Contents
Introduction .................................... 2
In brief ............................................ 6
Keys, doors and windows ............ 19
Seats, restraints ........................... 30
Storage ........................................ 44
Instruments and controls ............. 49
Lighting ........................................ 66
Climate control ............................. 72
Driving and operating ................... 77
Vehicle care ................................. 97
Service and maintenance .......... 130
Technical data ........................... 133
Customer information ................ 151
Index .......................................... 152
Back to overview

Advertisement

Table of Contents
loading

Related Manuals for Opel Movano

Summary of Contents for Opel Movano

  • Page 1 Contents Introduction ........2 In brief ..........6 Keys, doors and windows .... 19 Seats, restraints ......30 Storage ........44 Instruments and controls ..... 49 Lighting ........66 Climate control ......72 Driving and operating ....77 Vehicle care ......... 97 Service and maintenance ..
  • Page 2 Introduction Introduction Back to overview...

  • Page 3: Introduction

    "Service and prices. Experienced mechanics ■ The Owner's Manual uses the maintenance" and "Technical data" trained by Opel work according to factory engine designations. The as well as on the identification plate. specific Opel instructions. corresponding sales designations...
  • Page 4 Disregarding this information may lead to vehicle damage. Symbols Page references are indicated with 3. 3 means "see page". We wish you many hours of pleasurable driving. Adam Opel GmbH Back to overview...
  • Page 5 Introduction Back to overview...

  • Page 6: In Brief

    In brief In brief Vehicle unlocking Seat adjustment Seat positioning Initial drive information Press button c to unlock the doors. Open the doors by pulling the Pull handle, slide seat, release handles. handle. Press button G; only the load Seat position 3 31, Seat adjustment compartment is unlocked.
  • Page 7 In brief Seat backrests Seat height Lumbar support Pull lever, adjust inclination and Lever motion To adjust, turn the handwheel. release lever. Allow the seat to = seat higher Seat position 3 31, Seat adjustment engage audibly. down = seat lower 3 32.

  • Page 8: Head Restraint Adjustment

    In brief Head restraint adjustment Seat belt Mirror adjustment Interior mirror Press release catch, adjust height, Pull out the seat belt and engage in engage. belt buckle. The seat belt must not be twisted and must fit close against the Adjust the lever on the underside to Head restraints 3 30.
  • Page 9 In brief Steering wheel adjustment Exterior mirrors Select the relevant exterior mirror and Unlock lever, adjust steering wheel, adjust. then engage lever and ensure it is fully locked. Convex exterior mirrors 3 26, Electric adjustment 3 26, Heated Do not adjust steering wheel unless exterior mirrors 3 27.
  • Page 10 In brief Back to overview...
  • Page 11 In brief Instrument panel overview 10 Centre air vents ....75 11 Infotainment system ..... 10 Fixed air vents ...... 75 12 Passenger airbag ....39 Headlight range 13 Glovebox ......45 adjustment ......67 Storage compartment ..44 Parking assist ....... 92 Traction Control system ..
  • Page 12 In brief Back to overview...

  • Page 13: Exterior Lighting

    In brief Exterior lighting Headlight flash, high beam and Turn and lane-change signals low beam right = lever up Turn light switch left = lever down Pull lever. = Off High beam 3 67, Headlight flash = Sidelights Turn and lane-change signals 3 67.

  • Page 14: Washer And Wiper Systems

    In brief Horn Washer and wiper systems Hazard warning flashers Windscreen wiper Operated with the ¨ button. Press j. Hazard warning flashers 3 68. 0 = off P = timed interval wiping or automatic wiping with rain sensor = slow = fast Windscreen wiper 3 50, Wiper blade replacement 3 103.

  • Page 15: Climate Control

    In brief Climate control Windscreen washer Demisting and defrosting the windows Heated rear window, heated exterior mirrors Pull lever. Air distribution to V. Windscreen washer 3 50, Washer fluid 3 101. Set temperature control to warmest Heating is operated by pressing the level.
  • Page 16 In brief Transmission Electronic climate control system Manual transmission automated 3 73. Manual transmission = neutral = drive Reverse: with the vehicle stationary, = higher gear depress clutch pedal and then pull up = lower gear the collar on the selector lever and A/M = switch between automatic engage the gear.

  • Page 17: Starting Off

    In brief Starting off Parking Starting the engine ■ Always apply parking brake without Check before starting off pressing release button. Apply as ■ Tyre pressure and condition firmly as possible on a downhill 3 116, 3 148. slope or uphill slope. Depress foot brake at the same time to reduce ■...
  • Page 18 In brief ■ Close the windows. ■ The engine cooling fans may run after the engine has been switched off 3 98. ■ After running at high engine speeds or with high engine loads, operate the engine briefly at a low load or run in neutral for approx.

  • Page 19: Keys, Doors And Windows

    Keys, doors and windows Keys, doors and Keys, locks Radio remote control windows Keys Replacement keys Keys, locks ........19 The key number is specified in the Car Pass or on a detachable tag. Doors ........... 23 The key number must be quoted Vehicle security ......

  • Page 20: Central Locking System

    Keys, doors and windows Central locking system Fault Batteries do not belong in household waste. They must be disposed of at If the central locking system cannot Unlocks and locks doors and load an appropriate recycling collection be operated with the radio remote compartment.
  • Page 21 Keys, doors and windows If no door is opened within approx. Load compartment 2 minutes after the vehicle has been unlocked with the remote control, the vehicle is re-locked automatically. Locking Close doors and load compartment. If the doors are not closed properly, the central locking system will not work.

  • Page 22: Child Locks

    Keys, doors and windows Child locks Fault in central locking system Unlocking 9 Warning Manually unlock the door by turning the key in the lock. The other doors Use the child locks whenever can be opened by pulling the interior children are occupying the rear handle.

