997 1977 408 2215 2192 307 2054 2034 398 1817 1799 510...
  • Page 133 20.1.4 CS-TZ42TKEW/CU-TZ42TKE Indoor (°C) Outdoor DB (°C) 4445 3100 924 4466 3119 919 4484 3074 924 4356 3092 1076 4904 3338 735 4572 3263 975 4200 3010 1260 4903 2494 935 4825 2492 1016 4848 2486 988 5043 2549 857 5401 2711 703 5009 2562 963 4467 2402 1265 15.7 3970 3931 989 4000 3056 945 3960 3027 1034 3984 3944 1009 4418 4374 759 4098 3126 984 3625 2995 1260 18.4 4390 2473 924 4421 2469 894 4451 2485 925 4283 2442 1054 4696 2585 740 4470 2551 976 4018 2393 1261 13.3 3526 3491 1131 3494 2833 946 3772 3008 990 3660 2903 1033 4156 4115 776 3774 3049 988 3367 2857 1257...
  • Page 134 20.2 Heat Mode Performance Data Unit setting: Standard piping length, Hi Fan, Heat mode at 30°C Voltage: 230V 20.2.1 CS-TZ20TKEW/CU-TZ20TKE Indoor (°C) Outdoor WB (°C) 1653 1948 2535 2521 2684 1656 2140 2610 2700 2792 1561 2207 2627 2883 2959 20.2.2...

  • Page 135: Service Data

    Condition Indoor room temperature: 27°C Dry Bulb/19°C Wet Bulb Unit setting: Standard piping length, forced cooling at 16°C, Hi fan Compressor frequency: Rated for cooling operation Piping length: 5m Voltage: 230V 21.1.1 CS-TZ20TKEW CU-TZ20TKE 20.00 19.00 18.00 17.00 16.00 15.00 14.00...
  • Page 136 21.1.2 CS-TZ25TKEW CU-TZ25TKE 20.00 19.00 18.00 17.00 16.00 15.00 14.00 13.00 12.00 Outdoor Air Temperature (°C) 4.00 3.50 3.00 2.50 2.00 1.50 1.00 Outdoor Air Temperature (°C) 1.30 1.25 1.20 1.15 1.10 1.05 1.00 0.95 0.90 0.85 0.80 Outdoor Air Temperature (°C) AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 137 21.1.3 CS-TZ35TKEW CU-TZ35TKE 18.00 17.00 16.00 15.00 14.00 13.00 12.00 Outdoor Air Temperature (°C) 5.20 4.80 4.40 4.00 3.60 3.20 2.80 2.40 2.00 Outdoor Air Temperature (°C) 1.20 1.10 1.00 0.90 0.80 0.70 0.60 Outdoor Air Temperature (°C) AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 138 21.1.4 CS-TZ42TKEW/CU-TZ42TKE 14.50 14.00 13.50 13.00 12.50 12.00 11.50 Outdoor Air Temperature (°C) 7.50 6.50 5.50 4.50 3.50 2.50 1.50 Outdoor Air Temperature (°C) 1.10 1.00 0.90 0.80 0.70 0.60 Outdoor Air Temperature (°C) AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 139 Indoor room temperature: 20°C Dry Bulb/ -°C Wet Bulb Unit setting: Standard piping length, forced heating at 30°C, Hi fan Compressor frequency: Rated for Heating operation Piping length: 5m Voltage: 230V 21.2.1 CS-TZ20TKEW CU-TZ20TKE Outdoor Air Temperature (°C) 4.00 3.50 3.00 2.50 2.00...
  • Page 140 21.2.2 CS-TZ25TKEW CU-TZ25TKE Outdoor Air Temperature (°C) 4.50 4.00 3.50 3.00 2.50 2.00 1.50 Outdoor Air Temperature (°C) 3.50 3.00 2.50 2.00 1.50 1.00 Outdoor Air Temperature (°C) AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 141 21.2.3 CS-TZ35TKEW CU-TZ35TKE Outdoor Air Temperature (°C) 5.10 4.90 4.70 4.50 4.30 4.10 3.90 3.70 3.50 3.30 3.10 2.90 2.70 Outdoor Air Temperature (°C) 3.00 2.80 2.60 2.40 2.20 2.00 1.80 1.60 1.40 1.20 Outdoor Air Temperature (°C) AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 142 21.2.4 CS-TZ42TKEW CU-TZ42TKE Outdoor Air Temperature (°C) 7.00 6.50 6.00 5.50 5.00 4.50 4.00 Outdoor Air Temperature (°C) 3.60 3.40 3.20 3.00 2.80 2.60 2.40 2.20 2.00 1.80 Outdoor Air Temperature (°C) AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 143 21.3 Piping Length Correction Factor The characteristic of the unit has to be corrected in accordance with the piping length. 21.3.1 CS-TZ20TKEW CU-TZ20TKE CS-TZ25TKEW CU-TZ25TKE CS-TZ35TKEW CU-TZ35TKE CS-TZ42TKEW CU-TZ42TKE 1.02 1.00 0.98 0.96 0.94 0.92 Pipe Length (m) 1.04 1.02 1.00...