  • Page 23: Sliding Door

    Keys, doors and windows Doors Sliding door The left hand rear door is released To open the doors to 180º, release using the lever. locking stays from the catches on the door frames. 9 Warning When opening the doors to 270º, the The door can be locked from inside doors are retained in the fully open The rear lights may be obscured if...

  • Page 24: Vehicle Security

    Keys, doors and windows Vehicle security Activating Anti-theft locking system 9 Warning Do not use the system if there are people in the vehicle! The doors cannot be unlocked from the inside. The system deadlocks the doors. All doors must be closed or the system 9 Warning cannot be activated.
  • Page 25 Keys, doors and windows Activation Activation without monitoring of Deactivation passenger compartment Unlocking the vehicle deactivates the anti-theft alarm system. Turn signal lights flash once upon deactivation. When unlocking the vehicle using the key, the alarm siren will sound. To stop the siren, switch on the ignition.

  • Page 26: Exterior Mirrors

    Keys, doors and windows Exterior mirrors Immobiliser Electric adjustment The system is part of the ignition Convex shape switch and checks whether the vehicle is allowed to be started with The convex exterior mirror reduces the key being used. blind spots. The shape of the mirror makes objects appear smaller, which The electronic immobiliser activates will affect the ability to estimate...

  • Page 27: Interior Mirrors

    Keys, doors and windows Interior mirrors Folding Heated Manual anti-dazzle Operated by pressing the Ü button. For pedestrian safety, the exterior mirrors will swing out of their normal Heating works with the engine mounting position if they are struck running and is switched off To reduce dazzle, adjust the lever on with sufficient force.

  • Page 28: Rear Windows

    Keys, doors and windows Windows Rear windows Manual windows Sliding side windows To open, pull catch and slide open. To The door windows can be opened or close, pull catch and slide window closed with the window winders. until catch engages. Note Power windows During window opening or closing,...

  • Page 29: Sun Visors

    Keys, doors and windows Heating works with the engine running and is switched off automatically after a short time. Sun visors The sun visors can be folded down or swivelled to the side to prevent dazzling. If the sun visors have integral mirrors, the mirror covers should be closed when driving.

  • Page 30: Seats, Restraints

    Seats, restraints Seats, restraints Head restraints Height adjustment Position Head restraints ......30 9 Warning Front seats ........31 Seat belts ........35 Only drive with the head restraint Airbag system ......38 set to the proper position. Child restraints ......41 Press the catch, adjust height and engage.

  • Page 31: Seat Position

    Seats, restraints Front seats Removal ■ Sit with shoulders as far back against the backrest as possible. Set the backrest rake so that it is Seat position possible to reach the steering wheel with arms slightly bent. 9 Warning Maintain contact between shoulders and the backrest when Only drive with the seat correctly turning the steering wheel.

  • Page 32: Seat Adjustment

    Seats, restraints Seat adjustment Pull handle, slide seat, release Seat backrests handle. 9 Danger Suspension seat positioning Do not sit nearer than 25 cm from the steering wheel, to permit safe airbag deployment. 9 Warning Never adjust seats while driving as they could move uncontrollably.
  • Page 33 Seats, restraints Suspension seat backrests Seat height Suspension seat height Pull lever, adjust inclination and Pull forward lever up to adjust the Lever motion release lever. Allow the seat to front of the seat and rear lever to = seat higher engage.
  • Page 34 Seats, restraints Lumbar support Suspension seat lumbar support Suspension seat sensitivity Adjust lumbar support by activating Adjust lumbar support by turning the To adjust the level of sensitivity rotate bulb or releasing button. handwheel while relieving the load on knob. the backrest.

  • Page 35: Seat Belts

    Seats, restraints Seat belts Armrest Heating Press the ß button for the respective Armrest can be folded up when not The seat belts are locked during seat with the engine running. Press required. heavy acceleration or deceleration of the ß button again to switch off. the vehicle holding the occupants in Seat heating is thermostatically the sitting position.
  • Page 36 Seats, restraints Three-point seat belt Seat belts are only designed to be Deployment of the belt pretensioners used by only one person at a time. is indicated by continuous illumination They are not suitable for people of control indicator v 3 59. Fastening smaller than 150 cm.

  • Page 37: Height Adjustment

    Seats, restraints Height adjustment Adjust the height so that the belt lies Loose or bulky clothing prevents the across the shoulder. It must not lie belt from fitting snugly. Do not place 1. Pull belt out slightly. across the throat or upper arm. objects such as handbags or mobile 2.

  • Page 38: Airbag System

    Seats, restraints Airbag system Removing Using the seat belt while pregnant The airbag system consists of a number of individual systems depending on the scope of equipment. When triggered the airbags inflate within milliseconds. They also deflate so quickly that it is often unnoticeable during the collision.

  • Page 39: Front Airbag System

    Seats, restraints Front airbag system Note The airbag systems and belt The front airbag system consists of pretensioner control electronics are one airbag in the steering wheel and located in the centre console area. one in the instrument panel on the Do not put any magnetic objects in front passenger side.

  • Page 40: Airbag Deactivation

    Seats, restraints The side airbag system consists of an 9 Warning 9 Warning airbag in each front seat backrest. This can be identified by the word Optimum protection is only Keep the area in which the airbag AIRBAG. provided when the seat is in the inflates clear of obstructions.

  • Page 41: Child Restraints

    Child restraints 9 Danger Child restraint systems Risk of fatal injury for a child using a child restraint system together We recommend the Opel child with activated front passenger restraint system which is tailored airbag. specifically to the vehicle. Risk of fatal injury for an adult...
  • Page 42 Seats, restraints than 150 cm, we strongly advise to 9 Warning use an appropriate child restraint system, even though this might, due When using a child restraint to the age of the child, no longer be system on the front passenger legally binding.

  • Page 43: Child Restraint Installation Locations

    Seats, restraints Child restraint installation locations Permissible options for fitting a child restraint system Front seats - all variants Weight and age class Single seat - front passenger Bench seat - front passenger without airbag with airbag without airbag with airbag centre outer centre...

  • Page 44: Storage

    Storage Storage Storage compartments Document holder Instrument panel storage Storage compartments ....44 Load compartment ....... 47 Roof rack system ......47 Loading information ..... 48 Withdraw the document holder from the instrument panel by pulling the base towards you and then swivelling Storage compartments, pockets and it downwards.

  • Page 45: Glovebox

    Storage Glovebox Front storage Sunglasses storage Three coat hooks are located on the cabin bulkhead Folding passenger seatback The glovebox should be closed whilst Fold down to open. driving. Do not use for storing heavy objects. Glovebox cooler 3 75. The passenger seat backrest, when Cupholders folded fully forwards, features storage...

  • Page 46: Overhead Console

    Storage Overhead console Underseat storage Overcab storage The total weight in this compartment The total weight in these Using the two loops on the passenger must not exceed 35 kg. compartments must not exceed 5 kg. seat cushion, pull the cushion forwards to gain access to the storage under the seat.

  • Page 47: Load Compartment

    Storage Load compartment Roof rack system Warning triangle The warning triangle can be Lashing eyes Roof rack accommodated in the space under the front passenger seat. For safety reasons and to avoid damage to the roof, the vehicle Underseat storage 3 46. approved roof rack system is recommended.

  • Page 48: Loading Information

    Storage Loading information To calculate the EC kerb weight, enter the data for your vehicle in the Weights table at the front of this ■ Heavy objects in the load manual. compartment should be placed as The EC kerb weight includes far forward as possible.

  • Page 49: Instruments And Controls

    Instruments and controls Instruments and Controls Steering wheel controls controls Steering wheel adjustment Controls ........49 Warning lights, gauges and indicators ........54 Information displays ..... 63 Vehicle messages ......63 Trip computer ....... 64 Tachograph ........65 The cruise control and speed limiter can be operated via the controls on the steering wheel.

  • Page 50: Horn

    Instruments and controls Horn Steering column controls Windscreen wiper/washer Windscreen wiper Press j. The Infotainment system can be operated via the controls on the K = timed interval wipe steering column. = slow Further information is available in the = fast Infotainment manual.
  • Page 51 Instruments and controls Automatic wiping with rain sensor Adjustable sensitivity of the rain Windscreen washer sensor Turn the adjuster wheel to adjust the sensitivity: = turn adjuster wheel sensitivity downwards high = turn adjuster wheel sensitivity upwards K = automatic wiping with rain Pull lever.

  • Page 52: Outside Temperature

    Instruments and controls Outside temperature The Infotainment system must be off. 9 Warning Activate setting mode by holding the Ö button depressed for approx. The road surface may already be 2 seconds. The flashing value is icy even though the display adjusted using the ;...

  • Page 53: Power Outlet

    Instruments and controls Power outlets Caution Do not damage the outlet by using unsuitable plugs. Cigarette lighter Connecting electrical accessories while the engine is off will discharge 12 V power outlets are located in the the battery. Do not exceed the instrument panel and in the rear of the maximum power consumption of vehicle.

  • Page 54: Instruments

    Instruments and controls Warning lights, gauges Ashtrays Odometer and indicators Caution Speedometer To be used only for ash and not for combustible rubbish. Portable ashtray Displays the recorded distance. Trip odometer Press either button once on the end Indicates vehicle speed. of the windscreen wiper lever to Maximum speed may be restricted by display the trip odometer.

  • Page 55: Fuel Gauge

    Instruments and controls Tachometer Fuel gauge Engine coolant temperature gauge Displays the engine speed. Displays the fuel level in the tank. Drive in a low engine speed range for Control indicator Y illuminates if the Displays the coolant temperature. each gear as much as possible. level in the tank is low.

  • Page 56: Engine Oil Level Monitor

    Instruments and controls ⃞⃞⃞⃞⃞⃞ = Maximum level The vehicle needs a service. Caution ⃞⃞⃞＿＿＿ = Intermediate level Seek the assistance of a workshop. ＿＿＿＿＿＿ = Minimum level If engine coolant temperature is Resetting the service display too high, stop vehicle, switch off If the minimum engine oil level is Select the distance before service engine.

  • Page 57: Control Indicators

    Instruments and controls The mode or selected gear of the manual transmission automated is shown in the transmission display. = Reverse gear = Neutral = Automatic mode kg = Laden mode V = Winter mode T = Apply footbrake W = Transmission electronics Control indicators The control indicators described are not present in all vehicles.
  • Page 58 Instruments and controls Control indicators in the instrument cluster Back to overview...

  • Page 59: Turn Signal

    Instruments and controls Turn signal Deployment of the belt pretensioners 9 Danger or airbags is indicated by continuous O flashes green. illumination of v. Risk of fatal injury for a child using Flashes if a turn signal or the hazard a child restraint system together warning flashers are activated.

  • Page 60: System Check

    Instruments and controls Illuminates when the ignition is Depending on the type of fault, Illuminates after the ignition is switched on and goes out shortly after a warning message may also appear switched on if the parking brake is the engine starts. in the multifunction display.

  • Page 61: Engine Electronics

    Instruments and controls If control indicators u, F, R and C Illuminates while driving Illuminates when the engine is illuminate, the ABS and ESP are running The system is switched off. The deactivated and the message message ESP OFF will also appear in BRAKING FAULT is displayed.