  • Page 144 22. Exploded View and Replacement Parts List 22.1 Indoor Unit CWH5 5025J CWH5 5051J Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 145 REF. SAFETY PART NAME & DESCRIPTION QTY. CS-TZ20TKEW CS-TZ25TKEW CS-TZ35TKEW REMARK CHASSIS COMPLETE ACXD50C00440 ← ← FAN MOTOR L6CBYYYL0195 ← ← CROSS-FLOW FAN COMPLETE CWH02C1159 ← ← SCREW - CROSS-FLOW FAN CWH551146 ← ← BEARING ASSY CWH64K1010 ← ← EVAPORATOR ACXB30C02730 ←...
  • Page 146 REF. SAFETY PART NAME & DESCRIPTION QTY. CS-TZ20TKEW CS-TZ25TKEW CS-TZ35TKEW REMARK INSTALLATION INSTRUCTION ACXF60-05750 ← ← INSTALLATION INSTRUCTION ACXF60-05760 ← ← (NOTE)  All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).  “O” marked parts are recommended to be kept in stock.
  • Page 147 SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-TZ42TKEW CS-MTZ16TKE REMARK CHASSIS COMPLETE ACXD50C00440 ← FAN MOTOR L6CBYYYL0195 ← CROSS-FLOW FAN COMPLETE CWH02C1159 ← SCREW - CROSS-FLOW FAN CWH551146 ← BEARING ASSY CWH64K1010 ← EVAPORATOR ACXB30C02740 ACXB30C02730 FLARE NUT (LIQUID) CWT251030 ←...
  • Page 148 22.2 Outdoor Unit 22.2.1 CU-TZ20TKE CU-TZ25TKE CU-TZ35TKE Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 149 V-COIL COMPLETE (EXP. VALVE) CWA43C2603 ← ← STRAINER CWB11094 ← ← DISCHARGE MUFFLER CWB121021 ← ← PLATE SPRING CWH71044 ← PANASONIC BADGE CWE373439 ← ← INSTALLATION INSTRUCTION ACXF60-06330 ← ← INSTALLATION INSTRUCTION ACXF60-06340 ← ← INSTALLATION INSTRUCTION ACXF60-06350 ← ←...
  • Page 150 REF. SAFETY PART NAME & DESCRIPTION QTY. CU-TZ20TKE CU-TZ25TKE CU-TZ35TKE REMARK INSTALLATION INSTRUCTION ACXF60-06380 ← ← INSTALLATION INSTRUCTION ACXF60-06390 ← ← INSTALLATION INSTRUCTION ACXF60-06400 ← ← INSTALLATION INSTRUCTION ACXF60-06410 ← ← INSTALLATION INSTRUCTION ACXF60-06420 ← ← (NOTE)  All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488). ...
  • Page 151 22.2.2 CU-TZ42TKE Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
  • Page 152 CONTROL BOARD COVER CO. CWH13C1253 4-WAYS VALVE ACXB00-00130 V-COIL COMPLETE (4-WAY VALVE) ACXA43C00250 V-COIL COMPLETE CWA43C2603 DISCHARGE MUFFLER CWB121021 STRAINER CWB11094 PANASONIC BADGE CWE373439 BAG - COMPLETE CWG87C900 SOUND PROOF MATERIAL CWG302701 INSTALLATION INSTRUCTION ACXF60-06330 INSTALLATION INSTRUCTION ACXF60-06340 INSTALLATION INSTRUCTION ACXF60-06350...
  • Page 153 SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-TZ42TKE REMARK INSTALLATION INSTRUCTION ACXF60-06370 INSTALLATION INSTRUCTION ACXF60-06380 INSTALLATION INSTRUCTION ACXF60-06390 INSTALLATION INSTRUCTION ACXF60-06400 INSTALLATION INSTRUCTION ACXF60-06410 INSTALLATION INSTRUCTION ACXF60-06420 (NOTE)  All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488). ...