  • Page 62: Rear Fog Light

    Instruments and controls Rear fog light Illuminates when the ignition is 9 Warning switched on and goes out shortly after r illuminates yellow. the engine starts. When the engine is off, Illuminated when the rear fog light is considerably more force is needed Illuminates when the engine is on 3 69.

  • Page 63: Information Displays

    Instruments and controls Information displays Vehicle messages automatically and F remains illuminated. The fault will then be stored in the on board system. Triple-Info-Display Messages appear in the multifunction display, in combination with F or C. Fault messages Information messages CHECK ESP Information messages CHECK FUEL FILTER...

  • Page 64: Cruise Control And Speed Limiter

    Instruments and controls Trip computer Warning chimes ■ Cruise control and speed limiter stored speed When starting the engine or ■ Fault and information messages whilst driving shown in the multifunction display ■ During operation of the turn and Fuel used lane-change signals.
  • Page 65 Instruments and controls Tachograph Range Reset trip computer information The value is displayed after driving To reset the trip computer, select one a distance of 400 metres. of its functions then press and hold either button. The range is calculated from the current contents of the fuel tank and The trip computer will reset the average consumption since the...

  • Page 66: Lighting

    Lighting Lighting Exterior lighting Automatic light control Light switch Exterior lighting ......66 Interior lighting ......69 Lighting features ......70 Light switch set to AUTO: When the engine is running, headlights are switched on when external light Turn light switch: conditions are poor.

  • Page 67: Headlight Range Adjustment

    Lighting High beam Headlight range Headlights when driving adjustment abroad The asymmetrical headlight beam Manual headlight range extends visibility at the edge of the adjustment road at the passenger side. However, when driving in countries where traffic drives on the opposite side of the road, adjust the headlights to prevent dazzling.

  • Page 68: Turn And Lane-Change Signals

    Lighting Adaptive forward lighting Turn and lane-change If the lever is moved past the first stop, the indicator is switched on signals constantly. Switch the indicator off Cornering light manually by moving the lever to its Depending on the steering angle, original position.

  • Page 69: Rear Fog Light

    Lighting Interior lighting Rear fog lights Misted light covers The inside of the light covers may mist Interior lights up briefly in poor, wet and cold weather conditions, in heavy rain or With the switch in its central position, after washing. The mist disappears the light functions as a courtesy light quickly by itself;...

  • Page 70: Exit Lighting

    Lighting Lighting features Load compartment lighting Front courtesy light with reading light Exit lighting Operated by pressing the switch: Operated with the l button. ■ On constantly Headlights come on for approx. The reading light can be directed as ■ Controlled by the function of the 1 minute after the vehicle is parked required.
  • Page 71 Lighting This action can be repeated up to four times to a maximum period of 4 minutes. The lighting is turned off immediately by turning the light switch to any postion and returning to 7. Back to overview...

  • Page 72: Climate Control

    Climate control Climate control Climate control systems Heating will not be fully effective until the engine has reached normal operating temperature. Heating and ventilation system Fan speed Climate control systems ....72 Adjust the air flow by switching the fan Air vents ........

  • Page 73: Air Conditioning System

    Climate control Air conditioning system the freezing point. Therefore ■ Set temperature control to coldest condensation may form and drip from level. under the vehicle. ■ Set fan speed to highest level. If no cooling or drying is required, ■ Open all air vents. switch the cooling system off to save fuel.
  • Page 74 Climate control AUTO = Automatic mode Temperature preselection Demisting and defrosting the = air recirculation windows Temperatures can be set to the = demisting and defrosting desired value. Press the V button. For reasons of comfort, change Heated rear window Ü 3 28. Temperature and air distribution are temperature only in small increments.

  • Page 75: Fixed Air Vents

    Climate control Air vents Side air vents 9 Warning Adjustable air vents The exchange of fresh air is reduced in air recirculation mode. Centre air vents In operation without cooling the air humidity increases, so the windows may mist up. The quality of the passenger compartment air deteriorates, which may cause the vehicle occupants to feel drowsy.

  • Page 76: Air Conditioning Regular

    Climate control Maintenance Air conditioning regular operation Air intake In order to ensure continuously efficient performance, cooling must be operated for a few minutes once a month, irrespective of the weather and time of year. Operation with cooling is not possible when outside temperature is too low.

  • Page 77: Driving And Operating

    Driving and operating Driving and operating Driving hints Starting and operating Control of the vehicle New vehicle running-in Do not brake unnecessarily hard for Driving hints ......... 77 Never coast with engine not the first few journeys and after new Starting and operating ....

  • Page 78: Idle Speed Control

    Driving and operating Ignition switch positions Starting the engine Start attempts should not last longer than 15 seconds. If engine does not start, wait 15 seconds before repeating starting procedure. If necessary, depress accelerator before repeating starting procedure. Before restarting or to switch off the engine, turn key back to St.

  • Page 79: Engine Exhaust

    Driving and operating Engine exhaust The function will be deactivated uphill slopes. Operate the foot when: brake at the same time to reduce operating force. ■ The clutch pedal is depressed 9 Danger ■ Switch off the engine and ignition. ■...

  • Page 80: Catalytic Converter

    Driving and operating Diesel particle filter Malfunction indicator light 3 59. Caution The diesel particle filter system filters harmful soot particles out of the Fuel grades other than those listed exhaust gases. The system includes on page 3 93, 3 135 could a self-cleaning function that runs damage the catalytic converter or automatically during driving.
  • Page 81 Driving and operating Manual transmission Manual transmission Caution automated It is inadvisable to drive with hand resting on the selector lever. The MTA transmission permits manual (manual mode) or automatic gear shifting (automatic mode), both with automatic clutch control. Transmission display To engage reverse, with the vehicle stationary depress the clutch pedal, pull up the collar on the selector lever...

  • Page 82: Starting The Engine

    Driving and operating Starting the engine Always move the selector lever in the start off quickly, release the foot brake appropriate direction as far as it will and accelerate immediately after Depress the foot brake when starting go. Upon release, it automatically engaging a gear.

  • Page 83: Manual Mode

    Driving and operating Manual mode warning may sound as a signal to Rocking the vehicle depress the foot brake or apply the Rocking the vehicle is only If a higher gear is selected when the parking brake. permissible if the vehicle is stuck in engine speed is too low, or a lower sand, mud, snow or a hole.
  • Page 84 Driving and operating Electronic driving Deactivation It is possible to use the Laden mode in both manual and automatic modes. The Winter mode is switched off by: programmes In both cases, the gearshifting ■ pressing the V button again, patterns are adapted automatically Winter mode V ■...
  • Page 85 Driving and operating Brakes Fault Kickdown In the event of a fault, control indicator The brake system comprises two W is shown in the transmission independent brake circuits. display. Continued driving is possible provided the vehicle is driven with If a brake circuit fails, the vehicle can care and anticipation.

  • Page 86: Parking Brake

    Driving and operating Antilock brake system Parking brake 9 Warning Antilock brake system (ABS) prevents the wheels from locking. If there is a fault in the ABS, the wheels may be liable to lock due ABS starts to regulate brake pressure to braking that is heavier than as soon as a wheel shows a tendency normal.

  • Page 87: Traction Control System

    Driving and operating Ride control systems Brake assist 9 Warning If the brake pedal is depressed Traction Control system quickly and forcefully, maximum Do not let this special safety brake force is automatically applied feature tempt you into taking risks The Traction Control system (TC) is (full braking).

  • Page 88: Electronic Stability Program

    Driving and operating Press the v button. Control indicator Deactivation ESP® Plus is operational as soon as v illuminates in the instrument the ignition is switched on and control cluster. indicator v extinguishes in the instrument cluster. TC is reactivated by pressing the v button again.

  • Page 89: Cruise Control

    Driving and operating Cruise control When vehicle speed reaches Activation 50 km/h the ESP® Plus function will be restored automatically. The cruise control can store and maintain speeds of 30 km/h and Fault above. Deviations from the stored If the system detects a fault, control speeds may occur when driving uphill indicator F illuminates in the or downhill.
  • Page 90 Driving and operating Increase speed With cruise control active, the vehicle speed can be increased continuously or in small increments by holding down or tapping switch < repeatedly. When the switch is released the current speed is stored and maintained. Alternatively, accelerate to the desired speed and store by pressing switch <.
  • Page 91 Driving and operating Automatic deactivation: Activation Where the limit speed cannot be maintained, e.g. when driving on ■ Vehicle speed drops below a steep decline, the limit speed will 30 km/h, flash on the multifunction display. ■ The brake pedal is depressed, Increase limit speed ■...

  • Page 92: Parking Assist

    Driving and operating Object detection Deactivation Note Attached parts in the detection area Press switch §: speed limiter is systems cause system malfunction. deactivated and the vehicle can be driven normally. Activation Parking assist The limit speed is stored and When reverse gear is engaged, the The parking assist makes reverse a corresponding message appears in...

  • Page 93: Fuel For Diesel Engines

    Driving and operating Fuel Temporary deactivation Temporarily deactivate the system by pressing the r button on the Fuel for diesel engines instrument panel with the ignition on Only use diesel fuel that complies and reverse gear engaged. Control with DIN EN 590. The fuel must have indicator in the button illuminates.
  • Page 94 Driving and operating Refuelling Fuel consumption - CO The fuel filler flap can only be opened if the vehicle is unlocked and the door Emissions is opened. Open the fuel filler flap by 9 Danger hand. The determination of fuel consumption is regulated by Before refuelling, switch off engine European directive...

  • Page 95: General Information

    Driving and operating Towing equipment may result in slightly A maximum speed of 80 km/h must higher fuel consumption and CO not be exceeded, even in countries where higher speeds are permitted. emission levels and a lower maximum General information speed.

  • Page 96: Towing Equipment

    Driving and operating The permissible trailer loads are The maximum permissible vertical Towing equipment audible specified in the vehicle documents. In coupling load is specified on the warning general, they are valid for gradients towing equipment identification plate For vehicles fitted with towing up to max.

  • Page 97: Vehicle Care

    Vehicle care Vehicle care General Information ■ Change engine oil. ■ Drain washer fluid reservoir. Accessories and vehicle ■ Check coolant antifreeze. modifications ■ Adjust tyre pressure to the value General Information ..... 97 specified for full load. We recommend using Genuine Parts Vehicle checks ......
  • Page 98 Vehicle care Vehicle checks ■ Check the engine oil level. 9 Danger ■ Check the coolant level. Performing work ■ Fit the number plate, if necessary. The ignition system generates extremely high voltages. Do not touch. End-of-life vehicle recovery Bonnet Information on end-of-life vehicle recovery centres and the recycling of Opening...

  • Page 99: Engine Oil

    Vehicle care Closing Before closing the bonnet, press the support into the holder. Lower the bonnet and allow it to drop into the catch. Check that the bonnet is engaged. Engine oil It is advisable to check the engine oil level manually before embarking on a long journey.

  • Page 100: Engine Coolant

    Vehicle care Engine coolant If the cooling system is cold, the coolant level should be just above the The coolant provides freeze MINI mark. Top up if the level is low. protection down to approx. -28 °C. 9 Warning Caution Allow the engine to cool before Only use approved antifreeze.

  • Page 101: Power Steering Fluid

    Vehicle care Power steering fluid Washer fluid Once new brake linings are installed, do not brake unnecessarily hard for the first few journeys. Brake pad wear indicator F 3 60, 3 85. Brake fluid 9 Warning Brake fluid is poisonous and corrosive.

  • Page 102: Diesel Fuel Filter

    Vehicle care Diesel fuel filter When topping up, ensure maximum Battery access cleanliness as contamination of the brake fluid can lead to brake system malfunctions. Have the cause of the loss of brake fluid remedied by a workshop. Only use brake fluid approved for your vehicle.

  • Page 103: Diesel Fuel System

    Vehicle care Diesel fuel system 3. Manually operate the in-line Lift wiper arm, press retaining clip supply pump slowly and steadily towards wiper arm and detach wiper bleeding until fuel discharging from the blade. loosened vent screw is free of air bubbles.

  • Page 104: Bulb Replacement

    Vehicle care Bulb replacement High beam Switch off the ignition and turn off the relevant switch or close the doors. Only hold a new bulb at the base! Do not touch the bulb glass with bare hands. Use only the same bulb type for replacement.
  • Page 105 Vehicle care Low beam Sidelights 5. Detach bulb from bulb holder and renew the bulb. 1. Remove headlamp protective 1. Remove protective cover. 6. Insert the bulb holder, engaging cover. 2. Detach wiring connector from the two lugs in the reflector 2.

  • Page 106: Adaptive Forward Lighting

    Vehicle care Adaptive forward lighting Cornering light 5. Detach bulb from bulb holder and 5. Detach bulb from bulb holder and renew the bulb. renew the bulb. 6. Insert the bulb holder, engaging 6. Insert the bulb holder, engaging the two lugs in the reflector the two lugs in the reflector Headlights have separate systems for housing and rotate clockwise to...

  • Page 107: Front Turn Signal Lights

    Vehicle care Front turn signal lights Tail lights Rear brake, tail, turn signal, reverse and fog tail lights 5. Detach bulb from bulb holder and renew the bulb. 1. Remove protective cover. 6. Insert the bulb holder, engaging the two lugs in the reflector 2.

  • Page 108: Side Turn Signal Lights

    Vehicle care Side turn signal lights 7. Push bulb into socket slightly, rotate anti-clockwise, remove and 1. Push the lamp assembly to the renew bulb. right and pull at the left-hand side Turn signal light (1) of the lamp assembly to release Tail and brake light (2) from the aperture.
  • Page 109 Vehicle care 5. Reattach wiring connector. 5. Replace bulb holder. 6. Install lamp assembly into 6. Replace the screw. aperture and push to the left to secure. Centre high-mounted brake light Mirror turn signal lights 1. Move the lower mirror assembly from the front to access the screw.

  • Page 110: Number Plate Light

    Vehicle care Interior lights 8. Replace the nut onto the locating Load compartment light pin on the rear of the lamp assembly. Front courtesy light 9. Install cover on the inside of the rear door. Number plate light 1. Remove lamp assembly using a flat blade screwdriver.

  • Page 111: Electrical System

    Vehicle care Electrical system Instrument panel Front door panel light illumination Fuses Have bulbs replaced by a workshop. Data on the replacement fuse must match the data on the defective fuse. There are two fuse boxes in the vehicle: ■ on the left-hand side of the instrument panel, behind the trim panel.

  • Page 112: Engine Compartment Fuse

    Vehicle care Fuse extractor A blown fuse can be recognised by its To help in replacing fuses, a fuse melted wire. Do not replace the fuse extractor is located in the instrument until the cause of the fault has been panel fuse box.

  • Page 113: Fuse Box

    Vehicle care Instrument panel fuse box Due to restricted accessibility, have Some circuits may be protected by fuses replaced by a workshop. several fuses. Symbol Circuit Symbol Circuit Right side lights Infotainment system, seat heating, vehicle display Left side lights screen, audio connections, alarm Right low beam...

  • Page 114: Vehicle Tools

    Vehicle care Vehicle tools Symbol Circuit Body control module, power Tools windows, air conditioning Left heated rear window Right heated rear window Windscreen washer Electronic immobiliser Heated seats Cornering light Vehicles with Rear Wheel Drive: A hydraulic jack and a set of Hands-free connection extension pieces for use with the jack are also included.

  • Page 115: Wheels And Tyres

    Vehicle care Wheels and tyres To access this unit, slide the seat fully In accordance with country-specific forwards and fold down the backrest. regulations, a notice indicating the maximum permissible speed for the Tyre repair kit 3 117. Tyre condition, wheel condition tyres must be affixed within the Spare wheel 3 123.

  • Page 116: Tyre Pressure

    Vehicle care Tyre pressure Rear-wheel drive, with twin The legally permissible minimum tread depth (1.6 mm) has been wheels Check the pressure of cold tyres at reached when the tread has worn When inflating the outer tyre, the least every 14 days and before any down as far as one of the tread wear inflation tube should be passed long journey.

  • Page 117: Wheel Covers

    Vehicle care Wheel covers Tyre chains Wheel covers on steel wheels may come into contact with parts of the Wheel covers and tyres that are chains. In such cases, remove the factory approved for the respective wheel covers. vehicle and comply with all of the Tyre chains may only be used at relevant wheel and tyre combination speeds up to 50 km/h and, when...
  • Page 118 Vehicle care 1. Remove the compressor from the 5. Unscrew valve cap from defective 9 Warning tyre repair kit. tyre. 2. Remove the electrical connection Do not drive faster than 80 km/h. cable and air hose from the Do not use for a lengthy period. compartments on the underside Steering and handling may be of the compressor.
  • Page 119 Vehicle care 8. Connect the red < power supply 10. Set the rocker switch on the 13. The prescribed tyre pressure lead on the compressor to the compressor to I. The tyre is filled should be obtained within jump start terminal 3 124. with sealant.
  • Page 120 Vehicle care damaged. Seek the assistance of not be driven. Seek the a workshop. assistance of a workshop. Drain excess tyre pressure with 19. Stow tyre repair kit under the front the button above the pressure seat. indicator. 9 Warning Do not run the compressor for longer than 10 minutes.

  • Page 121: Wheel Changing

    Vehicle care Wheel changing Note ■ Never crawl under a jacked-up The driving characteristics of the vehicle. Some vehicles are equipped with repaired tyre is severely affected, ■ Do not start the engine when the a tyre repair kit instead of a spare therefore have this tyre replaced.
  • Page 122 Vehicle care Raise the vehicle by pressing the wheel wrench until the wheel is clear of the ground. 4. Unscrew wheel bolts/nuts completely and wipe clean with a cloth. Put wheel bolts/nuts somewhere where the threads will not be soiled. 5.

  • Page 123: Spare Wheel

    Vehicle care 11. Have the new wheel balanced on Place wheel upright, remove pin from the vehicle. Check the tyre retainer and release the wheel from pressure of the installed tyre the cable. 3 148 and also the wheel bolt/nut Twin wheel vehicles have an torque as soon as possible.

  • Page 124: Jump Starting

    Vehicle care Jump starting correctly positioned and that the front ■ A discharged battery can already of the wheel will be facing freeze at a temperature of 0 °C. downwards. Tighten cable using the Defrost the frozen battery before Do not start with a quick charger. wheel wrench and adapter until the connecting jump leads.
  • Page 125 Vehicle care Jump start terminal Jump starting procedure engine mounting bolt. Connect as far away from the discharged battery as possible. Route the leads so that they cannot catch on rotating parts in the engine compartment. To start the engine: 1.

  • Page 126: Towing The Vehicle

    Vehicle care Towing Do not tow the vehicle from the rear. After towing, unscrew the towing eye The front towing eye must only be and refit the cover. used for towing and not recovering Towing the vehicle a vehicle. Towing another vehicle The towing eye is stowed with the Switch on ignition to release steering vehicle tools 3 114.

  • Page 127: Appearance Care

    Vehicle care Appearance care If using a vehicle wash, comply with Caution the vehicle wash manufacturer's instructions. The windscreen wipers Exterior care Drive slowly. Do not drive jerkily. must be switched off. Remove Excessive tractive force can antenna and external accessories Locks damage the vehicle.
  • Page 128 Vehicle care Exterior lights For mechanical removal of ice, use After the underbody is washed, check a sharp-edged ice scraper. Press the the underbody and have it waxed if Headlight and other light covers are scraper firmly against the glass so necessary.

  • Page 129: Interior Care

    Vehicle care Do not use high-pressure jet Caution cleaners. Close Velcro fasteners as open Towing equipment Velcro fasteners on clothing could Do not clean the coupling ball bar with damage seat upholstery. a steam-jet or high-pressure jet cleaner. Plastic and rubber parts Plastic and rubber parts can be Interior care cleaned with the same cleaner as...

  • Page 130: Service And Maintenance

    Service and maintenance Service and General information Luxembourg, Netherlands, Norway, Poland, Portugal, Slovakia, Slovenia, maintenance Spain, Sweden, Switzerland, United Service information Kingdom. In order to ensure economical and Romania and Bulgaria service safe vehicle operation and to General information ....130 maintain the value of your vehicle, it intervals is of vital importance that all...

  • Page 131: Recommended Fluids

    Service and maintenance Recommended fluids, Confirmations The quality specification indicates its ability to protect the engine from Confirmation of service is recorded in lubricants and parts wear, whilst the viscosity grade the Service and Warranty Booklet. indicates its fluidity within The date and mileage is completed Recommended fluids and a temperature range.
  • Page 132 Service and maintenance Topping up engine oil Select the appropriate viscosity grade Over time, brake fluid absorbs depending on the minimum ambient moisture which will reduce braking Engine oils of different manufacturers temperature. effectiveness. The brake fluid should and brands can be mixed as long as therefore be replaced at the specified they comply with the required engine ■...

  • Page 133: Technical Data

    Technical data Technical data Vehicle identification Vehicle Identification Number Vehicle identification ....133 Vehicle data ....... 135 The VIN is also displayed behind a removable plastic cover on the right hand side door step. The Vehicle Identification Number is visible through the windscreen. Back to overview...

  • Page 134: Identification Plate

    Technical data Identification plate = Additional equipment specification = Fabrication number 10 = Interior trim code The combined total of front and rear axle loads must not exceed the permissible gross vehicle weight. For example, if the front axle is bearing its maximum permissible load, the rear axle can only bear a load that is equal to the gross vehicle weight minus the...

  • Page 135: Vehicle Data

    Technical data Vehicle data Engine data Sales designation 2.3 CDTI 2.3 CDTI 2.3 CDTI Engine identifier code Number of cylinders 2299 2299 2299 Piston displacement [cm Engine power [kW] (brake horse power) 74 (100) 92 (125) 110 (150) at rpm 3500 3500 3500...
  • Page 136 Technical data Vehicle weight Kerb weight, basic model Model Drive wheels Length Roof height Gross vehicle weight Kerb weight Rear-wheel drive 2110 3500 3500 2246 4500 2246 2110 3500 2246 3500 4500 2246 2324 3500 2324 4500 3500 2324 4500 2324 Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to VIN plate.
  • Page 137 Technical data Model Drive wheels Length Roof height Gross vehicle weight Kerb weight Rear-wheel drive 3500 2110 2246 3500 2246 4500 3500 2110 2246 3500 2246 4500 3500 2324 2324 4500 2324 3500 4500 2324 Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to VIN plate. With Single rear wheels.
  • Page 138 Technical data Model Drive wheels Length Roof height Gross vehicle weight Kerb weight Platform Cab Front-wheel drive 3500 1546 3500 1555 3500 1555 3500 1574 3500 1574 Model Drive wheels Length Roof height Gross vehicle weight Kerb weight Chassis Cab Front-wheel drive 3500 1681...
  • Page 139 Technical data Model Drive wheels Length Roof height Gross vehicle weight Kerb weight Crew Cab Front-wheel drive 3500 1908 Model Drive wheels Length Roof height Gross vehicle weight Kerb weight Crew Cab Rear-wheel drive 3500 2025 3500 2053 4500 2145 4500 2210 Kerb weight and gross vehicle weight increase on models fitted with bad road equipment package - refer to VIN plate.
  • Page 140 Technical data Vehicle dimensions Front-wheel drive 2800, 3300, 3300, Gross vehicle weight 3500 3500 3500 Length Length [mm] 5048 5548 6198 Width without mirrors [mm] 2070 2070 2070 Width with mirrors [mm] 2470 2470 2470 Height - unladen (without antenna) [mm] 2303 2499 2502...
  • Page 141 Technical data Rear-wheel drive 3500 3500 Gross vehicle weight 3500 4500 4500 Length Length [mm] 6198 6198 6848 Width without mirrors [mm] 2070 2070 2070 Width with mirrors [mm] 2470 2470 2470 Height - unladen (without antenna) [mm] 2539 2556 2553 2788 2816...
  • Page 142 Technical data Combi Front-wheel drive 2800, 2800, Gross vehicle weight 3500 3500 Length Length [mm] 5048 5548 Width without exterior mirrors [mm] 2020 2020 Width with mirrors [mm] 2470 2470 Height - unladen (without antenna) [mm] 2303 2502 Wheelbase [mm] 3182 3682 Track width [mm]...
  • Page 143 Technical data Chassis Cab, Crew Cab Front-wheel drive Rear-wheel drive 3500 3500 Gross vehicle weight 3500 3500 3500 3500 4500 4500 Size Length [mm] 5642 6292 5642 6292 6192 6842 Width without mirrors [mm] 2020 2020 2020 2020 2020 2020 Width with mirrors [mm] 2470 2470...
  • Page 144 Technical data Platform Cab Front-wheel drive Gross vehicle weight 3500 3500 3500 Size Length [mm] 5142 5642 6292 Width without mirrors [mm] 2020 2020 2020 Width with mirrors [mm] 2470 2470 2470 Wheelbase [mm] 3182 3682 4332 Track width [mm] 1750 1750 1750...
  • Page 145 Technical data Front-wheel drive Rear-wheel drive Gross vehicle weight 3900 4500 Length Wheelbase [mm] 4332 4332 Height - unladen (without antenna) [mm] Track width [mm] 1750 1750 Front Rear 1730 1730 Value not available at time of printing. Back to overview...
  • Page 146 Technical data Loadspace dimensions Front-wheel drive Length Roof height 2800, 2800, 3300, 3300, 3300, 3300, Gross vehicle weight 3500 3500 3500 3500 3500 3500 Maximum rear door aperture height [mm] 1627 1820 1820 1820 1820 1820 Rear door aperture width (at floor) [mm] 1580 1580 1580...
  • Page 147 Technical data Rear-wheel drive Length Roof height Gross vehicle weight 3500 4500 3500 4500 4500 4500 Maximum rear door aperture height [mm] 1724 1724 1724 1724 1724 1724 Rear door aperture width (at floor) [mm] 1580 1580 1580 1580 1580 1580 Maximum load area height [mm] 1798...

  • Page 148: Tyre Pressures

    Technical data Tyre pressures Front-wheel drive Tyre pressure with full load Engine Tyre Front Rear [kPa/bar] (psi) [kPa/bar] (psi) 2800 215/65 R16 C 340/3.4 (49) 360/3.6 (52) 3300 215/65 R16 C 360/3.6 (52) 430/4.3 (62) 3500 225/65 R16 C 380/3.8 (55) 460/4.6 (68) Rear-wheel drive, with single wheels Tyre pressure with full load...

  • Page 149: Towing Hitch Installation

    Technical data Towing hitch installation dimensions Drive Dimension A Front-wheel drive 1100 [mm] Rear-wheel drive, with 1760 single wheels [mm] Rear-wheel drive, with 1753 twin wheels [mm] Back to overview...
  • Page 150 Technical data Back to overview...

  • Page 151: Customer Information

    Customer information Customer information Vehicle data recording ■ with the consent of the vehicle owner or, if the vehicle is leased, and privacy with the consent of the lessee, ■ in response to an official request of Event data recorders Vehicle data recording and police or similar government office, privacy ........

  • Page 152: Index

    Index Accessories and vehicle Capacities ........147 modifications ......97 Car Pass ........19 Adaptive forward lighting ..68, 106 Catalytic converter ....... 80 Adjustable air vents ..... 75 Central locking system ....20 Airbag and belt tensioners ... 59 Centre high-mounted brake Airbag deactivation ....
  • Page 153 Door open ........62 Fixed air vents ......75 Heated rear window ..... 28 Drain fuel filter ......62 Fog light ........62 Heating ........35 Driving characteristics and Fog lights ........106 Heating and ventilation system . . . 72 towing tips ........
  • Page 154 Loading information ..... 48 Pollen filter ........76 Speedometer ....... 54 Low fuel ........62 Power outlets ....... 53 Speed regulator......54 Power steering fluid....101 Starting off ........17 Power windows ......28 Starting the engine ....78, 82 Malfunction indicator light ....
  • Page 155 Trip computer ......64 Wheel changing ......121 Triple-Info-Display ....... 63 Wheel covers ......117 Turn and lane-change signals ..68 Wheels and tyres ....... 115 Turn signal ........59 Windscreen wiper/washer ... 50 Tyre chains ........ 117 Winter tyres ....... 115 Tyre designations ......
  • Page 156 Back to overview...

Table of Contents
